A method executable by a system comprising a processor in communication with an extraluminal imaging device and an intravascular pressure measurement device. The method comprises acquiring contrast-agent angiographic images in a blood vessel having a contrast agent; based on contrast-agent angiographic images, generating a reconstructed geometry object of the blood vessel and estimating a blood flow in the blood vessel; determining output parameters based on the values of the blood pressure and the blood flow, by implementing a physical model of blood distribution using the reconstructed geometry object; and generating a reconciled hemodynamic parameter based on the output parameters. The reconciled hemodynamic parameter is adjusted based on measurements performed at various blood vessel states.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
A61B 6/00 - Appareils ou dispositifs pour le diagnostic par radiationsAppareils ou dispositifs pour le diagnostic par radiations combinés avec un équipement de thérapie par radiations
G16H 30/40 - TIC spécialement adaptées au maniement ou au traitement d’images médicales pour le traitement d’images médicales, p. ex. l’édition
G16H 50/20 - TIC spécialement adaptées au diagnostic médical, à la simulation médicale ou à l’extraction de données médicalesTIC spécialement adaptées à la détection, au suivi ou à la modélisation d’épidémies ou de pandémies pour le diagnostic assisté par ordinateur, p. ex. basé sur des systèmes experts médicaux
2.
Display screen or portion thereof with graphical user interface
There is described a pressure guidewire. It comprises a sensor housing and a sensor assembly embedded in the sensor housing and comprising a pressure sensor. There is a band to support the pressure sensor assembly, the band being embedded inside the sensor housing and fixed to the pressure sensor assembly for holding the pressure sensor inside the sensor housing.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Downloadable software for providing update to a medical
device allowing for synchronization of data consisting of
coronary measurements, values, and indices computed from a
medical guidewire during cardiovascular interventions
allowing for comparative analysis.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Downloadable software for providing update to a medical device allowing for synchronization of data consisting of coronary measurements, values, and indices computed from a medical guidewire during cardiovascular interventions allowing for comparative analysis
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Medical guidewire with pressure sensor for use in interventional cardiology. (1) Design and development of fiber optic sensing solutions and associated signal conditioner systems for temperature, pressure, strain, and displacement measurement, for use in the fields of defense, aerospace, laboratory, structure health monitoring and interventional cardiology, geotechnical, oil and gas, semiconductors, energy, microwave, chemistry and food industries; research and development (R&D) in the field of fiber optic sensing solutions and associated signal conditioner systems; technical consultation services related to fiber optic sensing solutions and associated signal conditioner systems; research, development, design and testing of medical guidewires; design and development of optical-based pressure guidewire for use in interventional cardiology.
09 - Appareils et instruments scientifiques et électriques
Produits et services
(1) Downloadable software for providing update to a medical device allowing for synchronization of data consisting of coronary measurements, values, and indices computed from a medical guidewire during cardiovascular interventions allowing for comparative analysis.
The system assesses a heart valve, such as a heart valve after deployment. The system uses pressure sensor calibration, waveform adjustment, feature detection, and/or valve condition generation to make a valve assessment. A graphical user interface presents metrics related to a valve assessment. A graphical user interface simultaneously presents graphs, physiological parameters, and/or values indicative of heart valve conditions (such as gradients, regurgitation indices, regurgitation ratios, etc.) for two recordings.
The system assesses a heart valve, such as a heart valve after deployment. The system uses pressure sensor calibration, waveform adjustment, feature detection, and/or valve condition generation to make a valve assessment. A graphical user interface presents metrics related to a valve assessment. A graphical user interface simultaneously presents graphs, physiological parameters, and/or values indicative of heart valve conditions (such as gradients, regurgitation indices, regurgitation ratios, etc.) for two recordings.
The heart valve assessment systems described herein advantageously provide indicators of a heart valve condition, such as a pressure gradient or a valve regurgitation index. The heart valve assessment systems can provide indicators of a heart valve condition during a heart procedure. A pressure gradient indicates a severity or measurement of the narrowing (or stenosis) of a valve by the increase in pressure behind it. A valve regurgitation index indicates a leakiness measurement of a valve.
There is described a method for calculating a patient-specific hemodynamic parameter. The method comprises measuring at least one pressure measurement in an artery using an intravascular pressure measurement device, and taking at least one medical image of the artery from a medical imaging instrument, the at least one medical image of the artery being synchronous with the at least one pressure measurement. Both the pressure measurement and the medical image are fed to a computing system to calculate a flow from the at least one medical image, to calculate parameters of the artery from at least two artery pressure drops and corresponding flow components, and based on the flow and the parameters of the artery, to calculate a patient-specific hemodynamic parameter or a plurality thereof.
A pressure guidewire is provided that includes an outer tube, a connector tube positioned radially inward of the outer tube, a pressure sensor assembly, and/or a distal tip at the distal end of the outer tube. A core wire may be positioned distal to the connector tube. The core wire may have a reduced diameter portion such as a tapered portion. The pressure sensor assembly may include a pressure sensor positioned distal of the connector tube, for example radially between a coil portion of the outer tube and the core wire. The pressure sensor assembly may also include one or more pressure wires leads extending from the pressure sensor and through the connector tube lumen.
A pressure guidewire is provided that has a proximal end and a distal end. The pressure guidewire has a proximal section a sensor housing section, and an intermediate section. The proximal section extends from the proximal end of the pressure guidewire to a distal end of the proximal section. The sensor housing section is disposed adjacent to the distal end of the pressure guidewire. The intermediate section disposed between the proximal section and the sensor housing section. The intermediate section has a proximal end separate from the proximal section. The proximal end can be coupled to the distal end of the proximal section. The pressure guidewire has a tubular body positioned within the intermediate section. A pressure sensor is positioned in the sensor housing section
There is described a method for calculating a patient-specific hemodynamic parameter. The method comprises measuring at least one pressure measurement in an artery using an intravascular pressure measurement device, and taking at least one medical image of the artery from a medical imaging instrument, the at least one medical image of the artery being synchronous with the at least one pressure measurement. Both the pressure measurement and the medical image are fed to a computing system to calculate a flow from the at least one medical image, to calculate parameters of the artery from at least two artery pressure drops and corresponding flow components, and based on the flow and the parameters of the artery, to calculate a patient-specific hemodynamic parameter or a plurality thereof.
A pressure guidewire is provided that includes an outer tube, a connector tube positioned radially inward of the outer tube, a pressure sensor assembly, and/or a distal tip at the distal end of the outer tube. A core wire may be positioned distal to the connector tube. The core wire may have a reduced diameter portion such as a tapered portion. The pressure sensor assembly may include a pressure sensor positioned distal of the connector tube, for example radially between a coil portion of the outer tube and the core wire. The pressure sensor assembly may also include one or more pressure wires leads extending from the pressure sensor and through the connector tube lumen.
A pressure guidewire is provided that includes an outer tube, a connector tube positioned radially inward of the outer tube, a pressure sensor assembly, and/or a distal tip at the distal end of the outer tube. A core wire may be positioned distal to the connector tube. The core wire may have a reduced diameter portion such as a tapered portion. The pressure sensor assembly may include a pressure sensor positioned distal of the connector tube, for example radially between a coil portion of the outer tube and the core wire. The pressure sensor assembly may also include one or more pressure wires leads extending from the pressure sensor and through the connector tube lumen.
The heart valve assessment systems described herein advantageously provide indicators of a heart valve condition, such as a pressure gradient or a valve regurgitation index. The heart valve assessment systems can provide indicators of a heart valve condition during a heart procedure. A pressure gradient indicates a severity or measurement of the narrowing (or stenosis) of a valve by the increase in pressure behind it. A valve regurgitation index indicates a leakiness measurement of a valve.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
25.
PRESSURE BASED STRUCTURAL HEART ASSESSMENT SYSTEMS AND METHODS
The heart valve assessment systems described herein advantageously provide indicators of a heart valve condition, such as a pressure gradient or a valve regurgitation index. The heart valve assessment systems can provide indicators of a heart valve condition during a heart procedure. A pressure gradient indicates a severity or measurement of the narrowing (or stenosis) of a valve by the increase in pressure behind it. A valve regurgitation index indicates a leakiness measurement of a valve.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A pressure guidewire is provided that has a proximal end and a distal end. The pressure guidewire has a proximal section, a sensor housing section, and an intermediate section. The proximal section extends from the proximal end of the pressure guidewire to a distal end of the proximal section. The sensor housing section is disposed adjacent to the distal end of the pressure guidewire. The intermediate section disposed between the proximal section and the sensor housing section. The intermediate section has a proximal end separate from the proximal section. The proximal end can be coupled to the distal end of the proximal section. The pressure guidewire has a tubular body positioned within the intermediate section. A pressure sensor is positioned in the sensor housing section.
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
A pressure guidewire is provided that has a proximal end and a distal end. The pressure guidewire has a proximal section, a sensor housing section, and an intermediate section. The proximal section extends from the proximal end of the pressure guidewire to a distal end of the proximal section. The sensor housing section is disposed adjacent to the distal end of the pressure guidewire. The intermediate section disposed between the proximal section and the sensor housing section. The intermediate section has a proximal end separate from the proximal section. The proximal end can be coupled to the distal end of the proximal section. The pressure guidewire has a tubular body positioned within the intermediate section. A pressure sensor is positioned in the sensor housing section.
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Structural heart pressure guidewires. Research and development of structural heart pressure guidewires; design and testing of structural heart pressure guidewires.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Structural heart pressure guidewires. (1) Research and development of structural heart pressure guidewires; design and testing of structural heart pressure guidewires.
The present document describes a pressure guidewire. It comprises a shaft tube having a proximal section and a sensor housing having a distal end, the proximal section and the sensor housing being the continuity of the same shaft tube. A fiber optic pressure sensor is embedded in the sensor housing and comprises an optical fiber extending within the sensor housing, the sensor adapted to measure a pressure of a fluid which is substantially applied in an axis collinear with the longitudinal axis of the guidewire. A marker band, to help in localizing the pressure guidewire in a patient's vessels, is embedded inside the sensor housing and fixed to the optical fiber for holding the pressure sensor inside the sensor housing.
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Pressure sensors Medical devices, namely, patient sensors for measuring arterial blood pressure, intracranial pressure, intrauterine pressure, intervertebral disc pressure, urodynamic pressure, intraocular pressure; medical devices, namely, sensors used to measure patient pressure under electro-surgery, MRIs and Microwaves and Radio Frequency (MW/RF); medical devices, namely, sensors used for measuring patient pressure in cardiovascular applications and compartment syndromes Research and development of pressure sensors; design and testing of new pressure sensors for others
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Pressure sensors. Sensors for measuring arterial blood pressure, intracranial pressure, intrauterine pressure, intervertebral disc pressure, urodynamic pressure, intraocular pressure; sensors used to measure pressure under electro-surgery, MRIs and Microwaves and Radio Frequency (MW/RF); sensors used for measuring pressure in cardiovascular applications and compartment syndromes. Research and development of pressure sensors; design and testing of pressure sensors.
There is described a method for calculating a patient-specific hemodynamic parameter. The method comprises measuring at least one pressure measurement in an artery using an intravascular pressure measurement device, and taking at least one medical image of the artery from a medical imaging instrument, the at least one medical image of the artery being synchronous with the at least one pressure measurement. Both the pressure measurement and the medical image are fed to a computing system to calculate a flow from the at least one medical image, to calculate parameters of the artery from at least two artery pressure drops and corresponding flow components, and based on the flow and the parameters of the artery, to calculate a patient-specific hemodynamic parameter or a plurality thereof.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
A61B 5/0275 - Mesure du débit sanguin utilisant des marqueurs, p. ex. dilution de colorant
G16H 50/20 - TIC spécialement adaptées au diagnostic médical, à la simulation médicale ou à l’extraction de données médicalesTIC spécialement adaptées à la détection, au suivi ou à la modélisation d’épidémies ou de pandémies pour le diagnostic assisté par ordinateur, p. ex. basé sur des systèmes experts médicaux
36.
HYBRID IMAGE-INVASIVE-PRESSURE HEMODYNAMIC FUNCTION ASSESSMENT
There is described a method for calculating a patient-specific hemodynamic parameter. The method comprises measuring at least one pressure measurement in an artery using an intravascular pressure measurement device, and taking at least one medical image of the artery from a medical imaging instrument, the at least one medical image of the artery being synchronous with the at least one pressure measurement. Both the pressure measurement and the medical image are fed to a computing system to calculate a flow from the at least one medical image, to calculate parameters of the artery from at least two artery pressure drops and corresponding flow components, and based on the flow and the parameters of the artery, to calculate a patient-specific hemodynamic parameter or a plurality thereof.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
A61B 5/0275 - Mesure du débit sanguin utilisant des marqueurs, p. ex. dilution de colorant
G16H 50/20 - TIC spécialement adaptées au diagnostic médical, à la simulation médicale ou à l’extraction de données médicalesTIC spécialement adaptées à la détection, au suivi ou à la modélisation d’épidémies ou de pandémies pour le diagnostic assisté par ordinateur, p. ex. basé sur des systèmes experts médicaux
A system for assessing a vascular condition includes a pressure sensing catheter and a pressure guidewire. Heartbeats of the patient can be detected while the pressure sensing catheter and the pressure guidewire are positioned at the proximal position and at a distal position respectively. A diastolic pressure ratio zone (dPR zone) is located within a heartbeat from analysis of a signal from at least one of the pressure sensing catheter and the pressure guidewire. The dPR value can be obtained by calculating an average of several ratios of Pa to Pd taken over time within the heartbeat. A multi-beat metric (dPRc) is calculated that includes the dPR value and that also includes a high frequency sample whole heartbeat pressure ratio.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
G06F 15/00 - Calculateurs numériques en généralÉquipement de traitement de données en général
39.
PRESSURE BASED BLOOD VESSEL ASSESSMENT SYSTEMS AND METHODS
A system for assessing a vascular condition includes a pressure sensing catheter and a pressure guidewire. Heartbeats of the patient can be detected while the pressure sensing catheter and the pressure guidewire are positioned at the proximal position and at a distal position respectively. A diastolic pressure ratio zone (dPR zone) is located within a heartbeat from analysis of a signal from at least one of the pressure sensing catheter and the pressure guidewire. The dPR value can be obtained by calculating an average of several ratios of Pa to Pd taken over time within the heartbeat. A multi-beat metric (dPRc) is calculated that includes the dPR value and that also includes a high frequency sample whole heartbeat pressure ratio.
G06F 15/00 - Calculateurs numériques en généralÉquipement de traitement de données en général
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
The present document describes a pressure guidewire. It comprises a shaft tube having a proximal section configured to provide pushability to the pressure guidewire; a middle section extending distally relative to the proximal section, the middle section comprising a cut pattern configured to provide greater flexibility in the middle section than the proximal section; and a sensor housing section extending distally relative to the middle section. The pressure guidewire further comprises an inner hypotube comprising a proximal end portion and a distal end portion, the inner hypotube positioned entirely radially inward of the shaft tube and within at least the middle section, the proximal end portion and the distal end portion of the inner hypotube being joined to the shaft tube; and a tip pressure sensor positioned in the sensor housing section.
The present document describes a pressure guidewire. It comprises a shaft tube having a proximal section and a sensor housing having a distal end, the proximal section and the sensor housing being the continuity of the same shaft tube. A fiber optic pressure sensor is embedded in the sensor housing and comprises an optical fiber extending within the sensor housing, the sensor adapted to measure a pressure of a fluid which is substantially applied in an axis collinear with the longitudinal axis of the guidewire. A marker band, to help in localizing the pressure guidewire in a patient's vessels, is embedded inside the sensor housing and fixed to the optical fiber for holding the pressure sensor inside the sensor housing.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
The present document describes a system for equalizing the pressure of a pressure guidewire against the pressure of an aortic pressure device: the system comprising two methods of equalizing the pressure against each other, one method that involves a gain adjustment and another method that involves the addition of an offset; the method further comprising a method for detecting which method should be applied to the situation, the detecting methods including: the contribution of the operator; an algorithm detecting the first equalization from subsequent post procedure equalizations, the algorithm including various factors such as incrementing the equalization requests, measuring the elapsed time and others.
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
There is described a method for terminating an optical fiber within a proximal portion of a guidewire tubing. The guidewire tubing has an outside diameter and comprises a lumen. The method comprises centering the optical fiber relative to the outside diameter of the proximal portion of the guidewire tubing. The optical fiber and the inside of the lumen define an average gap there between. The average gap around the optical fiber is between 1 μm and 100 μm for allowing a substantial displacement of the optical fiber inside the lumen during the centering.
The present document describes a pressure guidewire comprising a shaft tube, a tip portion and a fiber optic pressure sensor. The shaft tube comprises a middle section and a sensor housing extending distally relative to the middle section, the sensor housing having a distal end. The tip portion extends distally relative to the shaft tube. The pressure sensor is embedded in the sensor housing. The sensor housing defines a cavity, inside the sensor housing, which is distal relative to the pressure sensor and delimited at a proximal end thereof by the pressure sensor.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
The present document describes an interface connector handle for connecting a first optical fiber to a second optical fiber. The first optical fiber is substantially centered within a proximal portion of a guidewire tubing. The second optical fiber is routed through and extending from an optical interface cable. The interface connector handle comprises a biasing assembly for urging one of the first optical fiber and the second optical fiber toward the other one of the first optical fiber and the second optical fiber resulting in a contact therebetween.
Apparatus for measuring and displaying blood pressure and other parameters, namely, aortic pressure, distal pressure and ratios of the same in a specific mode
(1) Apparatus for measuring and displaying blood pressure and other parameters, namely aortic pressure, distal pressure and ratios of the same in a specific mode.
The present document describes a female optical receiving device for connecting a first optical fiber to a second optical fiber. The first optical fiber is substantially centered within a proximal portion of a guidewire tubing. The female optical receiving device comprises a first ferrule or tubing having a longitudinal axis and an inside diameter adapted to an outside diameter of the guidewire tubing, and a second ferrule or tubing having a longitudinal axis and an inside diameter adapted to an outside diameter of the second optical fiber. The longitudinal axis of the first ferrule or tubing is aligned with the longitudinal axis of the second ferrule or tubing.
The present document describes a pressure guidewire comprising: a shaft tube with a proximal section; a middle section extending from the proximal section of the shaft tube, the middle section having greater flexibility than the proximal section; an inner hypotube installed substantially within the middle section for optimal mechanical properties; a pressure sensor with a communication means routed through the middle section and the proximal section; and a sensor housing for receiving the pressure sensor. There are also described methods for joining the inner hypotube to the shaft tube.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A method for terminating a first optical fiber within a proximal portion of a guidewire tubing. The guidewire tubing has an outside diameter defined as having a tolerance of 25 .mu.m or less. The method comprises the step of centering the first optical fiber within the guidewire tubing. A female optical receiving device used to receive an optical guidewire and connect guidewire internal optical fiber to an external relaying optical cable is also provided.
There is described an interface connector handle for connecting a first optical fiber to a second optical fiber. The first optical fiber is bonded within a proximal portion of a guidewire tubing, and the guidewire is disconnectable from the interface connector handle. The second optical fiber is routed through and extending from an optical interface cable. The interface connector handle comprises a biasing assembly which causes a relative movement between the first optical fiber and the second optical fiber to provide a contact therebetween.
There is described a female optical receiving device for connecting a first optical fiber to a second optical fiber. The first optical fiber is within a proximal portion of a guidewire tubing. The female optical receiving device comprises a first ferrule or tubing, having a longitudinal axis and an inside diameter adapted to an outside diameter of the guidewire tubing; and a second ferrule or tubing, having a longitudinal axis and an inside diameter adapted to an outside diameter of the second optical fiber. The longitudinal axis of the first ferrule or tubing is aligned with the longitudinal axis of the second ferrule or tubing. The first optical fiber has an outside diameter which is different from the outside diameter of the second optical fiber.
A method for terminating a first optical fiber within a proximal portion of a guidewire tubing. The guidewire tubing has an outside diameter defined as having a tolerance of ±0.001" or less. The method comprises the step of centering the first optical fiber within the guidewire tubing. A female optical receiving device used to receive an optical guidewire and connect guidewire internal optical fiber to an external relaying optical cable is also provided.
A method for terminating a first optical fiber within a proximal portion of a guidewire tubing. The guidewire tubing has an outside diameter defined as having a tolerance of ±0.001″ or less. The method comprises the step of centering the first optical fiber within the guidewire tubing. A female optical receiving device used to receive an optical guidewire and connect guidewire internal optical fiber to an external relaying optical cable is also provided.
There is described a miniature fiber optic pressure sensor design where sensitivity around specific biased pressure is optimized. In an embodiment, the pressure sensor is a Fabry-Perot (FP) sensor which comprises a substrate; and a diaphragm mounted on the substrate. The diaphragm has a center and comprises: a first layer comprising a first material; and a second layer comprising a second material. The second layer forms a dot or a ring. The dot or ring is mounted on the first layer and is centered about the center of the diaphragm. The second material comprises internal pre-stresses to cause the center of the diaphragm (in the case of a dot) or the peripheral area about the center of the diaphragm (in the case of a ring) to camber away from the substrate upon relaxing the internal pre-stresses.
G01L 9/00 - Mesure de la pression permanente, ou quasi permanente d’un fluide ou d’un matériau solide fluent par des éléments électriques ou magnétiques sensibles à la pressionTransmission ou indication par des moyens électriques ou magnétiques du déplacement des éléments mécaniques sensibles à la pression, utilisés pour mesurer la pression permanente ou quasi permanente d’un fluide ou d’un matériau solide fluent
There is described a miniature fiber optic pressure sensor design where sensitivity around specific biased pressure is optimized. In an embodiment, the pressure sensor is a Fabry-Perot (FP) sensor which comprises a substrate; and a diaphragm mounted on the substrate. The diaphragm has a center and comprises: a first layer comprising a first material; and a second layer comprising a second material. The second layer forms a dot or a ring. The dot or ring is mounted on the first layer and is centered about the center of the diaphragm. The second material comprises internal pre-stresses to cause the center of the diaphragm (in the case of a dot) or the peripheral area about the center of the diaphragm (in the case of a ring) to camber away from the substrate upon relaxing the internal pre-stresses.
G01L 7/08 - Mesure de la pression permanente ou quasi permanente d’un fluide ou d’un matériau solide fluent par des éléments mécaniques ou hydrauliques sensibles à la pression sous forme de jauges, élastiquement déformables du type à diaphragme élastique
A61B 5/027 - Mesure du débit sanguin utilisant des moyens électromagnétiques, p. ex. débitmètre électromagnétique utilisant des cathéters
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
There is described a miniature fiber optic pressure sensor design where sensitivity around specific biased pressure is optimized. In an embodiment, the pressure sensor is a Fabry-Perot (FP) sensor which comprises a substrate; and a diaphragm mounted on the substrate. The diaphragm has a center and comprises: a first layer comprising a first material; and a second layer comprising a second material. The second layer forms a dot or a ring. The dot or ring is mounted on the first layer and is centered about the center of the diaphragm. The second material comprises internal pre-stresses to cause the center of the diaphragm (in the case of a dot) or the peripheral area about the center of the diaphragm (in the case of a ring) to camber away from the substrate upon relaxing the internal pre-stresses.
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
A61B 5/027 - Mesure du débit sanguin utilisant des moyens électromagnétiques, p. ex. débitmètre électromagnétique utilisant des cathéters
G01L 7/08 - Mesure de la pression permanente ou quasi permanente d’un fluide ou d’un matériau solide fluent par des éléments mécaniques ou hydrauliques sensibles à la pression sous forme de jauges, élastiquement déformables du type à diaphragme élastique
The present document describes a pressure guidewire comprising: a shaft tube with a proximal section; a middle section extending from the proximal section of the shaft tube, the middle section having greater flexibility than the proximal section; an inner hypotube installed substantially within the middle section for optimal mechanical properties; a pressure sensor with a communication means routed through the middle section and the proximal section; and a sensor housing for receiving the pressure sensor. There are also described methods for joining the inner hypotube to the shaft tube.
G01L 11/02 - Mesure de la pression permanente, ou quasi permanente d'un fluide ou d'un matériau solide fluent par des moyens non prévus dans les groupes ou par des moyens optiques
The present document describes a pressure guidewire comprising: a shaft tube with a proximal section; a middle section extending from the proximal section of the shaft tube, the middle section having greater flexibility than the proximal section; an inner hypotube installed substantially within the middle section for optimal mechanical properties; a pressure sensor with a communication means routed through the middle section and the proximal section; and a sensor housing for receiving the pressure sensor. There are also described methods for joining the inner hypotube to the shaft tube.
G01L 11/02 - Mesure de la pression permanente, ou quasi permanente d'un fluide ou d'un matériau solide fluent par des moyens non prévus dans les groupes ou par des moyens optiques
The present document describes a sensing apparatus for lowering into a well and cementing therein at a certain depth. The sensing apparatus comprises an elongated casing and a sensor device protruding from an outside surface of the elongated casing for generating measurement data and sending the data to the surface of the well using a cable extending from the sensor device along the outside surface of the casing. A flow of cement is provided between the outside surface of the casing and the well for cementing the casing in place and isolating different layers of the well. Presence of the sensor device and the cable creates an obstruction within the flow path of the cement which may result in the formation of micro-annulus around the sensor device and the cable. In order to address this problem, a plurality of fins is provided around the casing, the fins being shaped to cause a straight flow of cement received at the fins to rotate around the longitudinal axis of the casing when exiting the fins for increasing cement flow between the elongated casing and its surrounding environment to mitigate micro-annulus formation. Another means to address this problem is to provide cable attachments which distance the cable from the casing and thereby let cement flow between the cable and the casing also mitigating micro-annulus formation.
E21B 47/01 - Dispositifs pour supporter des instruments de mesure sur des trépans, des tubes, des tiges ou des câbles de forageProtection des instruments de mesure dans les trous de forage contre la chaleur, les chocs, la pression ou similaire
E21B 33/14 - Procédés ou dispositifs de cimentation, de bouchage des trous, des fissures ou analogues pour la cimentation des tubes dans les trous de forage ou de sondage
E21B 43/10 - Mise en place de tubages, filtres ou crépines dans les puits
E21B 47/12 - Moyens pour la transmission de signaux de mesure ou signaux de commande du puits vers la surface, ou de la surface vers le puits, p. ex. pour la diagraphie pendant le forage
64.
ECCENTRIC PRESSURE CATHETER WITH GUIDEWIRE COMPATIBILITY
There is herein described a catheter for measuring a pressure in a cardiovascular system. The catheter comprises: a guiding tube adapted for insertion into the cardiovascular system. The guiding tube defines a lumen for sliding a guidewire therethrough. The catheter further comprises a tip pressure sensor eccentrically mounted relative to the guiding tube and a signal communication means extending therefrom. The tip pressure sensor is for sensing a pressure in the cardiovascular system and the signal communicating means is for transmitting a signal indicative of the pressure to a processing device in order to obtain a pressure measurement reading.
There is herein described a catheter for measuring a pressure in a cardiovascular system. The catheter comprises: a guiding tube adapted for insertion into the cardiovascular system. The guiding tube defines a lumen for sliding a guidewire therethrough. The catheter further comprises a tip pressure sensor eccentrically mounted relative to the guiding tube and a signal communication means extending therefrom. The tip pressure sensor is for sensing a pressure in the cardiovascular system and the signal communicating means is for transmitting a signal indicative of the pressure to a processing device in order to obtain a pressure measurement reading.
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
66.
ECCENTRIC PRESSURE CATHETER WITH GUIDEWIRE COMPATIBILITY
There is herein described a catheter for measuring a pressure in a cardiovascular system. The catheter comprises: a guiding tube adapted for insertion into the cardiovascular system. The guiding tube defines a lumen for sliding a guidewire therethrough. The catheter further comprises a tip pressure sensor eccentrically mounted relative to the guiding tube and a signal communication means extending therefrom. The tip pressure sensor is for sensing a pressure in the cardiovascular system and the signal communicating means is for transmitting a signal indicative of the pressure to a processing device in order to obtain a pressure measurement reading.
The invention concerns a tandem interferometer for temperature sensing. The low coherence interferometry (LCI) system comprises a polarization-based sensing interferometer comprising a birefringent crystal having a sensor temperature sensitivity and a birefringence dispersion, and a readout interferometer being either a Fizeau interferometer using an optical wedge or a polarization interferometer using a birefringent wedge. In one embodiment of the invention, the birefringent crystal has dispersion properties similar to that of the birefringent wedge or that of the optical wedge of the readout interferometer. The present invention also provides a signal processing method for correcting the dispersion effect and for noise filtering in LCI-based optical sensors of the tandem interferometer arrangement.
The invention provides a miniature robust fiber optic pressure sensor. The miniature fiber optic sensor comprises a Fabry-Perot chip bonded to an optical fiber. The invention provides a new sensor design that reduces the amount of adhesive required to bond the optical fiber to the Fabry-Perot sensor such that the sensor is less sensitive to moisture. The invention also provides manufacturing methods of the sensor comprising a method based on etching and a method based on using an excimer laser. The invention also provides a chip design that renders the chip less sensitive to thermal changes. The invention also provides a chip design in which a sensor diaphragm has a well-defined thickness. The invention also provides a chip design that protects the chip from etching.
A61B 5/0215 - Mesure de la pression dans le cœur ou dans les vaisseaux sanguins par des moyens introduits dans le corps
G01L 7/08 - Mesure de la pression permanente ou quasi permanente d’un fluide ou d’un matériau solide fluent par des éléments mécaniques ou hydrauliques sensibles à la pression sous forme de jauges, élastiquement déformables du type à diaphragme élastique
G01L 11/02 - Mesure de la pression permanente, ou quasi permanente d'un fluide ou d'un matériau solide fluent par des moyens non prévus dans les groupes ou par des moyens optiques
The invention provides a miniature robust fiber optic pressure sensor. The miniature fiber optic sensor comprises a Fabry-Perot chip bonded to an optical fiber. The invention provides a new sensor design that reduces the amount of adhesive required to bond the optical fiber to the Fabry-Perot sensor such that the sensor is less sensitive to moisture. The invention also provides manufacturing methods of the sensor comprising a method based on etching and a method based on using an excimer laser. The invention also provides a chip design that renders the chip less sensitive to thermal changes. The invention also provides a chip design in which a sensor diaphragm has a well-defined thickness. The invention also provides a chip design that protects the chip from etching.
G02B 6/00 - Guides de lumièreDétails de structure de dispositions comprenant des guides de lumière et d'autres éléments optiques, p. ex. des moyens de couplage
The invention provides a method and a system for measuring a physical quantity by means of a tandem interferometer optical sensor system based on low-coherence interferometry. The system comprises a light system, a sensing interferometer and a polarization readout interferometer. The invention provides a polarization interferometer comprising a single birefringent wedge. The invention also provides for a dispersion-compensated optical sensor system. The invention also provides an interferometer sensitive to temperature that comprises a trajectory in a LiB3O5 crystal with an x-cut orientation.
G01D 5/26 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens optiques, c.-à-d. utilisant de la lumière infrarouge, visible ou ultraviolette
G01K 11/00 - Mesure de la température basée sur les variations physiques ou chimiques, n'entrant pas dans les groupes , , ou
09 - Appareils et instruments scientifiques et électriques
Produits et services
(1) Capteurs et postes à filtres optiques dont nommément des capteurs de température, des capteurs de pression et des postes de lecture à fibre optique.
