Abrégé

The invention relates to an actuator module (1) with a hermetically sealed housing (3) with at least one piezo actuator (2) arranged in the housing (3) and with electrical terminals (21, 22) at least for the piezo actuator (2). The terminals (21, 22) are fed through a housing wall (31, 32, 34), wherein a housing interior space (30) between the piezo actuator (2) and the housing wall (31, 32, 34) includes a potting compound (4), which electrically insulates the housing wall (31, 32, 34) from the piezo actuator (2). The potting compound (4) is a solid and comprises at least one particulate, heat-conducting, dielectric auxiliary substance (40), wherein the auxiliary substance (40) is arranged in the potting compound (4) so that a heat dissipation from the piezo actuator (2) to the housing wall (31, 32, 34) takes place during operation via the potting compound (4), in particular via the auxiliary substance (40).

Classes IPC  ?

• H10N 30/88 - MonturesSupportsEnveloppesBoîtiers
• H10N 30/02 - Formation d'enceintes ou d'enveloppes

Abrégé

The invention relates to an actuator module (1) with a hermetically sealed housing (3) with at least one piezo actuator (2) arranged in the housing (3) and with electrical terminals (21, 22) at least for the piezo actuator (2). The terminals (21, 22) are fed through a housing wall (31, 32, 34), wherein a housing interior space (30) between the piezo actuator (2) and the housing wall (31, 32, 34) includes a potting compound (4), which electrically insulates the housing wall (31, 32, 34) from the piezo actuator (2). The potting compound (4) is a solid and comprises at least one particulate, heat-conducting, dielectric auxiliary substance (40), wherein the auxiliary substance (40) is arranged in the potting compound (4) so that a heat dissipation from the piezo actuator (2) to the housing wall (31, 32, 34) takes place during operation via the potting compound (4), in particular via the auxiliary substance (40).

Classes IPC  ?

• H10N 30/02 - Formation d'enceintes ou d'enveloppes
• H10N 30/50 - Dispositifs piézo-électriques ou électrostrictifs avec une structure empilée ou multicouche
• H10N 30/88 - MonturesSupportsEnveloppesBoîtiers

Abrégé

The invention relates to a dosing device (1) having a rotary head (2) and at least one dosing valve (3), preferably a jet valve (3), which is arranged on the rotary head (2), said dosing valve (3) having a nozzle (41) for dispensing dosing material, a movably mounted element (42) and an actuator unit (30) coupled to the movably mounted element (42) and/or the nozzle (41). The rotary head (2) is designed to generate a continuous rotation (R) of the dosing valve (3) about a rotational axis (X) of the rotary head (2) during operation of the dosing device (1). The invention also relates to a rotary head (2) for a dosing device (1), to a method for controlling a rotary head (2) of a dosing device (1) and to a method for producing a rotary head (2) for a dosing device (1).

Classes IPC  ?

• B05B 1/14 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie

Abrégé

AXAXAX). The invention also relates to a metering system (50) having such an actuator module (1).

Classes IPC  ?

• H10N 30/50 - Dispositifs piézo-électriques ou électrostrictifs avec une structure empilée ou multicouche
• H10N 30/88 - MonturesSupportsEnveloppesBoîtiers
• B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage

Abrégé

The invention relates to a metering system (1) for metering a metered medium comprising a frame housing unit (2) and a lever mounting unit (3) which his supported on the frame housing unit (2) comprising a lever mount (4). The invention further comprises a, preferably asymmetrical lever (30) which is supported rotatably by means of the lever mount (4) about a tilt axis (R) comprising a two-sided lever arm (31) extending substantially in a longitudinal direction (30L) of the lever (30), wherein one lever arm side (35), preferably the longer lever arm side (35), has a first actuator engagement point (36) close to the tilt axis and is in contact remotely from the tilt axis at an end portion (33) with an ejection element (13), preferably a ram (13), and wherein the other lever arm side (32), preferably the shorter lever arm side (32), has a second actuator engagement point (37) close to the tilt axis. The invention further comprises two actuators (50a, 50b), which, during operation, exert a tilting moment in opposite directions on the lever (30) at the first and second actuator engagement point (36, 37), wherein the actuators (50a, 50b) are placed obliquely to one another. Together, the lever mounting unit (3), the lever (30), and the two actuators (50a, 50b) thereby form a movement mechanism (4, 30, 50a, 50b), which is braced on the frame housing unit (2) by means of at least one spring element (21), preferably a disc spring set (21), wherein the spring element (21) is preferably arranged so that it braces the lever mounting unit (3) against the frame housing unit (2) via the lever (30) as well as via the two actuators (50a, 50b).

Classes IPC  ?

• G01F 11/02 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage
• G01F 11/38 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec des chambres de mesure fixes ayant un volume constant au cours du mesurage avec des soupapes d'admission ou de décharge du type à tiroir se déplaçant d'une manière rectiligne pour un liquide ou un semi-liquide

Abrégé

The invention relates to a metering system (1) with a housing (2), a piezo actuator (10) located therein, a fluidic unit (15) with a valve (16), a plunger device (40) for closing the valve (16), and a transmission lever (20) for coupling the piezo actuator (10) to the plunger device (40), wherein the piezo actuator (10) is arranged substantially parallel next to the plunger device (40) in the housing (2), wherein the piezo actuator (10) extends away from the transmission lever (20) substantially in the direction of a side facing the valve (16).

Classes IPC  ?

• G01F 11/34 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec des chambres de mesure fixes ayant un volume constant au cours du mesurage avec des soupapes d'admission et de décharge du type à levée ou à boisseau coulissant pour un matériau solide fluent
• G01F 15/00 - Détails des appareils des groupes ou accessoires pour ces derniers, dans la mesure où de tels accessoires ou détails ne sont pas adaptés à ces types particuliers d'appareils, p. ex. pour l'indication à distance
• H10N 30/20 - Dispositifs piézo-électriques ou électrostrictifs à entrée électrique et sortie mécanique, p. ex. fonctionnant comme actionneurs ou comme vibrateurs

Abrégé

The invention relates to a metering module (1, 1″) for metering a metering medium, having a plurality of metering valves (4a, 4b), having a first valve actuator group (2), which has at least two valve actuators (3) arranged alongside one another in a row direction (QR, QR″), which valve actuators (3) each comprise at least one metering head part (4) with an expulsion element (4a), and a second valve actuator group (5) with at least one valve actuator (3), preferably with a plurality of valve actuators (3) that are arranged alongside one another in a row direction (QR, QR″), which at least one valve actuator (3) also comprises a metering head part (4) with an expulsion element (4a). Here, the metering head parts (4) of the first valve actuator group (2) and of the second valve actuator group (5) face one another. Furthermore, the metering module (1, 1″) comprises a metering nozzle arrangement (4′) having a plurality of metering nozzles (4b), wherein each metering head part (4) is assigned a metering nozzle (4b) of the metering nozzle arrangement (4′) such that the metering nozzle (4b), with the expulsion element (4a) of the metering head part (4), forms in each case a metering valve (4a, 4b).

Classes IPC  ?

• F15B 13/08 - Assemblages de distributeurs élémentaires utilisés chacun pour la commande d'un seul servomoteur
• B29C 64/209 - TêtesBuses
• B33Y 30/00 - Appareils pour la fabrication additiveLeurs parties constitutives ou accessoires à cet effet

Produits et services

Pumps, compressors and blowing machines; industrial robots; electricity generators; opening and closing mechanisms; machines and machine tools for working metals and for use in manufacturing; engines for use in machines; drives and controls used for apparatus and machines; dispensing machines; sweeping, cleaning, washing and laundering machines; automatic dispensing machines; dosing valves; valves [parts of machines]; valves for controlling fluid flows; actuators for valves; nozzels; nozzles for dosing devices; machine tools; machines for the surface- mounted assembly of printed circuit boards; automatic machines for the installation of components, including containers, workpiece feed, feed mechanisms and placement heads; parts and fittings for all the aforesaid goods, included in this class. Recorded data; information technology and audiovisual equipment; magnets, magnetizers and demagnetizers; apparatus, instruments and cables for electricity; optical devices, enhancers and correctors; safety, security, protection and signalling devices; measuring, detecting, monitoring instruments, devices and controllers; programmable controllers; electronic controllers; electronic controls for automatically operating valves; scientific research and laboratory apparatus, educational apparatus and simulators; apparatus for automatic dosage; dosage dispensers; electric and/or magnetically controlled valves; piezoelectric actuators; piezoelectric sensors; piezoelectrical transducers; parts and fittings for all the aforesaid goods, included in this class. IT services, namely development, programming, implementation, maintenance and updating of software; computer and machine hardware development; scientific and technological services; engineering; testing, authenticating and quality control; design services; consultancy and information in relation to the aforesaid services, included in this class.

Produits et services

(1) Pumps, compressors and blowing machines; industrial robots; electricity generators; opening and closing mechanisms; machines and machine tools for working metals and for use in manufacturing; engines for use in machines; drives and controls used for apparatus and machines; dispensing machines; sweeping, cleaning, washing and laundering machines; automatic dispensing machines; dosing valves; valves [parts of machines]; valves for controlling fluid flows; actuators for valves; nozzels; nozzles for dosing devices; machine tools; machines for the surface- mounted assembly of printed circuit boards; automatic machines for the installation of components, including containers, workpiece feed, feed mechanisms and placement heads; parts and fittings for all the aforesaid goods, included in this class. (2) Recorded data; information technology and audiovisual equipment; magnets, magnetizers and demagnetizers; apparatus, instruments and cables for electricity; optical devices, enhancers and correctors; safety, security, protection and signalling devices; measuring, detecting, monitoring instruments, devices and controllers; programmable controllers; electronic controllers; electronic controls for automatically operating valves; scientific research and laboratory apparatus, educational apparatus and simulators; apparatus for automatic dosage; dosage dispensers; electric and/or magnetically controlled valves; piezoelectric actuators; piezoelectric sensors; piezoelectrical transducers; parts and fittings for all the aforesaid goods, included in this class. (1) IT services, namely development, programming, implementation, maintenance and updating of software; computer and machine hardware development; scientific and technological services; engineering; testing, authenticating and quality control; design services; consultancy and information in relation to the aforesaid services, included in this class.

Produits et services

Hydraulic pumps, air compressors and blowing machines for dispensing fluids; industrial robots; electricity generators; opening and closing mechanisms in the nature of valves for controlling the flow of fluid; machines and machine tools for working metals and for use in manufacturing of electronic, automotive, medical and pharmaceutical products; electric engines for use in machines; drives and hydraulic controls used for apparatus in the nature of fluid dispensing machines; fluid dispensing machines for industrial use; sweeping, cleaning, washing and laundering machines for use in connection with products assembled with fluid dispensing machines; automatic fluid dispensing machines for industrial use; dosing valves being parts of machines; valves being parts of machines; valves for controlling fluid flow as parts of machines; hydraulic actuators for valves; nozzles for dosing apparatus for dispensing fluids for industrial uses; nozzles for dosing devices in the nature of fluid dispensers for industrial use; machine tools for assembling fluid dispensing apparatus for industrial use; machines for the surface-mounted assembly of printed circuit boards; automatic machines for the installation of components, including containers, workpiece feed, feed mechanisms and placement heads, namely, industrial robots; structural parts and fittings for all the aforesaid goods Recorded data, namely, electronic database in the field of fluid dispensing apparatus recorded on computer media; information technology and audiovisual equipment, namely, data processing equipment; magnets, magnetizers and demagnetizers; apparatus, instruments in the nature of electric wires and cables for electricity; optical devices, enhancers and correctors, namely, optical reflectors and mirrors; safety, security, protection and signaling devices, namely, warning lights and audio warning generators; measuring, detecting, monitoring instruments, devices and controllers, namely, power controllers; programmable logic controllers; electronic controllers for programming and operating fluid dispensing apparatus; electronic controls for automatically operating valves; apparatus for automatic dosage, namely, fluid dispensing devices for use in product assembly; dosage dispensers for dispensing fluids for industrial uses; electric and magnetically controlled valves, namely, solenoid valves; piezoelectric actuators; piezoelectric sensors; piezoelectrical transducers; structural parts and fittings for all the aforesaid goods IT services, namely, development, programming, implementation, maintenance and updating of software; computer and machine hardware development; scientific and technological services, namely, scientific research in the field of fluid dispensing and fluid dispensing apparatus; engineering; testing, authenticating being authentication in the field of fluid dispensing and fluid dispensing apparatus, and quality control for others; design services in the nature of fluid dispensing apparatus and components therefor; consultancy and information in relation to the aforesaid services

Abrégé

The invention relates to a dosing installation (1) comprising at least one dosing device (2), which dosing device (2) has at least one dosing system (3) having: at least one dosing valve (4) for dispensing a dosing material; and at least one change system (5) assigned to the dosing device (2). The dosing installation (1) is designed and can be actuated by a control device (6) in such a way that at least the dosing valve (4) can be releasably coupled to the dosing device (2) in an automated process via the change system (5) in order to dispense dosing material and/or in such a way that at least the dosing valve (4) can be releasably coupled to a supply device (7) in an automated process via the change system (5). The invention also relates to: a change system (5) for a dosing installation (1); a dosing device (2) for a dosing installation (1); a dosing system (3) comprising a dosing valve (4); and a dosing valve (4) for a dosing system (3). The invention also relates to a method for coupling at least one dosing valve (4) to a dosing device (2) and/or to a supply device (7) in an automated manner.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to a dosing installation (1) comprising at least one dosing device (2), which dosing device (2) has at least one dosing system (3) comprising: at least one dosing head (5) for dispensing a dosing material; and at least one change system (6, 6') assigned to the dosing device (2). The dosing device (2) and/or the change system (6, 6') and/or the dosing system (3) are designed and can be controlled by a control device (7) in such a way that, in order to form a dosing head (5), at least one first dosing head component (A) can be detachably coupled to at least one second dosing head component (B) in an automated process via the change system (6, 6'). The invention also relates to a change system (6, 6') and a dosing device (2) for such a dosing installation (1) as well as to a dosing system (3) and a dosing head (5) for a dosing system (3). The invention also relates to a method for coupling at least one first dosing head component (A) to a second dosing head component (B) in an automated manner in order to form a dosing head (5).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• B05B 12/14 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation pour fournir à un orifice de pulvérisation unique, un liquide ou un autre matériau fluide choisi parmi plusieurs
• B05B 15/65 - Aménagements de montage pour la liaison fluide de l’appareil de pulvérisation ou de ses sorties aux conduits d’écoulement
• B05B 15/55 - Aménagements pour le nettoyageAménagements pour empêcher les dépôts, le séchage ou un blocageAménagements pour détecter une évacuation incorrecte en raison de la présence d’un corps étranger en utilisant des fluides nettoyants
• B05B 15/60 - Aménagements pour le montage, le maintien ou le soutien des appareils de pulvérisation
• B25J 15/04 - Têtes de préhension avec possibilité pour l'enlèvement ou l'échange à distance de la tête ou de parties de celle-ci

Produits et services

Power supply apparatus [generators]; generators; emergency power supply generators; uninterruptible power supply generating machines; diesel electric generators; power generators for vehicles; mobile electrical power generators; heat exchangers [parts of machines]; fuel cell generators and micro-cogenerators for electricity and thermal power generation; parts and fittings for all the aforesaid goods, as far as included in this class. Scientific and research apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling the distribution or use of electricity; apparatus and instruments for storing energy; fuel cells; solid oxide fuel cells; solid oxide electrolysis cells; electrolysers; apparatus and instruments for monitoring, measuring, detecting and controlling apparatus and instruments for furnace installations in industrial plants, including sensors and detectors; safety monitoring apparatus for furnace installations in industrial plants; computer software for monitoring, measuring, detecting and controlling apparatus and instruments for furnace installations in industrial plants, including logging of data and images; downloadable computer software for remote monitoring and analysis of furnace installations in industrial plants; parts and fittings for all the aforesaid goods, as far as included in this class. Advertising; Business management; Business administration; Organization, operation and supervision of sales and promotional incentive schemes; Organization of trade fairs for commercial or advertising purposes; Marketing, sales promotion and wholesaling and retailing services, in relation to electric power equipment, generators, fuel cell generators and micro-cogenerators for electric and thermal power generation, heating systems, electric and thermal power generators, electric and thermal power generation devices, electrolyser; consultancy and information in relation to all the aforesaid services in this class. Installation, cleaning, repair and maintenance of fuel cell generators and micro-cogenerators for electric and thermal power generation, rechargeable cells, galvanic cells, fuel cells, solid oxide fuel cells, solid oxide electrolyser; consultancy and information in relation to all the aforesaid services in this class. Engineering research; industrial research; design services; industrial design; product design; engineering design and consultancy; development of new products; all the above services in relation to fuel cell, electrolyser, electric and thermal power generators; consultancy and information in relation to all the aforesaid services in this class.

Abrégé

d″) of the guide sleeve portions (20, 40). The invention further relates to a valve (100, 100″) having such a valve tappet rod (1, 1″) and to a metering system (200) having such a valve (100, 100″) or such a valve tappet rod (1, 1″).

Classes IPC  ?

• B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to an actuator module (1) with a hermetically sealed housing (3) with at least one piezo actuator (2) arranged in the housing (3) and with electrical terminals (21, 22) at least for the piezo actuator (2). The terminals (21, 22) are led through a housing wall (31, 32, 34), wherein a housing interior space (30) between the piezo actuator (2) and the housing wall (31, 32, 34) contains a potting compound (4), which electrically insulates the housing wall (31, 32, 34) from the piezo actuator (2). The potting compound (4) is a solid and comprises at least one particulate, heat-conducting, dielectric auxiliary additive (40), wherein the auxiliary additive (40) is arranged in the potting compound (4) such that heat dissipation from the piezo actuator (2) to the housing wall (31, 32, 34) takes place during operation by way of the potting compound (4), in particular by way of the auxiliary additive (40).

Classes IPC  ?

• H10N 30/88 - MonturesSupportsEnveloppesBoîtiers
• H10N 30/02 - Formation d'enceintes ou d'enveloppes
• H10N 30/50 - Dispositifs piézo-électriques ou électrostrictifs avec une structure empilée ou multicouche

Produits et services

Industrial chemicals; Hydrogen; Methane; Syngas; Carbon Monoxide; Oxides; Gases for industrial purposes; Metal oxide powders for industrial purposes; Industrial chemicals for fuel cell and electrolysis systems; Chemical additives for fuels; catalytic converter for use in chemical processes. Power supply apparatus [generators]; Generators; Emergency power supply generators; Uninterruptible power supply generating machines; Diesel electric generators; Power generators for vehicles; Mobile electrical power generators; Heat exchangers [parts of machines]; Fuel cell generators and micro-cogenerators for electricity and thermal power generation; parts and fittings for all the aforesaid goods, as far as included in this class. Scientific and research apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling the distribution or use of electricity; apparatus and instruments for storing energy; fuel cells; solid oxide fuel cells; solid oxide electrolysis cells; electrolysers; apparatus and instruments for monitoring, measuring, detecting and controlling apparatus and instruments for furnace installations in industrial plants, including sensors and detectors; safety monitoring apparatus for furnace installations in industrial plants; computer software for monitoring, measuring, detecting and controlling apparatus and instruments for furnace installations in industrial plants, including logging of data and images; downloadable computer software for remote monitoring and analysis of furnace installations in industrial plants; parts and fittings for all the aforesaid goods, as far as included in this class. Heating installations; Heating apparatus, electric; Catalytic combustion heating apparatus; Heaters for vehicles; Heating apparatus; Mobile heating apparatus; Heating apparatus for solid, liquid or gaseous fuels; Plants for cogeneration of heat and power; parts and fittings for all the aforesaid goods, as far as included in this class. Advertising; Business management; Business administration; Organization, operation and supervision of sales and promotional incentive schemes; Organization of trade fairs for commercial or advertising purposes; Marketing, sales promotion and wholesaling and retailing services, in relation to electric power equipment, generators, fuel cell generators and micro-cogenerators for electric and thermal power generation, heating systems, electric and thermal power generators, electric and thermal power generation devices, electrolyser; consultancy and information in relation to all the aforesaid services in this class. Installation, cleaning, repair and maintenance of fuel cell generators and micro-cogenerators for electric and thermal power generation, rechargeable cells, galvanic cells, fuel cells, solid oxide fuel cells, solid oxide electrolyser; consultancy and information in relation to all the aforesaid services in this class. Distribution of energy; Storage of energy and fuels; consultancy and information in relation to all the aforesaid services in this class. Electricity generating; Production of electricity by power plants; Energy production; consultancy and information in relation to all the aforesaid services in this class. Engineering research; Industrial research; design services; Industrial design; product design; engineering design and consultancy; development of new products; all the above services in relation to fuel cell, electrolyser, electric and thermal power generators; consultancy and information in relation to all the aforesaid services in this class.

Produits et services

Pharmaceuticals; medical and veterinary preparations; medicinal substances; veterinary substances; sanitary preparations for medical purposes; disinfectants; sanitizing wipes; diagnostic preparations for medical purposes; in vitro diagnostic preparations for medical purposes; diagnostic reagents and test kits for medical or veterinary purposes; biochemical preparations for medical use; medicated and sanitizing soaps and detergents; wipes for medical use; eyepatches for medical purposes; medical coverings and applicators, as far as included in this class; medical dressings, coverings and applicators, as far as included in this class; adhesive compositions for medical use; adhesive tapes for medical purposes; adhesive films for medical use; parts and fittings for all the aforesaid goods, as far as included in this class. Pumps, compressors and fans; compressed air pumps; compressed air engines; compressed air machines; robots; electricity generators; machines and machine tools for treatment of materials and for manufacturing; engines, not for land vehicles; powertrains, not for land vehicles; generic machine parts, namely linking elements, drive elements, working elements [parts of machines], axles, shafts for machines, bearings, gear units; dispensing machines; sweeping, cleaning, washing and laundering machines; electromechanical machines for chemical industry; heating and cooling systems [parts of machines]; control mechanisms for machines, engines or motors; automatic dispensing machines; dosing valves [parts of machines]; valves [parts of machines]; valves for controlling fluid flows [parts of machines]; actuators for valves; nozzles [parts of machines]; nozzles for dosing systems [parts of machines]; machine tools; machines for surface mount assembly of printed circuit boards; machines for the assembly of components, including containers, workpiece feeding, feed mechanisms and mounting heads; parts and fittings for all the aforesaid goods, as far as included in this class. Recorded content; information technology equipment; audiovisual equipment; electricity indicators; chemistry apparatus and instruments; computer programs, recorded; computer software, recorded; magnets, magnetizers and demagnetizers; apparatus, instruments and cables for electricity; sensors; detectors; computer software; optical devices, enhancers and correctors; safety, security, protection and signaling devices and equipment; measuring, detecting and monitoring instruments, indicators and controllers; programmable controllers; electronic controllers; scientific research and laboratory apparatus, educational apparatus and simulators; automatic dosage apparatus; dosage dispensers; electric installations for the remote control of industrial operations; interfaces for computers; calibrating apparatus; capillary tubes; solenoid valves [electromagnetic switches]; measuring devices [electric]; precision measuring apparatus; electric apparatus for commutation; electric and/or solenoid operated valves; transmitters of electronic signals; instrumentation simulators; parts and fittings for all the aforesaid goods, as far as included in this class. Surgical, medical, dental and veterinary apparatus and instruments; artificial limbs; artificial eyes; artificial teeth; orthopedic articles; suture materials for surgical use; medical apparatus, instruments and sensors; medical implants; testing apparatus for medical purposes; diagnostic, examination, and monitoring equipment; diagnostic apparatus for medical purposes; apparatus, devices, instruments and sensors for testing and monitoring of medical equipment; dosing systems for medical purposes; containers for medical purposes; medical apparatus and instruments made of elastomeric material; medical applicators, namely applicators for pharmaceutical preparations and receptacles for applying medicines; electrodes for medical use; compressors for medical [treatment] purposes; lamps for medical purposes; measuring apparatus, devices, instruments and sensors for medical and veterinary use; adhesive sutures; bags [fitted] for medical instruments; parts and fittings for all the aforesaid goods, as far as included in this class. Flexible pipes, tubes, hoses and fittings therefor, including valves [all not of metal]; seals, sealants and fillers; insulation and barrier articles and materials; vibration dampers; seals; adhesive tapes, strips, bands and films; parts and fittings for all the aforesaid goods, as far as included in this class. IT services, namely development, programming services, software application and software implementation, computer hardware development, software as a service [SaaS] and rental of computer software, IT security services, computer analysis and computer diagnostic services, research and development as well as computer and computer systems implementation, data mining; scientific and technological services; engineering services; scientific and technological consultancy regarding approval procedure; testing, authentication and quality control; design services; certification and testing of medical products; certification and testing of quality management systems in the healthcare sector; arranging and provision of technical know-how (technological consultancy); engineering technical consultancy; consultancy in the field of medical, human biological and microbiological research; services of a technical measuring and testing laboratory; services of a chemical laboratory; technical measuring, testing and checking; design and development of medical products, especially medical apparatus and instruments; preparation of technical assessments.

Abrégé

The invention relates to a metering system (1) with a housing (2), a piezo actuator (10) located therein, a fluidic unit (15) with a valve (16), a plunger device (40) for closing the valve (16), and a transmission lever (20) for coupling the piezo actuator (10) to the plunger device (40), wherein the piezo actuator (10) is arranged substantially parallel next to the plunger device (40) in the housing (2), wherein the piezo actuator (10) extends away from the transmission lever (20) substantially in the direction of a side facing the valve (16).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to a metering system (1) with a housing (2), a piezo actuator (10) located therein, a fluidic unit (15) with a valve (16), a plunger device (40) for closing the valve (16), and a transmission lever (20) for coupling the piezo actuator (10) to the plunger device (40), wherein the piezo actuator (10) is arranged substantially parallel next to the plunger device (40) in the housing (2), wherein the piezo actuator (10) extends away from the transmission lever (20) substantially in the direction of a side facing the valve (16).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to a metering module (1, 1'') for metering a metering medium, having a plurality of metering valves (4a, 4b), having a first valve actuator group (2), which has at least two valve actuators (3) arranged alongside one another in a row direction (QR, QR''), which valve actuators (3) each comprise at least one metering head part (4) with an expulsion element (4a), and a second valve actuator group (5) with at least one valve actuator (3), preferably with a plurality of valve actuators (3) that are arranged alongside one another in a row direction (QR, QR''), which at least one valve actuator (3) also comprises a metering head part (4) with an expulsion element (4a). Here, the metering head parts (4) of the first valve actuator group (2) and of the second valve actuator group (5) face one another. Furthermore, the metering module (1, 1'') comprises a metering nozzle arrangement (4') having a plurality of metering nozzles (4b), wherein each metering head part (4) is assigned a metering nozzle (4b) of the metering nozzle arrangement (4') such that the metering nozzle (4b), with the expulsion element (4a) of the metering head part (4), forms in each case a metering valve (4a, 4b).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05B 1/16 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie comportant des sorties de section réglable
• B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
• G01F 11/00 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume

Abrégé

The invention relates to a metering module (1, 1'') for metering a metering medium, having a plurality of metering valves (4a, 4b), having a first valve actuator group (2), which has at least two valve actuators (3) arranged alongside one another in a row direction (QR, QR''), which valve actuators (3) each comprise at least one metering head part (4) with an expulsion element (4a), and a second valve actuator group (5) with at least one valve actuator (3), preferably with a plurality of valve actuators (3) that are arranged alongside one another in a row direction (QR, QR''), which at least one valve actuator (3) also comprises a metering head part (4) with an expulsion element (4a). Here, the metering head parts (4) of the first valve actuator group (2) and of the second valve actuator group (5) face one another. Furthermore, the metering module (1, 1'') comprises a metering nozzle arrangement (4') having a plurality of metering nozzles (4b), wherein each metering head part (4) is assigned a metering nozzle (4b) of the metering nozzle arrangement (4') such that the metering nozzle (4b), with the expulsion element (4a) of the metering head part (4), forms in each case a metering valve (4a, 4b).

Classes IPC  ?

• B05B 1/16 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie comportant des sorties de section réglable
• B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 11/00 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume

Abrégé

The invention relates to dosing system (1) for a dosing substance, which dosing system (1) comprises a housing (11) having a nozzle (60) and a feed channel (64) for dosing substance, a discharge element (51) arranged in the housing (11) for discharging dosing substance from the nozzle (60), at least one first actuator (20), preferably a piezo actuator (20), coupled to the discharge element (51) and/or the nozzle (60), and at least one second actuator (30), preferably an expansion material element (30), coupled to the first actuator (20). The second actuator (30) is designed to set a position of the at least one first actuator (20) relative to the housing (11), particularly with respect to the discharge element (51) and/or the nozzle (60). The invention further relates to a method for controlling such a dosing system (1).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

Abrégé

The invention relates to a metering system (1) for metering a metered medium comprising a frame housing unit (2) and a lever mounting unit (3) which his supported on the frame housing unit (2) comprising a lever mount (4). The invention further comprises a, preferably asymmetrical lever (30) which is supported rotatably by means of the lever mount (4) about a tilt axis (R) comprising a two-sided lever arm (31) extending substantially in a longitudinal direction (30L) of the lever (30), wherein one lever arm side (35), preferably the longer lever arm side (35), has a first actuator engagement point (36) close to the tilt axis and is in contact remotely from the tilt axis at an end portion (33) with an ejection element (13), preferably a ram (13), and wherein the other lever arm side (32), preferably the shorter lever arm side (32), has a second actuator engagement point (37) close to the tilt axis. The invention further comprises two actuators (50a, 50b), which, during operation, exert a tilting moment in opposite directions on the lever (30) at the first and second actuator engagement point (36, 37), wherein the actuators (50a, 50b) are placed obliquely to one another. Together, the lever mounting unit (3), the lever (30), and the two actuators (50a, 50b) thereby form a movement mechanism (4, 30, 50a, 50b), which is braced on the frame housing unit (2) by means of at least one spring element (21), preferably a disc spring set (21), wherein the spring element (21) is preferably arranged so that it braces the lever mounting unit (3) against the frame housing unit (2) via the lever (30) as well as via the two actuators (50a, 50b).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 11/02 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage
• G01F 11/36 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec des chambres de mesure fixes ayant un volume constant au cours du mesurage avec des soupapes d'admission ou de décharge du type à tiroir se déplaçant d'une manière rectiligne

Abrégé

The invention relates to a metering system (1) for metering a metered medium, comprising a frame housing unit (2) and a lever mounting unit (3) which is supported on the frame housing unit (2) and has a lever mount (4). The invention also comprises a preferably asymmetrical lever (30), which is mounted rotatably by means of the lever mount (4) about a tilt axis (R) and which has a two-ended lever arm (31) extending substantially in a longitudinal direction (30L) of the lever (30), a lever arm side (35), preferably the longer lever arm side (35), having a first actuator engagement point (36) close to the tilt axis and being in contact remotely from the tilt axis, at an end portion (33), with an ejection element (13), preferably a ram (13), and the other lever arm side (32), preferably the shorter lever arm side (32), having a second actuator engagement point (37) close to the tilt axis. The invention also comprises two actuators (50a, 50b), which, during operation, exert in opposite directions a tilting moment on the lever (30) at the first and second actuator engagement point (36, 37), the actuators (50a, 50b) being moved obliquely relative to one another. Here, the lever mounting unit (3), the lever (30) and the two actuators (50a, 50b) jointly form a movement mechanism (4, 30, 50a, 50b), which is braced on the frame housing unit (2) by means of at least one spring element (21), preferably a diaphragm spring set (21), the spring element (21) preferably being arranged such that it braces the lever mounting unit (3) against the frame housing unit (2) via the lever (30) and via the two actuators (50a, 50b).

Classes IPC  ?

• G01F 11/02 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 11/36 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec des chambres de mesure fixes ayant un volume constant au cours du mesurage avec des soupapes d'admission ou de décharge du type à tiroir se déplaçant d'une manière rectiligne

Abrégé

The invention relates to a method for producing at least one molecular sensor (2, 2', 2'') having at least one nanoparticle (3), which nanoparticle (3) is coated with at least one molecularly imprinted polymer molecule (4). In a first step of the method, a mixture is provided that comprises at least one nanoparticle (3), at least one template molecule (6) and a number of monomer molecules (5, 5'). In a further step, at least part of a surface (7) of the nanoparticle (3) is excited by means of electromagnetic radiation and at least one monomer molecule (5) is activated such that polymerisation takes place to form at least one molecularly imprinted polymer molecule (4) and/or the nanoparticle (3) is coated with at least one molecularly imprinted polymer molecule (4). The invention also relates to a molecular sensor (2, 2', 2'') having at least one nanoparticle (3), which nanoparticle (3) is coated with at least one molecularly imprinted polymer molecule (4). The invention further relates to an analysis method for selectively detecting an analyte (41) in a sample (40) and to an analysis system (1) for detecting, in particular for quantifying, at least one analyte (41) in a sample (40).

Classes IPC  ?

• G01N 31/22 - Utilisation des réactifs chimiques
• G01N 21/78 - Systèmes dans lesquels le matériau est soumis à une réaction chimique, le progrès ou le résultat de la réaction étant analysé en observant l'effet sur un réactif chimique produisant un changement de couleur
• C08F 293/00 - Composés macromoléculaires obtenus par polymérisation sur une macromolécule contenant des groupes capables d'amorcer la formation de nouvelles chaînes polymères rattachées exclusivement à une ou aux deux extrémités de la macromolécule de départ
• B82Y 15/00 - Nanotechnologie pour l’interaction, la détection ou l'actionnement, p. ex. points quantiques comme marqueurs en dosages protéiques ou moteurs moléculaires

Abrégé

The invention relates to a valve tappet rod (1, 1'') for a valve (100, 100'') of a metering system (200) for a metering material. The valve tappet rod (1, 1'') has an elongate, substantially cylindrical body. Said body has a tappet tip (60) at a face-side end (B), a tappet head (10) in an opposite head region (A) and, therebetween, from the tappet head (10) to the tappet tip (60), at least a first guide-sleeve portion (20), a narrow portion (30), a second guide-sleeve portion (40) and a fluidic portion (50). An outside diameter (30d, 30d'') of the narrow portion (30) is reduced in comparison with the outside diameters (20d, 20d'', 40d, 40d'') of the guide-sleeve portions (20, 40). The invention also relates to a valve (100, 100'') having a valve tappet rod (1, 1'') of this type and to a metering system (200) having a valve (100, 100'') of this type or a valve tappet rod (1, 1'') of this type.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable

Abrégé

The invention relates to a dosing system (1) for a dosing material having a dosing device (5) with a housing (11), the housing (11) comprising a feed channel (80) for dosing material, a nozzle (40), a discharge element (31) and an actuator unit (10) coupled to the discharge element (31) and/or the nozzle (40). The dosing device (5) further comprises a dosing material reservoir (70) which is coupled to the housing (11) or integrated into the housing (11). The dosing system (1) has a plurality of temperature control devices (2, 2′, 2″) which are each assigned to different temperature zones (6, 6′, 6″) of the dosing system (1) in order to control the temperature zones (6, 6′, 6″) differently. At least one first temperature zone (6) is assigned to the dosing material reservoir (70) and at least one second temperature zone (6″) is assigned to the nozzle (40). Preferably, at least one of the temperature control devices (2, 2′, 2″), preferably at least the temperature control device (2) assigned to the dosing material reservoir (6), comprises a cooling device (3, 3′, 3″) having a cold source (93, 93′, 95, 99).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

Abrégé

The invention relates to a dosing system (1) for dosing a dosing material. The dosing system (1) has a housing (11), comprising a nozzle (70) and a supply channel (62) for dosing material, and a discharge element (80) movably mounted in the housing (11) and an actuator unit (10) coupled to the discharge element. The actuator unit (10) comprises an actuator (12) having a membrane (13) which can be pressurized by means of a pressure medium in order to move the discharge element (80) in a discharge direction (RA). The discharge element (80) is formed separately and, for coupling to the actuator unit (10), is pressed by means of a force acting on the discharge element (80) against a side surface (19) of the membrane (13) pointing in the direction of the discharge element (80). Furthermore, the invention relates to a method for controlling a dosing system (1).

Classes IPC  ?

• G01F 11/08 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage du type à diaphragme ou à soufflet
• B05B 1/24 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des moyens pour chauffer le liquide ou autre matériau fluide, p. ex. électriquement
• B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

Abrégé

The invention relates to a dosing system (1) for a dosing material having a nozzle (40), a feed channel (44) for dosing material, a discharge element (31), an actuator unit (10) that is coupled to the discharge element (31) and/or the nozzle (40) and has a piezo actuator (60), and a cooling device (2). The cooling device (2) comprises a supply device (21, 24, 26) for feeding a precooled cooling medium into a housing (11) of the dosing system (1). The cooling device (2) is configured for direct cooling of at least one subregion of the piezo actuator (60) and/or at least one subregion of a movement mechanism (14) coupled to the piezo actuator (60) by means of the precooled cooling medium.

Classes IPC  ?

• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to a dosing system (1) for a dosing material, which dosing system (1) comprises a housing (11) having a nozzle (60) and a feed channel (64) for the dosing material, a discharge element (51) arranged in the housing (11) for discharging dosing material out of the nozzle (60), at least one first actuator (20) coupled to the discharge element (51) and/or the nozzle (60), preferably a piezoactuator (20), and at least one second actuator (30) coupled to the first actuator (20), preferably an expansion material element (30). The second actuator (30) is designed to adjust a position of the at least one first actuator (20) relative to the housing (11), in particular in relation to the discharge element (51) and/or the nozzle (60). The invention also relates to a method for controlling such a dosing system (1).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

Abrégé

The invention relates to a metering system (1) for a metering substance, comprising a nozzle (40), a feed channel (44) for the metering substance, a discharge element (31), and a piezo actuator (61) which is coupled to the discharge element (31) and/or the nozzle (40). The piezo actuator (61) of the metering system (1) is hermetically encapsulated in a housing (62).

Classes IPC  ?

• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• H01L 41/053 - Montures, supports, enveloppes ou boîtiers

Abrégé

The present invention relates to a dosing system (100) with an actuator unit (60) and a fluidic unit (10) which can be coupled thereto in a detachable manner, wherein the fluidic unit (10) has a nozzle (20) an element (30), mounted in a movable manner, and the actuator unit (60) has an actuator system (90), in order to actuate the movable element (30) of the fluidic unit (10), wherein the fluidic unit (10) has a first plug coupling part (11) and the actuator unit (60) has a second plug coupling part (61), which can be plugged into one another for coupling the fluidic unit (10) to the actuator unit (60) along a plugging axis (S) and can be coupled to one another integrally. The invention additionally relates to a fluidic unit (10) and an actuator unit (60) for such a dosing system (100) and also a method for the detachable coupling of a fluidic unit (10) to an actuator unit (60) of a dosing system (100).

Classes IPC  ?

• G01F 11/44 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec des chambres de mesure fixes ayant un volume constant au cours du mesurage avec des soupapes d'admission ou de décharge du type à tiroir rotatif ou oscillant pour un liquide ou un semi-liquide
• G01F 15/18 - Supports ou moyens de raccordement pour les compteurs

Abrégé

The invention relates to a metering system (1) for metering a metering material. The metering system (1) comprises a housing (11), having a nozzle (70) and a supply channel (62) for metering material, and a discharge element (80) moveably mounted in the housing (11), as well as an actuator unit (10) coupled to the discharge element. The actuator unit (10) comprises an actuator (12) having a membrane (13) which can be applied with a pressure medium in order to move the discharge element (80) in a discharge direction (RA). The discharge element (80) is designed to be separate and is pressed against a lateral surface (19) of the membrane (13) pointing in the direction of the discharge element (80) by means of a force acting on the discharge element (80) for the purpose of coupling to the actuator unit. The invention also relates to a method for controlling a metering system (1).

Classes IPC  ?

• B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• F16K 31/12 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide

Abrégé

The invention relates to a metering system (1) for metering a metering material. The metering system (1) comprises a housing (11), having a nozzle (70) and a supply channel (62) for metering material, and a discharge element (80) moveably mounted in the housing (11), as well as an actuator unit (10) coupled to the discharge element. The actuator unit (10) comprises an actuator (12) having a membrane (13) which can be applied with a pressure medium in order to move the discharge element (80) in a discharge direction (RA). The discharge element (80) is designed to be separate and is pressed against a lateral surface (19) of the membrane (13) pointing in the direction of the discharge element (80) by means of a force acting on the discharge element (80) for the purpose of coupling to the actuator unit. The invention also relates to a method for controlling a metering system (1).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• F16K 31/12 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide
• B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable

Produits et services

Automatic dispensing machines; dosing valves; valves [parts of machines]; valves for controlling fluid flows; drives for valves; nozzles for valves and dosing valves; parts and fittings for all the aforesaid goods, included in this class. Electric and/or magnet controlled valves; apparatus for automatic dosage; dosage dispensers; measuring, detecting and monitoring instruments, indicators and controllers for automatically operating valves and dosing valves; apparatus for automatic dosage or dosage dispensers; software and electronic controls for automatically operating valves and dosing valves; parts and fittings for all the aforesaid goods, included in this class. IT services, namely development, programming, implementation, maintenance and updating of software for automatically operating valves, dosing valves, apparatus for automatic dosage apparatus or dosage apparatus; consultancy and information in relation to the aforesaid services, included in this class.

Abrégé

The invention relates to a dosing system (1) for a dosing material, comprising a nozzle (40), a feed channel (44), a discharge element (31), an actuator unit (10) coupled to the discharge element (31) and/or the nozzle (40) and comprising a piezo actuator (60) and a cooling device (2). The cooling device (2) comprises a supply device (21, 24, 26) for feeding a precooled cooling medium into a housing (11) of the dosing system (1). The cooling device (2) is designed to directly cool at least one partial area of the piezoactuator (60) and/or at least a subregion of a movement mechanism (14) coupled to the piezoactuator (60) by means of the precooled cooling medium.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

Abrégé

The invention relates to a dosing system (1) for a dosing material, comprising a dosing device (5) with a housing (11), wherein the housing (11) comprises a feed channel (80) for the dosing material, a nozzle (40), a discharge element (31) and an actuator unit (10) coupled to the discharge element (31) and/or the nozzle (40). The dosing device (5) also comprises a dosing material reservoir (70) which is coupled to the housing (11) or integrated into the housing (11). The dosing system (1) has a plurality of temperature control devices (2, 2', 2'') which are respectively assigned to different temperature zones (6, 6', 6'') of the dosing system (1) in order to control the temperature zones (6, 6', 6'' ') differently. At least one first temperature zone (6) is assigned to the dosing material reservoir (70) and at least one second temperature zone (6'') is assigned to the nozzle (40). Preferably, at least one of the temperature control devices (2, 2', 2''), preferably at least the temperature control device (2) assigned to the dosing material reservoir (6), comprises a cooling device (3, 3', 3'') having a cold source (93, 93', 95, 99).

Classes IPC  ?

• B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Produits et services

Automatic dispensing machines; dosing valves; valves [parts of machines]; valves for controlling fluid flows; drives for valves; nozzles for valves and dosing systems; parts and fittings for all the aforesaid goods, included in this class. Electric and/or magnet controlled valves; apparatus for automatic dosage; dosage dispensers; measuring, detecting and monitoring instruments, indicators and controllers for automatically operating valves and dosing valves; apparatus for automatic dosage or dosage dispensers; software and electronic controls for automatically operating valves and dosing valves, parts and fittings for all the aforesaid goods, included in this class. IT services, namely development, programming, implementation, maintenance and updating of software for automatically operating valves, dosing valves, apparatus for automatic dosage apparatus or dosage apparatus; consultancy and information in relation to the aforesaid services, included in this class.

Abrégé

The invention relates to a dosing system (1) for a dosing material, comprising a nozzle (40), a feed channel (44) for the dosing material, a discharge element (31) and a piezo actuator (61) coupled to the discharge element (31) and/or the nozzle (40). The piezo actuator (61) of the dosing system (1) is hermetically encapsulated in a housing (62).

Classes IPC  ?

• B05B 1/08 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour produire un jet, un pulvérisat ou tout autre écoulement de forme ou de nature particulière, p. ex. sous forme de gouttes individuelles de nature pulsatoire, p. ex. débitant un liquide en quantités successives séparées
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• H01L 41/053 - Montures, supports, enveloppes ou boîtiers

Produits et services

Automatic dispensing machines for liquids, pasty substances, or both; nozzles adapted for valves as machine components used for dispensing liquids, pasty substances, or both, and for dosing systems comprised of dispensing valves being machine parts used for liquids, pasty substances, or both; parts and fittings specially adapted for all the aforesaid goods, namely, mounting elements, tubes, pipes, and couplings Apparatus for automatic dosage, namely, machines for dispensing predetermined dosages for liquids, pasty substances, or both; dosage dispensers in the nature of machines for dispensing predetermined dosages for liquids, pasty substances, or both; apparatus for automatic dosage or dosage dispensers, namely, machines for dispensing dosages of liquids, pasty substances, or both; parts and fittings specially adapted for all the aforesaid goods, namely, mounting elements, tubes, pipes, and couplings

Produits et services

Pumps [machines], compressors [machines] and blowing machines; industrial robots; current generators; opening and closing mechanisms; machines and machine tools for treatment of materials and for manufacturing; engines for the operation of machines; parts of machines and engines, namely, drives and controls for the operation of machines and engines; dispensing machines; sweeping, cleaning, washing and laundering machines; automatic dispensing machines; dosing valves [parts of machines]; valves [parts of machines]; valves for controlling fluid flows; drives for valves; nozzles [parts of machines]; nozzles for dosing systems; machine tools; machines for surface mount assembly of printed circuit boards; machines for assembly of components, including containers, workpiece feeding, feed mechanisms and mounting heads; parts and fittings for all the aforesaid goods, included in this class. Recorded content; information technology and audiovisual equipment; magnets, magnetizers and demagnetizers; apparatus, instruments and cables for electricity; optical devices, enhancers and correctors; safety, security, protection and signalling devices and equipment; measuring, detecting and monitoring instruments, indicators and controllers; programmable controllers; electronic controllers; electronic controls for automatically operating valves; scientific research and laboratory apparatus, educational apparatus and simulators; automatic dosage apparatus; dosage dispensers; electric and/or magnet controlled valves; parts and fittings for all the aforesaid goods, included in this class. Flexible pipes, tubes, hoses and junctions therefor [including valves], and junctions for hard pipes, mainly not of metal; seals, sealants and fillers; insulation and barrier materials; shock-absorbing material and packing materials, vibration dampers; membranes and semi-processed synthetic filtering materials; adhesive tapes, adhesive strips and adhesive films; parts and fittings for all the aforesaid goods, included in this class. IT services, namely development, programming, implementation, maintenance and updating of software; computer and machine hardware development; scientific and technological services; engineering services; testing, authentication and quality control; design services; consultancy and information in relation to the aforesaid services, included in this class.

Produits et services

Pumps, compressors and fans; robots; current generators; machines and machine tools for treatment of materials and for manufacturing; engines, powertrains and generic machine parts; dispensing machines; sweeping, cleaning, washing and laundering machines; parts and accessories for all the aforesaid goods included in this class; automatic dispensing machines; dosing valves; valves [parts of machines]; valves for controlling fluid flows; actuators for valves; nozzles (parts of machines); nozzles for dosing systems; machine tools; machines for surface mount assembly of printed circuit boards; machines for the assembly of components, including containers, workpiece feeding, feed mechanisms and mounting heads. Recorded content; information technology and audiovisual equipment; magnets, magnetizers and demagnetizes; apparatus, instruments and cables for electricity; optical devices, enhancers and correctors; safety, security, protection and signaling devices and equipment; measuring, detecting and monitoring instruments, indicators and controllers; programmable and electronic controllers; scientific research and laboratory apparatus, educational apparatus and simulators; parts and accessories for all the aforesaid goods included in this class; automatic dosage apparatus; dosage dispensers; electric and/or solenoid operated valves. Non-metallic flexible pipes, tubes, hoses and fittings therefor, including valves; seals, sealants and fillers; insulation and barrier articles and materials; vibration dampers for effective absorption and compensation of disturbing excitation; adhesive tapes, strips, bands and films for industrial purposes; parts and accessories for all the aforesaid goods included in this class. IT services, namely development, programming services and software implementation; computer hardware development; scientific and technological services; engineering services; testing, authentication and quality control; design services; provision, rental and leasing of objects in connection with provision of the aforesaid services, included in this class; counseling and information services relating to the aforesaid services included in this class.

Abrégé

The invention relates to a metering system (100), comprising an actuator unit (60) and a fluidic unit (10), which can be detachably coupled to the actuator unit, wherein the fluidic unit (10) has a nozzle (20) and a movably mounted element (30) and the actuator unit (60) has an actuator system (90) for actuating the movable element (30) of the fluidic unit (10), and the fluidic unit (10) has a first plug-in coupling part (11) and the actuator unit (60) has a second plug-in coupling part (61), which plug-in coupling parts can be inserted into one another along a plugging axis (S) and can be coupled to each other in themselves in order to couple the fluidic unit (10) to the actuator unit (60). The invention further relates to a fluidic unit (10) and to an actuator unit (60) for such a metering system (100) and to a method for detachably coupling a fluidic unit (10) to an actuator unit (60) of a metering system (100).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

Abrégé

b) has an evaluation unit (50), which is configured to determine if a drop (TR) has been dispensed by the metering valve (DV) based on the measurement signal (MS) under consideration of the defined pulse frequency. A method (600) of detecting a drop (TR) of a metering valve (DV) is also described.

Classes IPC  ?

• G01N 15/14 - Techniques de recherche optique, p. ex. cytométrie en flux
• F16K 17/168 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté combinés avec des soupapes commandées à la main, p. ex. soupape à mécanisme de commande et soupape de sûreté combinées
• B05B 12/08 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation sensibles à l'état du liquide ou d'un autre matériau fluide expulsé, du milieu ambiant ou de la cible
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• G01V 8/12 - Détection, p. ex. en utilisant des barrières de lumière en utilisant un émetteur et un récepteur
• G01F 11/44 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec des chambres de mesure fixes ayant un volume constant au cours du mesurage avec des soupapes d'admission ou de décharge du type à tiroir rotatif ou oscillant pour un liquide ou un semi-liquide
• G01N 15/00 - Recherche de caractéristiques de particulesRecherche de la perméabilité, du volume des pores ou de l'aire superficielle effective de matériaux poreux
• B05B 12/00 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

A drop-detection device detects a drop that escapes from a metering valve. The drop-detection device includes a light guide with first and second light-guiding elements that are arranged opposite each other at an intermediate space. A drop trajectory runs through the intermediate space such that a light beam sent out by the first light-guiding element crosses the drop trajectory and is subsequently coupled into the second light-guiding element. In addition, the drop-detection device includes a light-signal generation device that couples a pulsed light beam with a carrier frequency into the first light-guiding element. Furthermore, the drop-detection device also has a light evaluation device for evaluating the light beam coupled into the second light-guiding element to determine if a drop has been dispensed by the metering valve. A method of detecting a drop is also described.

Classes IPC  ?

• G01F 25/00 - Test ou étalonnage des appareils pour la mesure du volume, du débit volumétrique ou du niveau des liquides, ou des appareils pour compter par volume
• G01F 11/00 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume
• B41J 2/125 - Capteurs, p. ex. capteurs de déviation
• G01F 22/00 - Procédés ou appareils pour la mesure du volume des fluides ou des matériaux solides fluents, non prévus ailleurs
• G01F 11/12 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure se déplaçant au cours de l'opération du type à soupapes, c.-à-d. que la séparation est effectuée par des mouvements étanches aux fluides ou aux poudres
• G01F 13/00 - Appareils pour mesurer par volumes et déverser des fluides ou des matériaux solides fluents, non prévus dans les groupes précédents
• G01V 8/24 - Détection, p. ex. en utilisant des barrières de lumière en utilisant plusieurs émetteurs ou récepteurs en utilisant des fibres optiques

Abrégé

The invention relates to a guide system (1) for a detection device (3) for monitoring a substance (23) coming out of a nozzle orifice (5) of a metering device (2), wherein a nozzle orifice region (6) for arrangement on the nozzle orifice (5) is associated with the guide system (1), and the guide system (1) comprises at least one material body (15, 16) in which at least two guide ducts (7) are formed, which are designed to guide signal conductors (8) to the nozzle orifice (6), wherein the end regions (14) of two guide ducts (7) facing the nozzle orifice region (6) are arranged, with regard to their central axes (9), substantially on a common straight line (G) relative to one another and are arranged, with regard to the nozzle orifice region (6), opposite one another. The invention further relates to a detection device (3) and to a metering device (2) having such a guide system (1) and to a method for configuring a detection device (3) having such a guide system (1).

Classes IPC  ?

• B05B 12/08 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation sensibles à l'état du liquide ou d'un autre matériau fluide expulsé, du milieu ambiant ou de la cible
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

Abrégé

The invention describes a piezo driving circuit, comprising an input at which a temporally variable voltage signal is applied; a piezo interface for connecting terminals of a piezo actuator arrangement with at least one voltage controlled piezo actuator; a sync control circuit realized to detect the phase position of the voltage signal; and an inverter circuit between the input and the piezo interface; whereby the sync control circuit is realized to control the inverter circuit, based on the phase position of the voltage signal, such that a control voltage with a predefined voltage curve is applied at the piezo interface. The invention further describes a method of controlling a piezo actuator arrangement. The invention also describes a piezo actuator configuration comprising a piezo actuator arrangement and an inventive piezo driving circuit. The invention also describes a metering valve comprising the inventive piezo actuator configuration.

Classes IPC  ?

• H02N 2/06 - Circuits d'entraînementDispositions pour la commande
• F16K 31/00 - Moyens de fonctionnementDispositifs de retour à la position de repos

Abrégé

Described is a drop detection apparatus (11, 11a) for detecting drops (TR) that exit a metering valve (DV) and move along a path. The drop detection apparatus (11, 11a) comprises an optical waveguide arrangement (L) having a first optical waveguide (L1) and a second optical waveguide (L2). The first optical waveguide (L1) and the second optical waveguide (L2) are arranged across from each other, in a space through which the path of the drop (TR) extends, in such a way that a light beam (LS) emitted by the first optical waveguide (L1) intersects the path (T) of the drop (TR) and is then coupled into the second optical waveguide (L2). The drop detection apparatus (11, 11a) additionally comprises a light signal generation device (70) for coupling a light beam (LS) pulsed at a carrier frequency into the first optical waveguide (L1). The drop detection apparatus (11, 11a) further comprises a light evaluation device (80) for evaluating the light beam (LS) coupled into the second optical waveguide (L2) in order to determine whether a drop (TR) has been dispensed by the metering valve (DV). A method (500) for detecting a drop (TR) is also described.

Classes IPC  ?

• G01N 21/43 - RéfringencePropriétés liées à la phase, p. ex. longueur du chemin optique en mesurant l'angle critique

Abrégé

The invention relates to a drop detection device (11, 11a, 11b) for detecting drops (TR) exiting from a nozzle of a metering valve (DV), preferably a micro-metering valve. The drop detection device (11, 11a, 11b) comprises a signal-generating unit (20), which is designed to generate a carrier signal (TS) having a defined pulse frequency. In addition, the drop detection device (11, 11a, 11b) has a modulation unit (30, 30a), which is designed to generate a modulated signal (MS) that is modulated by a physical interaction between the carrier signal (TS) and a detected drop (TR). Furthermore, the drop detection device (11, 11a, 11b) comprises an evaluation unit (50), which is designed to use the defined pulse frequency to determine, on the basis of the measurement signal (MS), whether a drop (TR) was discharged from the metering valve (DV). The invention further relates to a method (600) for detecting a drop (TR) from a metering valve (DV).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 13/00 - Appareils pour mesurer par volumes et déverser des fluides ou des matériaux solides fluents, non prévus dans les groupes précédents
• G01N 15/14 - Techniques de recherche optique, p. ex. cytométrie en flux

Produits et services

Pumps, compressors and fans; robots; current generators; machines and machine tools for treatment of materials and for manufacturing; engines, powertrains and generic parts for machines; dispensing machines; sweeping, cleaning, washing and laundering machines; parts and accessories for all the aforesaid goods included in this class; automatic dispensing machines; dosing valves; valves [parts of machines]; control valves for regulating the flow of liquids [parts of machines]; actuators for valves; nozzles [parts of machines], in particular nozzles for dosing systems; machine tools; machines for surface mount assembly of printed circuit boards; machines for the assembly of components, including containers, workpiece feeding, feed mechanisms and mounting heads; mechanical seals [parts of machines]. Flexible pipes, tubes, hoses and fittings therefor, including valves, mainly not of metal; seals; sealants and fillers; weatherstripping compositions; sealing rings; sealing strips; insulation and barrier articles and materials; non-metallic vibration dampers; adhesive tapes, strips, bands and films for industrial use; parts and accessories for all the aforesaid goods included in this class; plastics, rubber, gutta-percha, gum, asbestos, mica and goods made thereof, for sealing purposes. Advertising, marketing and promotional services; business management and administrative services; commercial trading and consumer information services; import and export services, as well as wholesaling and retailing services, including via the internet, in the fields of: chemicals, paints, fuels and motor fuel, machines, tools and goods of metal, seals, building materials, DIY articles and gardening articles, hobby requisites and craft supplies, electric goods and electronic goods, vehicles and vehicle accessories, agricultural products, horticultural products and forestry products.

Abrégé

The invention discloses a piezoelectric control circuit (11, 51, 81) having an input (12), at which a temporally variable voltage signal (UE) is provided, and an interface (13, 53, 83) for connecting at least one voltage-controlled piezoelectric actuator (Pz). A sync monitoring circuit (SK) detects the phase angle of the voltage signal and controls a converter circuit (16, 56, 86), in particular a switching matrix which is connected between the input and the interface, on the basis of the phase angle of the voltage signal in such a manner that the interface outputs a control voltage (Us) with a predetermined time curve, in particular pulses composed of sections of an AC voltage. A method for controlling a piezoelectric actuator arrangement, a piezoelectric actuator device having the piezoelectric control circuit according to the invention and a metering valve with the latter are also described.

Classes IPC  ?

• H02N 2/06 - Circuits d'entraînementDispositions pour la commande
• H03K 12/00 - Production d'impulsions par distortion ou combinaison d'ondes de forme sinusoïdale

Abrégé

The invention discloses a metering valve for metering a metering material, having a valve chamber comprising an outlet aperture, a closure element arranged in or on to the valve chamber, a valve chamber casing and an actuator assembly realized to move at least the outlet aperture, preferably the valve chamber, relative to the valve chamber casing in an ejection direction and/or a retraction direction during operation such that, in at least one movement mode, metering material is expelled by the closure element through the outlet aperture by a movement of the outlet aperture in the ejection direction. The invention further discloses a metering method which can be performed by means of such a metering valve.

Classes IPC  ?

• F16K 31/00 - Moyens de fonctionnementDispositifs de retour à la position de repos
• G05D 7/06 - Commande de débits caractérisée par l'utilisation de moyens électriques
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• F16K 51/00 - Autres détails non particuliers aux types de soupapes ou clapets ou autres appareils d'obturation
• F16K 17/00 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage
• F16K 11/04 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des soupapes ou des clapets
• F16K 49/00 - Moyens portés par ou sur les soupapes pour chauffer ou refroidir

Produits et services

Pumps, compressors and fans; robots; generators of electricity; machines and machine tools for the treatment of materials and for manufacturing; engines, power trains and generic machine parts; dispensing machines; sweeping, cleaning, washing and laundering machines; parts and accessories for all the aforesaid goods included in this class; automatic dispensing machines; dosing valves; valves [parts of machines]; valves for controlling fluid flows; actuators for valves; nozzles (parts of machines); nozzles for dosing systems; nozzles for dosing; machine tools; machines for surface mount assembly of printed circuit boards; machines for the assembly of components, including containers, workpiece feeding, feed mechanisms and mounting heads. Recorded content; information technology and audiovisual equipment; magnets, magnetizers and demagnetizers; apparatus, instruments and cables for electricity; optical devices, enhancers and correctors; safety, security, protection and signalling devices and equipment; measuring, detecting and monitoring instruments, indicators and controllers; programmable and electronic controllers; scientific research and laboratory apparatus, educational apparatus and simulators; parts and accessories for all the aforesaid goods included in this class; automatic dosage apparatus; dosage dispensers; electric and/or solenoid operated valves. Non-metallic flexible pipes, tubes, hoses and fittings therefor, including valves; seals, sealants and fillers; insulation and barrier articles and materials; vibration dampers; sealing compounds; adhesive tapes, strips, bands and films for industrial purposes; parts and accessories for all the aforesaid goods included in this class; flexible pipes, tubes, hoses and fittings therefor, including valves, mainly not of metal. IT services, namely development, programming services and software implementation; hardware development; scientific and technological services; engineering; testing, authentication and quality control; design services; provision, rental and leasing of objects in connection with provision of the aforesaid services; counseling and information services relating to the aforesaid services included in this class.

Abrégé

A tappet rod (10) for a valve tappet (7) of a metering valve (1) is described. The tappet rod (10) extends in a longitudinal direction, along a longitudinal axis (A). The tappet rod (10) comprises an actuator contact surface (29) and a positioning element (9) that is eccentric in relation to the longitudinal axis (A) of the tappet rod (10). A tappet tip (11) for a valve tappet (7) is also disclosed. The tappet tip (11) has an internal thread (12) at one end thereof for coupling the tappet tip (11) to an external thread (13) on a tappet rod (10). Also disclosed is a valve tappet (7), in particular for a metering valve (1). And finally described is a metering valve (1), especially for dispensing very small amounts of metered substances.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• F16K 1/36 - Corps de soupapes
• F16K 1/50 - Dispositifs empêchant la rotation des corps de soupapes
• F16K 31/00 - Moyens de fonctionnementDispositifs de retour à la position de repos

Abrégé

The present invention relates to a dosing systemwith a nozzle having an outlet opening, in the region of which a closure element is movably arranged, which is moved in an ejection and/or retracting direction during operation, wherein the closure element is thus coupled to at least two piezoelectric actuators which are connected in opposite direction such that a first piezoelectric actuator, when it is expanded in operation, moves the closure element in the retracting direction and a second piezoelectric actuator, when it is expanded in operation, moves the closure element in the ejection direction. The invention also relates to a dosing method that can be carried out using such a dosing system and to a method for producing such a dosing system.

Classes IPC  ?

• B65D 25/42 - Tuyères ou goulottes formant corps ou fixées à demeure
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 11/02 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage
• B05B 17/06 - Appareils de pulvérisation ou d'atomisation de liquides ou d'autres matériaux fluides, non couverts par les autres groupes de la présente sous-classe opérant suivant des procédés particuliers utilisant des vibrations ultrasonores
• B05B 1/02 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour produire un jet, un pulvérisat ou tout autre écoulement de forme ou de nature particulière, p. ex. sous forme de gouttes individuelles

Abrégé

6), whereby it deliberately moves the closure element (21) during operation in order to reduce the viscosity of the dosing material in at least a region of the aperture gap (57). The invention further describes a method of manufacturing such a dosing system (3), and a dosing method that can be carried out with the dosing system (3).

Classes IPC  ?

• F15D 1/08 - Action sur l'écoulement des fluides des jets sortant d'un orifice
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 11/02 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage

Abrégé

A dosing system for a liquid or viscous dosing material, including an actuator system, that has at least one actuating element and a nozzle with an outlet opening. The dosing system is designed so that during a movement in a closure direction the actuating element is initially moved in a first partial movement in such a way that the actuating element is separated from the closure element at a stop location, intended for that purpose, and then comes into contact with the closure element at the stop location and exerts an impulse on the closure element. This also relates to a corresponding dosing method.

Classes IPC  ?

• B67D 3/00 - Appareils ou dispositifs pour commander le débit du liquide à distribuer par gravité à partir des récipients de stockage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 11/02 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage
• H05K 3/12 - Appareils ou procédés pour la fabrication de circuits imprimés dans lesquels le matériau conducteur est appliqué au support isolant de manière à former le parcours conducteur recherché utilisant la technique de l'impression pour appliquer le matériau conducteur

Abrégé

The present invention relates to a metering valve (1) for metering material to be metered, comprising: a valve chamber (33) having an outlet opening (21); a closure element (3) arranged in or on the valve chamber (33); a valve chamber bearing (23); and an actuator device (7), in order to move at least the outlet opening (21), preferably the valve chamber (33), in relation to the valve chamber bearing (23) in an ejection direction (E) and/or a retraction direction (R) in operation such that in operation material to be metered is pushed through the outlet opening (21) by the plunger (3) in at least one movement mode if there is a movement of the outlet opening (21) in the ejection direction (E). The invention further relates to a metering method that can be performed by means of such a metering valve (1).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• F16K 31/385 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation le fluide travaillant directement sur les deux côtés du moteur à fluide, un des côtés étant relié par un étranglement et le moteur étant actionné par la décharge effectuée de ce même côté le fluide agissant sur un diaphragme
• F16K 31/00 - Moyens de fonctionnementDispositifs de retour à la position de repos
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant

Abrégé

The present invention relates to a dosing system (3) for a shear-thinning or thixotropic, liquid to viscous dosing substance. Said dosing system comprises a nozzle (1) having a closure channel (55), within which a closure element (21) is moved in an ejection (E) and/or retracting direction (R) and is controlled during operation by an automatic control unit (63). The closure channel (55) is configured in at least one cross section perpendicular to the ejection (E) and/or retracting direction (R) in relation to the cross section of the closure element (21) in the same cutting plane such that a passage gap (57) is formed between the outer surface (S1) of the closure element (21) and the inner surface (S2) of the closure channel (55), said closure gap being formed and/or dimensioned such that it forms at least in some regions a passage channel for the dosing substance. Furthermore, the control unit (63) is designed such that, during operation, it generates control signals (SS1, SS2) for different movements of the closing element (21) in at least two movement modes (M1, M2, M4, M5, M6), wherein it moves in at least one of the movement modes (Μ1, M2, M4, M5, M6) the closure element (21) in such a way that the viscosity of the dosing substance is reduced in at least one region of the passage gap (57). The invention also relates to a method for producing such a dosing system (3) and to a dosing method that can be carried out using said dosing system (3).

Classes IPC  ?

• B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 11/00 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume

Abrégé

The present invention relates to a dosing system (3) with a nozzle (1) having an outlet opening (19), in the region of which a closure element (21) is movably arranged, which, during operation, is moved in an ejection (E) and/or retracting direction (R), wherein the closure element (21) is thus coupled to at least two piezoelectric actuators (23a, 23b) which are connected in opposite direction such that a first piezoelectric actuator (23a), when it is expanded in operation, moves the closure element (21) in the retracting direction (R) and a second piezoelectric actuator (23b), when it is expanded in operation, moves the closure element (21) in the ejection direction (E). The invention also relates to a dosing method that can be carried out using such a dosing system (3) and to a method for producing such a dosing system (3).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• G01F 11/36 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec des chambres de mesure fixes ayant un volume constant au cours du mesurage avec des soupapes d'admission ou de décharge du type à tiroir se déplaçant d'une manière rectiligne

Abrégé

The invention relates to a dosing system (1', 1'') for a liquid to viscous dosing material comprising an actuator system (2), which comprises at least one actuating element (29, 57), and a nozzle (13) having an outlet opening (19). According to the invention, the actuating element (29, 57) is first moved in a first partial movement upon a movement in a closure direction (V) so that it is separated from the closure element (15) at a proper stop location (31) and then meets the closure element on the stop location (31) and exerts an impulse (I) on the closure element (15). The invention also relates to a correspondingly designed dosing method.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
