A blind fastener includes a bolt and a nut. The bolt includes a shaft, a bolt head, and a lug. The bolt head being disposed between the shaft and the lug and extending radially outward from the shaft. An end of the shaft opposite the bolt head defining external threads. The lug includes a first tool engagement portion, a first frangible portion, and a rim. The rim extends between the first tool engagement portion and the first frangible portion and extends radially inward of the first tool engagement portion. The nut includes a sleeve, a nut head, and a handling member. The sleeve defines a central bore configured to receive the shaft and defining internal threads configured to mate with the external threads. The nut head defining a recess configured to receive the bolt head. The handling member includes a second frangible portion and a second tool engagement portion.
A tool for installing a blind fastener including a bolt and a nut includes a collet, a socket assembly, a drive body and a mode clutch. The collet is configured to selectively engage a tool engagement portion of the nut. The socket assembly includes a socket housing and a plurality of rollers. The socket housing defines a bore disposed about the axis. A surface of each roller is configured to engage a cylindrical tool engagement portion of the bolt within a bore to rotate the bolt about an axis. The drive body is coupled to the socket housing and configured to rotate the socket housing about the axis. The mode clutch is operable in an engaged mode in which the socket housing is coupled to the collet for common rotation about the axis and a disengaged mode in which the socket housing is rotatable relative to the collet.
A tool for installing a blind fastener including a bolt and a nut includes a base, collet, socket assembly, drive body, and mode clutch. The collet is coupled to the base and disposed about an axis. The collet can selectively engage a portion of the nut. The socket assembly includes a socket housing and a plurality of rollers. The socket housing is rotatable relative to the collet and defines a bore disposed about the axis. The rollers are spaced circumferentially about the axis. A surface of each roller can engage a cylindrical portion of the bolt within the bore to rotate the bolt about the axis. The drive body is coupled to the socket housing and configured to rotate the socket housing about the axis relative to the base. The mode clutch is configured to selectively couple the socket housing with the collet for common rotation about the axis.
A tool for installing a blind fastener including a bolt and a nut includes a base, collet, socket assembly, drive body, and mode clutch. The collet is coupled to the base and disposed about an axis. The collet can selectively engage a portion of the nut. The socket assembly includes a socket housing and a plurality of rollers. The socket housing is rotatable relative to the collet and defines a bore disposed about the axis. The rollers are spaced circumferentially about the axis. A surface of each roller can engage a cylindrical portion of the bolt within the bore to rotate the bolt about the axis. The drive body is coupled to the socket housing and configured to rotate the socket housing about the axis relative to the base. The mode clutch is configured to selectively couple the socket housing with the collet for common rotation about the axis.
A blind fastener for connecting workpieces includes a bolt and nut. The bolt includes a shaft, bolt head, and lug. The bolt head is between the shaft and lug and extends radially outward from the shaft. The shaft defines external threads opposite the bolt head. The lug includes a first tool engagement portion and a first frangible portion that frangibly couples the lug to the bolt head. The nut includes a sleeve, nut head, and handling member. The shaft is threadably received in the sleeve. The nut head extends radially outward from the sleeve and defines a recess that receives the bolt head. The handling member surrounds at least a portion of the lug. The handling member includes a second frangible portion and a second tool engagement portion. The second frangible portion frangibly couples the second tool engagement portion to the nut head.
B21J 15/26 - Entraînements pour machines à riveterMoyens de transmission correspondants actionnés par un entraînement rotatif, p. ex. par des moteurs électriques
B25B 27/00 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs
F16B 5/04 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par rivetage
F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
A blind fastener (10) for connecting workpieces (26,30) includes a bolt (14) and nut (18). The bolt includes a shaft (110), bolt head (114), and lug (118). The bolt head is between the shaft and lug and extends radially outward from the shaft. The shaft defines external threads (126)opposite the bolt head. The lug includes a first tool engagement portion (1509 and a first frangible portion (174) that frangibly couples the lug to the bolt head. The nut includes a sleeve (210), nut head (214), and handling member (218). The shaft is threadably received in the sleeve. The nut head extends radially outward from the sleeve and defines a recess (242) that receives the bolt head. The handling member surrounds at least a portion of the lug. The handling member includes a second frangible (270) portion and a second tool engagement portion (266). The second frangible portion frangibly couples the second tool engagement portion to the nut head.
B21J 15/26 - Entraînements pour machines à riveterMoyens de transmission correspondants actionnés par un entraînement rotatif, p. ex. par des moteurs électriques
B25B 27/00 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs
F16B 5/04 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par rivetage
F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
A blind fastener (10) for connecting workpieces (26,30) includes a bolt (14) and nut (18). The bolt includes a shaft (110), bolt head (114), and lug (118). The bolt head is between the shaft and lug and extends radially outward from the shaft. The shaft defines external threads (126)opposite the bolt head. The lug includes a first tool engagement portion (1509 and a first frangible portion (174) that frangibly couples the lug to the bolt head. The nut includes a sleeve (210), nut head (214), and handling member (218). The shaft is threadably received in the sleeve. The nut head extends radially outward from the sleeve and defines a recess (242) that receives the bolt head. The handling member surrounds at least a portion of the lug. The handling member includes a second frangible (270) portion and a second tool engagement portion (266). The second frangible portion frangibly couples the second tool engagement portion to the nut head.
B21J 15/26 - Entraînements pour machines à riveterMoyens de transmission correspondants actionnés par un entraînement rotatif, p. ex. par des moteurs électriques
F16B 5/04 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par rivetage
F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
B25B 27/00 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs
A connector assembly includes a first member, a threaded shaft, a nut, a set of first teeth, a set of second teeth, and a tab. The threaded shaft is disposed about an axis. The nut is threadably engaged with the threaded shaft. The nut includes a plurality of radially outward extending protrusions. The first teeth face axially and are non-rotatably coupled to the first member. The second teeth are configured to mate with the first teeth. The second teeth are coupled to the threaded shaft for axial movement relative to the threaded shaft and for common rotation with the threaded shaft. The tab is non-rotatable relative to the first member. The tab engages the protrusions to inhibit rotation of the nut relative to the first member.
F16B 39/282 - Blocage par dispositifs dont les surfaces de travail ont une forme particulière, p. ex. écrous à encoches ou à dents
F16B 39/24 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet
A tool for installing a blind fastener including a core bolt and a core nut is provided. The tool includes a driving member, a collet driven by the driving member for engaging the core bolt, and an external sleeve for holding the core nut and preventing the core nut from rotating during installation of the blind fastener. The external sleeve is movable between a first position in which the external sleeve is driven by the collet to rotate with the collet and a second position in which the external sleeve is stationary despite rotating action of the collet.
B21J 15/12 - Machines à riveter avec outils ou parties d'outils possédant un mouvement propre s'ajoutant au mouvement d'avance, p. ex. repoussage
B21J 15/14 - Machines à riveter spécialement adaptées au rivetage de pièces déterminées, p. ex. machines pour poser les garnitures de frein
B25B 27/00 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs
F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
A tool for installing a blind fastener including a core bolt and a core nut is provided. The tool includes a driving member, a collet driven by the driving member for engaging the core bolt, and an external sleeve for holding the core nut and preventing the core nut from rotating during installation of the blind fastener. The external sleeve is movable between a first position in which the external sleeve is driven by the collet to rotate with the collet and a second position in which the external sleeve is stationary despite rotating action of the collet.
B25B 27/00 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs
F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
B21J 15/12 - Machines à riveter avec outils ou parties d'outils possédant un mouvement propre s'ajoutant au mouvement d'avance, p. ex. repoussage
B21J 15/14 - Machines à riveter spécialement adaptées au rivetage de pièces déterminées, p. ex. machines pour poser les garnitures de frein
A blind fastener (10) for connecting panels (26,30) includes a bolt (14) and nut (18). The bolt includes a shaft (110), bolt head (114), and lug (118). The bolt head is between the shaft and lug. The lug includes a first tool engagement portion (150) and first frangible portion (154) that connects the lug and bolt head. The nut includes a sleeve (210), nut head (214), and handling member (218). A central bore (230) of the sleeve receives the shaft and defines internal threads (234) mated with the external threads. The nut head extends radially from the sleeve and defines a recess (242) that receives the bolt head. The handling member surrounds a portion of the lug. The handling member includes a second frangible portion (270) and a second tool engagement portion (266). The second frangible portion couples the second tool engagement portion to the nut head.
A blind fastener (30) for connecting a plurality of panels (1,2) includes a core bolt (3) and a core nut (5). The core nut surrounds the core bolt. The core nut includes a main body (40), a nut head (46), and a tool engagement section (42). The nut head has a larger outside diameter than the main body. The core nut defines a frangible portion (52) between the nut head and the tool engagement section. The frangible portion is configured to allow the tool engagement section to break off from the nut head when a torque applied to the tool engagement section is greater than a threshold torque after the blind fastener is installed in the plurality of panels.
A blind fastener for connecting panels includes a bolt and nut. The bolt includes a shaft, bolt head, and lug. The bolt head is between the shaft and lug. The shaft defines external threads opposite the bolt head. The lug includes a first tool engagement portion and first frangible portion that connects the lug and bolt head. The nut includes a sleeve, nut head, and handling member. A central bore of the sleeve receives the shaft and defines internal threads mated with the external threads. The nut head is between the handling member and sleeve. The nut head extends radially from the sleeve and defines a recess that receives the bolt head. The handling member surrounds a portion of the lug. The handling member includes a second frangible portion and a second tool engagement portion. The second frangible portion couples the second tool engagement portion to the nut head.
F16B 13/06 - Chevilles ou autres dispositifs fixés à des parois ou autres emplacements par insertion dans des trous préparés à cet effet avec parties s'agrippant dans le trou ou derrière la paroi après insertion et combinées avec un manchon extensible
F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
F16B 5/02 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation utilisant un filetage
F16B 31/02 - Assemblages à vis spécialement modifiés en vue de résister à une charge de tractionBoulons de rupture signalant ou limitant la charge de traction
F16B 19/00 - Chevilles à têteGoupilles, y compris celles réalisées par déformation d'élémentsRivets
B23P 19/06 - Machines pour mettre ou retirer les vis ou les écrous
F16B 37/14 - Écrous-chapeauxChapeaux d'écrous ou de boulons
A tool for installing a blind fastener including a core bolt and a core nut is provided. The tool includes a driving member, a collet driven by the driving member for engaging the core bolt, and an external sleeve for holding the core nut and preventing the core nut from rotating during installation of the blind fastener. The external sleeve is movable between a first position in which the external sleeve is driven by the collet to rotate with the collet and a second position in which the external sleeve is stationary despite rotating action of the collet.
B23P 19/04 - Machines effectuant simplement l'assemblage ou la séparation de pièces ou d'objets métalliques entre eux ou des pièces métalliques avec des pièces non métalliques, que cela entraîne ou non une certaine déformationOutils ou dispositifs à cet effet dans la mesure où ils ne sont pas prévus dans d'autres classes pour assembler ou séparer des pièces
F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
B21J 15/18 - Entraînements pour machines à riveterMoyens de transmission correspondants actionnés par pression d'air ou par pression d'un autre gaz, p. ex. par pression d'explosion
B25B 27/00 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs
B21J 15/14 - Machines à riveter spécialement adaptées au rivetage de pièces déterminées, p. ex. machines pour poser les garnitures de frein
B21J 15/12 - Machines à riveter avec outils ou parties d'outils possédant un mouvement propre s'ajoutant au mouvement d'avance, p. ex. repoussage
A method of installing an insert in an aperture of a panel includes inserting a sleeve central portion into the aperture so that a sleeve flange opposes a first side of the panel. The sleeve central portion extends from the sleeve flange. The method further includes inserting a plug central portion into the aperture so that a plug flange opposes a second side of the panel. The plug central portion extends from the plug flange. The method also includes pressing at least one of the plug and sleeve into sliding engagement with the other until the plug and sleeve are installed. When installed, a distal end of the plug is received into a sleeve cavity and resilient beams defined by an extension of the sleeve central portion are elastically deflected by a wall of the plug central portion. The plug flange defines an aperture extending into a plug cavity.
F16B 5/02 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation utilisant un filetage
F16B 37/12 - Écrous ou pièces similaires avec entrées de filetage avec surfaces d'entrée de filetage consistant en une insertion de ressorts hélicoïdaux, de disques ou de pièces analoguesÉcrous constitués par des morceaux indépendants de fil métallique enrouléGarnitures filetées intérieures pour trous
B64C 1/14 - FenêtresPortesTrappes d'évacuation ou panneaux de visiteStructures de cadres environnantsVerrièresPare-brise
27.
INTERNAL POSITIVE STOP, BREAK-OFF FLUSHNESS IN BLIND FASTENERS
A blind fastener (30) includes a core bolt (3) and a core nut (5). The core bolt (3) has a threaded section (34), a non-threaded section (32), a bolt head (9), and a stop shoulder (10). The non-threaded section (32) is disposed axially between the threaded section (34) and the bolt head (9). The stop shoulder (10) is disposed axially between the threaded section (34) and the non-threaded section (32). The core nut (5) surrounds the core bolt (3) and is threadably engaged with the threaded section (34) of the core bolt (3). The core nut (5) has an internal positive stop (15) extending radially inward from an inner surface of the core nut (5). The positive stop (15) of the core nut (5) opposes the stop shoulder (10) and cooperates with the stop shoulder (10) to inhibit further tightening of the core bolt (3) when the blind fastener (30) is in a completely installed condition.
An adjustment system for a fastener pulling head includes a swivel adapter, an adjustment member, and a retention member. The fastener pulling head includes a frame, a jaw, and a drawbolt body, the adjustment system. The swivel adapter is configured to engage with a proximal end portion of the drawbolt body. The swivel adapter defines an internal bore. The adjustment member is disposed within the internal bore and configured to engage the drawbolt body. The retention member is configured to engage and secure the swivel adapter at a location within the drawbolt body. When the retention member is disengaged from the swivel adapter, the pulling head can be rotated to cause the frame to move relative to the drawbolt body to adjust a gripping force of the jaw.
A self-locking plug assembly is provided that includes a plug, a lower clutch disposed around the plug and defining engagement features, an upper clutch disposed around the plug and defining mating engagement features, a resilient member and a cap surrounding the resilient member and disposed around a proximal end portion of the plug. The mating engagement features are configured to apply higher torque to the engagement features in one direction than in an opposite direction. In one form, the engagement features of the lower clutch and upper clutch comprise a plurality of teeth arranged around a central aperture.
F16B 39/22 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage
F16B 39/282 - Blocage par dispositifs dont les surfaces de travail ont une forme particulière, p. ex. écrous à encoches ou à dents
F16B 5/02 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation utilisant un filetage
G02B 23/24 - Instruments pour regarder l'intérieur de corps creux, p. ex. endoscopes à fibres
F01D 21/00 - Arrêt des "machines" ou machines motrices, p. ex. dispositifs d'urgenceDispositifs de régulation, de commande ou de sécurité non prévus ailleurs
F02B 77/00 - Parties constitutives, détails ou accessoires, non prévus ailleurs
Power-operated installation tools, namely, pullers and components therefor, extractors and power operated rivet guns. Hand-operated installation tools, namely, hand-operated riveting tools and hand-operated pulling heads for installing metal fasteners and nut plates.
Power-operated installation tools, namely, pullers and components therefor, extractors and power operated rivet guns Hand-operated installation tools, namely, hand-operated riveting tools and hand-operated pulling heads for installing metal fasteners and nut plates
A ferrule for connecting two adjacent components is provided, wherein the ferrule defines an exterior wall portion having a plurality of asymmetrical dimples. Each asymmetrical dimple has at least two sidewalls, and one sidewall defines a first ramp angle, and the other sidewall defines a second ramp angle that is steeper than the first ramp angle. At least one feature of one of the adjacent components engages the plurality of asymmetrical dimples such that the sidewall with the first ramp angle provides less force in an engaging direction and the sidewall with the second ramp angle provides more force in a disengaging direction.
F16L 37/088 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'un segment élastique fendu
A locknut assembly (20) for securing a component to a shaft is provided that includes, in one form, a locknut (22) defining an internal cavity (32) and an aperture (34) having internal threads (36), the internal cavity (32) defining an internal wall (37) comprising at least one location feature (38). A lockwasher (24) defines an internal cavity (42), an external wall (44) comprising at least one mating location feature (40), and an anti-rotation feature (46) disposed within the internal cavity (42) and adapted for engagement with a corresponding anti-rotation feature (48) located at an end portion (49) of the shaft (30). The internal threads (36) of the locknut aperture (34) engage continuous external threads (31) of the shaft (30), the mating location feature (40) of the lockwasher (24) engages the location feature (38) of the locknut (22), and the anti-rotation feature (46) of the lockwasher (24) engages the corresponding anti-rotation feature (46) of the shaft (30) to limit rotation of the locknut (22).
F16B 39/08 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage avec un chapeau agissant contre l'écrou relié au boulon par une broche ou une goupille fendue
A locknut assembly for securing a component to a shaft is provided that includes, in one form, a locknut defining an internal cavity and an aperture having internal threads, the internal cavity defining an internal wall comprising at least one location feature. A lockwasher defines an internal cavity, an external wall comprising at least one mating location feature, and an anti-rotation feature disposed within the internal cavity and adapted for engagement with a corresponding anti-rotation feature located at an end portion of the shaft. The internal threads of the locknut aperture engage continuous external threads of the shaft, the mating location feature of the lockwasher engages the location feature of the locknut, and the anti-rotation feature of the lockwasher engages the corresponding anti-rotation feature of the shaft to limit rotation of the locknut.
F16B 39/10 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage par une plaque ou un anneau immobile par rapport au boulon ou à l'objet
F16B 39/12 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage par écrous de blocage, c.-à-d. contre-écrous
An insert for use in a panel and method of installation is provided by the present disclosure. The insert includes a plug having an outer flange, a central portion having a wall extending from the outer flange, and a distal end portion having a rollover. A cavity extends through the central portion, and an aperture extends through the outer flange and into the cavity. A sleeve is configured for sliding engagement with the plug, the sleeve having an outer flange, a central portion defining an extension having a plurality of resilient beams, and a cavity extending through the central portion, the cavity adapted for receiving the distal end portion of the plug. A retaining plate is secured to the plug by the rollover, and a threaded insert is disposed within the cavity of the plug and adapted to float therein.
F16B 5/02 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation utilisant un filetage
F16B 37/12 - Écrous ou pièces similaires avec entrées de filetage avec surfaces d'entrée de filetage consistant en une insertion de ressorts hélicoïdaux, de disques ou de pièces analoguesÉcrous constitués par des morceaux indépendants de fil métallique enrouléGarnitures filetées intérieures pour trous
B64C 1/14 - FenêtresPortesTrappes d'évacuation ou panneaux de visiteStructures de cadres environnantsVerrièresPare-brise
An insert for use in a sandwich-type structure, such as a honeycomb panel, is provided that includes a plug and a sleeve. The sleeve includes a plurality of resilient beams, and when the plug is inserted into the sleeve, the resilient beams are elastically deflected by an exterior surface of a wall of the plug such that the insert is adjustable in height and can be positioned properly in an axial/insertion direction to accommodate sandwich-type structures of varying thickness. The result is an insert that maintains a flush profile with both opposing face sheets of the sandwich-type structure, thus reducing discontinuities in surface profile of the overall assembly.
B32B 3/06 - Caractérisés par des caractéristiques de forme en des endroits déterminés, p. ex. au voisinage des bords pour lier les couches ensembleCaractérisés par des caractéristiques de forme en des endroits déterminés, p. ex. au voisinage des bords pour attacher le produit à quelque chose d'autre p. ex. à un support
B32B 3/12 - Produits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche discontinue, c.-à-d. soit continue et percée de trous, soit réellement constituée d'éléments individuels caractérisés par une couche d'alvéoles disposées régulièrement, soit formant corps unique dans un tout, soit structurées individuellement ou par assemblage de bandes indépendantes, p. ex. structures en nids d'abeilles
B32B 3/26 - Produits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche continue dont le périmètre de la section droite a une allure particulièreProduits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche comportant des cavités ou des vides internes
B32B 3/30 - Produits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche continue dont le périmètre de la section droite a une allure particulièreProduits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche comportant des cavités ou des vides internes caractérisés par une couche comportant des retraits ou des saillies, p. ex. des gorges, des nervures
F16B 5/01 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation spécialement adaptés pour panneaux en nid d'abeilles
An insert for use in a sandwich-type structure, such as a honeycomb panel, is provided that includes a plug (22) and a sleeve (24). The sleeve includes a plurality of resilient beams (48), and when the plug is inserted into the sleeve, the resilient beams are elastically deflected by an exterior surface of a wall of the plug such that the insert is adjustable in height and can be positioned properly in an axial/insertion direction to accommodate sandwich-type structures of varying thickness. The result is an insert that maintains a flush profile with both opposing face sheets of the sandwich-type structure, thus reducing discontinuities in surface profile of the overall assembly.
F16B 5/01 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation spécialement adaptés pour panneaux en nid d'abeilles
An adjustment system for a fastener pulling head is provided that includes a swivel adapter configured for engagement with a proximal end portion of a drawbolt body of the pulling head, the swivel adapter defining an internal bore. A cap screw is disposed within the internal bore of the swivel adapter and configured to threadably engage the drawbolt body, and a set screw is configured to engage and secure the swivel adapter within the drawbolt body. The set screw is tightened in order to install or remove the fastener pulling head from a power tool. Once installed on the power tool, the set screw is disengaged from the swivel adapter, the pulling head can be rotated, which causes the frame to move relative to the drawbolt body within the pulling head to adjust a jaw gripping force.
B23P 19/00 - Machines effectuant simplement l'assemblage ou la séparation de pièces ou d'objets métalliques entre eux ou des pièces métalliques avec des pièces non métalliques, que cela entraîne ou non une certaine déformationOutils ou dispositifs à cet effet dans la mesure où ils ne sont pas prévus dans d'autres classes
B21J 15/38 - Accessoires utilisés en liaison avec le rivetage, p. ex. pinces à refoulerOutils de rivetage à main
An adjustment system for a fastener pulling head is provided that includes a swivel adapter configured for engagement with a proximal end portion of a drawbolt body of the pulling head, the swivel adapter defining an internal bore. A cap screw is disposed within the internal bore of the swivel adapter and configured to threadably engage the drawbolt body, and a set screw is configured to engage and secure the swivel adapter within the drawbolt body. The set screw is tightened in order to install or remove the fastener pulling head from a power tool. Once installed on the power tool, the set screw is disengaged from the swivel adapter, the pulling head can be rotated, which causes the frame to move relative to the drawbolt body within the pulling head to adjust a jaw gripping force.
A tacking fastener for securing workpieces together to form a temporary assembly includes a stem and an elongated sleeve. The stem includes a head disposed at a proximal end portion, a tapered portion extending between the proximal end portion and a central portion, a break notch extending around a circumference of the proximal end portion between the head and the tapered portion, and a plurality of ridges and grooves disposed along a distal end portion. The elongated sleeve is disposed around the stem between the head and the plurality of ridges and grooves and configured to form a tacking rivet upon installation of the tacking fastener. The elongated sleeve is plastically deformed during installation to form a plurality of bulbs, thereby being capable of securing workpieces of varying grip length. The stem and the tacking rivet remain within the workpieces after the workpieces are secured.
F16B 13/04 - Chevilles ou autres dispositifs fixés à des parois ou autres emplacements par insertion dans des trous préparés à cet effet avec parties s'agrippant dans le trou ou derrière la paroi après insertion
F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
A coupling for joining fluid conduits includes a nut portion having a circumferential groove that extends at least partially along an interior surface thereof. The nut portion further includes a tab opening extending therethrough. A cylindrical shaft portion extends from the nut portion. A retaining clip is disposed within the circumferential groove of the nut portion and includes a tab disposed within the tab opening. A first arc of the retaining clip extends from the tab in a first circumferential direction, and a second arc of the retaining clip extends from the tab in a second, opposing circumferential direction. The first arc includes a first knob and terminates in a second knob, and the second arc includes a third knob and terminates in a fourth knob. The second and fourth knobs are larger than the first and third knobs, respectively.
F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord
47.
Jaw grip force adjustment system for offset and 90 degree pulling heads
The invention provides a system configured to adjust a jaw gripping force of a pulling head. A locking nut is threadedly attached to the pulling head and defines an aperture which extends therethrough. A frame adaptor is at least partially positioned within the aperture of the locking nut. The frame adaptor further receives a portion of the pulling head and a piston of a power tool within an aperture thereof, with the portion and the piston engaging one another within the aperture of the frame adaptor. The portion of the pulling head is operatively associated with a jaw of the pulling head. An adjustment nut is threadedly attached to the frame adaptor. Rotation of the adjustment nut, with the locking nut in an unlocked position, causes the jaw gripping force of the pulling head to either be strengthened or weakened, depending on the direction of rotation.
A tool for setting blind fasteners is disclosed. A stem of a fastener is engaged by a pulling head and its sleeve is also engaged by the pulling head. In an initial stage, a pump piston compresses fluid in a hydraulic pump, affecting movement of a drawbar and piston in relation to a stationary adaptor connected to the tool, pulling the stem in relation to the sleeve at a fast rate per pump. As the pulling force increases, pressure in the pump triggers a logic system to shift the tool into a high pressure mode, decreasing the effort to complete fastener installation. The logic system resets after each squeeze of the lever, minimizing the number of pumps necessary to complete the installation while keeping effort at a comfortable level. An adjustable pressure relief valve allows the fluid to return to the reservoir chamber, returning the tool to its initial condition.
Power-operated installation tools, namely, pullers and components therefor, extractors and power operated rivet guns Hand-operated installation tools, namely, hand-operated riveting tools and hand-operated pulling heads for installing metal fasteners and nut plates
Power-operated installation tools, namely, pullers and components therefor, extractors and power operated rivet guns Hand-operated installation tools, namely, hand-operated riveting tools and hand-operated pulling heads for installing metal fasteners and nut plates
52.
NUT PLATE FASTENER ASSEMBLY FOR COMPOSITE MATERIALS
A rivetless nut plate assembly (20), which is fully preassembled, which can be installed into an aperture (1 12) of a composite material workpiece (110), such as a carbon fiber structure, without risking delamination of the workpiece. The rivetless nut plate assembly (20) includes a nut (22), a holding bracket (24), a retainer (28), and a sleeve member (25, 25a, 25b, 25c). Additionally, a stem (26) is used to install the rivetless nut plate assembly (20). The sleeve member (25, 25a, 25b, 25c) is configured such that the nut plate assembly (20) can be installed in a composite material workpiece (110) without risking delamination. The sleeve member (25, 25a, 25b, 25c) may be formed of 45Cb-55Ti Titanium Columbium, as Titanium Colurnbium is a high strength and ductile material that resists corrosion in the presence of, for example, a carbon fiber composite structure (110). Monel, Titanium alloys, and other soft Nickel alloys are also good material selections for the sleeve (25, 25a, 25b, 25c), for similar reasons. Non-metallic materials with high tensile and shear strengths, such as Torlon or Parmax, would provide the desired corrosion protection and also offer a potential weight savings.
A rivetless nut plate assembly, which is fully preassembled, which can be installed into an aperture of a composite material workpiece, such as a carbon fiber structure, without risking delamination of the workpiece. The rivetless nut plate assembly includes a nut, a holding bracket, a retainer, and a sleeve member. Additionally, a stem is used to install the rivetless nut plate assembly. The sleeve member is configured such that the nut plate assembly can be installed in a composite material workpiece without risking delamination. The sleeve member may be formed of 45Cb-55Ti Titanium Columbium, as Titanium Columbium is a high strength and ductile material that resists corrosion in the presence of, for example, a carbon fiber composite structure. Monel, Titanium alloys, and other soft Nickel alloys are also good material selections for the sleeve, for similar reasons. Non-metallic materials with high tensile and shear strengths, such as Torlon or Parmax, would provide the desired corrosion protection and also offer a potential weight savings.
A rivetless nut plate assembly, which is fully preassembled, which can be installed into an aperture of a hard metal material workpiece having a hardness of at least 25 Rc, such as Titanium and Steel Alloys. The rivetless nut plate assembly includes a nut, a holding bracket, a retainer, and a sleeve member. Additionally, a stem is used to install the rivetless nut plate assembly. The sleeve member is configured such that the nut plate assembly can be installed in a hard metal material workpiece. The sleeve member may be formed of a high strength, but ductile material, such as Titanium Columbium, Monel, soft Nickel alloys or soft Titanium alloys.
F16B 39/28 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par organes particuliers portés par l'écrou ou le boulon ou par la forme particulière de ceux-ci
Metal rivets; metallic fasteners, namely, blind fasteners in the nature of blind bolts and blind rivets, bolts, nuts, screws, washers and rivetless nut plates Power-operated pulling heads for installing metal fasteners Hand-operated pulling heads for installing metal fasteners
56.
Fluid coupling assembly with integral retention mechanism
The fluid coupling assembly for retaining a sealed joint includes the first member adapted to be connected to a first fluid conduit with a per sealing surface and a series of axially aligned serrations along with helical threads. A second member of a complementary configuration is adapted to be connected to a second fluid conduit with complementary threads and an axially extending cylindrical collar with spaced axial notches forming cantilevered beams. Each of the cantilevered beams can have teeth capable of engaging a series of serrations to provide an appropriate resistant force for both sealing engagement and disengagement. The teeth and serrations can remain in contact to provide a visual determination of a pretorqued force between the first member and the second member.
A repair/replacement nut plate assembly, which is fully preassembled, is provided which can be inserted into an oversized or reworked/reconditioned aperture of a workpiece after an original nut plate has been removed from the original aperture of the workpiece. The repair/replacement nut plate assembly includes a nut, a holding bracket, a stem, a nut retainer, and a sleeve member. The sleeve member is configured to be secured to a nut plate assembly, of the same type originally used to provide the original nut plate in the original aperture of the workpiece to compensate for material lost from the workpiece during the removal of the original nut plate. The sleeve member allows for the original nut plate assembly to be utilized, with only the securement of the sleeve member to the holding bracket prior to setting.
A pulling head that can be used with a wide range of fasteners and power tools having different stroke lengths and/or power ratings. The pulling head has a set of internal jaws which has serrations that are configured to grip a wide range of fastener types and sizes. The effective stroke of the pulling head is determined by the power tool to which it is engaged, rather than by the structure and design of the pulling head. The pulling head preferably has two jaws and a jaw follower with a leading surface which provides two beveled surfaces. As a result, the trailing surface of the jaws need not be conical, thereby providing that the jaws need not be machined after they are cast, thereby providing a very low cost manufacturing solution.
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
Produits et services
Component parts for airplanes, namely, metal connectors and ultra-high tensile chrome bolts for landing gear and actuation applications, and hydraulic metal tube fittings in the nature of external and internal swage, dual seal and weld fittings; stand-alone metal housings for use with airplane fluid conveyance tubes, pipes and pumps [ Component parts for airplanes, namely, precision machined structural brackets ] Manufacturing services for others in the field of airplane components
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Component parts for airplanes, namely, metal connectors and ultra-high tensile chrome bolts for landing gear and actuation applications, and hydraulic metal tube fittings in the nature of external and internal swage, dual seal and weld fittings Component parts for airplanes, namely, [ precision machined structural brackets and ] stand-alone housings for fluid conveyance applications
Metal threaded fasteners and fastener devices, namely nuts, bolts, screws, pins, plugs and collars business services, namely providing product information, related literature and sales contact information relating to metal forming and cutting tools, magnetic products, metal threaded fasteners and fastener devices namely nuts, bolts, screws, pins, plugs, collars; business services, namely providing press releases and general product information in the field of fasteners, precision components, metal and magnetic products for the commercial and military aircraft, aerospace, automotive, truck, farming and construction equipment, industrial machinery, office automation, electronic equipment and electronic surveillance markets via a global computer network
Business services, namely, providing product information, related literature and sales contact information relating to metal forming and cutting tools, magnetic products, metal threaded fasteners and fastener devices namely nuts, bolts, screws, pins, plugs, collars; business services, namely, providing press releases and general product information in the field of fasteners, precision components, metals and magnetic products for the commercial and military aircraft, aerospace, automotive, truck, farming and construction equipment, industrial machinery, office automation, electronic equipment and electronic surveillance markets via a global computer network
