Abrégé

A flexible, flat laminar element (1), configured to be shaped so as to define a pot and comprising: a central element (3) of circular shape corresponding to the bottom (Vf) of the pot (V) and at least two side appendages (5; 6) corresponding to the side surface (Ve) of the pot (V), each of which is delimited by a curved lower edge (5a; 6a), a curved upper edge (5e; 6e) and two side edges (5g; 6g) which are placed in contact with each other when the side appendages (5; 6) are raised with respect to the central element (3) and curved. The method for making the pot (V) involves the use of a press (14) and comprises the following operations: positioning the flexible, flat laminar element (1) between a punch (12) and a die (13), penetrating the punch (12) in the die (13) to shape the side surface (Ve) of the pot (V), compressing the bottom (12b) of the punch (12) against a shaping unit (15) to shape the bottom (Vf) of the pot (V), extracting the punch (12) from the die (13) and withdrawing the pot (V).

Classes IPC  ?

• B31B 50/46 - Pliage des feuilles, des flans ou des bandes par des plongeurs se déplaçant dans des matrices de pliage et réunissant les parois latérales
• B65D 3/06 - Réceptacles rigides ou semi-rigides ayant un corps ou des parois périphériques de section transversale courbe ou partiellement courbe, réalisés en enroulant ou courbant du papier sans plier selon des lignes définies caractérisés par la forme essentiellement coniques ou à peu près coniques
• B31B 50/59 - Mise en forme sous pression de matériaux en feuilles
• B31B 110/10 - Forme des réceptacles rigides ou semi-rigides ayant une section transversale variable en taille ou en forme, p. ex. conique ou pyramidale
• B31B 110/20 - Forme des réceptacles rigides ou semi-rigides à section transversale courbe, p. ex. circulaire
• B31B 100/00 - Réceptacles rigides ou semi-rigides fabriqués par pliage de feuilles, de flans ou de bandes d’une seule pièce

Abrégé

The machine (2) for removal and extraction of a lid (L) for paint containers or cans (C) comprises: a centering element (3), adapted to allow properly aligning the machine (2) above the container or can (C); a gripping device (6) adapted to selectively act upon at least two points of a lid (L) of the container (C), being capable of both disengaging the lid (L) from the container (C) and holding the same lid (L); a first moving device (5) adapted to move said gripping device (6) along a vertical axis (Z), between at least one first position, proximal to said centering element (3), and at least one second position, away from said centering element (3); and a support structure (4), fixed to said centering element (3), adapted to support said first moving device (5). The gripping device (6) being adapted to take a first operating configuration, wherein it does not act upon said lid, and a second operating configuration, wherein it is adapted to act upon a protruding portion of the lid (L). The centering element (3) comprises an abutment portion (32) adapted to abut against an upper edge of the outer wall of the container (C), and is adapted to prevent the container (C) from moving, without exerting any pressure force upon said edge, in any operating configuration or spatial arrangement of the gripping device (6).

Classes IPC  ?

• B67B 7/14 - Dispositifs à main ou à moteur pour ouvrir des récipients fermés pour enlever les couvercles ou opercules à fermeture très ajustée, p. ex. des boîtes de cirage, par saisie et rotation

Produits et services

Machines for producing and metering cosmetics, machine tools; Mixers of fluids, powders and solids for industrial use, for flavours, perfumes and colorants, installations for managing dosing, mixing, automation, dosing valves; Motors and engines (except for land vehicles); Machine coupling and transmission components (except for land vehicles); All of the aforesaid goods being in relation to the chemical, ceramics, pharmaceutical and food industries. Electric and/or electronic scientific checking (supervision), measuring, monitoring, control apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Magnetic data carriers, recording discs; Compact discs, DVDs and other digital data carriers; Data processing equipment, computers; Computer software; Dosage dispensers, dosing systems, automatic dispensers, all of the aforesaid goods being related to the chemical, ceramics, pharmaceutical and food industries. Repair, maintenance and installation of machines for producing and metering cosmetics, installations for managing metering, mixing, automation relating to the chemical, ceramic, pharmaceutical and food industries; Painting, interior and exterior. Processing and treatment of varnishes, cosmetics, flavourings, powders, perfumes and colorants relating to the chemical, ceramic, pharmaceutical and food industries.

Produits et services

Rotor stator for slurries of paints and coat.

Produits et services

Machines and machine tools; Mixers of fluids, powders and solids for industrial use, for flavours, perfumes and colorants, installations for managing dosing, mixing, automation, dosing valves; Motors and engines (except for land vehicles); Machine coupling and transmission components (except for land vehicles); Electric apparatus and devices; All of the aforesaid goods being in relation to the chemical, ceramics, pharmaceutical and food industries. Electric and/or electronic scientific checking (supervision), measuring, monitoring, control apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Magnetic data carriers, recording discs; Compact discs, DVDs and other digital data carriers; Data processing equimpent, Computers; Computer software; Colorimeters; Dosage dispensers, dosing systems, automatic dispensers, all of the aforesaid goods being related to the chemical, ceramics, pharmaceutical and food industries. Repair; Installation services; Painting; Mechanical maintenance. Treatment of materials in relation to the chemical, ceramics, pharmaceutical and food industries.
