Computer hardware and sensors for use in mobile concrete
delivery vehicles for monitoring and controlling properties
of ready-mix concrete during transport; downloadable
computer software for measuring, predicting, and adjusting
concrete rheology and workability in real time; downloadable
computer software for data collection, visualization, and
analytics in the field of concrete production and delivery. Software as a service (SaaS) featuring software for
monitoring, managing, and optimizing concrete production and
delivery processes; providing online non-downloadable
software for analyzing sensor data and predicting concrete
workability and performance.
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Computer hardware and sensors for use in mobile concrete delivery vehicles for monitoring and controlling properties of ready-mix concrete during transport; downloadable computer software for measuring, predicting, and adjusting concrete rheology and workability in real time; downloadable computer software for data collection, visualization, and analytics in the field of concrete production and delivery. (1) Software as a service (SaaS) featuring software for monitoring, managing, and optimizing concrete production and delivery processes; providing online non-downloadable software for analyzing sensor data and predicting concrete workability and performance.
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer hardware and sensors for use in mobile concrete delivery vehicles for monitoring and controlling properties of ready-mix concrete during transport; downloadable computer software for measuring, predicting, and adjusting concrete rheology and workability in real time; downloadable computer software for data collection, visualization, and analytics in the field of concrete production and delivery Software as a service (SaaS) featuring software for monitoring, managing, and optimizing concrete production and delivery processes; providing online non-downloadable software for analyzing sensor data and predicting concrete workability and performance
A method and system for concrete monitoring calibration using truck-mounted mixer drum jump speed data selectively assimilated from previous deliveries. In preferred embodiments, the invention surprisingly employs data obtained using different concrete mix designs, as well as jump speed data obtained from high speed mixing after the trucks arrive at the construction delivery site and before pouring the concrete into place at the site. The method involves measuring energy (E) in terms of pressure or force associated with mixing the concrete (“E1”) at a first drum speed (“V1”) and measuring energy (E2) after a speed jump of +/−2.5 RPM or more to a second drum speed (V2). Slump is calculated using low speed energy/speed/slump curve data, or pre-stored equation wherein slump(S) is derived as a function of slope of the line defined by E1, V1 and E2, V2 and intercept of the plotted relationship (at E axis where V is zero). The E/V/S relationship in the provided concrete is compared to at least two pre-stored data curves across drum speed ranges of 0.5 RPM-6 RPM and 6 RPM-20 RPM, to ascertain whether the provided concrete matches any of the stored curve data (i.e., previous concrete E/V/S profiles); and either activating the monitoring system for all drum speed ranges where a match is confirmed or allowing the monitoring system to calculate slump only at low drum speeds (below 6 RPM) and alerting a system user or operator that the system is only active for low speed monitoring.
B28C 5/42 - Appareillage spécialement adapté pour être monté sur des véhicules avec possibilité de mélanger au cours du transport
B01F 101/28 - Mélange d'ingrédients de ciment, de mortier, d'argile, de plâtre ou de béton
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
5.
MINIMIZING VARIATION DUE TO CONSTRUCTION AGGREGATE MOISTURE PROBES
Described are a method and system for minimizing errors in the manufacture or management of aggregate-containing construction materials such as concrete. Aggregates used for making concrete are stored or weighed in dry bulk bin type hoppers, and conveyed from these hoppers into mixer drums which batching or mix the concrete. The hoppers or conveyor belts may contain sensor probes for measuring moisture levels in the aggregate. These sensor probes require calibration from time to time, but time and expense are required for proper calibration, leading to habitually erroneous moisture level data used in the industry on a daily basis. The present inventors believe that the smallest inaccuracies in aggregate moisture level readings can have profound effects on the properties of the resultant concrete product. To confront this long suffered problem, the present inventors surprisingly discovered that the inaccuracy of these aggregate moisture sensors, as used for evaluating the aggregate as a dry bulk material, can be detected and even addressed through the use of slump monitoring systems to evaluate the concrete slurry mix prepared from the aggregates.
A method and system for initiating a majority percentage of chemical admixture dosage into a delivered concrete load preferably just before arrival of the concrete delivery truck at the delivery pour site, such that a maximized slump (or slump flow, or other slump characteristic) increase occurs just before discharge/pour. The invention employs a concrete slump management system having a processor that is programed to consider time of pour (discharge) and stored data that includes dosage response (change of slump characteristic) of the concrete mix due to past additions in the same type of concrete mix, and thus maximizes pre-pour increase in slump characteristic while minimizing or avoiding the risk of overshooting the slump target as well as limiting the time required for adjusting concrete to attain the target slump value at the jobsite.
Process and system for managing a mix design catalog of a concrete producer that involves collecting slump curve data obtained during in-transit monitoring of delivered concrete loads made from a plurality of various mix designs, wherein each mix design is identified by a different identification code (regardless of whether components are different), clustering slump curve data having same movement characteristics according to assigned strength value, and selecting a mix design to produce, to display, or both to produce and to display, from among the two or more slump data curves of individual mix designs within the same data curve cluster. The selection is based on same movement characteristic and assigned strength value, and at least one factor relative to cost, performance, physical aspect, quality, or other characteristic of the concrete mix or its components. Exemplary methods for generating new mix designs are also set forth.
A method and system for concrete monitoring calibration using truck-mounted mixer drum jump speed data selectively assimilated from previous deliveries. The method involves measuring energy at a first drum speed and a second drum speed. Slump is calculated using low speed energy/speed/slump curve data, or pre-stored equation wherein slump is derived as a function of slope of the line. The energy, speed, slump relationship in the provided concrete is compared to at least two pre-stored data curves across drum speed ranges of 15 0.5 RPM-6 RPM and 6 RPM-20 RPM, to ascertain whether the provided concrete matches any of the stored curve data; either activating the monitoring system for all drum speed ranges where a match is confirmed or allowing the monitoring system to calculate slump only at low drum speeds.
B28C 5/42 - Appareillage spécialement adapté pour être monté sur des véhicules avec possibilité de mélanger au cours du transport
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
B01F 101/28 - Mélange d'ingrédients de ciment, de mortier, d'argile, de plâtre ou de béton
9.
Minimizing variation due to construction aggregate moisture probes
Exemplary methods and systems of the invention minimize errors in the manufacture or management of aggregate-containing construction materials such as concrete. Aggregates used for making concrete are stored or weighed in dry bulk bin type hoppers, and conveyed from these hoppers into mixer drums which batching or mix the concrete. The hoppers or conveyor belts may contain sensor probes for measuring moisture levels in the aggregate. These sensor probes require calibration from time to time, but time and expense are required for proper calibration, leading to habitually erroneous moisture level data used in the industry on a daily basis. The present inventors believe that the smallest inaccuracies in aggregate moisture level readings can have profound effects on the properties of the resultant concrete product. To confront this long suffered problem, the present inventors surprisingly discovered that the inaccuracy of these aggregate moisture sensors, as used for evaluating the aggregate as a dry bulk material, can be detected and even addressed through the use of slump monitoring systems during delivery to evaluate the concrete slurry mix prepared from the aggregates.
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
Disclosed are dosing methods for mitigating the deleterious effect of clays, which are born or conveyed by sand aggregates, crushed rock, gravel, and other aggregates used in the manufacture of concrete, upon the dosage efficiency of cement dispersants added into concrete. Instead of introducing the entire clay mitigation agent (CMA) into the aggregate material before or during batching in the cement batch plant in a singular, upfront dose, the present invention comprises administering CMA doses on at least two instances in a rotatable truck-mounted mixer drum, wherein at least 21%-100% of the total CMA added into the concrete is added after initial batching of water, cement binder, and clay-bearing aggregates in the rotatable truck-mounted mixer drum during the transit portion of the delivery between initial batching at the cement batch plant and the pour event at the job site.
C04B 40/00 - Procédés, en général, pour influencer ou modifier les propriétés des compositions pour mortiers, béton ou pierre artificielle, p. ex. leur aptitude à prendre ou à durcir
Disclosed are exemplary process and system for managing a mix design catalog of a concrete producer that involves collecting slump curve data obtained during in-transit monitoring of delivered concrete loads made from a plurality of various mix designs, wherein each mix design is identified by a different identification code (regardless of whether components are different), clustering slump curve data having same movement characteristics according to assigned strength value, and selecting a mix design to produce, to display, or both to produce and to display, from among the two or more slump data curves of individual mix designs within the same data curve cluster. The selection is based on same movement characteristic and assigned strength value, and at least one factor relative to cost, performance, physical aspect, quality, or other characteristic of the concrete mix or its components. Exemplary methods for generating new mix designs are also disclosed.
B28C 5/42 - Appareillage spécialement adapté pour être monté sur des véhicules avec possibilité de mélanger au cours du transport
G05B 1/11 - Éléments de comparaison, c.-à-d. éléments pour effectuer la comparaison directement ou indirectement entre une valeur désirée et des valeurs existantes ou prévues fluidiques
Disclosed are exemplary process and system for managing a mix design catalog of a concrete producer that involves collecting slump curve data obtained during in-transit monitoring of delivered concrete loads made from a plurality of various mix designs, wherein each mix design is identified by a different identification code (regardless of whether components are different), clustering slump curve data having same movement characteristics according to assigned strength value, and selecting a mix design to produce, to display, or both to produce and to display, from among the two or more slump data curves of individual mix designs within the same data curve cluster. The selection is based on same movement characteristic and assigned strength value, and at least one factor relative to cost, performance, physical aspect, quality, or other characteristic of the concrete mix or its components. Exemplary methods for generating new mix designs are also disclosed.
B28C 5/42 - Appareillage spécialement adapté pour être monté sur des véhicules avec possibilité de mélanger au cours du transport
G05B 1/11 - Éléments de comparaison, c.-à-d. éléments pour effectuer la comparaison directement ou indirectement entre une valeur désirée et des valeurs existantes ou prévues fluidiques
G06Q 10/06 - Ressources, gestion de tâches, des ressources humaines ou de projetsPlanification d’entreprise ou d’organisationModélisation d’entreprise ou d’organisation
The present invention provides a method and system for detecting hardened concrete buildup in a mixer drum which is substantially devoid of plastic concrete. An exemplary method involves monitoring the hydraulic pressure required to rotate the drum through at least two successive rotations at constant speed, using a hydraulic pressure sensor on hydraulic charge side, discharge side, or preferably both sides of the hydraulic motor which turns the mixer drum; and detecting when the pressure/time data curve indicates eccentric behavior of the mixer drum, whereby an alarm or other indication is provided to confirm that the hardened concrete buildup in the truck is not acceptable. The buildup detection method and system of the present invention does not require the use of an automated slump monitoring system, but can be implemented in combination with such systems with favorable results and advantages.
B28C 7/00 - Commande de l'opération de production des mélanges d'argile ou de ciment avec d'autres substancesAlimentation ou dosage des ingrédients pour les mélanges ci-dessusDéchargement du mélange
A system and process for detecting dynamic segregation in concrete rotated within a mixer drum, such as mounted on a delivery truck. A system processor is programmed to monitor an instantaneous and averaged rheology parameter and to deploy protocols for detecting segregation. A first protocol comprises monitoring the averaged slump during and immediately after a jump in drum speed of at least plus or minus four rotations per minute and detecting when a change in the averaged slump value meets or exceeds a threshold; and a second protocol comprises monitoring the instantaneous slump when the mixer drum is rotating at a constant speed for at least three successive rotations and detecting when the instantaneous slump value meets or exceeds a threshold limit. Once segregation is detected, one or more operations can be initiated, such as initiating an alarm or adjusting the mix.
E01C 19/10 - Appareils ou installations pour mélanger ou enduire à l'avance des agrégats ou produits de remplissage avec des liants non hydrauliques, p. ex. avec du bitume, des résinesAppareils pour remélanger à nouveau les mélanges non hydrauliques avant de les mettre en place ou pour reconditionner les compositions non hydrauliques récupérées
Described are a method and system for minimizing errors in the manufacture or management of aggregate-containing construction materials such as concrete. Aggregates used for making concrete are stored or weighed in dry bulk bin type hoppers, and conveyed from these hoppers into mixer drums which batching or mix the concrete. The hoppers or conveyor belts may contain sensor probes for measuring moisture levels in the aggregate. These sensor probes require calibration from time to time, but time and expense are required for proper calibration, leading to habitually erroneous moisture level data used in the industry on a daily basis. The present inventors believe that the smallest inaccuracies in aggregate moisture level readings can have profound effects on the properties of the resultant concrete product. To confront this problem, the present inventors discovered that the inaccuracy of these aggregate moisture sensors, as used for evaluating the aggregate as a dry bulk material, can be detected and even addressed through the use of slump monitoring systems to evaluate the concrete slurry mix prepared from the aggregates.
B28C 5/34 - Mélange sur des transporteurs ou par des transporteurs
B28C 5/42 - Appareillage spécialement adapté pour être monté sur des véhicules avec possibilité de mélanger au cours du transport
B28C 7/00 - Commande de l'opération de production des mélanges d'argile ou de ciment avec d'autres substancesAlimentation ou dosage des ingrédients pour les mélanges ci-dessusDéchargement du mélange
Described are a method and system for minimizing errors in the manufacture or management of aggregate-containing construction materials such as concrete. Aggregates used for making concrete are stored or weighed in dry bulk bin type hoppers, and conveyed from these hoppers into mixer drums which batching or mix the concrete. The hoppers or conveyor belts may contain sensor probes for measuring moisture levels in the aggregate. These sensor probes require calibration from time to time, but time and expense are required for proper calibration, leading to habitually erroneous moisture level data used in the industry on a daily basis. The present inventors believe that the smallest inaccuracies in aggregate moisture level readings can have profound effects on the properties of the resultant concrete product. To confront this problem, the present inventors discovered that the inaccuracy of these aggregate moisture sensors, as used for evaluating the aggregate as a dry bulk material, can be detected and even addressed through the use of slump monitoring systems to evaluate the concrete slurry mix prepared from the aggregates.
B28C 7/00 - Commande de l'opération de production des mélanges d'argile ou de ciment avec d'autres substancesAlimentation ou dosage des ingrédients pour les mélanges ci-dessusDéchargement du mélange
Described are a method and system for initiating a majority percentage of chemical admixture dosage into a delivered concrete load preferably just before arrival of the concrete delivery truck at the delivery pour site, such that a maximized slump (or slump flow, or other slump characteristic) increase occurs just before discharge/pour. The invention employs a concrete slump management system having a processor that is programed to consider time of pour (discharge) and stored data that includes dosage response (change of slump characteristic) of the concrete mix due to past additions in the same type of concrete mix, and thus maximizes pre-pour increase in slump characteristic while minimizing or avoiding the risk of overshooting the slump target as well as limiting the time required for adjusting concrete to attain the target slump value at the jobsite.
Described are a method and system for initiating a majority percentage of chemical admixture dosage into a delivered concrete load preferably just before arrival of the concrete delivery truck at the delivery pour site, such that a maximized slump (or slump flow, or other slump characteristic) increase occurs just before discharge/pour. The invention employs a concrete slump management system having a processor that is programed to consider time of pour (discharge) and stored data that includes dosage response (change of slump characteristic) of the concrete mix due to past additions in the same type of concrete mix, and thus maximizes pre-pour increase in slump characteristic while minimizing or avoiding the risk of overshooting the slump target as well as limiting the time required for adjusting concrete to attain the target slump value at the jobsite.
The present invention provides a method and system for detecting hardened concrete buildup in a mixer drum which is substantially devoid of plastic concrete. An ex- emplary method involves monitoring the hydraulic pressure required to rotate the drum through at least two successive ro- tations at constant speed, using a hydraulic pressure sensor on hydraulic charge side, discharge side, or preferably both sides of the hydraulic motor which turns the mixer drum; and de- tecting when the pressure/time data curve indicates eccentric behavior of the mixer drum, whereby an alarm or other indic- ation is provided to confirm that the hardened concrete buildup in the truck is not acceptable. The buildup detection method and system of the present invention does not require the use of an automated slump monitoring system, but can be implemented in combination with such systems with favor- able results and advantages.
The present invention provides a method and system for detecting hardened concrete buildup in a mixer drum which is substantially devoid of plastic concrete. An exemplary method involves monitoring the hydraulic pressure required to rotate the drum through at least two successive rotations at constant speed, using a hydraulic pressure sensor on hydraulic charge side, discharge side, or preferably both sides of the hydraulic motor which turns the mixer drum; and detecting when the pressure/time data curve indicates eccentric behavior of the mixer drum, whereby an alarm or other indication is provided to confirm that the hardened concrete buildup in the truck is not acceptable. The buildup detection method and system of the present invention does not require the use of an automated slump monitoring system, but can be implemented in combination with such systems with favorable results a nd advantages.
The invention relates to a method for adjusting concrete rheology requiring only that load size and target rheology value be selected initially rather than requiring inputs into and consultation of a lookup table of parameters such as water and hydration levels, mix components, temperature, humidity, aggregate components, and others. Dosage of particular rheology-modifying agent or combination of rheology-modifying agents is calculated based on a percentage of a nominal dose calculated with reference to a nominal dose response (“NDR”) curve or profile. The NDR profile is based on a correlation between a rheology value (e.g., slump, slump flow, yield stress) and the rheology-modifying agent(s) dose required to change rheology value by one unit (e.g., slump change from 2 to 3 inches) such that exemplary methods can employ corrective dosing based on the NDR and the measured deviation by the system.
B28C 7/00 - Commande de l'opération de production des mélanges d'argile ou de ciment avec d'autres substancesAlimentation ou dosage des ingrédients pour les mélanges ci-dessusDéchargement du mélange
C04B 40/00 - Procédés, en général, pour influencer ou modifier les propriétés des compositions pour mortiers, béton ou pierre artificielle, p. ex. leur aptitude à prendre ou à durcir
A method and system for concrete monitoring calibration using truck-mounted mixer drum jump speed data selectively assimilated from previous deliveries. The method involves measuring energy at a first drum speed and a second drum speed. Slump is calculated using low speed energy/speed/slump curve data, or pre-stored equation wherein slump is derived as a function of slope of the line. The energy, speed, slump relationship in the provided concrete is compared to at least two pre-stored data curves across drum speed ranges of 15 0.5 RPM - 6 RPM and 6 RPM - 20 RPM, to ascertain whether the provided concrete matches any of the stored curve data; either activating the monitoring system for all drum speed ranges where a match is confirmed or allowing the monitoring system to calculate slump only at low drum speeds.
A method and system for concrete monitoring calibration using truck-mounted mixer drum jump speed data selectively assimilated from previous deliveries. The method involves measuring energy at a first drum speed and a second drum speed. Slump is calculated using low speed energy/speed/slump curve data, or pre-stored equation wherein slump is derived as a function of slope of the line. The energy, speed, slump relationship in the provided concrete is compared to at least two pre-stored data curves across drum speed ranges of 15 0.5 RPM - 6 RPM and 6 RPM - 20 RPM, to ascertain whether the provided concrete matches any of the stored curve data; either activating the monitoring system for all drum speed ranges where a match is confirmed or allowing the monitoring system to calculate slump only at low drum speeds.
Disclosed are method and system for treating concrete in mixing drums of delivery vehicles having automated rheology (e.g., slump) monitoring systems programmed to dose fluids into concrete based on the monitored rheology. The present invention takes into account a Revolution-To-Discharge value (“RTD”) which reflects drum rotations needed to move concrete towards and through the mixing drum opening from which concrete is discharged, and also takes into consideration a Volume-Per-Revolution-Upon-Discharge (“VPRUD”) value which reflects the relation between the rate of discharge and rheology (e.g., slump) of concrete upon discharge. The invention is especially useful for reclaiming concrete in the drum after delivery and can confirm rheology based upon peak (maximum) discharge pressure. The present inventors found surprisingly that discharge pressure readings are useful for recalibrating automated rheology monitoring systems as well as for reporting and/or treating the remainder concrete.
B28C 5/42 - Appareillage spécialement adapté pour être monté sur des véhicules avec possibilité de mélanger au cours du transport
F24S 25/61 - Moyens de fixation, p. ex. moyens d’assemblage, spécialement adaptés pour supporter des modules de collecteurs de chaleur solaire pour ancrer au sol ou à la structure d’un bâtiment
F24F 3/044 - Systèmes dans lesquels tout le traitement est fait dans une centrale, c.-à-d. systèmes "tout-air"
F24F 13/32 - Supports pour les ensembles de conditionnement de l'air, d'humidification de l'air ou de ventilation
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
F24S 25/60 - Moyens de fixation, p. ex. moyens d’assemblage, spécialement adaptés pour supporter des modules de collecteurs de chaleur solaire
A system and process for detecting dynamic segregation in concrete rotated within a mixer drum, such as mounted on a delivery truck. A system processor is programmed to monitor an instantaneous and averaged rheology parameter and to deploy protocols for detecting segregation. A first protocol comprises monitoring the averaged slump during and immediately after a jump in drum speed of at least plus or minus four rotations per minute and detecting when a change in the averaged slump value meets or exceeds a threshold; and a second protocol comprises monitoring the instantaneous slump when the mixer drum is rotating at a constant speed for at least three successive rotations and detecting when the instantaneous slump value meets or exceeds a threshold limit. Once segregation is detected, one or more operations can be initiated, such as initiating an alarm or adjusting the mix.
E01C 19/10 - Appareils ou installations pour mélanger ou enduire à l'avance des agrégats ou produits de remplissage avec des liants non hydrauliques, p. ex. avec du bitume, des résinesAppareils pour remélanger à nouveau les mélanges non hydrauliques avant de les mettre en place ou pour reconditionner les compositions non hydrauliques récupérées
The present invention relates to mitigating the deleterious effect of clays, which are born or conveyed by sand aggregates, crushed rock, gravel, and other aggregates used in the manufacture of concrete, upon the dosage efficiency of cement dispersants or other admixtures which are added into concrete. Instead of introducing the entire cement mitigation agent (CMA) into the aggregate material at a quarry or upon batching in the mix plant in a singular, upfront dose, the present invention comprises combining at least 51% and up to 100%, and, most preferably, at least 75% and up to 100%, of the total dosage amount of the CMAs into a given concrete mix batch during the transit portion of the delivery between initial batching at the mix plant and the pour event at the job site.
Disclosed are dosing methods for mitigating the deleterious effect of clays, which are born or conveyed by sand aggregates, crushed rock, gravel, and other aggregates used in the manufacture of concrete, upon the dosage efficiency of cement dispersants added into concrete. Instead of introducing the entire cement mitigation agent (CMA) into the aggregate material at a quarry or upon batching in the mix plant in a singular, upfront dose, the present invention comprises combining at least 51% and up to 100%, and, most preferably, at least 75% and up to 100%, of the total dosage amount of the CMAs into a given concrete mix batch during the transit portion of the delivery between initial batching at the mix plant and the pour event at the job site.
C04B 24/26 - Composés macromoléculaires obtenus par des réactions faisant intervenir uniquement des liaisons non saturées carbone-carbone
C04B 28/02 - Compositions pour mortiers, béton ou pierre artificielle, contenant des liants inorganiques ou contenant le produit de réaction d'un liant inorganique et d'un liant organique, p. ex. contenant des ciments de polycarboxylates contenant des ciments hydrauliques autres que ceux de sulfate de calcium
C04B 40/00 - Procédés, en général, pour influencer ou modifier les propriétés des compositions pour mortiers, béton ou pierre artificielle, p. ex. leur aptitude à prendre ou à durcir
The present invention relates to mitigating the deleterious effect of clays, which are born or conveyed by sand aggregates, crushed rock, gravel, and other aggregates used in the manufacture of concrete, upon the dosage efficiency of cement dispersants or other admixtures which are added into concrete. Instead of introducing the entire cement mitigation agent (CMA) into the aggregate material at a quarry or upon batching in the mix plant in a singular, upfront dose, the present invention comprises combining at least 51% and up to 100%, and, most preferably, at least 75% and up to 100%, of the total dosage amount of the CMAs into a given concrete mix batch during the transit portion of the delivery between initial batching at the mix plant and the pour event at the job site.
C04B 40/00 - Procédés, en général, pour influencer ou modifier les propriétés des compositions pour mortiers, béton ou pierre artificielle, p. ex. leur aptitude à prendre ou à durcir
B28C 7/00 - Commande de l'opération de production des mélanges d'argile ou de ciment avec d'autres substancesAlimentation ou dosage des ingrédients pour les mélanges ci-dessusDéchargement du mélange
A system and process for detecting dynamic segregation in concrete rotated within a mixer drum, such as mounted on a delivery truck. A system processor is programmed to monitor an instantaneous and averaged rheology parameter (e.g., instantaneous and averaged slump values) and to deploy one or more protocols for detecting the occurrence of segregation. A first protocol comprises monitoring the averaged slump or other rheology value of concrete during and immediately after a jump in drum speed of at least plus or minus four rotations per minute and detecting when a change in the averaged slump value meets or exceeds a threshold limit pre-selected by the user or the system processor; and an optional second protocol comprises monitoring the instantaneous slump or other rheology value of the concrete when the mixer drum is rotating at a constant speed for at least three successive rotations.
B28C 5/22 - Mélange dans des récipients mis en mouvement pour effectuer ce mélange tournant autour d'un axe horizontal ou approximativement horizontal pendant le mélange, p. ex. sans agitateurs indépendants avec agitateurs maintenus fixes
A system and process for detecting dynamic segregation in concrete rotated within a mixer drum, such as mounted on a delivery truck. A system processor is programmed to monitor an instantaneous and averaged rheology parameter (e.g., instantaneous and averaged slump values) and to deploy one or more protocols for detecting the occurrence of segregation. A first protocol comprises monitoring the averaged slump or other rheology value of concrete during and immediately after a jump in drum speed of at least plus or minus four rotations per minute and detecting when a change in the averaged slump value meets or exceeds a threshold limit pre-selected by the user or the system processor; and an optional second protocol comprises monitoring the instantaneous slump or other rheology value of the concrete when the mixer drum is rotating at a constant speed for at least three successive rotations.
A gyroscopic rotational monitoring system may be utilized for monitoring one or more properties of rotatable container or vessel (2), and/or one or more properties of a displaceable material contained in the rotatable vessels. An exemplary aspect relates to the use of a gyroscope (22) and periodicity sensor (e.g., accelerometer) (24) to determine rotational speed of a concrete mixing drum, so that the slump or other property of the concrete can be monitored or adjusted such as by dosing with water, chemical admixtures, or mixture thereof.
G01C 19/56 - Dispositifs sensibles à la rotation utilisant des masses vibrantes, p. ex. capteurs vibratoires de vitesse angulaire basés sur les forces de Coriolis
G01P 3/00 - Mesure de la vitesse linéaire ou angulaireMesure des différences de vitesses linéaires ou angulaires
A gyroscopic rotational monitoring system may be utilized for monitoring one or more properties of rotatable container or vessel, and/or one or more properties of a displaceable material contained in the rotatable vessels. An exemplary aspect relates to the use of a gyroscope and periodicity sensor (e.g., accelerometer) to determine rotational speed of a concrete mixing drum, so that the slump or other property of the concrete can be monitored or adjusted such as by dosing with water, chemical admixtures, or mixture thereof.
B01F 9/06 - Mélangeurs à récipients rotatifs tournant autour d'un axe horizontal ou incliné, p.ex. mélangeurs à tambour à barres fixes
G01C 19/00 - GyroscopesDispositifs sensibles à la rotation utilisant des masses vibrantesDispositifs sensibles à la rotation sans masse en mouvementMesure de la vitesse angulaire en utilisant les effets gyroscopiques
G01C 25/00 - Fabrication, étalonnage, nettoyage ou réparation des instruments ou des dispositifs mentionnés dans les autres groupes de la présente sous-classe
A gyroscopic rotational monitoring system may be utilized for monitoring one or more properties of rotatable container or vessel (2), and/or one or more properties of a displaceable material contained in the rotatable vessels. An exemplary aspect relates to the use of a gyroscope (22) and periodicity sensor (e.g., accelerometer) (24) to determine rotational speed of a concrete mixing drum, so that the slump or other property of the concrete can be monitored or adjusted such as by dosing with water, chemical admixtures, or mixture thereof.
B28C 5/42 - Appareillage spécialement adapté pour être monté sur des véhicules avec possibilité de mélanger au cours du transport
G01C 19/56 - Dispositifs sensibles à la rotation utilisant des masses vibrantes, p. ex. capteurs vibratoires de vitesse angulaire basés sur les forces de Coriolis
G01P 3/00 - Mesure de la vitesse linéaire ou angulaireMesure des différences de vitesses linéaires ou angulaires
34.
Wireless temperature sensor for concrete delivery vehicle
A wireless temperature sensor for a concrete delivery vehicle senses temperatures of the drum, and wirelessly transmits this data to a central processor. The sensor implements power management methods to reduce power consumption and increase battery life, permitting the use of battery power in the sensor. Temperature readings from the sensor may be used qualify or evaluate a load.
G01K 13/04 - Thermomètres spécialement adaptés à des fins spécifiques pour mesurer la température de corps solides en mouvement
G01K 13/08 - Thermomètres spécialement adaptés à des fins spécifiques pour mesurer la température de corps solides en mouvement en mouvement rotatif
G01K 1/02 - Moyens d’indication ou d’enregistrement spécialement adaptés aux thermomètres
G01K 7/24 - Mesure de la température basée sur l'utilisation d'éléments électriques ou magnétiques directement sensibles à la chaleur utilisant des éléments résistifs l'élément étant une résistance non linéaire, p. ex. une thermistance dans un circuit spécialement adapté, p. ex. un circuit en pont
Disclosed are method and system for treating concrete in mixing drums of delivery vehicles having automated rheology (e.g., slump) monitoring systems programmed to dose fluids into concrete based on the monitored rheology. The present invention takes into account a Revolution-To-Discharge value ("RTD") which reflects drum rotations needed to move concrete towards and through the mixing drum opening from which concrete is discharged, and also takes into consideration a Volume-Per-Revolution-Upon-Discharge ("VPRUD") value which reflects the relation between the rate of discharge and rheology (e.g., slump) of concrete upon discharge. The invention is especially useful for reclaiming concrete in the drum after delivery and can confirm rheology based upon peak (maximum) discharge pressure. The present inventors found surprisingly that discharge pressure readings are useful for recalibrating automated rheology monitoring systems as well as for reporting and/or treating the remainder concrete.
G01F 1/00 - Mesure du débit volumétrique ou du débit massique d'un fluide ou d'un matériau solide fluent, dans laquelle le fluide passe à travers un compteur par un écoulement continu
G06F 19/00 - Équipement ou méthodes de traitement de données ou de calcul numérique, spécialement adaptés à des applications spécifiques (spécialement adaptés à des fonctions spécifiques G06F 17/00;systèmes ou méthodes de traitement de données spécialement adaptés à des fins administratives, commerciales, financières, de gestion, de surveillance ou de prévision G06Q;informatique médicale G16H)
36.
SNEAK WATER DETECTION FOR CONCRETE DELIVERY VEHICLES
The invention provides a method and system for detecting "sneak" additions of water or other fluid into the mixing drum of a concrete delivery vehicle having an automated rheology (e.g., slump) monitoring system. Sneak fluid additions are detected based on continuous rheology monitoring, even where valves and flow meters on the delivery vehicle are not used for the fluid addition. The invention is effective for monitoring additions by truck drivers who might add water from an undocumented water source (e.g., hose) along the delivery route or at the site, to hasten pouring, placement, and finishing at the time of delivery. Once sneak fluid addition is detected, the methods and system provide for reporting in the form of alerts, alarms, or other indications that sneak fluid addition has occurred, including monitor graphs or printouts confirming existence and/or extent of sneak fluid added into the vehicle mixing drum.
B28C 5/00 - Appareillages ou procédés pour la production de mélanges de ciment avec d'autres substances, p. ex. coulis, mortiers, compositions poreuses ou fibreuses
Disclosed are method and system for treating concrete in mixing drums of delivery vehicles having automated rheology (e.g., slump) monitoring systems programmed to dose fluids into concrete based on the monitored rheology. The present invention takes into account a Revolution-To-Discharge value ("RTD") which reflects drum rotations needed to move concrete towards and through the mixing drum opening from which concrete is discharged, and also takes into consideration a Volume-Per-Revolution-Upon-Discharge ("VPRUD") value which reflects the relation between the rate of discharge and rheology (e.g., slump) of concrete upon discharge. The invention is especially useful for reclaiming concrete in the drum after delivery and can confirm rheology based upon peak (maximum) discharge pressure. The present inventors found surprisingly that discharge pressure readings are useful for recalibrating automated rheology monitoring systems as well as for reporting and/or treating the remainder concrete.
G01F 22/02 - Procédés ou appareils pour la mesure du volume des fluides ou des matériaux solides fluents, non prévus ailleurs comportant un mesurage de pression
G01N 11/02 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement en mesurant l'écoulement du matériau
Disclosed are method and system for treating concrete in mixing drums of delivery vehicles having automated rheology (e.g., slump) monitoring systems programmed to dose fluids into concrete based on the monitored rheology. The present invention takes into account a Revolution-To-Discharge value ("RTD") which reflects drum rotations needed to move concrete towards and through the mixing drum opening from which concrete is discharged, and also takes into consideration a Volume-Per-Revolution-Upon-Discharge ("VPRUD") value which reflects the relation between the rate of discharge and rheology (e.g., slump) of concrete upon discharge. The invention is especially useful for reclaiming concrete in the drum after delivery and can confirm rheology based upon peak (maximum) discharge pressure. The present inventors found surprisingly that discharge pressure readings are useful for recalibrating automated rheology monitoring systems as well as for reporting and/or treating the remainder concrete.
B28C 7/04 - Alimentation ou dosage des ingrédients
B28C 7/14 - Moyens d'alimentation incorporés dans les mélangeurs ou montés sur ceux-ci
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
39.
SNEAK WATER DETECTION FOR CONCRETE DELIVERY VEHICLES
The invention provides a method and system for detecting "sneak" additions of water or other fluid into the mixing drum of a concrete delivery vehicle having an automated rheology (e.g., slump) monitoring system. Sneak fluid additions are detected based on continuous rheology monitoring, even where valves and flow meters on the delivery vehicle are not used for the fluid addition. The invention is effective for monitoring additions by truck drivers who might add water from an undocumented water source (e.g., hose) along the delivery route or at the site, to hasten pouring, placement, and finishing at the time of delivery. Once sneak fluid addition is detected, the methods and system provide for reporting in the form of alerts, alarms, or other indications that sneak fluid addition has occurred, including monitor graphs or printouts confirming existence and/or extent of sneak fluid added into the vehicle mixing drum.
Disclosed are method and system for treating concrete in mixing drums of delivery vehicles having automated rheology (e.g., slump) monitoring systems programmed to dose fluids into concrete based on the monitored rheology. The present invention takes into account a Revolution-To-Discharge value (“RTD”) which reflects drum rotations needed to move concrete towards and through the mixing drum opening from which concrete is discharged, and also takes into consideration a Volume-Per-Revolution-Upon-Discharge (“VPRUD”) value which reflects the relation between the rate of discharge and rheology (e.g., slump) of concrete upon discharge. The invention is especially useful for reclaiming concrete in the drum after delivery and can confirm rheology based upon peak (maximum) discharge pressure. The present inventors found surprisingly that discharge pressure readings are useful for recalibrating automated rheology monitoring systems as well as for reporting and/or treating the remainder concrete.
A system for managing a concrete delivery vehicle having a mixing drum 14 and hydraulic drive 16 for rotating the mixing drum, including a rotational sensor 20 configured to sense a rotational speed of the mixing drum, a hydraulic sensor 22 coupled to the hydraulic drive and configured to sense a hydraulic pressure required to turn the mixing drum, a temperature sensor for sensing temperature of the drum, and a communications port 26 configured to communicate a slump calculation to a status system 28 commonly used in the concrete industry, wherein the sensing of the rotational speed of the mixing drum is used to qualify a calculation of current slump based on the hydraulic pressure required to turn the mixing drum. Temperature readings are further used to qualify or evaluate a load. Also, water purge connections facilitate cold weather operation.
The invention relates to a method and system for monitoring and adjusting both air content and rheology (e.g., slump, slump flow) properties of a hydratable concrete mix contained within a concrete mixer. The system simultaneously tracks dosage of both rheology-modifying admixture (e.g., polycarboxylate polymer cement dispersant) and air control agent or "ACA" (e.g., air entraining agent) by reference to at least four nominal dose response ("NDR") curves or profiles, which at least four NDR profiles are based on the respective behaviors of each of the ACA and rheology- modifying agent on air content and rheology.
The invention relates to a method and system for monitoring and adjusting both air content and rheology (e.g., slump, slump flow) properties of a hydratable concrete mix contained within a concrete mixer. The system simultaneously tracks dosage of both rheology-modifying admixture (e.g., polycarboxylate polymer cement dispersant) and air control agent or "ACA" (e.g., air entraining agent) by reference to at least four nominal dose response ("NDR") curves or profiles, which at least four NDR profiles are based on the respective behaviors of each of the ACA and rheology- modifying agent on air content and rheology.
B28C 7/12 - Alimentation ou dosage des ingrédients liquides
B28C 7/00 - Commande de l'opération de production des mélanges d'argile ou de ciment avec d'autres substancesAlimentation ou dosage des ingrédients pour les mélanges ci-dessusDéchargement du mélange
44.
Multivariate management of entrained air and rheology in cementitious mixes
The invention relates to a method and system for monitoring and adjusting both air content and rheology (e.g., slump, slump flow) properties of a hydratable concrete mix contained within a concrete mixer. The system simultaneously tracks dosage of both rheology-modifying admixture (e.g., polycarboxylate polymer cement dispersant) and air control agent or “ACA” (e.g., air entraining agent) by reference to at least four nominal dose response (“NDR”) curves or profiles, which at least four NDR profiles are based on the respective behaviors of each of the ACA and rheology-modifying agent on air content and rheology.
System and method for dispensing liquids into concrete mixer drums, particularly suitable for use on concrete mix trucks, involve use of liquid admixtures nozzle that is separate from water conduit and water nozzle, the admixtures nozzle being aimed and focused to spray through drum opening with dispersion pattern substantially within air/concrete interface defined by minimal volume concrete contained within the drum; and the water conduit or nozzle having a dispersion pattern preferably whereby wash water hits a portion of the inner drum wall and a portion of the air/concrete interface defined by a maximum amount of concrete contained within the drum. In preferred embodiments, a check valve assembly is used to connect separate admixture and water lines, so that both admixture and water nozzles can be used simultaneously during purging operation.
A wireless temperature sensor for a concrete delivery vehicle senses temperatures of the drum, and wirelessly transmits this data to a central processor. The sensor implements power management methods to reduce power consumption and increase battery life, permitting the use of battery power in the sensor. Temperature readings from the sensor may be used qualify or evaluate a load.
Method and system for motoring and obtaining information about quantity and characteristics of cementitious material In a rotating mixing drum. The present invention involves analysis of a sequence of values corresponding to a waveform reflecting the hydraulic pressure required to turn a concrete mixing drum at successive instances during rotation. Preferred embodiments involve the conversion of this time-domain data into the frequency-domain. Behavior of multiple harmonics can be examined in real time and further information obtained regarding physical properties of the concrete. Rheology or other properties can be adjusted by introducing a liquid into the concrete, based on a comparison between time-domain and/or frequency-domain values derived from a sample concrete in the drum and previously stored time-domain and/or frequency-domain values, which are preferably correlated with physical characteristics of concrete, such as slump, slump flow, load weight, and other factors.
Method and system for monitoring slump flow of hydratable cementitious material such as wet concrete in a rotating mixing drum. Whereas prior art methods use a single value of the hydraulic pressure for turning the drum (such as the average value) and correlating with slump values using the vertical drop measurements of the standard slump test (e.g. ASTM C 143-05), the present invention involves analysis of values corresponding to slump flow of concrete samples, preferably having slump flow values of 16-36 inches when measured using standard slump flow tests (e.g., ASTM C1611-05).
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
49.
METHOD FOR ADJUSTING CONCRETE RHEOLOGY BASED UPON NOMINAL DOSE-RESPONSE PROFILE
The invention relates to a method for adjusting concrete rheology requiring only that load size and target rheology value be selected initially rather than requiring inputs into and consultation of a lookup table of parameters such as water and hydration levels, mix components, temperature, humidity, aggregate components, and others. Dosage of particular rheology-modifying agent or combination of rheology-modifying agents is calculated based on a percentage of a nominal dose calculated with reference to a nominal dose response ("NDR") curve or profile. The NDR profile is based on a correlation between a rheology value (e.g., slump, slump flow, yield stress) and the rheology-modifying agent(s) dose required to change rheology value by one unit (e.g., slump change from 2 to 3 inches) such that exemplary methods can employ corrective dosing based on the NDR and the measured deviation by the system.
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
The invention relates to a method for adjusting concrete rheology requiring only that load size and target rheology value be selected initially rather than requiring inputs into and consultation of a lookup table of parameters such as water and hydration levels, mix components, temperature, humidity, aggregate components, and others. Dosage of particular rheology-modifying agent or combination of rheology-modifying agents is calculated based on a percentage of a nominal dose calculated with reference to a nominal dose response ("NDR") curve or profile. The NDR profile is based on a correlation between a rheology value (e.g., slump, slump flow, yield stress) and the rheology-modifying agent(s) dose required to change rheology value by one unit (e.g., slump change from 2 to 3 inches) such that exemplary methods can employ corrective dosing based on the NDR and the measured deviation by the system.
C04B 40/00 - Procédés, en général, pour influencer ou modifier les propriétés des compositions pour mortiers, béton ou pierre artificielle, p. ex. leur aptitude à prendre ou à durcir
The invention relates to a method for adjusting concrete rheology requiring only that load size and target rheology value be selected initially rather than requiring inputs into and consultation of a lookup table of parameters such as water and hydration levels, mix components, temperature, humidity, aggregate components, and others. Dosage of particular rheology-modifying agent or combination of rheology-modifying agents is calculated based on a percentage of a nominal dose calculated with reference to a nominal dose response (“NDR”) curve or profile. The NDR profile is based on a correlation between a rheology value (e.g., slump, slump flow, yield stress) and the rheology-modifying agent(s) dose required to change rheology value by one unit (e.g., slump change from 2 to 3 inches) such that exemplary methods can employ corrective dosing based on the NDR and the measured deviation by the system.
G05D 11/02 - Commande du rapport des débits de plusieurs matériaux fluides ou fluents
G05D 11/16 - Commande du rapport du mélange de fluides ayant des températures différentes, p. ex. en déterminant la température d'un mélange de fluides ayant des viscosités différentes
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
G01N 11/14 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement en déplaçant un corps à l'intérieur du matériau en utilisant des corps en rotation, p. ex. moulinet
B28C 7/04 - Alimentation ou dosage des ingrédients
B28C 5/18 - Mélange dans des récipients mis en mouvement pour effectuer ce mélange
A system for calculating and reporting slump in a delivery vehicle having a mixing drum 14 and hydraulic drive 16 for rotating the mixing drum, including a rotational sensor 20 configured to sense a rotational speed of the mixing drum, a hydraulic sensor 22 coupled to the hydraulic drive and configured to sense a hydraulic pressure required to turn the mixing drum, and a communications port 26 configured to communicate a slump calculation to a status system 28 commonly used in the concrete industry, wherein the sensing of the rotational speed of the mixing drum is used to qualify a calculation of current slump based on the hydraulic pressure required to turn the mixing drum.
Method and system for motoring and obtaining information about quantity and characteristics of cementitious material In a rotating mixing drum. The present invention involves analysis of a sequence of values corresponding to a waveform reflecting the hydraulic pressure required to turn a concrete mixing drum at successive instances during rotation. Preferred embodiments involve the conversion of this time-domain data into the frequency-domain. Behavior of multiple harmonics can be examined in real time and further information obtained regarding physical properties of the concrete. Rheology or other properties can be adjusted by introducing a liquid into the concrete, based on a comparison between time-domain and/or frequency-domain values derived from a sample concrete in the drum and previously stored time-domain and/or frequency-domain values, which are preferably correlated with physical characteristics of concrete, such as slump, slump flow, load weight, and other factors.
A system for managing a concrete delivery vehicle having a mixing drum 14 and hydraulic drive 16 for rotating the mixing drum, including a rotational sensor 20 configured to sense a rotational speed of the mixing drum, a hydraulic sensor 22 coupled to the hydraulic drive and configured to sense a hydraulic pressure required to turn the mixing drum, a temperature sensor for sensing temperature of the drum, and a communications port 26 configured to communicate a slump calculation to a status system 28 commonly used in the concrete industry, wherein the sensing of the rotational speed of the mixing drum is used to qualify a calculation of current slump based on the hydraulic pressure required to turn the mixing drum. Temperature readings are further used to qualify or evaluate a load. Also, water purge connections facilitate cold weather operation.
G05B 15/00 - Systèmes commandés par un calculateur
H02H 7/00 - Circuits de protection de sécurité spécialement adaptés aux machines ou aux appareils électriques de types particuliers ou pour la protection sectionnelle de systèmes de câble ou de ligne, et effectuant une commutation automatique dans le cas d'un changement indésirable des conditions normales de travail
B28C 5/42 - Appareillage spécialement adapté pour être monté sur des véhicules avec possibilité de mélanger au cours du transport
B28B 23/00 - Aménagements spécialement adaptés à la fabrication d'objets façonnés avec des éléments complètement ou partiellement enrobés dans le matériau de moulage
A system for managing a concrete delivery vehicle having a mixing drum 14 and hydraulic drive 16 for rotating the mixing drum, including a rotational sensor 20 configured to sense a rotational speed of the mixing drum, a hydraulic sensor 22 coupled to the hydraulic drive and configured to sense a hydraulic pressure required to turn the mixing drum, a temperature sensor for sensing temperature of the drum, and a communications port 26 configured to communicate a slump calculation to a status system 28 commonly used in the concrete industry, wherein the sensing of the rotational speed of the mixing drum is used to qualify a calculation of current slump based on the hydraulic pressure required to turn the mixing drum. Temperature readings are further used to qualify or evaluate a load. Also, water purge connections facilitate cold weather operation.
G01N 11/00 - Recherche des propriétés d'écoulement des matériaux, p. ex. la viscosité, la plasticitéAnalyse des matériaux en déterminant les propriétés d'écoulement
B28C 7/00 - Commande de l'opération de production des mélanges d'argile ou de ciment avec d'autres substancesAlimentation ou dosage des ingrédients pour les mélanges ci-dessusDéchargement du mélange
56.
METHOD AND SYSTEM FOR CALCULATING AND REPORTING SLUMP IN DELIVERY VEHICLES
The present invention relates to a system for managing the mixing of construction material in a rotating mixing drum. A sensor is coupled to the mixing drum and or drive system therefor and is configured to sense rotation and/or torque applied to the mixing drum and/or the contents thereof A processor receives data from the sensor and utilizes the data in evaluating the condition of the material in the mixing drum. The processor compares data from the sensor to a stored curve or curve family to evaluate the condition of the material in the mixing drum.
A system for managing a concrete delivery vehicle having a mixing drum (14) and hydraulic drive (16) for rotatingthe mixing drum, including a rotational sensor (20) configured to sense a rotational speed of the mixing drum, a hydraulic sensor(22) coupled to the hydraulic drive and configured to sense a hydraulic pressure required to turn the mixing drum, a temperaturesensor for sensing temperature of the drum, and a communications port (26) configured to communicate a slump calculation to astatus system (28) commonly used in the concrete industry, wherein the sensing of the rotational speed of the mixing drum is usedto qualify a calculation of current slump based on the hydraulic pressure required to turn the mixing drum. Temperature readingsare further used to qualify or evaluate a load. Also, water purge connections facilitate cold weather operation.
The present invention relates to a system for a system for managing a concrete delivery vehicle having a mixing drum and a controller. A chemical additive supply is coupled to the controller and has two or more supply containers each containing a different chemical additive. A temperature sensor is mounted to the mixing drum. The controller obtains information on a condition of the concrete, and in response causes the chemical additive supply to selectively deliver chemical additive to the concrete. The controller collects data on the condition of the concrete from two or more of: a temperature measurement of the concrete; a rate or amount of measured temperature change of the concrete measured during a time period; a measured amount of energy required in mixing the concrete; and measured completion of mixing of the concrete.
09 - Appareils et instruments scientifiques et électriques
Produits et services
system comprising computer hardware, software, and sensors in mobile delivery vehicles for monitoring, reporting, and tracking construction materials in the construction industry; a system comprising computer hardware, software, and sensors in mobile delivery vehicles for measuring and reporting the characteristics of concrete mixtures in delivery vehicles
09 - Appareils et instruments scientifiques et électriques
Produits et services
(1) System comprising computer hardware, software, and sensors in mobile delivery vehicles for monitoring, reporting, and tracking construction materials, namely concrete mixtures, in the construction industry; a system comprising computer hardware, software, and sensors in mobile delivery vehicles for measuring and reporting the characteristics of concrete mixtures in delivery vehicles.
09 - Appareils et instruments scientifiques et électriques
Produits et services
System comprising computer hardware, software and sensors in mobile delivery vehicles for monitoring, reporting and tracking construction materials in the construction industry; a system comprising computer hardware, software, and sensors in mobile delivery vehicles for measuring and reporting the characteristics of concrete mixtures in delivery vehicles.
09 - Appareils et instruments scientifiques et électriques
Produits et services
System comprising computer hardware, software, and sensors in mobile delivery vehicles for monitoring, reporting, and tracking construction materials in the construction industry; a system comprising computer hardware, software, and sensors in mobile delivery vehicles for measuring and reporting the characteristics of concrete mixtures in delivery vehicles
63.
System for calculating and reporting slump in delivery vehicles
A system for calculating and reporting slump in a delivery vehicle having a mixing drum (14) and hydraulic drive (16) for rotating the mixing drum, including a rotational sensor (20) configured to sense a rotational speed of the mixing drum, a hydraulic sensor (22) coupled to the hydraulic drive and configured to sense a hydraulic pressure required to turn the mixing drum, and a communications port (26) configured to communicate a slump calculation to a status system (28) commonly used in the concrete industry, wherein the sensing of the rotational speed of the mixing drum is used to qualify a calculation of current slump based on the hydraulic pressure required to turn the mixing drum.
The present invention relates to a system for the delivery of concrete, a wireless rotational sensor and a device for determining the rotation of a concrete mixing drum on a concrete delivery truck. The wireless rotational sensor for detecting the rotation of a mixing drum on a concrete delivery vehicle includes an accelerometer mounted to the mixing drum. A wireless transmitter coupled to the accelerometer transmits a signal reflective of rotation of the mixing drum. A wireless receiver receives the signal reflective of drum rotation. A computer processor can also be included, coupled to the accelerometer and wireless transmitter and configured to determine angular motion of the concrete mixing drum from the accelerometer signal. Conversely, the computer can be coupled to the wireless receiver and configured to receive the signal reflective of rotational state from the wireless transmitter and determine angular motion of the concrete mixing drum therefrom.
B60P 3/16 - Véhicules adaptés pour transporter, porter ou comporter des charges ou des objets spéciaux pour porter du mélange de béton, p. ex. avec tambour tournant
G01P 3/00 - Mesure de la vitesse linéaire ou angulaireMesure des différences de vitesses linéaires ou angulaires
65.
METHOD AND SYSTEM FOR CALCULATING AND REPORTING SLUMP IN DELIVERY VEHICLES
A system for calculating and reporting slump in a delivery vehicle having a mixing drum (14) and hydraulic drive (16) for rotating the mixing drum, including a rotational sensor (20) configured to sense a rotational speed of the mixing drum, a hydraulic sensor (22) coupled to the hydraulic drive and configured to sense a hydraulic pressure required to turn the mixing drum, and a communications port (26) configured to communicate a slump calculation to a status system (28) commonly used in the concrete industry, wherein the sensing of the rotational speed of the mixing drum is used to qualify a calculation of current slump based on the hydraulic pressure required to turn the mixing drum.
