A method comprises producing or receiving information regarding content to be displayed on an array of pixels as a function of time, wherein the information includes a specified light output for each pixel in the array as a function of time, determining an expected change in light output intensity for each of one or more of the pixels as a function of time, wherein the expected change in light output intensity for each of the one or more of the pixels is dependent, at least in part, on the specified light output for at least a portion of the pixels in the array, and modifying an output of each of the one or more of the pixels as a function of time to compensate for at least a portion of the expected change in the light output intensity.
G09G 3/32 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels semiconductive, e.g. using light-emitting diodes [LED]
An electronic display comprises an array of pixels each comprising first, second, and third primary light-emitting elements that emit primary colors at first, second, and third physical primary color points on a chromaticity diagram, and one or more derivative light-emitting elements that each emit a derivative color at a derivative color point on the chromaticity diagram. The physical primary color points and each derivative color point are located on a boundary of a virtual color space that includes first, second, and third apexes at first, second, and third virtual primary color points on the chromaticity diagram. At least one of the first, second, and third virtual primary color points is different from the first, second, and third physical primary color points, respectively. A color gamut for the pixels is greater than a corresponding gamut for corresponding pixels that are configured to only emit the primary colors.
G09G 3/32 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels semiconductive, e.g. using light-emitting diodes [LED]
An electronic display comprises an array of pixels each comprising first, second, and third primary light-emitting elements that emit primary colors at first, second, and third physical primary color points on a chromaticity diagram, and one or more derivative light-emitting elements that each emit a derivative color at a derivative color point on the chromaticity diagram. The physical primary color points and each derivative color point are located on a boundary of a virtual color space that includes first, second, and third apexes at first, second, and third virtual primary color points on the chromaticity diagram. At least one of the first, second, and third virtual primary color points is different from the first, second, and third physical primary color points, respectively. A color gamut for the pixels is greater than a corresponding gamut for corresponding pixels that are configured to only emit the primary colors.
H01L 25/075 - Assemblies consisting of a plurality of individual semiconductor or other solid-state devices all the devices being of a type provided for in a single subclass of subclasses , , , , or , e.g. assemblies of rectifier diodes the devices not having separate containers the devices being of a type provided for in group
A display module comprises light-emitting elements coupled to one or more mounting structures and grouped Into a pixels in a pixel array on a display face to display textual, graphical, or video Information, with each pixel comprising a grouping of one or more light-emitting elements. A face cover Is mounted to the mounting structure and is positioned in front of at least a portion of the display face. The face cover comprises a plurality of moguls arranged in a mogul array with each mogul positioned in front of and proximate to a corresponding one of the pixels so that the mogul covers at least a portion of the corresponding pixel, and one or more light-emitting openings in each mogul, each positioned relative to one or more corresponding light-emitting element of the pixel to permit light emitted from the corresponding one or more light-emitting elements to pass through the mogul.
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G06F 3/147 - Digital output to display device using display panels
42 - Scientific, technological and industrial services, research and design
Goods & Services
Software as a service services; software as a service services, namely, providing a platform for content design; software as a service services, namely, providing a platform for content design for electronic signs and displays.
7.
ADJUSTABLE MOUNTING FRAME FOR AN ELECTRONIC DISPLAY
A support system for an electronic display comprises one or more support frames configured to be mounted to a planar or substantially planar building structure, wherein each support frame comprises a mounting face configured for mounting one or more display modules to the one or more support frames to form a display surface, and at least one adjustment mechanism corresponding to each of the one or more support frames for adjusting a position or an alignment, or both, of the support frame relative to the planar or substantially planar building structure.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 19/22 - Advertising or display means on roads, walls or similar surfaces, e.g. illuminated
8.
ADJUSTABLE MOUNTING FRAME FOR AN ELECTRONIC DISPLAY
A support system for an electronic display comprises one or more support frames configured to be mounted to a planar or substantially planar building structure, wherein each support frame comprises a mounting face configured for mounting one or more display modules to the one or more support frames to form a display surface, and at least one adjustment mechanism corresponding to each of the one or more support frames for adjusting a position or an alignment, or both, of the support frame relative to the planar or substantially planar building structure.
A display module comprises a circuit board, a plurality of light-emitting elements coupled to a front surface of the circuit board and arranged in an array configured to produce at least a portion of a display image at the front surface of the circuit board, and a contrast mask directly coupled to the front surface of the circuit board, the contrast mask defining a plurality of windows, with each window surrounding a group of one or more of the plurality of light-emitting elements.
H01L 25/075 - Assemblies consisting of a plurality of individual semiconductor or other solid-state devices all the devices being of a type provided for in a single subclass of subclasses , , , , or , e.g. assemblies of rectifier diodes the devices not having separate containers the devices being of a type provided for in group
H01L 33/48 - SEMICONDUCTOR DEVICES NOT COVERED BY CLASS - Details thereof characterised by the semiconductor body packages
H01L 33/62 - Arrangements for conducting electric current to or from the semiconductor body, e.g. leadframe, wire-bond or solder balls
A display module comprises light-emitting elements coupled to one or more mounting structures and grouped into a pixels in a pixel array on a display face to display textual, graphical, or video information, with each pixel comprising a grouping of one or more light-emitting elements. A face cover is mounted to the mounting structure and is positioned in front of at least a portion of the display face. The face cover comprises a plurality of moguls arranged in a mogul array with each mogul positioned in front of and proximate to a corresponding one of the pixels so that the mogul covers at least a portion of the corresponding pixel, and one or more light-emitting openings in each mogul, each positioned relative to one or more corresponding light-emitting element of the pixel to permit light emitted from the corresponding one or more light-emitting elements to pass through the mogul.
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G06F 3/147 - Digital output to display device using display panels
12.
Portion of a display screen with a graphical user interface
An electronic display comprises a support system comprising a plurality of support chassis, each support chassis comprising a plurality of chassis components each formed from one or more pieces of sheet metal, wherein the plurality of chassis components are welded together with a plurality of laser weld joints to form the support chassis having a front wall with a planar or substantially planar front mounting face, and a plurality of planar or substantially planar side walls, wherein the planar or substantially planar mounting faces of the plurality of support chassis are aligned to collectively form a front mounting surface, and a plurality of display modules mounted to the front mounting face, wherein each display module comprises an array of light-emitting element pixels, wherein the plurality of display modules collectively form a display surface.
An electronic display (170) comprises a support system (130) comprising a plurality of support chassis, each support chassis comprising a plurality of chassis components (50A, 50B, 50C, 50D) each formed from one or more pieces of sheet metal, wherein the plurality of chassis components are welded together with a plurality of laser weld joints to form the support chassis having a front wall with a planar or substantially planar front mounting face, and a plurality of planar or substantially planar side walls, wherein the planar or substantially planar mounting faces of the plurality of support chassis are aligned to collectively form a front mounting surface, and a plurality of display modules (134) mounted to the front mounting face, wherein each display module comprises an array of light-emitting element pixels, wherein the plurality of display modules collectively form a display surface.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
15.
COMPENSATION FOR THERMALLY-INDUCED DISPLAY LIGHT OUTPUT VARIATION
A method comprises producing or receiving information regarding content to be displayed on an array of pixels as a function of time, wherein the information includes a specified light output for each pixel in the array as a function of time, determining an expected change in light output intensity for each of one or more of the pixels as a function of time, wherein the expected change in light output intensity for each of the one or more of the pixels is dependent, at least in part, on the specified light output for at least a portion of the pixels in the array, and modifying an output of each of the one or more of the pixels as a function of time to compensate for at least a portion of the expected change in the light output intensity.
G09G 3/20 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix
16.
Dynamic compensation for thermally induced light output variation in electronic displays
A method comprises producing or receiving information regarding content to be displayed on an array of pixels as a function of time, wherein the information includes a specified light output for each pixel in the array as a function of time, determining an expected change in light output intensity for each of one or more of the pixels as a function of time, wherein the expected change in light output intensity for each of the one or more of the pixels is dependent, at least in part, on the specified light output for at least a portion of the pixels in the array, and modifying an output of each of the one or more of the pixels as a function of time to compensate for at least a portion of the expected change in the light output intensity.
G09G 3/32 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels semiconductive, e.g. using light-emitting diodes [LED]
A display comprises a display surface formed from a plurality of display modules arranged in proximity, each display module comprising a plurality of light-emitting elements configured to collectively display one or more of video, graphical, or textual information, and a support array onto which the plurality of display modules is mounted to form the display surface. The support array comprises a plurality of tension members, a plurality of support members arranged in an array, each of the plurality of support members comprising a mounting face and each being supported by at least one of the plurality of tension members. Each of the tension members is suspended either from a support structure or another one of the support members, and each of the display modules is coupled to the mounting face of one or more of the support members.
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
A display system comprises a display of one or more display surfaces, each formed from a plurality of display modules arranged in proximity. Each display module comprising light-emitting elements configured to collectively display information. The display system also comprises one or more tension members and one or more base supporting members connected to the one or more tension members and positioned proximate to one or more of the display modules located at a vertical base of the display. The one or more base supporting members are coupled to the display modules located at the vertical base such that the one or more base supporting members provide underlying support to the plurality of display modules. The one or more tension members and the one or more base supporting members support the weight of the display when the one or more tension members are connected to a support structure.
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
A display module (102) comprises light-emitting elements (106) coupled to one or more mounting structures and grouped into a pixels in a pixel array on a display face to display textual, graphical, or video information, with each pixel comprising a grouping of one or more light-emitting elements. A face cover (100) is mounted to the mounting structure and is positioned in front of at least a portion of the display face. The face cover comprises a plurality of moguls (110) arranged in a mogul array with each mogul positioned in front of and proximate to a corresponding one of the pixels so that the mogul covers at least a portion of the corresponding pixel, and one or more light-emitting openings (112) in each mogul, each positioned relative to one or more corresponding light-emitting element of the pixel to permit light emitted from the corresponding one or more light-emitting elements to pass through the mogul.
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G06F 3/147 - Digital output to display device using display panels
09 - Scientific and electric apparatus and instruments
37 - Construction and mining; installation and repair services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Electronic displays; electronic advertising displays; LED displays; OLED displays; display screens; electronic display panels; electronic display boards; visual display screens; video display units; display apparatus; electronic signs; LED signs; electronic score display apparatus; electronic billboards; LCD large-screen displays; advertising display apparatus; advertising display signs; software; display control software; software for statistical information; software for sports statistical and scoring information; traffic management system; software for traffic management systems; parts and fittings for all the aforesaid goods. Installation of display and signage apparatus; maintenance of display and signage apparatus; repair of display and signage apparatus; installation, repair and maintenance of traffic management systems. Training services; technical training services; production of sound and/or image recordings on sound and/or image carriers; image production services; visual production services; animation production services; library services; image library services; media library services; event production services; event management services. Software consultancy; software installation and maintenance services; monitoring services for the operation of electronic display apparatus and systems; design services; animation design for others; animation and special effects design for others; providing technical support for display systems and software at events.
09 - Scientific and electric apparatus and instruments
37 - Construction and mining; installation and repair services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Electronic displays; electronic advertising displays; LED displays; OLED displays; display screens; electronic display panels; electronic display boards; visual display screens; video display units; display apparatus; electronic signs; LED signs; electronic score display apparatus; electronic billboards; LCD large-screen displays; advertising display apparatus; advertising display signs; software; display control software; software for statistical information; software for sports statistical and scoring information; traffic management system; software for traffic management systems; parts and fittings for all the aforesaid goods. Installation of display and signage apparatus; maintenance of display and signage apparatus; repair of display and signage apparatus; installation, repair and maintenance of traffic management systems. Training services; technical training services; production of sound and/or image recordings on sound and/or image carriers; image production services; visual production services; animation production services; library services; image library services; media library services; event production services; event management services. Software consultancy; software installation and maintenance services; monitoring services for the operation of electronic display apparatus and systems; design services; animation design for others; animation and special effects design for others; providing technical support for display systems and software at events.
09 - Scientific and electric apparatus and instruments
42 - Scientific, technological and industrial services, research and design
Goods & Services
Electronic displays; electronic advertising displays; LED displays; OLED displays; display screens; electronic display panels; electronic display boards; visual display screens; video display units; display apparatus; electronic signs; LED signs; electronic score display apparatus; electronic billboards; LCD large-screen displays; advertising display apparatus; advertising display signs; software; display control software; software for statistical information; software for sports statistical and scoring information; traffic management system; software for traffic management systems; parts and fittings for all the aforesaid goods. Software consultancy; software installation and maintenance services; monitoring services for the operation of electronic display apparatus and systems; design services; animation design for others; animation and special effects design for others; providing technical support for display systems and software at events.
A display module comprises a circuit board, a plurality of light-emitting elements coupled to a front surface of the circuit board and arranged in an array configured to produce at least a portion of a display image at the front surface of the circuit board, and a contrast mask directly coupled to the front surface of the circuit board, the contrast mask defining a plurality of windows, with each window surrounding a group of one or more of the plurality of light-emitting elements.
H01L 25/075 - Assemblies consisting of a plurality of individual semiconductor or other solid-state devices all the devices being of a type provided for in a single subclass of subclasses , , , , or , e.g. assemblies of rectifier diodes the devices not having separate containers the devices being of a type provided for in group
A display system comprises a plurality of displays each comprising an array of light-emitting elements to display a corresponding message, a primary controller that controls the array of light-emitting elements of each display to control the content of each message, a communication network to transmit control signals from the primary controller to the displays, a remote manager in communication with the primary controller via a primary manager communication link, and a redundant controller configured and able to control the array of light-emitting elements of each display to control the content of each message if it is determined that there is a malfunction of the primary controller, an interruption in the communication network between the primary controller and at least one of the displays, or an interruption in the primary communication link.
G09G 3/32 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels semiconductive, e.g. using light-emitting diodes [LED]
26.
Power supply redundancy device for a display system
A system comprises a redundancy circuit board including a plurality of primary input connectors each connectible to a primary power supply that supplies primary electrical energy, a redundancy power input connector connectible to a redundant power supply that supplies redundant electrical energy, a plurality of output connectors connectible to a display component powerable by the primary or redundant electrical energy, and a plurality of electrical pathways including primary pathways each connecting a primary input connector to a corresponding output connector, redundant pathways each connecting the redundancy input connector to a corresponding output connector. The system also includes one or more electrical devices that detect whether primary electrical energy has been interrupted along a first primary pathway, activate the redundant power supply to supply redundant electrical energy to the redundancy input connector, and direct redundant electrical energy along a first redundant pathway to the first output connector.
H02J 9/06 - Circuit arrangements for emergency or stand-by power supply, e.g. for emergency lighting in which the distribution system is disconnected from the normal source and connected to a standby source with automatic change-over
G09G 3/32 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels semiconductive, e.g. using light-emitting diodes [LED]
27.
MAGNETICALLY-ACTUATED LATCH MECHANISM FOR DISPLAY MODULE
A display module comprises a support, a plurality of light-emitting elements coupled to the support and a latch mechanism (150) to removeably couple the support to a chassis (154). The latch mechanism includes a movable member (156), a latch member (168), and a linkage mechanism (166). The movable member is moved from a first position to a second position when magnetically engaged by a tool magnet. The latch member moves between a first latch member position and a second latch member position and can engage a chassis mating structure when in the first latch member position. The linkage mechanism mechanically connects the movable member to the latch member so that they move together such that the latch member is in the first latch member position when the movable member is in the first position and is in the second latch member position when the movable member is in the second position.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
28.
Magnetically-actuated latch mechanism for display module
A display module comprises a support, a plurality of light-emitting elements coupled to the support and a latch mechanism to removeably couple the support to a chassis. The latch mechanism includes a movable member, a latch member, and a linkage mechanism. The movable member is moved from a first position to a second position when magnetically engaged by a tool magnet. The latch member moves between a first latch member position and a second latch member position and can engage a chassis mating structure when in the first latch member position. The linkage mechanism mechanically connects the movable member to the latch member so that they move together such that the latch member is in the first latch member position when the movable member is in the first position and is in the second latch member position when the movable member is in the second position.
F16M 11/04 - Means for attachment of apparatusMeans allowing adjustment of the apparatus relatively to the stand
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
F16B 1/00 - Devices for securing together, or preventing relative movement between, constructional elements or machine parts
A display system (10) comprises a display (12) of one or more display surfaces (24), each formed from a plurality of display modules (14) arranged in proximity. Each display module comprising light-emitting elements configured to collectively display information. The display system also comprises one or more tension members (30) and one or more base supporting members (32) connected to the one or more tension members and positioned proximate to one or more of the display modules located at a vertical base of the display. The one or more base supporting members are coupled to the display modules located at the vertical base such that the one or more base supporting members provide underlying support to the plurality of display modules. The one or more tension members and the one or more base supporting members support the weight of the display when the one or more tension members are connected to a support structure.
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
A display comprises a mounting structure comprising one or more structural members (122) having a first face (136) and a second face (138), a first plurality of display modules (112) mounted to the first faces of the one or more structural members with a plurality of magnetic mounts (19A, 110B), wherein the first plurality of display modules are arranged in proximity to form a first display surface, and one or more tension members coupled to the mounting structure, wherein the one or more tension members support the display when the one or more tension members are connected to a support structure.
H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 15/00 - Boards, hoardings, pillars, or like structures for notices, placards, posters, or the like
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
A display module comprises a support structure, a plurality of light-emitting elements mounted to the support structure, and a latch assembly that includes a latch plate comprising a magnetically-engageable material, wherein the latch plate is movable relative to the module support structure within a range of motion between a first position and a second position. The magnetically-engageable material of the latch plate forms a first magnetic attraction force between the latch plate and a support chassis mating structure when the latch plate is in the first position to at least partially secure the display module to the support chassis. A corresponding magnetic device can generate a second magnetic attraction force between the corresponding magnetic device and the latch plate that overcomes the first magnetic attraction force and moves the latch plate from the first position to the second position.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
A display module comprises a support structure, a plurality of light-emitting elements mounted to the support structure, and a latch assembly that includes a latch plate comprising a magnetically-engageable material, wherein the latch plate is moveable relative to the module support structure within a range of motion between a first position and a second position. The magnetically-engageable material of the latch plate forms a first magnetic attraction force between the latch plate and a support chassis mating structure when the latch plate is in the first position to at least partially secure the display module to the support chassis. A corresponding magnetic device can generate a second magnetic attraction force between the corresponding magnetic device and the latch plate that overcomes the first magnetic attraction force and moves the latch plate from the first position to the second position.
H05K 7/02 - Arrangements of circuit components or wiring on supporting structure
H05K 7/04 - Arrangements of circuit components or wiring on supporting structure on conductive chassis
H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
An electronic sign having slotted frame cabinets whereby each slotted frame cabinet can conveniently be attached to one or more vertically or horizontally positioned adjacent slotted frame cabinets by using connecting components which are generally located around the periphery of one or more slotted frame cabinets. Connecting components, including splice bars, splice plates, and mounting clamps, are aligned in, positioned along and secured to backing bars which are co-located in backing bar slots in one or more of the slotted frame cabinets. Lift eyes can be variably located in one or more lift eye slots. The use of externally located connecting components, which do not extend through the cabinetry, minimize the entry of environmental elements into the interior of the electronic sign. Multiple slotted frame cabinets can be connected without the removal of LED display panels.
H04N 5/64 - Constructional details of receivers, e.g. cabinets or dust covers
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
F16B 2/12 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action using sliding jaws
H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
The present disclosure provides a display module. The module includes a module support structure, a plurality of light-emitting elements coupled to the module support structure, and one or more latch assemblies configured to removeably couple the module support structure to a support chassis. Each of the one or more latch assemblies includes a first magnet movably coupled with the module support structure at a first location. The assemblies further include a second magnet movably coupled with the module support structure at a second location. The second magnet is movable relative to the module support structure between a first corresponding position and a second corresponding position. The assemblies further include a shaft connecting the first magnet and the second magnet so that the first magnet and the second magnet move together.
G06F 9/302 - Controlling the executing of arithmetic operations
F16B 1/00 - Devices for securing together, or preventing relative movement between, constructional elements or machine parts
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
According to various examples, a display assembly includes a support chassis. The display assembly further includes a display module. The display module includes a front major face, a plurality of light-emitting elements mounted to the front major face, and a rear major face generally opposing the front major face. The rear major face is mounted to the support chassis. The display assembly further includes a first biasing subassembly positioned generally at or proximate to a first biasing location along the front major face, the biasing subassembly. The first biasing subassembly includes a first biasing magnet located within a first cavity in the display module. The first biasing magnet is movable within the cavity between a first position and a second position relative to the display module. The first biasing subassembly further includes a first biasing member extending generally between the front major face and the rear major face.
H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
H05K 1/18 - Printed circuits structurally associated with non-printed electric components
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
The present disclosure provides a display module (12). The module includes a module support structure, a plurality of light-emitting elements coupled to the module support structure, and one or more latch assemblies (40) configured to removeably couple the module support structure to a support chassis (14). Each of the one or more latch assemblies includes a first magnet (42) movably coupled with the module support structure at a first location. The assemblies further include a second magnet (46) movably coupled with the module support structure at a second location. The second magnet is movable relative to the module support structure between a first corresponding position and a second corresponding position. The assemblies further include a shaft (51) connecting the first magnet and the second magnet so that the first magnet and the second magnet move together.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
A display assembly includes a display module and a support chassis (14). The display module includes a front major face (28), a plurality of light-emitting elements mounted to the front major face, and a rear major face generally opposing the front major face. The rear major face is mounted to the support chassis (14). The display assembly further includes a first biasing subassembly positioned generally at or proximate to a first biasing location along the front major face, the biasing subassembly. The first biasing subassembly includes a first biasing magnet (80) located within a first cavity in the display module. The first biasing magnet is movable within the cavity between a first position and a second position relative to the display module. The first biasing subassembly further includes a first biasing member (70) extending generally between the front major face and the rear major face.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
38.
Encapsulation of light-emitting elements on a display module
A display module comprises a circuit board having a front face, a plurality of light-emitting elements electrically coupled to the front face of the circuit board, a polymer encapsulating member adhered to the front face of the circuit board, the polymer encapsulating member substantially covering at least a portion of the circuit board and a portion of the plurality of light-emitting elements, the polymer encapsulating member substantially sealing the portion of the circuit board and the portion of the plurality of light-emitting elements, and an ultraviolet-radiation diminishing component in the polymer encapsulating member or on one or more of at least a portion of the circuit board or at least a portion of each of the light-emitting elements, wherein the ultraviolet-radiation diminishing component filters, blocks, or reflects more ultraviolet radiation than would be filtered, blocked, or reflected by the polymer encapsulating member without the ultraviolet-radiation diminishing component.
H01L 33/56 - Materials, e.g. epoxy or silicone resin
H01L 33/62 - Arrangements for conducting electric current to or from the semiconductor body, e.g. leadframe, wire-bond or solder balls
H01L 27/15 - Devices consisting of a plurality of semiconductor or other solid-state components formed in or on a common substrate including semiconductor components with at least one potential-jump barrier or surface barrier, specially adapted for light emission
G09F 27/00 - Combined visual and audible advertising or displaying, e.g. for public address
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
A display module (102) comprises light-emitting elements (106) coupled to one or more mounting structures and grouped into a pixels in a pixel array on a display face to display textual, graphical, or video information, with each pixel comprising a grouping of one or more light-emitting elements. A face cover (100) is mounted to the mounting structure and is positioned in front of at least a portion of the display face. The face cover comprises a plurality of moguls (110) arranged in a mogul array with each mogul positioned in front of and proximate to a corresponding one of the pixels so that the mogul covers at least a portion of the corresponding pixel, and one or more light-emitting openings (112) in each mogul, each positioned relative to one or more corresponding light-emitting element of the pixel to permit light emitted from the corresponding one or more light-emitting elements to pass through the mogul.
G09F 27/00 - Combined visual and audible advertising or displaying, e.g. for public address
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G09F 9/35 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being liquid crystals
G09F 13/22 - Illuminated signsLuminous advertising with luminescent surfaces or parts electroluminescent
A display system comprises a plurality of displays each comprising an array of light-emitting elements to display a corresponding message, a primary controller that controls the array of light-emitting elements of each display to control the content of each message, a communication network to transmit control signals from the primary controller to the displays, a remote manager in communication with the primary controller via a primary manager communication link, and a redundant controller configured and able to control the array of light-emitting elements of each display to control the content of each message if it is determined that there is a malfunction of the primary controller, an interruption in the communication network between the primary controller and at least one of the displays, or an interruption in the primary communication link.
A system comprises a redundancy circuit board including a plurality of primary input connectors each connectible to a primary power supply that supplies primary electrical energy, a redundancy power input connector connectible to a redundant power supply that supplies redundant electrical energy, a plurality of output connectors connectible to a display component powerable by the primary or redundant electrical energy, and a plurality of electrical pathways including primary pathways each connecting a primary input connector to a corresponding output connector, redundant pathways each connecting the redundancy input connector to a corresponding output connector. The system also includes one or more electrical devices that detect whether primary electrical energy has been interrupted along a first primary pathway, activate the redundant power supply to supply redundant electrical energy to the redundancy input connector, and direct redundant electrical energy along a first redundant pathway to the first output connector.
G09G 3/32 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels semiconductive, e.g. using light-emitting diodes [LED]
H02J 9/06 - Circuit arrangements for emergency or stand-by power supply, e.g. for emergency lighting in which the distribution system is disconnected from the normal source and connected to a standby source with automatic change-over
A display comprises a mounting structure comprising one or more structural members (122) having a first face (136) and a second face (138), a first plurality of display modules (112) mounted to the first faces of the one or more structural members with a plurality of magnetic mounts (119A, 110B), wherein the first plurality of display modules are arranged in proximity to form a first display surface, and one or more tension members coupled to the mounting structure, wherein the one or more tension members support the display when the one or more tension members are connected to a support structure.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 15/00 - Boards, hoardings, pillars, or like structures for notices, placards, posters, or the like
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G09F 9/35 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being liquid crystals
G09F 19/22 - Advertising or display means on roads, walls or similar surfaces, e.g. illuminated
A display system (10) comprises a display (12) of one or more display surfaces (24), each formed from a plurality of display modules (14) arranged in proximity. Each display module comprising light-emitting elements configured to collectively display information. The display system also comprises one or more tension members (30) and one or more base supporting members (32) connected to the one or more tension members and positioned proximate to one or more of the display modules located at a vertical base of the display. The one or more base supporting members are coupled to the display modules located at the vertical base such that the one or more base supporting members provide underlying support to the plurality of display modules. The one or more tension members and the one or more base supporting members support the weight of the display when the one or more tension members are connected to a support structure.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
A display (10) comprises a mounting structure (20) comprising one or more composite members (22) having a first face and a second face, a first plurality of display modules (12) mounted to the first face of the one or more composite members and arranged in proximity to form a first display surface, and one or more tension members (24) coupled to the mounting structure, wherein the one or more tension members support the display when the one or more tension members are connected to a support structure.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 15/00 - Boards, hoardings, pillars, or like structures for notices, placards, posters, or the like
G09F 19/22 - Advertising or display means on roads, walls or similar surfaces, e.g. illuminated
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G09F 9/35 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being liquid crystals
An electronic sign having slotted frame cabinets, whereby each slotted frame cabinet can conveniently be attached to one or more vertically or horizontally positioned adjacent slotted frame cabinets by using connecting components which are generally located around the periphery of one or more slotted frame cabinets. Connecting components including splice bars, splice plates, and mounting clamps are aligned in, positioned along, and secured to backing bars which are co-located in backing bar slots in one or more of the slotted frame cabinets. Lift eyes can be variably located in one or more lift eye slots. The use of externally located connecting components, which do not extend through the cabinetry, minimize the entry of environmental elements into the interior of the electronic sign. Multiple slotted frame cabinets can be connected without the removal of LED display panels. Bracket assemblies and clamping assemblies are provided.
A47B 96/00 - Details of cabinets, racks or shelf units not covered by a single one of groups General details of furniture
A47B 57/54 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of detachable shelf supports consisting of clamping means, e.g. with sliding bolts or sliding wedges
F16M 13/02 - Other supports for positioning apparatus or articlesMeans for steadying hand-held apparatus or articles for supporting on, or attaching to, an object, e.g. tree, gate, window-frame, cycle
F16B 2/12 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action using sliding jaws
F16B 2/02 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening
H05K 7/14 - Mounting supporting structure in casing or on frame or rack
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
F16B 2/06 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action
A47B 57/58 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting partitions horizontally
A display module comprises a circuit board including a plurality of light-emitting elements, a frame having a first face coupled with the circuit board and a second face, one or more first securing structures coupled to the second face, and one or more mounting hooks with a first hook portion coupled to and extending generally rearward from the second face and a second hook portion extending generally downward from the first hook portion. The first securing structures are actuable between an engaged configuration wherein the first securing structures mount or secure the display module to a support structure to at least partially support a display module weight, and a disengaged configuration wherein the display module is not secured to the support structure by the first securing structures, and wherein the mounting hooks at least partially support the display module weight when the first securing structures are in the disengaged configuration.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
H05K 1/18 - Printed circuits structurally associated with non-printed electric components
H05K 7/14 - Mounting supporting structure in casing or on frame or rack
Display module mounting configurations and methods are disclosed. A frame for a video display module can comprise a first face configured for coupling with a light-emitting element circuit board and a second face configured for mounting to a support chassis and one or more first securing structures coupled to the second face, the one or more first securing structures being configured to mount or secure the frame to the support chassis. The frame can also include one or more security latches each comprising a latch body movable between a latched position and an unlatched position, each latch body configured to engage a first feature of the support chassis to prevent removal of the video display module when in the latched position.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
H05K 1/18 - Printed circuits structurally associated with non-printed electric components
H05K 7/14 - Mounting supporting structure in casing or on frame or rack
An audio and display system comprising a housing having an interior region, at least one audio speaker positioned within the interior region, and a display coupled to the housing. The display includes a frame coupled to the housing, the frame having a plurality of mounting members, wherein at least two adjacent mounting members of the plurality of mounting members are spaced apart by a first distance, a plurality of support members coupled to the mounting members of the frame, wherein at least two adjacent support members of the plurality of support members are spaced apart by a second distance, and a plurality of light-emitting elements coupled to each of the plurality of support members, wherein the display module is substantially acoustically transparent.
H04R 1/26 - Spatial arrangement of separate transducers responsive to two or more frequency ranges
G09F 27/00 - Combined visual and audible advertising or displaying, e.g. for public address
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
An electronic sign having slotted frame cabinets whereby each slotted frame cabinet can conveniently be attached to one or more vertically or horizontally positioned adjacent slotted frame cabinets by using connecting components which are generally located around the periphery of one or more slotted frame cabinets. Connecting components, including splice bars, splice plates, and mounting clamps, are aligned in, positioned along and secured to backing bars which are co-located in backing bar slots in one or more of the slatted frame cabinets. Lift eyes can be variably located in one or more lift eye slots. The use of externally located connecting components, which do not extend through the cabinetry, minimize the entry of environmental elements into the interior of the electronic sign. Multiple slotted frame cabinets can be connected without the removal of LED display panels.
H05K 5/00 - Casings, cabinets or drawers for electric apparatus
F16B 2/12 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action using sliding jaws
H04N 5/64 - Constructional details of receivers, e.g. cabinets or dust covers
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
An electronic sign having slotted frame cabinets, whereby each slotted frame cabinet can conveniently be attached to one or more vertically or horizontally positioned adjacent slotted frame cabinets by using connecting components which are generally located around the periphery of one or more slotted frame cabinets. Connecting components including splice bars, splice plates, and mounting clamps are aligned in, positioned along, and secured to backing bars which are co-located in backing bar slots in one or more of the slotted frame cabinets. Lift eyes can be variably located in one or more lift eye slots. The use of externally located connecting components, which do not extend through the cabinetry, minimize the entry of environmental elements into the interior of the electronic sign. Multiple slotted frame cabinets can be connected without the removal of LED display panels. Bracket assemblies and clamping assemblies are provided.
A47B 96/00 - Details of cabinets, racks or shelf units not covered by a single one of groups General details of furniture
F16L 3/00 - Supports for pipes, cables or protective tubing, e.g. hangers, holders, clamps, cleats, clips, brackets
G09F 7/00 - Signs, name or number plates, letters, numerals, or symbolsPanels or boards
F16M 13/02 - Other supports for positioning apparatus or articlesMeans for steadying hand-held apparatus or articles for supporting on, or attaching to, an object, e.g. tree, gate, window-frame, cycle
F16B 2/12 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action using sliding jaws
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
F16B 2/06 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action
F16B 2/02 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening
A47B 57/54 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of detachable shelf supports consisting of clamping means, e.g. with sliding bolts or sliding wedges
A47B 57/58 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting partitions horizontally
51.
Apparatus, method and process of influencing information gathered by a tethered item and computer-readable medium thereof
A tethered item is associated with an identifier that uniquely identifies the item, and one or more content processing devices execute obtaining an identifier of the item, and correlating the obtained item identifier with information related to the tethered item.
G06F 3/00 - Input arrangements for transferring data to be processed into a form capable of being handled by the computerOutput arrangements for transferring data from processing unit to output unit, e.g. interface arrangements
G06Q 30/02 - MarketingPrice estimation or determinationFundraising
A display module comprises a circuit board having a front face, a plurality of light-emitting elements electrically coupled to the front face of the circuit board, a polymer encapsulating member adhered to the front face of the circuit board, the polymer encapsulating member substantially covering at least a portion of the circuit board and a portion of the plurality of light-emitting elements, the polymer encapsulating member substantially sealing the portion of the circuit board and the portion of the plurality of light-emitting elements, and an ultraviolet-radiation diminishing component in the polymer encapsulating member or on one or more of at least a portion of the circuit board or at least a portion of each of the light-emitting elements, wherein the ultraviolet-radiation diminishing component filters, blocks, or reflects more ultraviolet radiation than would be filtered, blocked, or reflected by the polymer encapsulating member without the ultraviolet-radiation diminishing component.
H01L 33/56 - Materials, e.g. epoxy or silicone resin
H01L 27/15 - Devices consisting of a plurality of semiconductor or other solid-state components formed in or on a common substrate including semiconductor components with at least one potential-jump barrier or surface barrier, specially adapted for light emission
H01L 33/62 - Arrangements for conducting electric current to or from the semiconductor body, e.g. leadframe, wire-bond or solder balls
G09F 27/00 - Combined visual and audible advertising or displaying, e.g. for public address
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
H04N 9/30 - Picture reproducers using solid-state colour display devices
Pixel interleaving configurations for use in high definition electronic sign displays where each and every scan line includes full red, green, and blue color representation to provide for high resolution electronic video sign displays.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G09G 3/20 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix
G09G 3/32 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels semiconductive, e.g. using light-emitting diodes [LED]
H04N 9/30 - Picture reproducers using solid-state colour display devices
54.
Encapsulation of light-emitting elements on a display module
A video display module comprises a circuit board having a front face, a plurality of light-emitting elements electrically coupled to the front face of the circuit board, and a polymer encapsulating member adhered to the front face of the circuit board, the polymer encapsulating member substantially covering at least a portion of the circuit board and a portion of the plurality of light-emitting elements, the polymer encapsulating member substantially sealing the portion of the circuit board and the portion of the plurality of light-emitting elements.
G09F 27/00 - Combined visual and audible advertising or displaying, e.g. for public address
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
F21V 19/00 - Fastening of light sources or lamp holders
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
A cabinet system having a protective shroud and an external frame with a linear track. The protective shroud provides a protected inner space shielded from moisture and airborne contaminants. The cabinet system also includes a mounting assembly having a mounting arm that can be affixed to a support structure and also having a mounting foot slidably engaged to the at least one track. The mounting foot can be fixed at positions along the linear track allowing the cabinet to be mounted at different position relative to the support structure.
A display enclosure assembly comprises a cabinet enclosing an interior space, the cabinet comprising a front wall and a rear wall, one or more display modules at least partially enclosed within the interior space, the one or more display modules configured to form an electronic display at the front wall, one or more fans mounted at the rear wall, each of the one or more fans comprising a fan intake facing rearward from the rear wall and a fan exhaust facing into the interior space, a vent extending at least partially between the front wall and the rear wall, the vent providing a first pathway for cooling air to pass from a front side of the cabinet to arear side of the cabinet, and an exhaust providing a second pathway for warmed air to exit the interior space.
An electronic sign having slotted frame cabinets, whereby each slotted frame cabinet can conveniently be attached to one or more vertically or horizontally positioned adjacent slotted frame cabinets by using connecting components which are generally located around the periphery of one or more slotted frame cabinets. Connecting components including splice bars, splice plates, and mounting clamps are aligned in, positioned along, and secured to backing bars which are co-located in backing bar slots in one or more of the slotted frame cabinets. Lift eyes can be variably located in one or more lift eye slots. The use of externally located connecting components, which do not extend through the cabinetry, minimize the entry of environmental elements into the interior of the electronic sign. Multiple slotted frame cabinets can be connected without the removal of LED display panels. Bracket assemblies and clamping assemblies are provided.
A47B 96/00 - Details of cabinets, racks or shelf units not covered by a single one of groups General details of furniture
A47B 57/54 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting the height of detachable shelf supports consisting of clamping means, e.g. with sliding bolts or sliding wedges
F16B 2/02 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening
H05K 7/14 - Mounting supporting structure in casing or on frame or rack
F16B 2/12 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action using sliding jaws
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
A47B 57/58 - Cabinets, racks or shelf units, characterised by features for adjusting shelves or partitions with means for adjusting partitions horizontally
A method and apparatus is provided for content influencing according to real time and/or dynamic computed profile of a user visiting the apparatus on basis of information obtained about the user by the apparatus at a geographic location.
G06F 15/173 - Interprocessor communication using an interconnection network, e.g. matrix, shuffle, pyramid, star or snowflake
G06F 17/30 - Information retrieval; Database structures therefor
H04L 9/06 - Arrangements for secret or secure communicationsNetwork security protocols the encryption apparatus using shift registers or memories for blockwise coding, e.g. D.E.S. systems
An audio and display system comprising a housing having an interior region, at least one audio speaker positioned within the interior region, and a display coupled to the housing. The display includes a frame coupled to the housing, the frame having a plurality of mounting members, wherein at least two adjacent mounting members of the plurality of mounting members are spaced apart by a first distance, a plurality of support members coupled to the mounting members of the frame, wherein at least two adjacent support members of the plurality of support members are spaced apart by a second distance, and a plurality of light-emitting elements coupled to each of the plurality of support members, wherein the display module is substantially acoustically transparent.
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G09F 27/00 - Combined visual and audible advertising or displaying, e.g. for public address
H04R 1/26 - Spatial arrangement of separate transducers responsive to two or more frequency ranges
61.
ENCAPSULATION OF LIGHT-EMITTING ELEMENTS ON A DISPLAY MODULE
A video display module (10) comprises a circuit board (16) having a front face, a plurality of light-emitting elements (14) electrically coupled to the front face of the circuit board (16), and a polymer encapsulating member adhered to the front face of the circuit board (16), the polymer encapsulating member substantially covering at least a portion of the circuit board (16) and a portion of the plurality of light-emitting elements (14), the polymer encapsulating member substantially sealing the portion of the circuit board (16) and the portion of the plurality of light-emitting elements (14).
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 27/00 - Combined visual and audible advertising or displaying, e.g. for public address
62.
Encapsulation of light-emitting elements on a display module
A video display module comprises a circuit board having a front face, a plurality of light-emitting elements electrically coupled to the front face of the circuit board, and a polymer encapsulating member adhered to the front face of the circuit board, the polymer encapsulating member substantially covering at least a portion of the circuit board and a portion of the plurality of light-emitting elements, the polymer encapsulating member substantially sealing the portion of the circuit board and the portion of the plurality of light-emitting elements.
H04N 9/30 - Picture reproducers using solid-state colour display devices
G09F 27/00 - Combined visual and audible advertising or displaying, e.g. for public address
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
G09F 9/33 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being semiconductor devices, e.g. diodes
Display module mounting configurations and methods are disclosed. A frame (28) for an LED module (12A) can comprise a first face configured for coupling with an LED circuit board (22), a second face configured for mounting to a support chassis (14), and one or more translating structures (44) coupled to the second face. Each translating structure (44) can be configured to engage a feature of the support chassis (14) effectuating a translation of the LED module (12A) to avoid contact or interference with an adjacently-positioned LED module (12B), mounted to the support chassis (14), during a mounting or a dismounting procedure. The LED module (12A, 12B) can also include one or more securing structures (46) coupled to the second face. An LED module (12A) can include a circuit board (22) including a plurality of LEDs (20), and the frame (28).
G09F 3/16 - Fastening or securing by means not forming part of the material of the label itself by clamps
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
Display module mounting configurations and methods are disclosed. A frame (1228) for a video display module (1212) can comprise a first face configured for coupling with a light - emitting element circuit board and a second face configured for mounting to a support chassis (1214) and one or more first securing structures coupled to the second face, the one or more first securing structures being configured to mount or secure the frame (1228) to the support chassis (1214). The frame (1228) can also include one or more security latches (1201) each comprising a latch body (1230) movable between a latched position and an unlatched position, each latch body (1230) configured to engage a first feature of the support chassis (1214) to prevent removal of the video display module (1212) when in the latched position.
G09F 3/16 - Fastening or securing by means not forming part of the material of the label itself by clamps
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
Display module mounting configurations and methods are disclosed. A frame for an LED module can comprise a first face configured for coupling with an LED circuit board, a second face configured for mounting to a support chassis, and one or more translating structures coupled to the second face. Each translating structure can be configured to engage a feature of the support chassis effectuating a translation of the LED module to avoid contact or interference with an adjacently-positioned LED module, mounted to the support chassis, during a mounting or a dismounting procedure. The LED module can also include one or more securing structures coupled to the second face. An LED module can include a circuit board including a plurality of LEDs, and the frame.
F21V 21/34 - Supporting elements displaceable along a guiding element
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
Display module mounting configurations and methods are disclosed. A frame for a video display module can comprise a first face configured for coupling with a light-emitting element circuit board and a second face configured for mounting to a support chassis and one or more first securing structures coupled to the second face, the one or more first securing structures being configured to mount or secure the frame to the support chassis. The frame can also include one or more security latches each comprising a latch body movable between a latched position and an unlatched position, each latch body configured to engage a first feature of the support chassis to prevent removal of the video display module when in the latched position.
F16M 1/00 - Frames or casings of engines, machines, or apparatusFrames serving as machinery beds
F16M 3/00 - Portable or wheeled frames or beds, e.g. for emergency power-supply aggregates, compressor sets
F16M 5/00 - Engine beds, i.e. means for supporting engines or machines on foundations
F16M 7/00 - Details of attaching or adjusting engine beds, frames, or supporting-legs on foundation or baseAttaching non-moving engine parts, e.g. cylinder blocks
F16M 9/00 - Special layout of foundations with respect to machinery to be supported
F16M 11/00 - Stands or trestles as supports for apparatus or articles placed thereon
F21V 21/34 - Supporting elements displaceable along a guiding element
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
09 - Scientific and electric apparatus and instruments
Goods & Services
Computer application software with a customized sport oriented user interface for laptops, rackmount PCs, tablets, and smart phones that allows an operator to insert game information into a media stream for the purpose of broadcasting sporting events
An LED panel assembly includes a circuit board having a plurality of LEDs. An LED seal louver is coupled over the circuit board. The LED seal louver includes a substrate and a pliable seal membrane. The substrate includes one or more substrate cavities. The pliable seal membrane is coupled with the substrate, and the pliable seal membrane includes a pliable material partially extending across the one or more substrate cavities. One or more LED passages extends through the pliable material adjacent to the substrate cavities. Each of the LED passages is sized and shaped to receive a single LED. Bulbs for one or more of the plurality of LEDs are correspondingly received within the LED passages, and the pliable material seals around each bulb with an interference fit. The bulbs are directly visible through the LED seal louver while the pliable seal membrane is sealed around the bulbs, and the circuit board is concealed by the LED seal louver and isolated from an environment exterior to the LED panel assembly.
A tethered item is associated with an identifier that uniquely identifies the item, and one or more content processing devices execute obtaining an identifier of the item, and correlating the obtained item identifier with information related to the tethered item.
A software application program that intelligently interfaces with a statistical data recording program, mass data storage devices and programmable electronic display devices to monitor the situational current state of a real-time event or activity such as a sporting contest and to identify, select, compile, organize, prioritize, present and recommend a plurality of relevant data items compiled from a plurality of recorded data sources to provide visual display content for selection by an operator for display on one or more electronic display boards. The intelligent interface software application program enables an operator of a programmable electronic display device instantly to review and select relevant data items corresponding to a given situational current state of a real-time event or activity and transmit selected data items for display on electronic display boards to a viewing party or public.
A63F 13/27 - Output arrangements for video game devices characterised by a large display in a public venue, e.g. in a movie theatre, stadium or game arena
G06F 3/038 - Control and interface arrangements therefor, e.g. drivers or device-embedded control circuitry
A software application program that intelligently interfaces with a statistical data recording program, mass data storage devices and programmable electronic display devices to monitor the situational current state of a real-time event or activity such as a sporting contest and to identify, select, compile, organize, prioritize, present and recommend a plurality of relevant data items compiled from a plurality of recorded data sources to provide visual display content for selection by an operator for display on one or more electronic display boards. The intelligent interface software application program enables an operator of a programmable electronic display device instantly to review and select relevant data items corresponding to a given situational current state of a real-time event or activity and transmit selected data items for display on electronic display boards to a viewing party or public.
A louver panel for an electronic sign incorporating multiple spaced primary and secondary louvers extending outwardly from a configured substantially planar panel to provide direct shading of the structure adjacent to an LED, to the structure of the louver panel including the louvers and the panel, and to provide shading for all or part of an LED. Spacings of the louvers provide for regions of shade which improve contrast and which in transition between panels camouflage horizontal seams.
G09G 3/32 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels semiconductive, e.g. using light-emitting diodes [LED]
74.
Pixel interleaving configurations for use in high definition electronic sign displays
Pixel interleaving configurations for use in high definition electronic sign displays where each and every scan line includes full red, green, and blue color representation to provide for high resolution electronic video sign displays.
A precision alignment system for the alignment of modular frames of an electronic sign including a plurality of precision alignment mechanisms which are mounted to the outer panels of the modular frames and an alignment fixture having a plurality of configurable jig towers. The configurable jig towers include moveable components which are used to precisionally align the outer contact surfaces of contact blocks in the precision alignment mechanisms for subsequent intimate contact between other like outer contact surfaces of contact blocks in the precision alignment mechanisms of horizontally and vertically adjacent modular frames.
Pixel interleaving configurations for use in high definition electronic sign displays where each and every scan line includes full red, green, and blue color representation to provide for high resolution electronic video sign displays.
G09G 3/30 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels
77.
Pixel interleaving configurations for use in high definition electronic sign displays
Pixel interleaving configurations for use in high definition electronic sign displays where each and every scan line includes full red, green, and blue color representation to provide for high resolution electronic video sign displays.
G09G 3/30 - Control arrangements or circuits, of interest only in connection with visual indicators other than cathode-ray tubes for presentation of an assembly of a number of characters, e.g. a page, by composing the assembly by combination of individual elements arranged in a matrix using controlled light sources using electroluminescent panels
78.
Electronic sign having vertically hinged face panel doors
An electronic sign having vertically hinged face panel doors which open individually about offset hinge assemblies and which aid in minimizing distorted seal compression. Individual door stop assemblies allow an operator to manageably open the face panel doors and to lock the face panel doors. In the open position, the face panel doors are protected from damage due to wind currents or gusts. The use of face panel doors having a parallelogram cross section profile allows for closely spaced face panel doors with a minimum panel-to-panel gap for uniform spacing and viewing of lighted pixel displays.
09 - Scientific and electric apparatus and instruments
Goods & Services
Electronic voting systems, namely a plurality of voting stations, at least one display unit and recording unit and one or more control units for the same; electronic scoreboards for athletic events, including a control unit for the same.
An electronic sign having slotted frame cabinets whereby each slotted frame cabinet can conveniently be attached to one or more vertically or horizontally positioned adjacent slotted frame cabinets by using connecting components which are generally located around the periphery of one or more slotted frame cabinets. Connecting components including splice bars, splice plates, and mounting clamps are aligned in, positioned along and secured to backing bars which are co-located in backing bar slots in one or more of the slotted frame cabinets. Lift eyes can be variably located in one or more lift eye slots. The use of externally located connecting components, which do not extend through the cabinetry, minimize the entry of environmental elements into the interior of the electronic sign. Multiple slotted frame cabinets can be connected without the removal of LED display panels.
An LED panel assembly includes a circuit board having a plurality of LEDs. An LED seal louver is coupled over the circuit board. The LED seal louver includes a substrate and a pliable seal membrane. The substrate includes one or more substrate cavities. The pliable seal membrane is coupled with the substrate, and the pliable seal membrane includes a pliable material partially extending across the one or more substrate cavities. One or more LED passages extends through the pliable material adjacent to the substrate cavities. Each of the LED passages is sized and shaped to receive a single LED. Bulbs for one or more of the plurality of LEDs are correspondingly received within the LED passages, and the pliable material seals around each bulb with an interference fit. The bulbs are directly visible through the LED seal louver while the pliable seal membrane is sealed around the bulbs, and the circuit board is concealed by the LED seal louver and isolated from an environment exterior to the LED panel assembly.
An electronic sign having slotted frame cabinets whereby each slotted frame cabinet can conveniently be attached to one or more vertically or horizontally positioned adjacent slotted frame cabinets by using connecting components which are generally located around the periphery of one or more slotted frame cabinets. Connecting components, including splice bars, splice plates, and mounting clamps, are aligned in, positioned along and secured to backing bars which are co-located in backing bar slots in one or more of the slotted frame cabinets. Lift eyes can be variably located in one or more lift eye slots. The use of externally located connecting components, which do not extend through the cabinetry, minimize the entry of environmental elements into the interior of the electronic sign. Multiple slotted frame cabinets can be connected without the removal of LED display panels.
G09F 9/302 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements characterised by the form or geometrical disposition of the individual elements
F16B 2/12 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action using sliding jaws
H04N 5/64 - Constructional details of receivers, e.g. cabinets or dust covers
The present invention provides a multiple seal electronic display module having displacement springs for distributed use as major components of an electronic sign. Displacement springs are provided to displace the electronic display module from the front of an electronic sign mounting panel until latching mechanisms are properly actuated in order to secure the electronic display module to the electronic sign mounting panel and thus provide a visual clue indicating proper or improper securing. A configured front edge seal provides for multiple surface sealing of multiple components consisting of, but not limited to, a louver panel, an LED circuit board, and a housing. A rear seal is also provided to seal the rear of the electronic display module to the electronic sign mounting panel. Input and output signal jack base seals and a power jack base seal provide effective seals between the housing and the signal and power jacks.
An electronic sign having a formed metal cabinet where precise and close tolerance formed planar panels and formed channels are fastened together only by rivets, nut inserts, adhesive coated tapes, or the combination thereof for rapid assembly thereof.
G09F 9/00 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements
87.
Enterprise network system for programmable electronic displays
A client-server based enterprise network system providing network services and applications to administer, manage, control access to, and use a plurality of programmable electronic display devices and systems is disclosed. The enterprise network system may include client-server network system configurations and methods to enable a plurality of enterprise users to expeditiously, efficiently and securely access and use enterprise network resources and capabilities, including provisioning of graphical display content on a plurality of programmable electronic display systems sited locally, regionally, globally or in combination thereof. The enterprise network system and the network services and capabilities here disclosed, may be accessed through Web-enabled applications with Internet/Web browsers, which enable users to access network services and capabilities from any Internet/Web-enabled computer or workstation from any location.
G06F 15/16 - Combinations of two or more digital computers each having at least an arithmetic unit, a program unit and a register, e.g. for a simultaneous processing of several programs
88.
AN ENTERPRISE NETWORK SYSTEM FOR PROGRAMMABLE ELECTRONIC DISPLAYS
Methods, apparatus and methodology are disclosed for a client-server based enterprise network system that provides network services and applications to administer, manage and control access to and use of a plurality of programmable electronic display systems. The enterprise network system of the present invention teaches application of client-server network system means and methods to create an enterprise body comprising an exclusive class of enterprise users having common purpose in performing shared work task burden to achieve shared objectives and goals. The enterprise network system here disclosed provides means novel and efficacious for a plurality of enterprise users to expeditiously, efficiently and securely access and use enterprise network resources and capabilities to manage provisioning of graphical display content on a plurality of programmable electronic display systems sited locally, regionally, globally or in combination thereof preferably through Web-enabled applications within an Internet/Web-enabled paradigm. The enterprise network system here disclosed, and the network services and capabilities therein provided, preterably are accessed by means of standard commercial Internet/Web browsers, which enable users to access network services and capabilities from any Internet/Web-enabled computer or workstation from any location.
An electronic sign having slotted frame cabinets, whereby each slotted frame cabinet can conveniently be attached to one or more vertically or horizontally positioned adjacent slotted frame cabinets by using connecting components which are generally located around the periphery of one or more slotted frame cabinets. Connecting components including splice bars, splice plates, and mounting clamps are aligned in, positioned along, and secured to backing bars which are co-located in backing bar slots in one or more of the slotted frame cabinets. Lift eyes can be variably located in one or more lift eye slots. The use of externally located connecting components, which do not extend through the cabinetry, minimize the entry of environmental elements into the interior of the electronic sign. Multiple slotted frame cabinets can be connected without the removal of LED display panels. Bracket assemblies and clamping assemblies are provided.
A dual power supply switching system for use in an electronic sign where independent suitably sized power supplies each capable of independently powering an entire plurality of LED display modules supply power on an alternating distributed basis to the plurality of LED display modules. A microcontroller having an odd or even address on each LED display module controls the connection of the respective LED display module to a particular power supply by controlling onboard solid state switches and, upon sensing an inadequate power source supply, switches to the other power supply to re-establish power to the LED display module.
G05F 5/00 - Systems for regulating electric variables by detecting deviations in the electric input to the system and thereby controlling a device within the system to obtain a regulated output
91.
FLEXIBLE PIXEL ELEMENT FABRICATION AND SEALING METHOD
Discrete flexible pixel elements are hermetically sealed from the environment and comprise unitary, self-contained replaceable modules which enable efficient, economical production of large scale, free-form electronic displays, signs and lighting effects for outdoor use. The method and means for producing hermetically sealed discrete flexible pixel elements include encapsulation means, exterior casement means, and cable connector means.
Discreet flexible pixel elements connected in series comprise flexible pixel strings that are conformably applied to irregular shapes and surfaces thereby to produce free-form electronic displays and signage. Means for serial connection of discreet flexible pixel elements enable efficient power, data and control signal distribution. Image data conversion means translates conventional graphical image data into visual image data and control signals to drive discreet flexible pixel elements. The discreet flexible pixel element, serial connection means, and signal distribution means of the present invention enable efficient, economical production of large scale, free-form electronic displays, signs and lighting effects.
Discrete flexible pixel elements are hermetically sealed from the environment and comprise unitary, self-contained replaceable modules which enable efficient, economical production of large scale, free-form electronic displays, signs and lighting effects for outdoor use. The method and means for producing hermetically sealed discrete flexible pixel elements include encapsulation means, exterior casement means, and cable connector means.
Discrete flexible pixel elements are hermetically sealed from the environment and comprise unitary, self-contained replaceable modules which enable efficient, economical production of large scale, free-form electronic displays, signs and lighting effects for outdoor use. The method and means for producing hermetically sealed discrete flexible pixel elements include encapsulation means, exterior casement means, and cable connector means.
G09G 5/04 - Control arrangements or circuits for visual indicators common to cathode-ray tube indicators and other visual indicators characterised by the way in which colour is displayed using circuits for interfacing with colour displays
Disclosed are redundant data path(s) for transmission of graphical data between components in a graphical display system. The redundant data path(s) are used to transmit graphical data by at least two independent means, so that if a failure in one data path occurs, a data transmitted via a separate data path can be used for display. The system is particularly advantageous for multiple-serial-module configurations. The redundant data path(s) minimize disruption of data display and make repair and maintenance of the display system more efficient. The invention includes apparatus for graphical display systems, and also includes methods of data transmission for graphical display systems, and methods of maintenance of graphical display systems.
The present invention relates to image displays and signage, and more particularly, to displays of custom or arbitrary shape. Such shaped displays include channel letter displays, logo or design displays, multiple displays in an assembly, multiple display modules, curved or round displays, or other arbitrary shaped or unusual aspect ratio displays. The present invention further relates to software, apparatus, and methods for a translation table which maps graphical data from an initial shape to an arbitrary shape for use on such displays.
An electronic sign having a formed metal cabinet where precise and close tolerance formed planar panels and formed channels are fastened together only by rivets, nut inserts or the combination thereof for rapid assembly thereof.
G09F 9/37 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being movable elements
98.
CAPACITIVE RELAY TAKEOFF SWIMMING PLATFORM SENSOR SYSTEM
A capacitive relay takeoff swimming platform sensor system including multiple stations, timing devices and capacitive sensor devices where the presence or departure of a second swimmer on a relay takeoff swimming platform is sensed by the change in capacitance of a sensor mat and compared to the arrival of a first swimmer at a touchpad sensor. The system includes automatic recalibration of sensing, such that presence of a swimmer is sensed and then system recalibrated so as to detect departure of the swimmer. The sensor mat includes an polycarbonate perimeter.
H01H 35/00 - Switches operated by change of a physical condition
H03K 17/94 - Electronic switching or gating, i.e. not by contact-making and -breaking characterised by the way in which the control signals are generated
A sign system having components promoting ease of construction and readily accomplished changeout. Unique geometrically configured top and bottom support channels and other related components readily accommodate and capture the top and bottom edges of electronic display panels. Top and bottom shrouds attach automatically to the unique geometrically configured top and bottom support channels and include weatherstrip seals which automatically seal against the upper and lower regions of the electronic display panels. Other automatic seals are also incorporated.
G09F 9/37 - Indicating arrangements for variable information in which the information is built-up on a support by selection or combination of individual elements in which the desired character or characters are formed by combining individual elements being movable elements
G09F 13/04 - Signs, boards, or panels, illuminated from behind the insignia
G09F 7/00 - Signs, name or number plates, letters, numerals, or symbolsPanels or boards
E04B 1/00 - Constructions in generalStructures which are not restricted either to walls, e.g. partitions, or floors or ceilings or roofs
E04C 2/38 - Building elements of relatively thin form for the construction of parts of buildings, e.g. sheet materials, slabs, or panels characterised by the shape or structure with attached ribs, flanges, or the like, e.g. framed panels
A transportable electronic sign display system having modular cabinets which support electronic display modules and electronics having male and female latching assemblies connecting adjacent electronic display modules. Robust male and female latching assemblies at the top and bottom of electronic display modules provide for forcible positive action latching between vertically situated electronic display modules to provide a minimally visible horizontally oriented seam therebetween. Side latches between horizontally situated electronic display modules assemblies provide for latching to provide a minimally visible vertically oriented seam therebetween.
