A method for controlling a wrench (1) includes the steps of providing a calibration association between a screwing torque (M) and a corresponding electric current (I) absorbed by a motor (3) of the wrench (1), selecting a rotation direction of a tool holder shaft (2) of the wrench (1), actuating a motor (3) of the wrench (1), detecting an instantaneous current (I_inst) of the motor (3) during its operation, controlling the power supply of the electric motor (3) depending on the selected rotation direction, a target torque screwing value (M_tgt), the detected instantaneous current (I_inst), and the calibration association, and if the selected rotation direction is a screwing direction, when the detected instantaneous current (I_inst) reaches or exceeds a target current value (I_tgt) corresponding to the target torque value (M_tgt) according to the calibration association, deactivating and/or stopping the motor (3), changing a rotation speed (RPM) of the motor (3) depending on the detected instantaneous current (I_inst), and in a final screwing step in which the detected instantaneous current (I_inst) increases until it reaches the target current value (I_tgt), reducing the rotation speed (RPM) of the motor (3) to a final speed value (RPM_final) lower than an initial speed value (RPM_init) in an initial screwing step.
A portable tool (100) includes a working shaft (2), an electric motor (3), a reducer (6), an electronic control system (7) with an actuation device (5, 5′), a memory (8) in which a calibration association between the working torque or force M of the tool (100) and a corresponding electric current (I) absorbed by the motor (3) is stored, a motor module (14) with its motor housing (15) which houses the electric motor (3) and an electronic motor control board (16), a reducer module (17) with its reducer housing (18) which houses the reducer (6), a handle module (19) with its supporting structure (20) which forms gripping handles (21), a control panel (22) with its panel housing (23) which supports a user interface (10) with a display (24) and a parameter selection member (11), wherein the motor housing (15), the reducer housing (18), the supporting structure (20) and the panel housing (22) are individually self-supporting distinct components reversibly connectable to one another to form the tool (100).
Screwdrivers, electric; cordless electric screwdrivers;
pneumatic nut runners; drills [power tools]; drills,
electric; electric hand drills; cordless electric hand
drills; screwdrivers, pneumatic; ergonomic electric
screwdrivers for the railway sector.
An impact wrench (1) with an upper handle assembly (2), a lower working assembly (3) and an intermediate connecting bar (4) connected between the handle assembly (2) and the working assembly (3) and comprising a tubular body (4′) with a first end portion (15) ( coupled with a first coupling seat (16) of the handle assembly (2) and a second end portion (17) coupled with a second coupling seat (18) of the working assembly (3), wherein the first end portion (15) and the first coupling seat (16) both have a non-circular or polygonal or rectangular or square cross-section, orthogonal to the longitudinal direction (14), so as to make an anti-rotation shape coupling with the interposition of a first damping assembly (24) forming a damping layer between the first end portion (15) and the first coupling seat (16).
B25B 21/02 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts avec des moyens pour communiquer un choc à la tige du tournevis ou à la douille de la clé à écrou
B25B 23/147 - Agencement pour limiter le couple de blocage ou pour indiquer le couple des clés ou des tournevis spécialement adapté aux clés ou tournevis électriques
B25B 23/18 - Dispositifs pour illuminer la tête d'une vis ou d'un écrou
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
Screwdrivers, electric; cordless electric screwdrivers; pneumatic nut runners; drills [power tools]; drills, electric; electric hand drills; cordless electric hand drills; screwdrivers, pneumatic; ergonomic electric screwdrivers for the railway sector
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
Produits et services
electronic label printing machines for commercial use; automatic industrial labeling machines for applying labels to containers and bottles; Industrial printing machines; Printing machines for commercial or industrial use; Typesetting machines Labels carrying magnetically, optically, or electronically recorded or encoded information, machine-readable; Barcode labels, encoded; Wireless portable document printers for use with laptops and mobile devices; document printers for use with computers; Barcode printers Automatic adhesive tape dispensers for office use; Holders for adhesive tapes; holders for adhesive tapes; Marking tabs; Hand-held labelling devices; Office labelling machines; labels of paper or cardboard; Labelling machines for office use; label printers being addressing machines; imprinters for office use; Handheld label printing machines being office requisites; Office requisites, except furniture, namely, correcting tapes, rubber bands, staplers
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
Produits et services
Labellers [machines]; Industrial printing machines; Printing machines; Type-setting machines [printing]. Labels with machine-readable codes; Bar code labels, encoded; Wireless portable printers for use with laptops and mobile devices; Printers for use with computers; Bar code printers. Dispensing machines for adhesive tape; Holders for adhesive tapes; Holders for adhesive tape; Printed tables; Marking tabs; Hand labelling appliances; Office labeling machines; Labels of paper or cardboard; Label dispensing machines for office use; Label printers being addressing machines; Imprinters for office use; Handheld label printers [office requisites]; Ribbons for handheld label printers [office requisites].
A cable lead through device (1) with a framework (3) formed by a base beam (4), an upper beam (6), and lateral uprights (9) extending from the base beam (4) to the upper beam (6) on two opposite lateral sides (34) of the framework (3) to form receiving seats (12), wherein the framework (3) is divided into a first framework part (15) and a second framework part (16) connectable to each other in a closed position to lock cable grommets (19) in the receiving seats (12), wherein the lateral uprights (9) comprise a first base upright (91) and a second base upright (92) protruding from the base beam (4) and forming, together with the base beam (4), a first "U"-shaped receiving seat boundary (22), as well as a first upper upright (93) and a second upper upright (94) protruding from the upper beam (6) and forming, together with the upper beam (6), a second "U"-shaped receiving seat boundary (23), wherein, in the closed position, the first upper upright (93) is accommodated in a first upright seat (95) of the first base upright (91) and the second base upright (92) is accommodated in a second upright seat (96) of the second upper upright (94).
A method for operating a hydrodynamic compression tool (1) comprises moving a compression jaw (9) towards an abutment jaw (8) by actuating a hydraulic pump (18), counting a number (N_p) of pumping strokes of the hydraulic pump (18) from an actuation start of the hydraulic pump (18) when the piston is in the stroke start position (16), identifying a compression start condition (22) when the abutment jaw (8) and the compression jaw (9) both engage the object (11) to be compressed, determining a control parameter or compression completion criterion depending on a pumping stroke number at contact (N_p_c) consisting of the pumping stroke number (N_p) counted up to the occurrence of the compression start condition (22).
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
A cable lead through device (1) comprises a rectangular frame (3) delimiting a plurality of receiving seats (11) to accommodate a plurality of cable gland blocks (16) made of elastomeric material having two first opposite faces (17) facing in a first local direction (18) of the cable gland block (16), two second opposite faces (19) facing in a second local direction (20) of the cable gland block (16), two third opposite faces (21) facing in a third local direction (22) of the cable gland block (16) and intended to face, in the operating position, two lateral sides (9) of the frame (3), respectively, wherein the two second faces (19) of the cable gland block (16) are both planar, parallel to each other and smooth or structured, wherein the two third faces (21) of the cable gland block (16) each form a block coupling surface (25) having a plurality of linear grooves (26) and ribs (27), parallel to one another and parallel to the second local direction (20), wherein the block coupling surfaces (25) or the entire third faces (21) are symmetric to a first local symmetry plane (29) orthogonal to the first local direction (18).
A cable gland block (16) made of elastomeric material having two first opposite faces (17) facing in a first local direction (18) of the cable gland block (16), two opposite second faces (19) facing in a second local direction (20) of the cable gland block (16), two third opposite faces (21) facing in a third local direction (22) of the cable gland block (16) and intended to face, in an operating position, two lateral sides (9), respectively, of a cable lead through device (1), wherein the two second faces (19) of the cable gland block (16) are both planar, parallel to each other and smooth, wherein the two third faces (21) of the cable gland block (16) each form a block coupling surface (25) having a plurality of linear grooves (26) and ribs (27), parallel to one another and parallel to the second local direction (20), wherein the block coupling surfaces (25) or the entire third faces (21) are symmetric to a first local symmetry plane (29) orthogonal to the first local direction (18).
A method for operating a hydrodynamic compression tool (1) comprises moving a compression jaw (9) towards an abutment jaw (8) by actuating the hydraulic pump (18), detecting the pressure (p) of a hydraulic fluid acting on the piston (13), identifying a compression start condition when the abutment jaw (8) and the compression jaw (9) both engage an object (11) to be compressed, detecting the pressure (p) of the hydraulic fluid acting on the piston (13) in a piston advancement step (F1 ) without compression up to the occurrence of the compression start condition, determining a value of compression start position (22) of the piston (13) in the compression start condition, determining an operating parameter or a compression completion criterion depending on the compression start position (22).
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
A work head for or of a compression tool includes a compression jaw and an abutment jaw forming an arched abutment surface having a longitudinal extension arched in a hypothetical arc plane orthogonal to an insertion direction of the object into the abutment seat. The longitudinal extension has a first side segment, a second side segment opposite to the first side segment, and an apex segment in the shape of a neck extending between the first side segment and the second side segment, and an abutment width measurable in the insertion direction and orthogonal to the arc plane. The abutment width decreases from a first base width of the first side segment to an apex width of the apex segment. The abutment width decreases from a second base width of the second side segment to the apex width of the apex segment.
B21D 39/04 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des tubesUtilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des barres
A method for controlling a wrench (1) includes the steps of providing a calibration association between a screwing torque (M) and a corresponding electric current (I) absorbed by a motor (3) of the wrench (1), selecting a rotation direction of a tool holder shaft (2) of the wrench (1), actuating a motor (3) of the wrench (1), detecting an instantaneous current (I_inst) of the motor (3) during its operation, controlling the power supply of the electric motor (3) depending on the selected rotation direction, a target torque screwing value (M_tgt), the detected instantaneous current (I_inst), and the calibration association, and if the selected rotation direction is a screwing direction, when the detected instantaneous current (I_inst) reaches or exceeds a target current value (I_tgt) corresponding to the target torque value (M_tgt) according to the calibration association, deactivating and/or stopping the motor (3), changing a rotation speed (RPM) of the motor (3) depending on the detected instantaneous current (I_inst), and in a final screwing step in which the detected instantaneous current (I_inst) increases until it reaches the target current value (I_tgt), reducing the rotation speed (RPM) of the motor (3) to a final speed value (RPM_final) lower than an initial speed value (RPM_init) in an initial screwing step.
A portable tool (100) includes a working shaft (2), an electric motor (3), a reducer (6), an electronic control system (7) with an actuation device (5, 5'), a memory (8) in which a calibration association between the working torque or force M of the tool (100) and a corresponding electric current (I) absorbed by the motor (3) is stored, a motor module (14) with its motor housing (15) which houses the electric motor (3) and an electronic motor control board (16), a reducer module (17) with its reducer housing (18) which houses the reducer (6), a handle module (19) with its supporting structure (20) which forms gripping handles (21), a control panel (22) with its panel housing (23) which supports a user interface (10) with a display (24) and a parameter selection member (11), wherein the motor housing (15), the reducer housing (18), the supporting structure (20) and the panel housing (22) are individually self- supporting distinct components reversibly connectable to one another to form the tool (100).
An impact wrench motor unit includes a motor and an operating switch. A tool-holder shaft rotates about a rotation axis. A transmission unit percussion mechanism connects the motor unit and the tool-holder shaft. A handlebar structure has two handles for manually gripping the wrench. An electronic control system, containing a control board, connected to electric batteries and the operating switch. The electric motor is simultaneously powered by rechargeable batteries connected in parallel. The control system includes a device for generating three-phase current to the motor, utilizing a first battery generating a first phase, a second battery generating a second phase, and both the first and second batteries for generating a third phase. A ratio of contributions of the first and second batteries to the third phase generation depends on the residual charge state of the batteries. The least charged battery contributes less than the most charged battery.
B25B 21/02 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts avec des moyens pour communiquer un choc à la tige du tournevis ou à la douille de la clé à écrou
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
H02K 7/14 - Association structurelle à des charges mécaniques, p. ex. à des machines-outils portatives ou des ventilateurs
An impact wrench includes a motor producing rotary motion and a motor operating switch. A tool-holder shaft is rotatable about a rotation axis. A transmission unit with a percussion mechanism connects between the motor and the tool-holder shaft. A handlebar structure has two manual gripping handles. An electronic control system contains an electronic control board connected to electric batteries and the operating switch. A motor cooling fan conveys air along the motor. The motor is housed in a motor compartment of the main housing and a heat-sensitive part of the electronic control system, containing an electronic control board housed inside a protected compartment of the main housing. The protected compartment borders directly on the motor compartment and is separated from the motor compartment by a metal radiator directly facing the motor compartment and in heat exchange relation with the heat-sensitive part of the electronic control system.
B25B 21/02 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts avec des moyens pour communiquer un choc à la tige du tournevis ou à la douille de la clé à écrou
B25B 23/147 - Agencement pour limiter le couple de blocage ou pour indiquer le couple des clés ou des tournevis spécialement adapté aux clés ou tournevis électriques
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
An impact wrench includes a motor unit with a motor adapted to produce a rotary motion and an operating switch for operating the motor. A tool-holder shaft rotatable about a rotation axis. A transmission unit with a percussion mechanism, connects between the motor unit and the tool-holder shaft. A handlebar structure has two manual gripping handles. An electronic control system contains at least one electronic control board connected to one or more electric batteries and to the operating switch. A damping connection system mechanically connects a transmission housing of the transmission unit to a main housing of the motor unit and the main housing to the handlebar structure. The damping connection system includes: one or more first damper elements interposed between the transmission housing and the main housing, and one or more second damper elements interposed between the main housing and the handlebar structure.
B25B 21/02 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts avec des moyens pour communiquer un choc à la tige du tournevis ou à la douille de la clé à écrou
B25B 21/00 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts
B25B 23/147 - Agencement pour limiter le couple de blocage ou pour indiquer le couple des clés ou des tournevis spécialement adapté aux clés ou tournevis électriques
09 - Appareils et instruments scientifiques et électriques
Produits et services
Plastic conduit for electric cables for electrical use; Junction sleeves for electric cables; Sheaths for electric cables; Ducting for
electric cables; Cable adapters; Cables, electric; Materials for electricity mains, namely, copper, aluminum, and steel.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Conduit for electric cables; Junction sleeves for electric cables; Sheaths for electric cables; Ducting for electric cables; Cable adapters; Cables, electric; Materials for electricity mains [wires, cables].
09 - Appareils et instruments scientifiques et électriques
Produits et services
Batteries, electric, for vehicles; Battery chargers; Battery chargers; Battery charging devices for motor vehicles; Electric car charging piles; Electric batteries for powering electric vehicles; Computer software for mobile applications that enable interaction and interface between vehicles and mobile devices; apparatus, instruments and cables for controlling electricity; Electrical devices, namely, Charging stations for electric vehicles; computer hardware and communications servers for monitoring and managing electrical charging stations and networks; meters for electrical monitoring; computer hardware and software for charging EV batteries; communications software for monitoring and managing electrical charging stations and networks; Computer hardware and software for monitoring, optimising and regulating the storage, transmission and discharge of energy to or from an electric battery system; computer hardware and software for processing financial payments for electricity; Mobile apps.
An impact wrench (1) comprises a motor unit (3) with a motor (3') adapted to produce a rotary motion and an operating switch (5) for operating the motor (3'), a tool-holder shaft (2) rotatable about a rotation axis (R), a transmission unit (6) with a percussion mechanism (7), connected between the motor unit (3) and the tool-holder shaft (2), a handlebar structure (14) with two gripping handles (9, 10) for manually gripping the wrench (1 ), an electronic control system (27), containing at least one electronic control board, connected to one or more electric batteries (4) and to the operating switch (5), a damping connection system (12), which mechanically connects a transmission housing (13) of the transmission unit (6) to a main housing (15) of the motor unit (3) and the main housing (15) to the handlebar structure (14) and which comprises: - one or more first damper elements (16) interposed between the transmission housing (13) and the main housing (15), and - one or more second damper elements (17) interposed between the main housing (15) and the handlebar structure (14).
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
B25F 5/02 - Structure des boîtiers, corps ou poignées
B25B 21/02 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts avec des moyens pour communiquer un choc à la tige du tournevis ou à la douille de la clé à écrou
An impact wrench (1) comprises a motor unit (3) with a motor (3') adapted to produce a rotary motion and an operating switch (5) for operating the motor (3'), a tool-holder shaft (2) rotatable about a rotation axis (R), a transmission unit (6) with a percussion mechanism (7) connected between the motor unit (3) and the tool-holder shaft (2), a handlebar structure (14) with two gripping handles (9, 10) for manually gripping the wrench (1 ), an electronic control system (27), containing at least one electronic control board, connected to one or more electric batteries (4) and to the operating switch (5), a cooling fan (30) for the motor (3') for conveying the air along the motor (3'), wherein the motor (3') is housed in a motor compartment (32) of the main housing (15) and at least a heat-sensitive part of the electronic control system (27), containing at least one electronic control board, is housed inside a protected compartment (33) of the main housing (15), wherein the protected compartment (33) borders directly on the motor compartment (32) and is separated from the motor compartment (32) by means of a metal radiator (35) directly facing into the motor compartment (32) and in heat exchange relation with the heat-sensitive part of the electronic control system (27) in the protected compartment (33).
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
B25F 5/02 - Structure des boîtiers, corps ou poignées
B25B 21/02 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts avec des moyens pour communiquer un choc à la tige du tournevis ou à la douille de la clé à écrou
An impact wrench (1) comprises a motor unit (3) with a motor (3') adapted to produce a rotary motion and an operating switch (5) for operating the motor (3'), a tool-holder shaft (2) rotatable about a rotation axis (R), a transmission unit (6) with a percussion mechanism (7), connected between the motor unit (3) and the tool-holder shaft (2), a handlebar structure (14) with two gripping handles (9, 10) for manually gripping the wrench (1), an electronic control system (27), containing at least one electronic control board, connected to one or more electric batteries (4) and to the operating switch (5), wherein the electric motor (3') is simultaneously powered by two rechargeable batteries (4), connected in parallel to each other and housed together in the main housing (15), wherein the electronic control system (27) comprises a device for generating the current supplied to the motor (3'), configured to utilize a first battery (4') of the batteries (4) for generating a first phase of a three-phase current, a second battery (4'') of the batteries (4) for generating a second phase of the three-phase current, and both the first and second batteries (4', 4'') for generating a third-phase of the three-phase current, wherein the ratio of the contributions of the first battery (4') and second battery (4'') to the generation of the third phase is determined depending on the residual charge state of the batteries (4', 4''), wherein the least charged battery (4', 4'') contributes less to the generation of the third phase than the most charged battery (4'', 4').
B25B 21/02 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts avec des moyens pour communiquer un choc à la tige du tournevis ou à la douille de la clé à écrou
B25F 5/02 - Structure des boîtiers, corps ou poignées
A shear bolt for a junction of electrical conductors includes a tool seat for engagement of the shear bolt by a screwing tool, an externally threaded portion to be screwed in a terminal body of the junction, along a screwing axis, and a tightening portion for engaging an electrical conductor to be tightened in the terminal body. The tool seat is formed at the threaded portion and the tightening portion is connected to the threaded portion on an opposite side with respect to the tool seat. The shear bolt can be sheared in one or more programmed rupture areas in the threaded portion when exceeding a predetermined tightening torque for each of the programmed rupture areas, respectively. Even with the screw unscrewed, the tightening portion is connected to the threaded portion and is rotatable with respect to the threaded portion about the screwing axis and non-detachable from the threaded portion.
F16B 31/02 - Assemblages à vis spécialement modifiés en vue de résister à une charge de tractionBoulons de rupture signalant ou limitant la charge de traction
F16B 35/00 - Boulons filetésBoulons d'ancrageGoujons filetésVisVis de pression
F16B 37/14 - Écrous-chapeauxChapeaux d'écrous ou de boulons
H01R 4/36 - Conducteurs logés sous l'extrémité d'une vis
A hand-held tool (1) manually operable to compress or cut, the tool (1) being elongated bar-shaped or gun-shaped and including a casing (2) forming a grip portion, a motor (3) supported by the casing (2), a reduction and conversion mechanism (5) supported by the casing (2) and connected to the motor (3) and to an actuating member (6). The reduction and conversion mechanism (5) is configured to make the actuating member (6) translate along an actuating axis (7) in response to a rotational motion of the motor (3). A working head (8), connected to the casing (2), interacts with the actuating member (6) so that the working head (8) performs a compression or cutting movement in response to the translation of the actuating member (6). The reduction and conversion mechanism (5) has a conversion mechanism (9) with a planetary roller screw (10, 12, 14).
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
B23D 29/00 - Dispositifs à main pour le cisaillage ou le découpage des métaux
F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes
F16H 57/08 - Parties constitutives générales des transmissions des transmissions à organes à mouvement orbital
F16H 25/24 - Éléments essentiels pour ces mécanismes, p. ex. vis, écrous
36.
System for spiking, i.e. exploring voltage, in electric cables
A system (1) for spiking, i.e. exploring voltage, in electric cables (5) comprises a first clamping jaw (3) and a second clamping jaw (4) to lock a portion of an electric cable (5) in a clamping position (7), an elongated metal blade (8) which can be displaced between a retracted position and an extended position in the clamping position (7), a hydraulic actuator (9) to displace the blade (8), with respect to the first and second clamping jaws (3, 4), from the retracted position into the extended position, a pump (10) adapted to increase the pressure of a hydraulic liquid acting on the hydraulic actuator (9), a hand-held remote control (12) for remotely actuating and controlling the pump (10), wireless actuation communication means (13) adapted to provide pump actuation signals from the remote control (12) to the pump (10).
F15B 15/28 - Moyens pour indiquer la position, p. ex. fin de course
G01R 19/145 - Indication de l'existence d'un courant ou d'une tension
H01R 4/2406 - Connexions utilisant des organes de contact pénétrant dans, ou transperçant, l'isolation ou les brins du câble les organes de contact étant munis de dents, de fourchons, de broches ou d’aiguilles pénétrant dans l’isolation étant munis d’aiguilles ou de broches
A drill (1) for drilling railway sleepers comprises a support structure (2), a motor unit (3) supported by the support structure (2), a handle (4) connected to the support structure (2), at least one control member (5) arranged at the handle (4) for actuating the motor (3), a spindle (7) supported by the support structure (2) and operable by the motor (3), to rotate about a spindle axis (16), wherein a drilling tip (8) can be coupled to said spindle, a protective casing (11) connected to the support structure (2) and sliding in the direction of the spindle axis (16) between an axially protracted position, in which it envelops the tip (8) and an axially retracted position, in which the tip (8) protrudes from the protective casing (11), wherein the handle (4) comprises two gripping portions (36, 37), for the user's two hands, situated on two diametrically opposite sides of the drill (1) with respect to the spindle axis (16), and the motor unit (3) comprises an electric motor which can be powered by means of a rechargeable and replaceable battery (6).
A working head (1) for a compression or cutting tool (100) comprises a connecting portion (3) for a removable connection of the working head (1) with an actuation part (2) of the tool (100), two jaws (4) movable between an open position and a closed position to perform the compression or cutting, and a local storage (6) configured for storing one or more cumulative data representative of a stress history of the jaws (4), wherein the local storage (6) is fixed to the working head (1).
B25F 3/00 - Associations d'outils pour différents travaux avec un seul moyen d'entraînement mécanique portatifRaccords appropriés
B21D 39/04 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des tubesUtilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des barres
B23D 29/00 - Dispositifs à main pour le cisaillage ou le découpage des métaux
B25B 27/02 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
A shear bolt (1) for a junction (2) of electrical conductors (3), comprises a tool seat (4) for the engagement of the shear bolt (1) by means of a screwing tool, an externally threaded portion (5) intended to be screwed in a terminal body (6) of the junction (2), along a screwing axis (7), a tightening portion (8) intended to engage an electrical conductor (3) to be tightened in the terminal body (6), wherein the tool seat (4) is formed at the threaded portion (5) and the tightening portion (8) is connected to the threaded portion (5) on an opposite side with respect to the tool seat (4), wherein the shear bolt (1) can be sheared in one or more programmed rupture areas (9, 9', 9'') in the threaded portion (5) when exceeding a predetermined tightening torque for each of the programmed rupture areas (9, 9', 9''), respectively, wherein, even with the screw (1) unscrewed, the tightening portion (8) is connected to the threaded portion (5) so as to be able to rotate with respect to the threaded portion (5) about the screwing axis (7) and so as to be non-detachable from the threaded portion (5).
H01R 4/36 - Conducteurs logés sous l'extrémité d'une vis
F16B 31/02 - Assemblages à vis spécialement modifiés en vue de résister à une charge de tractionBoulons de rupture signalant ou limitant la charge de traction
A rail tool-holder cart (1) comprises a “T”-shaped support frame (2), a tool-holder arm, (12) rotatable about a vertical axis and tiltable between an upper position and a lower position and having a coupling interface for a tool (17, 17′), a spring (19), which pushes the tool-holder arm permanently towards the upper position, so as to compensate at least one part of the weight of the tool (17, 17′), as well as adjustment means (20) for adjusting the spring thrust (19).
E01B 31/04 - Sectionnement ou entaillage, p. ex. par sciage, cisaillement, coupe au chalumeau
E01B 31/24 - Perçage, traitement, remise en état ou nettoyage des trous dans les traversesGabarits de perçage
B61D 15/00 - Autres véhicules ferroviaires, p. ex. véhicules à échafaudageAdaptation des véhicules pour leur utilisation sur voies ferrées
E01B 11/46 - Méthodes générales pour la réalisation de voies continues
E01B 29/16 - Transport, pose, enlèvement, ou remplacement des railsDéplacement des rails placés sur traverses dans la voie
E01B 31/18 - Remise en état ou réparation sur place de parties usagées ou endommagées, p. ex. application de pièces intercalées, reconstruction des rails par soudageChauffage ou refroidissement sur place des parties, p. ex. pour réduire les intervalles des joints, pour durcir les rails
42.
METHOD OF OPERATING A HYDRODYNAMIC COMPRESSION TOOL AND HYDRODYNAMIC COMPRESSION TOOL
A hydrodynamic compression tool comprises a motor which actuates a hydrodynamic group suitable to increase the pressure of a hydraulic fluid acting on an actuation piston connected to jaws, an electronic control system connected to the electric motor and to a user operating member for the actuation of the electric motor. An identification detector in connection with the control circuit detects an identification characteristic of the jaws or inserts housed in the jaws or of an object to be compressed or cut.
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
B21D 39/04 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des tubesUtilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des barres
B25B 27/02 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
B23D 29/00 - Dispositifs à main pour le cisaillage ou le découpage des métaux
A hand-held tool (1) manually operable to compress or cut, said tool (1) being elongated bar- shaped or gun-shaped and comprising: - a casing (2) which forms a grip portion, - a motor (3) supported by the casing (2), - a reduction and conversion mechanism (5) supported by the casing (2) and connected to the motor (3) and to an actuating member (6), wherein the reduction and conversion gear (5) is configured to make the actuating member (6) translate along an actuating axis (7) in response to a rotational motion of the motor (3), - a working head (8) connected to the casing (2) and which interacts with the actuating member (6) so that the working head (8) performs a compression or cutting movement in response to the translation of the actuating member (6), wherein the reduction and conversion mechanism (5) comprises a conversion mechanism (9) with a planetary roller screw (10, 12, 14).
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
B23D 17/04 - Machines à cisailler ou dispositifs de cisaillage taillant au moyen de lames articulées sur un seul axe caractérisés par leur entraînement ou transmission commandés par un arbre rotatif
F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes
44.
HYDRODYNAMIC TOOL FOR THE AXIAL COMPRESSION OF TUBE CONNECTIONS
A hydrodynamic tool (1) for the axial compression of connection devices (100) for tubes comprises an electrohydraulic pump (2) with a pump body (3) forming a handle (4) for manually gripping the tool (1) and an operating button (5) for operating the pump (2) arranged on an operating side (6) of the pump body (3), a compression head (7) with a head body (8) connected to the pump body (3) and a hydraulic actuator (9) supported by the head body (8), which can be operated by the electrohydraulic pump (3), in which the head body (8) supports compression jaws protruding towards a compression side (15), in which the head body (8) is connected so as to be able to rotate with respect to the pump body (3) to allow orientation of the compression side (15) with respect to the operating side (6) of the tool (1).
B21D 39/00 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
B25F 5/02 - Structure des boîtiers, corps ou poignées
B25B 27/02 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
45.
SYSTEM FOR SPIKING, I.E. EXPLORING VOLTAGE, IN ELECTRIC CABLES
A system (1) for spiking, i.e. exploring voltage, in electric cables (5) comprises a first clamping jaw (3) and a second clamping jaw (4) to lock a portion of an electric cable (5) in a clamping position (7), an elongated metal blade (8) which can be displaced between a retracted position and an extended position in the clamping position (7), a hydraulic actuator (9) to displace the blade (8), with respect to the first and second clamping jaws (3, 4), from the retracted position into the extended position, a pump (10) adapted to increase the pressure of a hydraulic liquid acting on the hydraulic actuator (9), a hand-held remote control (12) for remotely actuating and controlling the pump (10), wireless actuation communication means (13) adapted to provide pump actuation signals from the remote control (12) to the pump (10).
G01R 19/145 - Indication de l'existence d'un courant ou d'une tension
H01R 4/2404 - Connexions utilisant des organes de contact pénétrant dans, ou transperçant, l'isolation ou les brins du câble les organes de contact étant munis de dents, de fourchons, de broches ou d’aiguilles pénétrant dans l’isolation
A drill (1) for drilling railway sleepers comprises a support structure (2), a motor unit (3) supported by the support structure (2), a handle (4) connected to the support structure (2), at least one control member (5) arranged at the handle (4) for actuating the motor (3), a spindle (7) supported by the support structure (2) and operable by the motor (3), to rotate about a spindle axis (16), wherein a drilling tip (8) can be coupled to said spindle, a protective casing (11) connected to the support structure (2) and sliding in the direction of the spindle axis (16) between an axially protracted position, in which it envelops the tip (8) and an axially retracted position, in which the tip (8) protrudes from the protective casing (11), wherein the handle (4) comprises two gripping portions (36, 37), for the user's two hands, situated on two diametrically opposite sides of the drill (1) with respect to the spindle axis (16), and the motor unit (3) comprises an electric motor which can be powered by means of a rechargeable and replaceable battery (6).
A rail tool-holder cart (1) comprises a "T"-shaped support frame (2), a tool-holder arm, (12) rotatable about a vertical axis and tiltable between an upper position and a lower position and having a coupling interface for a tool (17, 17'), a spring (19), which pushes the tool-holder arm permanently towards the upper position, so as to compensate at least one part of the weight of the tool (17, 17'), as well as adjustment means (20) for adjusting the spring thrust (19).
A working head (1) for a compression or cutting tool (100) comprises a connecting portion (3) for a removable connection of the working head (1) with an actuation part (2) of the tool (100), two jaws (4) movable between an open position and a closed position to perform the compression or cutting, and a local storage (6) configured for storing one or more cumulative data representative of a stress history of the jaws (4), wherein the local storage (6) is fixed to the working head (1).
A working head for a hydrodynamic cutting tool includes a working head, an electro-hydraulic pump adapted to increase the pressure of a hydraulic liquid, and a pressure tube connected between the pump and the working head to communicate the pressure of the hydraulic liquid from the pump to the working head. The working head may be removably connectable to the pressure tube and includes two jaws movable, in response to the increase of the hydraulic liquid pressure, between an open position and a closed position to perform the cutting. A cutting detector may be used to detect the completion of the cutting. A cutting confirmation transmitter may be connected to the cutting detector and configured for a wireless transmission of a cutting completion confirmation signal to a cutting confirmation receiver of the cutting tool.
B23D 29/00 - Dispositifs à main pour le cisaillage ou le découpage des métaux
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
H02G 1/00 - Méthodes ou appareils spécialement adaptés à l'installation, entretien, réparation, ou démontage des câbles ou lignes électriques
B23D 36/00 - Agencements de commande spécialement adaptés aux machines de cisaillage ou machines de coupe analogues, ou aux machines à scier, pour produits bruts se déplaçant autrement que dans la direction de la coupe
B23D 17/06 - Machines à cisailler ou dispositifs de cisaillage taillant au moyen de lames articulées sur un seul axe caractérisés par leur entraînement ou transmission commandés hydrauliquement ou pneumatiquement
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
F15B 11/08 - Systèmes de servomoteurs dépourvus d'asservissement avec un seul servomoteur
Portable work equipment (30) comprises a portable tool (1) and a portable electronic device (32) with global positioning means (34), in which the portable tool transmits to the electronic device (32) in real time and in wireless manner identification data of the portable tool (1) and data representative of a set of parameters of a work cycle, in which the electronic device (32) generates traceability data-sets by associating to each set of parameters of the work cycle a unique identification code for the portable tool (1), the global positioning coordinates of the portable electronic device (32) and the time of receipt of the set of parameters of the work cycle, and transmits these traceability data-sets to a central database (36) which is remotely accessible provided that the distance between the portable tool (1) and the electronic device (32) is less than a predetermined maximum allowed distance.
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
H01R 43/04 - Appareils ou procédés spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation de connecteurs de lignes ou de collecteurs de courant ou pour relier les conducteurs électriques pour établir des connexions par déformation, p. ex. outil à plier
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
H02G 1/00 - Méthodes ou appareils spécialement adaptés à l'installation, entretien, réparation, ou démontage des câbles ou lignes électriques
B23D 29/00 - Dispositifs à main pour le cisaillage ou le découpage des métaux
A hydrodynamic compression or cutting tool comprises a housing, an electric motor arranged in the housing and having a motor rotational axis, a gripping portion formed by the housing and extending around the motor and along the motor rotational axis, a hydraulic pump arranged inside the housing and which can be driven by the motor so as to move a actuating piston along a actuating axis, a transmission mechanism arranged inside the housing between the motor and the hydraulic pump, two jaws connected to the housing and to the actuating piston, and which can be moved between an open position and a closed position for carrying out the compression or cut, wherein the actuating axis and the motor rotational axis are reciprocally parallel and offset.
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
B25B 27/02 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher
H02G 1/00 - Méthodes ou appareils spécialement adaptés à l'installation, entretien, réparation, ou démontage des câbles ou lignes électriques
B23D 29/00 - Dispositifs à main pour le cisaillage ou le découpage des métaux
A hydrodynamic compression tool comprises an electrical motor, which can be powered by a control circuit, a hydraulic pump which can be actuated by the motor so as to increase the pressure of a hydraulic liquid acting on an actuating piston, two jaws, which can be mutually moved by the actuating piston between an open position and a closed position for carrying out the compression or the cut, an actuating button, which acts on a switch of the control circuit to actuate the motor, a return device which returns the jaws to the open position by a return of the hydraulic fluid from the actuating piston towards the hydraulic pump through a return valve, and a mechanism for delaying the opening of the return valve via the return device, so as to allow verification of the position of the jaws before the return of the jaws to the open position.
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
F15B 11/08 - Systèmes de servomoteurs dépourvus d'asservissement avec un seul servomoteur
B23D 29/00 - Dispositifs à main pour le cisaillage ou le découpage des métaux
F15B 13/04 - Dispositifs de distribution ou d'alimentation du fluide caractérisés par leur adaptation à la commande de servomoteurs pour utilisation avec un servomoteur unique
F15B 20/00 - Dispositions propres à la sécurité pour systèmes de manœuvre utilisant les fluidesUtilisation des dispositifs de sécurité dans les systèmes de manœuvre utilisant des fluidesMesures d'urgence pour les systèmes de manœuvre utilisant des fluides
H02K 7/14 - Association structurelle à des charges mécaniques, p. ex. à des machines-outils portatives ou des ventilateurs
B23D 15/14 - Machines à cisailler ou dispositifs de cisaillage taillant au moyen de lames se déplaçant parallèlement les unes par rapport aux autres caractérisés par leur entraînement ou transmission commandés hydrauliquement ou pneumatiquement
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
A device for coupling and centering tools has a tubular portion with a coupling seat laterally delimited by a cylindrical centering surface, a first threaded hole with a first tightening dowel projecting into the coupling seat, a second threaded hole with a second tightening end projecting into the coupling seat, a third hole tangential to the centering surface and a locking pin removably lockable in the third hole in a position interfering with the coupling seat, and removable from the third hole to free the coupling seat.
B23B 31/107 - Caractérisés par les dispositifs de maintien ou de serrage ou par leurs moyens d'action directe le maintien étant assuré par des éléments d'arrêt agissant latéralement, p. ex. doigts, écrous, clavettesCaractérisés par les dispositifs de maintien ou de serrage ou par leurs moyens d'action directe le maintien étant assuré par éléments mobiles, p. ex. des billes
B23B 31/113 - Caractérisés par les dispositifs de maintien ou de serrage ou par leurs moyens d'action directe le maintien étant assuré par liaison du type à baïonnette
F16D 1/08 - Accouplements pour établir une liaison rigide entre deux arbres coaxiaux ou d'autres éléments mobiles d'une machine pour montage d'un organe sur un arbre ou à l'extrémité d'un arbre avec moyeu de serrageAccouplements pour établir une liaison rigide entre deux arbres coaxiaux ou d'autres éléments mobiles d'une machine pour montage d'un organe sur un arbre ou à l'extrémité d'un arbre avec moyeu et clavette longitudinale
A cutting or compression tool comprises a housing and a driving group for moving a driving piston with respect to the housing, a fixed jaw with a first connecting seat and a second connecting seat for a stationary connection to the housing, a mobile jaw with a first fulcrum seat hinged to the fixed jaw at the second connecting seat and a second fulcrum seat hinged to a first connecting plate connected to the driving piston. The distance between the first connecting seat and the second connecting seat of the fixed jaw is equal to the distance between the first fulcrum seat and the second fulcrum seat of the mobile jaw.
B26D 5/12 - Moyens pour actionner l'outil de coupe afin d'effectuer la coupe au moyen de la pression d'un fluide
H02G 1/00 - Méthodes ou appareils spécialement adaptés à l'installation, entretien, réparation, ou démontage des câbles ou lignes électriques
B26B 27/00 - Outils coupants à main non prévus dans les groupes , p. ex. bagues pour couper la ficelle, dispositifs de coupe au moyen de fils métalliques
B26D 5/08 - Moyens pour actionner l'outil de coupe afin d'effectuer la coupe
56.
Method of operating a hydrodynamic compression tool and hydrodynamic compression tool
A hydrodynamic compression tool (1) comprises a motor (6) which actuates a hydrodynamic group (11) suitable to increase the pressure of a hydraulic fluid acting on an actuation piston (12) connected to jaws (13, 14), an electronic control system (9) connected to the electric motor (6) and to a user operating member (7) for the actuation of the electric motor (6) wherein the control system (9) monitors the reaching of a closed position of the jaws (13, 14) and switches off the motor (6) automatically upon reaching the closed position.
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
B21D 39/04 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des tubesUtilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des barres
B25B 27/02 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
B23D 29/00 - Dispositifs à main pour le cisaillage ou le découpage des métaux
Portable work equipment (30) comprises a portable tool (1) and a portable electronic device (32) with global positioning means (34), in which the portable tool transmits to the electronic device (32) in real time and in wireless manner identification data of the portable tool (1) and data representative of a set of parameters of a work cycle, in which the electronic device (32) generates traceability data-sets by associating to each set of parameters of the work cycle a unique identification code for the portable tool (1), the global positioning coordinates of the portable electronic device (32) and the time of receipt of the set of parameters of the work cycle, and transmits these traceability data- sets to a central database (36) which is remotely accessible provided that the distance between the portable tool (1) and the electronic device (32) is less than a predetermined maximum allowed distance.
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
B21D 39/04 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des tubesUtilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des barres
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
An apparatus (1) for drilling railway rails (2) comprises a supporting portion (8) supporting a battery operable electrical motor (3), a drilling tool (4) defining a tool axis (5) and a drilling direction (12), a reduction gear (6) interposed between the motor (3) and the drilling tool (4), a replaceable battery (7) and means (13) for removably fastening the supporting portion (8) to an object to be drilled, as well as a lighting system (14) having two light sources (15, 16) spaced from each other and arranged on two opposite sides with respect to a theoretical vertical working plane (17) containing the tool axis (5), wherein the two light sources (14, 15) generate two light cones at least partially overlapping in a drilling area (18) of the drilling tool (4).
Seaming machines; Couplings for machines; Compressing machines; Stapling presses [other than for surgical or stationery use]; Metal forming machines; Machines, tools and apparatus for fastening and joining; Electric jacks; hydraulic presses [for metalworking]; Power operated tools; Power operated tools; Hydraulic tools; Portable electric power tools; Hydraulic tools; Hand-held tools, other than hand-operated; Hand-held tools, other than hand-operated; Hand-held tools, other than hand-operated; Machine tools; electrically operated tools; Oleo-dynamic or mechanical compression tools, battery-operated, and related accessories, namely replaceable jaws. Hand tools and implements (hand-operated); Oleo-dynamic or mechanical compression tools, hand-operated, and related accessories, namely replaceable jaws.
61.
METHOD OF OPERATING A HYDRODYNAMIC COMPRESSION TOOL AND HYDRODYNAMIC COMPRESSION TOOL
A hydrodynamic compression tool (1) comprises a motor (6) which actuates a hydrodynamic group (11) suitable to increase the pressure of a hydraulic fluid acting on an actuation piston (12) connected to jaws (13, 14), an electronic control system (9) connected to the electric motor (6) and to a user operating member (7) for the actuation of the electric motor (6) wherein the control system (9) monitors the reaching of a closed position of the jaws (13, 14) and switches off the motor (6) automatically upon reaching the closed position.
B25B 27/02 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher
B25B 28/00 - Outils portatifs à moteur pour assembler ou séparer
B25F 5/00 - Détails ou parties constitutives d'outils portatifs à moteur sans relation spécifique avec les opérations exécutées et non prévus ailleurs
B21D 39/04 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des tubesUtilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des barres
B25B 27/14 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher
A machine (1) for the application of connecting fasteners (2) of a rail (3) to a railway tie (4) comprising a thrust assembly (8) with a thrust member (9) to engage the connecting fastener (2) and an oleo-dynamic actuator (10) for moving the thrust member (9), an actuating assembly (14) with an internal combustion engine (15) and an oleo-dynamic pump (16) to actuate the oleo-dynamic actuator (10), an adjusting device (20) of an accelerator (21) of the engine (15), which automatically adjusts the number of revolutions of the engine (15) depending on the actuation of the oleo-dynamic actuator (10).
E01B 29/24 - Fixation ou enlèvement des moyens d'attache démontables ou des accessoires pour ceux-ciAssemblage préalable d'éléments de la voie par des moyens d'attache démontables
F02D 41/02 - Dispositions de circuits pour produire des signaux de commande
F02D 29/04 - Commande de moteurs, cette commande étant particulière aux dispositifs entraînés, ces dispositifs étant autres que des organes ou accessoires essentiels à la marche du moteur, p. ex. commande de moteur par des signaux extérieurs particulière aux moteurs entraînant des pompes
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
Produits et services
Machines and machine tools; motors and engines (except for
land vehicles); machine coupling and transmission components
(except for land vehicles); agricultural implements other
than hand-operated; incubators for eggs; power tools; pumps;
electric pumps; drills; automatic cutting machines for
rails; pandrol clip machines; parts and fittings for all the
aforesaid goods; automatic vending machines. Hand tools and implements (hand operated); cutlery; forks
and spoons; side arms; razors; hand pumps; hand-operated
cutting tools for rails; parts and fittings for aforesaid
goods. Scientific, nautical, surveying, photographic,
cinematographic, optical, weighing, measuring, signalling,
checking (supervision), life-saving and teaching apparatus
and instruments; apparatus and instruments for conducting,
switching, transforming, accumulating, regulating or
controlling electricity; apparatus for recording,
transmission or reproduction of sound or images; magnetic
data carriers, recording discs; mechanisms for coin-operated
apparatus; cash registers; calculating machines; computers;
fire-extinguishing apparatus; computer programmes, recorded;
pressure gauges; electrical connectors; printers; thermal
transfer printers; plotters; parts and fittings for all the
aforesaid goods. Paper, cardboard and goods made from these materials, not
included in other classes; printed matter; bookbinding
material; photographs; stationery; adhesives for stationery
or household purposes; artists' materials; paint brushes;
typewriters and office requisites (except furniture);
instructional and teaching material (except apparatus);
plastic materials for packaging (not included in other
classes); printers' type; printing blocks; labels; adhesive
labels; industrial sealing products, including tapes,
adhesives, tags, markers, films for thermal printing.
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
Produits et services
Machines and machine tools; motors and engines (except for
land vehicles); machine coupling and transmission components
(except for land vehicles); agricultural implements other
than hand-operated; incubators for eggs; power tools; pumps;
electric pumps; drills; automatic cutting machines for
rails; pandrol clip machines; parts and fittings for all the
aforesaid goods; automatic vending machines. Hand tools and implements (hand operated); cutlery; forks
and spoons; side arms; razors; hand pumps; hand-operated
cutting tools for rails; parts and fittings for aforesaid
goods. Scientific, nautical, surveying, photographic,
cinematographic, optical, weighing, measuring, signalling,
checking (supervision), life-saving and teaching apparatus
and instruments; apparatus and instruments for conducting,
switching, transforming, accumulating, regulating or
controlling electricity; apparatus for recording,
transmission or reproduction of sound or images; magnetic
data carriers, recording discs; mechanisms for coin-operated
apparatus; cash registers; calculating machines; computers;
fire-extinguishing apparatus; computer programmes, recorded;
pressure gauges; electrical connectors; printers; thermal
transfer printers; plotters; parts and fittings for all the
aforesaid goods. Paper, cardboard and goods made from these materials, not
included in other classes; printed matter; bookbinding
material; photographs; stationery; adhesives for stationery
or household purposes; artists' materials; paint brushes;
typewriters and office requisites (except furniture);
instructional and teaching material (except apparatus);
plastic materials for packaging (not included in other
classes); printers' type; printing blocks; labels; adhesive
labels; industrial sealing products, including tapes,
adhesives, tags, markers, films for thermal printing.
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
Produits et services
machines and machines tools, namely, saw, cutting and crimping machines for metal working and metal working machines tools; power tools, namely, drills, disk saws; pumps, namely, hydraulic pumps; electric pumps; drills, namely, power rail drills; automatic cutting machines for rails; clip machines, namely, machines for installing railway clips; parts and fittings for all the aforesaid goods hand operated tools, namely, crimping tools, cutting tools, extrusion tools, punching tools, ratchet wrenches; hand pumps, namely, hand operated pumps for crimping and cutting heads; parts and fittings for all the aforesaid goods, namely, dies for crimping tools, blades for cutting tools, plungers for extrusion tools, punches for punching tools computer operation recorded programmes; pressure gauges; electrical connectors; printers; thermal transfer printers; [ plotters; ] parts and fittings for all the aforesaid goods, namely, [ pens for plotters, ] print heads for printers Printing blocks; paper labels and plastic labels; adhesive labels; markers; films for thermal printing, namely, Polyvinylchloride film, Polycarbonate film, Polyester film [, Polyethylene film, Polyethylene Terephthalate film ]
Machines and machine tools, namely, saw, cutting and crimping machines for metal working and metal working machines tools; power tools, namely, drills, disk saws; pumps, namely, hydraulic pumps; electric pumps; drills, namely, power rail drills; automatic cutting machines for rails; clip machines, namely, machines for installing railway clips; parts and fittings for all the aforesaid goods Printing blocks; paper labels; adhesive labels; markers; films for thermal printing, namely, Polyvinylchloride film, Polycarbonate film, Polyester film, [ Polyethylene film, ] Polyethylene Terephthalate film
69.
Applicator for the removal and attachment of a contact clip to a rail
An applicator for the removal and attachment of a contact clip to a railway rail comprises an applicator body forming a clip seat to receive the contact clip, a thrust jaw suitable for engaging the clip housed in the clip seat, a contrast jaw suitable for engaging the foot of the rail, a thrust device for moving the thrust jaw towards the contrast jaw so as to push the contact clip housed in the clip seat in a thrust direction towards the contrast side, in which the clip seat is suitable for supporting the contact clip transversally to the thrust direction in an area between the thrust jaw and the contrast jaw.
E01B 29/32 - Mise en place ou enlèvement d'éléments de la voie, non couverts dans les groupes précédents, p. ex. patins, ancrages de rails
E01B 29/24 - Fixation ou enlèvement des moyens d'attache démontables ou des accessoires pour ceux-ciAssemblage préalable d'éléments de la voie par des moyens d'attache démontables
70.
Permanent electrical contact applicable to the web of rails and the like
A permanent electrical contact applicable to the web of rails. The contact comprises a bush in electrically conductive material having a tubular stem suitable for inserting in a hole in the web of a rail, a flanged head radially widened compared to the stem and suitable for engaging in abutment with a portion surrounding the hole, and an axial through hole in which a punch can be inserted to expand the tubular stem radially and join a radially outer surface of the stem closely with the hole. At least a portion of the outer surface of the stem is substantially made of a first conductive metal and at least a portion of the flanged head is substantially made of a second conductive metal different from the first conductive metal.
H01R 4/62 - Connexions entre des conducteurs constitués de matériaux différentsConnexions entre ou avec des conducteurs en aluminium avec ou sans âme en acier
B21D 19/08 - Mise en forme ou autres traitements des bords, p. ex. des bords des tubes par l'action unique ou successive d'outils presseurs, p. ex. de mors d'étaux
B21K 1/60 - Fabrication d'éléments de machines de rivets de rivets creux ou semi-creux
H01R 43/16 - Appareils ou procédés spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation de connecteurs de lignes ou de collecteurs de courant ou pour relier les conducteurs électriques pour la fabrication des pièces de contact, p. ex. par découpage et pliage
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Materials of metal for railway tracks; Metal connectors; Small springs of metal for railway tracks. Contacts, electric; Connectors (electrical). Installation and maintenance of materials of metal for railway tracks, connectors of metal, small springs of metal for railway tracks, electric contacts and electric connectors.
A hydrodynamic compression and/or cutting tool (1 ) comprises an electric motor (6), a transformation mechanism (8) suitable for transforming the rotary motion of the motor (6) into an oscillating translation motion, a two-speed hydraulic pump (1 1 ) suitable for carrying out an increase in pressure of a pressure fluid acting on an actuation piston (12) in response to the oscillating translation movement so as to move the actuation piston (12).
B25B 27/10 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets par ajustage à la presse, ou pour les détacher pour emmancher des raccords dans des tuyaux souples ou manches
B23D 15/14 - Machines à cisailler ou dispositifs de cisaillage taillant au moyen de lames se déplaçant parallèlement les unes par rapport aux autres caractérisés par leur entraînement ou transmission commandés hydrauliquement ou pneumatiquement
F15B 7/04 - Systèmes de manœuvre utilisant la pression d'un fluide dans lesquels le mouvement produit est lié de façon définie au débit d'une pompe volumétriqueTélémoteurs dans lesquels le rapport entre les courses de la pompe et du moteur varie avec la résistance opposée au moteur
A portable apparatus (1) for the tooling of a workpiece (9) comprises a motor (3) with a cyclic movement output member (4), a tool holder (5) adapted to carry a tool (6) and a movement transmitter (7) engaging the motor output member (4) and the tool holder (5) to set the tool holder (5) in a cyclic movement, wherein the movement transmitter (7) comprises a transmission ratio adjuster (8) that, in response to a preset reduction of the cyclic movement speed (ω_m) of the output member (4) of the motor, increases the transmission ratio (ω_m/ω_ph) thereby reducing the cyclic movement speed (ω ph) of the tool holder (5) with respect to the cyclic movement speed (ω_m) of the output member (4) of the motor (3).
A portable cutting apparatus (1) for the in situ truncation of railway rails (9) comprises a rail saw (2) having a motor (3) with a cyclic movement output member (4), a plate holder (5) adapted to carry an abrasive blade (6) and a movement transmitter (7) engaging the motor output member (4) and the plate holder (5) to set the plate holder (5) in a cyclic movement, a linkage structure (27) with a rail connector (29) and a saw connector (31) and a sawing position alternator (45) to autonomously and alternately move the plate holder (5) to and fro.
A connector (1) for connecting an electric cable (2) to a terminal (3) comprises a multi-layer tubular body that forms a cable connection portion (4) suitable for receiving an end of the electric cable (2) and a terminal connection portion (6) suitable for being connected in contact with the terminal (3).
H01R 4/20 - Connexions conductrices de l'électricité entre plusieurs organes conducteurs en contact direct, c.-à-d. se touchant l'un l'autreMoyens pour réaliser ou maintenir de tels contactsConnexions conductrices de l'électricité ayant plusieurs emplacements espacés de connexion pour les conducteurs et utilisant des organes de contact pénétrant dans l'isolation effectuées uniquement par torsion, enroulage, pliage, sertissage ou autre déformation permanente par sertissage en utilisant un manchon de sertissage
H01R 4/62 - Connexions entre des conducteurs constitués de matériaux différentsConnexions entre ou avec des conducteurs en aluminium avec ou sans âme en acier
H01R 11/12 - Pièces d'extrémité se terminant par un œillet, un crochet ou une fourchette
H01R 13/03 - Contacts caractérisés par le matériau, p. ex. matériaux de plaquage ou de revêtement
A portable apparatus (1) for the tooling of a workpiece (9) comprises a motor (3) with a cyclic movement output member (4), a tool holder (5) adapted to carry a tool (6) and a movement transmitter (7) engaging the motor output member (4) and the tool holder (5) to set the tool holder (5) in a cyclic movement, wherein the movement transmitter (7) comprises a transmission ratio adjuster (8) that, in response to a preset reduction of the cyclic movement speed (ω_m) of the output member (4) of the motor, increases the transmission ratio (ω_m/ω_ph) thereby reducing the cyclic movement speed (ω ph) of the tool holder (5) with respect to the cyclic movement speed (ω_m) of the output member (4) of the motor (3).
A portable cutting apparatus (1) for the in situ truncation of railway rails (9) comprises a rail saw (2) having a motor (3) with a cyclic movement output member (4), a plate holder (5) adapted to carry an abrasive blade (6) and a movement transmitter (7) engaging the motor output member (4) and the plate holder (5) to set the plate holder (5) in a cyclic movement, a linkage structure (27) with a rail connector (29) and a saw connector (31) and a sawing position alternator (45) to autonomously and alternately move the plate holder (5) to and fro.
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
Produits et services
Machines and machine tools; Motors and engines (except for land vehicles); Machine coupling and transmission components (except for land vehicles); Agricultural implements other than hand-operated; Incubators for eggs; Power tools; Pumps; Drills; Automatic cutting machines for rails; Pandrol clip machines; Electric pumps; Parts and fittings for all the aforesaid goods. Hand tools and implements (hand operated); Cutlery; Forks and spoons; Side arms; Razors; Hand pumps; Hand-operated cutting machines for rails; Parts and fittings for aforesaid goods. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Apparatus for recording, transmission or reproduction of sound or images; Magnetic data carriers, recording discs; Automatic vending machines and mechanisms for coin-operated apparatus; Cash registers; Calculating machines; Computers; Fire-extinguishing apparatus; Computer programmes, recorded; Pressure gauges; Electrical connectors; Printers; Thermal transfer printing machines; Plotters; Parts and fittings for all the aforesaid goods. Paper, cardboard and goods made from these materials, not included in other classes; Printed matter; Bookbinding material; Photographs; Stationery; Adhesives for stationery or household purposes; Artists' materials; Paint brushes; Typewriters and office requisites (except furniture); Instructional and teaching material (except apparatus); Plastic materials for packaging (not included in other classes); Printers' type; Printing blocks; Labels; Adhesive labels; Industrial sealing products, including tapes, adhesives, tags, markers, films for thermal printing.
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
Produits et services
Machines and machine tools; Motors and engines (except for land vehicles); Machine coupling and transmission components (except for land vehicles); Agricultural implements other than hand-operated; Incubators for eggs; Power tools; Pumps; Drills; Automatic cutting machines for rails; Pandrol clip machines; Electric pumps; Parts and fittings for all the aforesaid goods. Hand tools and implements (hand operated); Cutlery; Forks and spoons; Side arms; Razors; Hand pumps; Hand-operated cutting machines for rails; Parts and fittings for aforesaid goods. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Apparatus for recording, transmission or reproduction of sound or images; Magnetic data carriers, recording discs; Automatic vending machines and mechanisms for coin-operated apparatus; Cash registers; Calculating machines; Computers; Fire-extinguishing apparatus; Computer programmes, recorded; Pressure gauges; Electrical connectors; Printers; Thermal transfer printing machines; Plotters; Parts and fittings for all the aforesaid goods. Paper, cardboard and goods made from these materials, not included in other classes; Printed matter; Bookbinding material; Photographs; Stationery; Adhesives for stationery or household purposes; Artists' materials; Paint brushes; Typewriters and office requisites (except furniture); Instructional and teaching material (except apparatus); Plastic materials for packaging (not included in other classes); Printers' type; Printing blocks; Labels; Adhesive labels; Industrial sealing products, including tapes, adhesives, tags, markers, films for thermal printing.
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Machines and machine tools; motors and engines (except for land vehicles); machine coupling and transmission components (except for land vehicles); agricultural implements other than hand-operated; incubators for eggs; Automatic cutting machines for rails. Hand tools and implements (hand operated); cutlery; side arms; razors; Hand-operated cutting machines for rails. Building construction; repair; installation services; maintenance and repair of automatic cutting machines for rails and hand-operated cutting machines for rails.
An impact mechanism (12) for an impact wrench comprises an anvil (8) with a middle portion (13), at least one abutment surface (14) radially protruding therefrom, which forms at least one abutment surface (15), a hammer (4) with an impact surface (16) suitable to give rotational pulses to the anvil (8) by the impact surface (16) hitting the abutment surface (15). The anvil (8) comprises a first connection area (17) connecting the abutment portion (14) to the middle portion (13) within the axial extension of the abutment surface (15) and the middle portion (13) and a reinforcement rib (18) axially arranged out of the abutment surfaces (15) that connects the abutment portion (14) to the middle portion (13) of the anvil (8), thereby forming a second connecting area.
An impact motorized wrench includes a tool-holder shaft arranged on a front side of the wrench and pivoting around a rotation axis, a rotary motion producing motor unit arranged on a rear side of the wrench opposite the front side and an operating member to operate the motor unit, a drive unit with a percussion mechanism being arranged between the motor unit and the tool-holder shaft. The motor unit, the drive unit and the percussion mechanism together form a base body of the wrench and the wrench includes two gripping handles attached to the base body, both being of elongated shape and transversally spaced apart relative to their longitudinal extensions. The handles define a common gripping plane tangential to both handles, which plane extends transversally to the rotation axis. The operating member is associated to one of the two handles.
B25B 21/02 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts avec des moyens pour communiquer un choc à la tige du tournevis ou à la douille de la clé à écrou
85.
HYDRAULIC PRESSING AND/OR CUTTING TOOL AND MECHANISM FOR CONVERTING A ROTARY MOTION INTO A TRANSLATIONAL OSCILLATING MOTION FOR THIS TOOL
A hydraulic pressing and/or cutting tool (1) comprises an electric motor (6), a converting mechanism (8) suitable to convert the rotary motion of the motor (9) to an oscillating translational motion, a hydraulic pump (11) suitable to carry out, in response to the oscillating translational motion, an increase in the pressure of a pressure fluid acting on an operating piston (12) such that the operating piston (12) is displaced, a stationary jaw (13) and a movable jaw (14) connected to the operating piston (12) such that, in response to the displacement of the operating piston (12), the movable jaw is displaced to the stationary jaw (13) to carry out pressing or cutting operations. The converting mechanism (8) comprises an epicycloidal gear (16) and a thrust unit (17) co-axial with the epicycloidal gear (16).
H01R 43/00 - Appareils ou procédés spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation de connecteurs de lignes ou de collecteurs de courant ou pour relier les conducteurs électriques
86.
Screw, particularly for the electrical connection of a cable terminal to a railway track or the like
A screw for the electrical connection of a cable terminal to a railway track or the like comprises a base body having an elongated shank having a longitudinal axis, a strike head connected with a first end of the shank, and threads for the removable connection of a strike organ or nut with a second end of the shank opposite said first end. The screw further comprises a support element manufactured separately from the base body and associated to the strike head so as to form a stroke that defines a cavity turned towards the second end of the shank. The screw is pre-assembled and the support element is substantially irreversibly connected to the base body.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Outils tenus à la main actionnés autrement que manuellement,
outils (parties de machines), machines et machines-outils;
moteurs (à l'exception des moteurs pour véhicules
terrestres); accouplements et organes de transmission (à
l'exception de ceux pour véhicules terrestres); instruments
agricoles autres que ceux actionnés manuellement; couveuses
pour les oeufs. Outils et instruments à main entraînés manuellement;
coutellerie, fourchettes et cuillers; armes blanches;
rasoirs. Connecteurs électriques.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Outils tenus à la main actionnés autrement que manuellement,
outils (parties de machines), machines et machines-outils;
moteurs (à l'exception des moteurs pour véhicules
terrestres); accouplements et organes de transmission (à
l'exception de ceux pour véhicules terrestres); instruments
agricoles autres que ceux actionnés manuellement; couveuses
pour les oeufs. Outils et instruments à main entraînés manuellement;
coutellerie, fourchettes et cuillers; armes blanches;
rasoirs. Connecteurs électriques.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Installation material for electric installations, in particular cable clips, connection caps for electric cables, end contacts, end caps for conduits, connection pieces for conduits made from insulating material, seals, pipe clips.
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
Produits et services
Registration plates of metal. Identification sheaths and wires for electric wiring; magnetic data carriers, optical and magnetic media for storage of data, images and sound, compact discs, floppy disks, computer programs, recorded, and components therefor, electronic apparatus for data processing and transmission; printers, computer peripheral devices. Labels, seals (stamps), hand labelling appliances.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Materials for electric installations, in particular wire connectors, cable lugs, cable contacts, thread plugs, pipe connections of electric insulating materials.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Materials for electric installations, in particular wire connectors, cable lugs, cable contacts, thread plugs, pipe connections of electric insulating materials.
