Abrégé

A swiveling device includes a housing, an output shaft mounted in the housing and led out of the housing, a drive arranged in the housing for swiveling the output shaft, a swiveling element connected for conjoint rotation to the output shaft in the region thereof which is led out of the housing, and with a receptacle mounted in the swiveling element and connected thereto, wherein the receptacle can be arranged at different angular positions. The swiveling device provides that the swiveling element has a receiving profile for the receptacle, and the receptacle has a mating profile which corresponds to the receiving profile, wherein the receiving profile and the mating profile are configured so that the profiles can be arranged in different positions of receptacle and swiveling element with respect to each other.

Classes IPC  ?

• B23Q 1/52 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en rotation uniquement avec un seul guidage en rotation
• B25J 17/02 - Joints articulés
• B25B 5/16 - Parties constitutives, p. ex. mâchoires, fixations des mâchoires
• F16M 11/06 - Moyens pour la fixation des appareilsMoyens permettant le réglage des appareils par rapport au banc permettant la rotation

Abrégé

The invention relates to a device (1) for positioning body components in the motor vehicle industry, having a housing (2) and two rods (3) which are mounted in the housing (2) parallel to each other and which can be moved axially, wherein the two rods (3) can be moved by means of a common drive unit (6). One end of each rod (3) is guided out of the housing (2), and a positioning tool (14) can be connected to said end. Each rod (3) of the device (1) has a bearing section (4) formed within the housing (2). The device (1) further has at least one bearing element (7) which receives the bearing sections (4), and the bearing element (7) interacts with the drive unit (6) in order to move the rods (3). Each bearing section (4) is mounted in the bearing element (7) in a rotatable manner about a longitudinal axis (10) of the respective rod (3).

Classes IPC  ?

• B25B 5/12 - Dispositions pour transmettre le mouvement aux mâchoires utilisant des leviers articulés
• B25B 11/00 - Porte-pièces ou dispositifs de mise en position non couverts par l'un des groupes , p. ex. porte-pièces magnétiques, porte-pièces utilisant le vide
• F15B 15/00 - Dispositifs actionnés par fluides pour déplacer un organe d'une position à une autreTransmission associée à ces dispositifs

Abrégé

The invention proposes a connection of two adapter parts (5, 19) of a supporting apparatus (1), which can be constructed in a modular manner, for supporting tools, workpieces or the like, having a first adapter part (19) which has an end-side attachment (25) with a partially spherical recess (26), a second adapter part (5) which has an end-side spherical attachment (7) for insertion into the partially spherical recess (26) in the first adapter part (19) and has a clamping ring (9) which bears against the spherical attachment (7), on its half which is averted from the partially spherical recess (26), having a connecting clip (36) which engages behind the attachment (25) of the first adapter part (19) and the clamping ring (9) of the second adapter part (5) on sides which are averted from one another and also fixes said attachment and clamping ring axially and radially in relation to one another, wherein the attachment (25) of the first adapter part (19) and the clamping ring (9) each have at least one weakening region (34, 33) for deforming the attachment (25) of the first adapter part (19) and clamping ring (9) when the connecting clip (36) acts on said attachment and clamping ring. A connection of this kind is secure when tools, workpieces or the like of a relatively high weight are held by the supporting apparatus.

Classes IPC  ?

• F16C 11/10 - Dispositions pour le verrouillage
• E04B 1/19 - Structures à ossature tridimensionnelle
• F16M 11/14 - Moyens pour la fixation des appareilsMoyens permettant le réglage des appareils par rapport au banc permettant la rotation dans plus d'une direction avec articulation à rotule

Abrégé

A clamping device has a clamping arm mounted pivotable in a housing of the clamping device, a first locking means pivotable corresponding to the pivoting movement of the clamping arm, and a second locking means arranged in the pivot path of the first locking means and mounted in the housing, wherein the two locking means interact in an end position of the clamping arm. The first locking means, in the region of the end remote from the pivot axis of the first locking means, on the side facing the second locking means, has a recess defined at the side by two projections, wherein the second locking means contacts the projections when the clamping arm pivots into the end position thereof and is inserted into the recess in the end position, wherein the first locking means has a first portion which receives the first projection, and a second portion which receives the second projection, wherein the two portions, with the second locking means acting upon the two projections, are movable toward one another against a spring force with the spacing between the projections increasing.

Classes IPC  ?

• B25B 5/12 - Dispositions pour transmettre le mouvement aux mâchoires utilisant des leviers articulés
• B25B 5/16 - Parties constitutives, p. ex. mâchoires, fixations des mâchoires

Abrégé

A pneumatically operable work tool for use in body construction in the motor vehicle industry includes a cylinder which has a cylinder housing, a piston moveable therein and a piston rod, which is connected to said piston, moveable linearly and guided out of the cylinder housing, and with a head housing connected to the cylinder housing, wherein a region of the piston rod protruding into the head housing cooperates with at least one toggle lever to pivot an arm assigned to the toggle lever, in particular a gripper arm or clamping arm, wherein this arm is mounted in the head housing and is pivotable between a closed position and an opened position. In the region of its end protruding into the head housing, the piston rod receives a bearing element for the toggle lever, wherein the bearing element is guided in a guide of the head housing in the direction of the longitudinal axis of the piston rod, and the bearing element, at a radial distance from the longitudinal axis of the piston rod, has a receiver for pivotable mounting of a hinge connector, which in the region of an end facing away from the bearing element is connected pivotably to the arm at a distance from a pivot axis of the arm, wherein the end pivot axes of the hinge connector and the pivot axis of the arm are arranged parallel to each other.

Classes IPC  ?

• B25B 5/06 - Dispositions pour transmettre le mouvement aux mâchoires
• B25B 5/12 - Dispositions pour transmettre le mouvement aux mâchoires utilisant des leviers articulés

Abrégé

The invention relates to a pneumatically operable work tool (1) for use in the manufacture of vehicle bodies in the motor vehicle industry, comprising a cylinder (3) which has a cylinder housing (4), a piston (6) that can be moved in the cylinder housing, and a piston rod (7) that is connected to the piston, can be moved linearly, and is guided out of the cylinder housing (4) and comprising a head housing (5) which is connected to the cylinder housing (4). A piston rod (7) region which protrudes into the head housing (5) interacts with at least one toggle lever (8) for pivoting an arm (2) paired with the toggle lever (8), in particular a gripping arm or clamping arm. The arm (2) is mounted in the head housing (5) and can be pivoted between a closed position and an open position. The piston rod (7) receives a bearing element (15) for the toggle lever (8) in the region of the piston rod end which protrudes into the head housing (5). The bearing element (15) is guided in a guide (27) of the head housing open (5) in the direction of the longitudinal axis (13) of the piston rod (7), and the bearing element (15) has a receiving area (28) for pivotally supporting a hinge connector (29) at a radial distance to the longitudinal axis (13) of the piston rod (7), said hinge connector being connected to the arm (2) at a distance to a pivot axis (9) of the arm (2) in the region of a face facing away from the bearing element (15), wherein the end-face pivot axes (30/31) of the hinge connector (29) and the pivot axis (9) of the arm (29) are parallel to one another.

Classes IPC  ?

• B25B 5/06 - Dispositions pour transmettre le mouvement aux mâchoires
• B25B 5/12 - Dispositions pour transmettre le mouvement aux mâchoires utilisant des leviers articulés

Abrégé

A self-locking braking device, for rotary shafts connectable to external loads, comprises braking means which can be operated to lock, respectively to release the rotation of a drive shaft; the braking means consist of a rigid braking disk, rotating with the drive shaft, and slidingly supported in an axial direction between two clutch members, one of which is secured to a support body for the drive shaft, while the other clutch member is supported by a plate which is elastically biased against the braking disk and operatively connected to a pneumatic cylinder for releasing the brake.

Classes IPC  ?

• B25B 5/12 - Dispositions pour transmettre le mouvement aux mâchoires utilisant des leviers articulés
• F15B 15/26 - Mécanismes de blocage

Produits et services

PNEUMATIC COMPONENTS FOR INDUSTRIAL AUTOMATION, NAMELY, PNEUMATIC ACTUATORS; MACHINE PARTS, NAMELY, PNEUMATIC CYLINDERS, SLIDE UNITS FOR CYLINDERS, ELECTRICALLY OR PNEUMATICALLY OPERATED CLAMPS, AND CENTERING DEVICES; FILTERS AND REGULATORS AND LUBRICATION DEVICES FOR PNEUMATIC PLANTS AND APPARATUSES, NAMELY, AIR FILTERS FOR INDUSTRIAL INSTALLATIONS, PRESSURE REGULATORS FOR AIR, AIR TREATMENT UNITS FOR FILTERING, PRESSURE REGULATION AND LUBRICATION OF COMPRESSED AIR FOR PRESSURIZED AIR DISTRIBUTION PLANTS IN INDUSTRIAL FIELD; PNEUMATIC VALVES, NAMELY, PNEUMATIC PRESSURE REDUCERS FOR AIR, PNEUMATIC PRESSURE REGULATORS FOR AIR, CONTROL VALVES OF PLUG [, ROTARY AND SLIDE TYPE FOR PRESSURE AIR DISTRIBUTION PLANTS AND INDUSTRIAL INSTALLATIONS; INDUSTRIAL ROBOTS] SOLENOID VALVES; MAGNETIC AND ELECTROMAGNETIC SENSORS FOR POSITION DETECTING; PRESSURE GAUGES;[ ELECTRONIC CONTROLS IN THE NATURE OF AN ELECTRIC AXIS USED IN THE OPERATION OF ELECTRIC MOTORS TO CONTROL THE TORQUE AND SPEED REQUIREMENTS OF THE MOTORS FOR CONTROLLING LINEAR MOVEMENTS;] PROGRAM CARDS FOR ELECTRIC AND ELECTRONIC CIRCUITS; ELECTRICAL CABLES

Produits et services

Pneumatic parts for industrial automation; pneumatic devices; pneumatic cylinders; guiding devices and units for cylinders; electric or pneumatic locking devices; centring devices; filters, regulators and lubricators for pneumatic installations. Pneumatically operated valves; electrovalves; magnetic and electromagnetic sensors, manometers; digital height gauges; electric axles; electric and/or pneumatic robotics; electronic cards for controlling and checking; power cables.

Produits et services

(1) Pneumatic cylinders, pneumatic pistons, pneumatic valves and pneumatic control valves, hydraulic jacks; pneumatic valves which function automatically through electric current, through solenoids.

Produits et services

Dispositifs de commande pour machines et circuits pneumatiques, par exemple cylindres et distributeurs pneumatiques, pédales pneumatiques, fin de course. Électrovalves.

Produits et services

Control devices for pneumatic machines and circuits, especially pneumatic cylinders and regulators, pneumatic pedals, travel control devices. Electromagnetic valves.
