Abstract

The invention relates to an actuator module (1) with a hermetically sealed housing (3) with at least one piezo actuator (2) arranged in the housing (3) and with electrical terminals (21, 22) at least for the piezo actuator (2). The terminals (21, 22) are fed through a housing wall (31, 32, 34), wherein a housing interior space (30) between the piezo actuator (2) and the housing wall (31, 32, 34) includes a potting compound (4), which electrically insulates the housing wall (31, 32, 34) from the piezo actuator (2). The potting compound (4) is a solid and comprises at least one particulate, heat-conducting, dielectric auxiliary substance (40), wherein the auxiliary substance (40) is arranged in the potting compound (4) so that a heat dissipation from the piezo actuator (2) to the housing wall (31, 32, 34) takes place during operation via the potting compound (4), in particular via the auxiliary substance (40).

IPC Classes  ?

• H10N 30/88 - MountsSupportsEnclosuresCasings
• H10N 30/02 - Forming enclosures or casings

Abstract

The invention relates to an actuator module (1) with a hermetically sealed housing (3) with at least one piezo actuator (2) arranged in the housing (3) and with electrical terminals (21, 22) at least for the piezo actuator (2). The terminals (21, 22) are fed through a housing wall (31, 32, 34), wherein a housing interior space (30) between the piezo actuator (2) and the housing wall (31, 32, 34) includes a potting compound (4), which electrically insulates the housing wall (31, 32, 34) from the piezo actuator (2). The potting compound (4) is a solid and comprises at least one particulate, heat-conducting, dielectric auxiliary substance (40), wherein the auxiliary substance (40) is arranged in the potting compound (4) so that a heat dissipation from the piezo actuator (2) to the housing wall (31, 32, 34) takes place during operation via the potting compound (4), in particular via the auxiliary substance (40).

IPC Classes  ?

• H10N 30/02 - Forming enclosures or casings
• H10N 30/50 - Piezoelectric or electrostrictive devices having a stacked or multilayer structure
• H10N 30/88 - MountsSupportsEnclosuresCasings

Abstract

The invention relates to a dosing device (1) having a rotary head (2) and at least one dosing valve (3), preferably a jet valve (3), which is arranged on the rotary head (2), said dosing valve (3) having a nozzle (41) for dispensing dosing material, a movably mounted element (42) and an actuator unit (30) coupled to the movably mounted element (42) and/or the nozzle (41). The rotary head (2) is designed to generate a continuous rotation (R) of the dosing valve (3) about a rotational axis (X) of the rotary head (2) during operation of the dosing device (1). The invention also relates to a rotary head (2) for a dosing device (1), to a method for controlling a rotary head (2) of a dosing device (1) and to a method for producing a rotary head (2) for a dosing device (1).

IPC Classes  ?

• B05B 1/14 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening

Abstract

AXAXAX). The invention also relates to a metering system (50) having such an actuator module (1).

IPC Classes  ?

• H10N 30/50 - Piezoelectric or electrostrictive devices having a stacked or multilayer structure
• H10N 30/88 - MountsSupportsEnclosuresCasings
• B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work

Abstract

The invention relates to a metering system (1) for metering a metered medium comprising a frame housing unit (2) and a lever mounting unit (3) which his supported on the frame housing unit (2) comprising a lever mount (4). The invention further comprises a, preferably asymmetrical lever (30) which is supported rotatably by means of the lever mount (4) about a tilt axis (R) comprising a two-sided lever arm (31) extending substantially in a longitudinal direction (30L) of the lever (30), wherein one lever arm side (35), preferably the longer lever arm side (35), has a first actuator engagement point (36) close to the tilt axis and is in contact remotely from the tilt axis at an end portion (33) with an ejection element (13), preferably a ram (13), and wherein the other lever arm side (32), preferably the shorter lever arm side (32), has a second actuator engagement point (37) close to the tilt axis. The invention further comprises two actuators (50a, 50b), which, during operation, exert a tilting moment in opposite directions on the lever (30) at the first and second actuator engagement point (36, 37), wherein the actuators (50a, 50b) are placed obliquely to one another. Together, the lever mounting unit (3), the lever (30), and the two actuators (50a, 50b) thereby form a movement mechanism (4, 30, 50a, 50b), which is braced on the frame housing unit (2) by means of at least one spring element (21), preferably a disc spring set (21), wherein the spring element (21) is preferably arranged so that it braces the lever mounting unit (3) against the frame housing unit (2) via the lever (30) as well as via the two actuators (50a, 50b).

IPC Classes  ?

• G01F 11/02 - Apparatus requiring external operation adapted at each repeated and identical operation to measure and separate a predetermined volume of fluid or fluent solid material from a supply or container, without regard to weight, and to deliver it with measuring chambers which expand or contract during measurement
• G01F 11/38 - Apparatus requiring external operation adapted at each repeated and identical operation to measure and separate a predetermined volume of fluid or fluent solid material from a supply or container, without regard to weight, and to deliver it with stationary measuring chambers having constant volume during measurement with supply or discharge valves of the rectilinearly-moved slide type for liquid or semiliquid

Abstract

The invention relates to a metering system (1) with a housing (2), a piezo actuator (10) located therein, a fluidic unit (15) with a valve (16), a plunger device (40) for closing the valve (16), and a transmission lever (20) for coupling the piezo actuator (10) to the plunger device (40), wherein the piezo actuator (10) is arranged substantially parallel next to the plunger device (40) in the housing (2), wherein the piezo actuator (10) extends away from the transmission lever (20) substantially in the direction of a side facing the valve (16).

IPC Classes  ?

• G01F 11/34 - Apparatus requiring external operation adapted at each repeated and identical operation to measure and separate a predetermined volume of fluid or fluent solid material from a supply or container, without regard to weight, and to deliver it with stationary measuring chambers having constant volume during measurement with supply and discharge valves of the lift or plug-lift type for fluent solid material
• G01F 15/00 - Details of, or accessories for, apparatus of groups insofar as such details or appliances are not adapted to particular types of such apparatus
• H10N 30/20 - Piezoelectric or electrostrictive devices with electrical input and mechanical output, e.g. functioning as actuators or vibrators

Abstract

The invention relates to a metering module (1, 1″) for metering a metering medium, having a plurality of metering valves (4a, 4b), having a first valve actuator group (2), which has at least two valve actuators (3) arranged alongside one another in a row direction (QR, QR″), which valve actuators (3) each comprise at least one metering head part (4) with an expulsion element (4a), and a second valve actuator group (5) with at least one valve actuator (3), preferably with a plurality of valve actuators (3) that are arranged alongside one another in a row direction (QR, QR″), which at least one valve actuator (3) also comprises a metering head part (4) with an expulsion element (4a). Here, the metering head parts (4) of the first valve actuator group (2) and of the second valve actuator group (5) face one another. Furthermore, the metering module (1, 1″) comprises a metering nozzle arrangement (4′) having a plurality of metering nozzles (4b), wherein each metering head part (4) is assigned a metering nozzle (4b) of the metering nozzle arrangement (4′) such that the metering nozzle (4b), with the expulsion element (4a) of the metering head part (4), forms in each case a metering valve (4a, 4b).

IPC Classes  ?

• F15B 13/08 - Assemblies of units, each for the control of a single servomotor only
• B29C 64/209 - HeadsNozzles
• B33Y 30/00 - Apparatus for additive manufacturingDetails thereof or accessories therefor
