The invention relates to a trigger operated foam sprayer comprising, a reservoir, a foam nozzle, and a pump mechanism with a trigger. The foam nozzle has a foam outlet and a liquid inlet orifice at a distance from the foam outlet for creating a liquid jet in the direction of the foam outlet along a liquid path, the liquid inlet orifice defining a primary flow direction coinciding with a central axis of the orifice. The foam nozzle further comprises a baffle disposed in the liquid path, wherein the baffle comprises an impingement surface which is oriented at a first angle, which is an acute internal angle, with respect to the primary flow direction. The invention also relates to such a foam nozzle by itself.
B05B 7/00 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p. ex. un liquide et de l'air, une poudre et un gaz
The invention relates to a device for dispensing a liquid from a container, comprising an inlet channel configured to be brought in fluid communication with the container, a pump in fluid communication with the inlet channel, the pump including a pump chamber and a piston reciprocally movable in the pump chamber, and an inlet valve arranged between the inlet channel and the pump. The liquid dispensing device further comprises a buffer in fluid communication with the pump, a nozzle for dispensing the liquid, the nozzle in fluid communication with the pump and/or the buffer, and an outlet valve arranged between the pump and/or buffer and the nozzle. The buffer comprises an elastic buffer bag arranged at least partially in the piston. The elastic buffer bag defines an internal volume and has an opening in fluid communication with the pump.
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers, vaporizers, and sprayers for use
with industrial, industrial chemical, and commercial
liquids. Non-metallic containers, sold empty, for industrial,
industrial chemical and commercial liquids, including foams
and mists; plastic packaging components for containers and
bottles, including spraying heads and dispensing closures;
non-metallic containers, sold empty, for cleaning agents,
disinfecting solutions, personal care fluids, plant care
liquids, pet care, car care, food and cooking liquids,
including foams and mists; non-metallic caps and closures
featuring a trigger spray, for containers and bottles to
dispense industrial, industrial chemical or commercial
liquids, including foams and mists. Empty trigger spray bottles, hand-operated, not for medical
use; manually actuated pump dispensers for use with liquids
for household purposes, personal care liquids, liquid soaps,
plant care liquids, pet care, car care, food and cooking
liquids; empty trigger spray dispensers for use with liquids
for household purposes, personal care liquids, liquid soaps,
plant care liquids, pet care, car care, food and cooking
liquids; empty spray bottles; empty spray bottles for use
with liquids for household purposes, personal care liquids,
liquid soaps, plant care liquids, pet care, car care, food
and cooking liquids, and components for these empty spray
bottles in the form of caps and closures equipped with a
manually actuated spraying mechanism to propel liquids, also
in the form of foams and mists; trigger spray heads and
dispensing closures connectable to containers and bottles to
dispense its content, namely industrial, chemical or
commercial liquids, also in the form of foams and mists;
manually actuated pump dispensers connectable to containers
and bottles to dispense cleaning agents, disinfecting
solutions, personal care liquids, liquid soaps, plant care
liquids, pet care, car care, food and cooking liquids,
including foams and mists; hand-operated atomizers,
vaporizers, and sprayers for household use, for use with
cleaning agents and disinfecting solutions, personal care
fluids, plant care liquids, pet care fluids, car care
solutions, food and cooking liquids; plastic packaging
components for containers and bottles, namely spraying heads
and dispensing closures; non-metallic trigger spray bottles,
sold empty, for industrial, industrial chemical and
commercial liquids, including foams and mists.
4.
Systems and Methods to Precisely Control Output Pressure in Buffered Sprayers (DuO1)
A liquid dispensing device includes a dispensing head, an outlet valve and a nozzle. The dispensing head includes an inlet valve, a piston and a piston chamber, an actuator for controlling the piston, and a buffer or bladder. The outlet valve has a defined minimum opening pressure and is in direct fluid communication with either the buffer or bladder, or both the buffer or bladder and the piston chamber. The nozzle, with a defined throughput, is in fluid communication with the outlet valve. A volume of the piston chamber, a volume of the buffer, a pressure response of the buffer, the throughput of the nozzle, and the minimum opening pressure of the outlet valve are together arranged to restrict the outlet pressures of liquid droplets exiting the nozzle within a defined range of from (P−ΔP) to (P+ΔP), where P is a nominal pressure and ΔP a maximum pressure variation.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
A47L 11/40 - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p. ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
A47L 13/22 - Balais à franges avec systèmes d'alimentation en liquide
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
B05B 15/62 - Aménagements pour le maintien des appareils de pulvérisation, p. ex. ventouses pour accrochage
B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
B29C 65/08 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage avec des vibrations ultrasonores
Dispensing devices are provided. Such devices utilize a combination of Flair® technology, pre-compression valves and aerosol-like pressurization of the dispensed liquid. An example dispensing device has, for example, a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a container and fills the pressure chamber with that liquid as a user operates a trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve. Liquid exiting the piston chamber under pressure enters a central vertical channel which is in fluid communication with both the pressure chamber and a dome valve, with pre-defined opening pressure, provided near the outlet channel at the top of the dispensing head.
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 11/02 - Membranes ou pistons agissant sur le contenu à l'intérieur du récipient, p. ex. pistons suiveurs
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
B65D 83/62 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur avec un contenu et un propulseur séparés par des membranes, des sacs ou similaires
The invention relates to a device for dispensing a liquid from a container comprising an inlet channel configured to be brought in fluid communication with the container and a pump in fluid communication with the inlet channel, the pump including a pump chamber and a piston reciprocally movable in the pump chamber. The liquid dispensing device further comprises a gas buffer in fluid communication with the pump, the gas buffer comprising a buffer chamber and a gas-filled compressible buffer bag arranged in the buffer chamber, a nozzle for dispensing the liquid, the nozzle in fluid communication with the pump and/or the gas buffer, and a pre-compression valve arranged between the pump and/or gas buffer and the nozzle. The pump chamber has an axis defining a direction of reciprocal movement of the piston which is arranged at an angle with respect to an axis of the inlet channel. The invention further relates to a system for dispensing a liquid, comprising a container and a liquid dispensing device as described above connected thereto.
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
7.
PRODUCT DISPENSING SYSTEM COMPRISING A MOTOR DRIVEN AIR PUMP, A DISPENSING DEVICE AND A PRODUCT CONTAINER
A dispensing system includes a motor driven air pump having an air inlet and an air outlet, and a dispensing device. The dispensing device is releasably connected to the air pump. The dispensing device includes an air connector connected to the air outlet of the pump, a mixture outlet, a product inlet, and a product uptake system connected to the air connector, the mixture outlet, and the product inlet. The dispensing system includes a product container for a product to be dispensed. The product container is connected to the product inlet. The product container is integrated in the dispensing device. The product uptake system may include an ejector for sucking product from the container and/or a container air inlet for pressurizing the container.
B05B 7/24 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p. ex. un liquide et de l'air, une poudre et un gaz avec des moyens, p. ex. un récipient, pour alimenter en liquide ou autre matériau fluide un dispositif de décharge
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Hand operated atomizers, vaporizers, and sprayers for use with industrial, industrial chemical, and commercial liquids.
(2) Non-metallic containers, sold empty, for industrial, industrial chemical and commercial liquids, including foams and mists; plastic packaging components for containers and bottles, including spraying heads and dispensing closures; non-metallic containers, sold empty, for cleaning agents, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids, including foams and mists; non-metallic caps and closures featuring a trigger spray, for containers and bottles to dispense industrial, industrial chemical or commercial liquids, including foams and mists.
(3) Empty aerosol dispensers, in the form of trigger sprayers, for household and kitchen use, as well as for use with liquids for personal care, plant care, pet care, car care, food and cooking; manually actuated pump dispensers for attachment to containers for use with liquids for household purposes, personal care liquids, liquid soaps, plant care liquids, pet care, car care, food and cooking liquids; empty trigger spray dispensers for use with liquids for household purposes, personal care liquids, liquid soaps, plant care liquids, pet care, car care, food and cooking liquids; empty spray bottles; empty spray bottles for use with liquids for household purposes, personal care liquids, liquid soaps, plant care liquids, pet care, car care, food and cooking liquids, and components for these empty spray bottles in the form of caps and closures equipped with a manually actuated spraying mechanism to propel liquids, also in the form of foams and mists; trigger spray heads and dispensing closures connectable to containers and bottles to dispense its content, namely industrial, chemical or commercial liquids, also in the form of foams and mists; manually actuated pump dispensers connectable to containers and bottles to dispense cleaning agents, disinfecting solutions, personal care liquids, liquid soaps, plant care liquids, pet care, car care, food and cooking liquids, including foams and mists; hand-operated atomizers, vaporizers, and sprayers for household use, for use with cleaning agents and disinfecting solutions, personal care fluids, plant care liquids, pet care fluids, car care solutions, food and cooking liquids; plastic packaging components for containers and bottles, namely spraying heads and dispensing closures; non-metallic trigger spray bottles, sold empty, for industrial, industrial chemical and commercial liquids, including foams and mists.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers and sprayers for use with industrial, industrial chemical, and commercial liquids; hand operated vaporizers for use with industrial and industrial chemical liquids. Plastic packaging closures for containers and bottles, namely, spraying heads and dispensing closures connectable to containers and bottles to dispense industrial, industrial chemical, or commercial liquids; non-metallic containers, sold empty, for use with cleaning agents, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids. Empty trigger spray bottles, hand-operated, not for medical use; manually actuated pump dispensers for attachment to containers for use in dispensing liquids for household purposes; manually actuated pump dispensers for attachment to containers for use in dispensing liquids for personal care, namely liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants; manually actuated pump dispensers for attachment to containers for use in dispensing liquids for plant care, namely solutions for plant care and shine, insect repellent; manually actuated pump dispensers for attachment to containers for use in dispensing liquids for pet care namely pet smell remover, equine care sprays, liquid soaps and hair care products for animals; manually actuated pump dispensers for attachment to containers for use in dispensing liquids for car care, namely vehicle cleaning solutions, surface maintenance and repair solutions, odour fragrances; manually actuated pump dispensers for attachment to containers for use in dispensing liquids for food and cooking, namely solutions for cooking, dressing, seasoning, baking, including in the form of foams and mists; empty trigger spray dispensers for use with liquids for household purposes; empty trigger spray dispensers for use with liquids for personal care, namely liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants; empty trigger spray dispensers for use with liquids for plant care, namely solutions for plant care and shine, insect repellent; empty trigger spray dispensers for use with liquids for pet care namely pet smell remover, equine care sprays, liquid soaps and hair care products for animals; empty trigger spray dispensers for use with liquids for car care, namely vehicle cleaning solutions, surface maintenance and repair solutions, odour fragrances; empty trigger spray dispensers for use with liquids for food and cooking, namely solutions for cooking, dressing, seasoning, baking, including in the form of foams and mists; empty spray bottles; empty spray bottles for use with liquids for household purposes, and components for these empty spray bottles in the form of caps and closures equipped with a manually actuated spraying mechanism to propel liquids, also in the form of foams and mists; empty spray bottles for use with liquids for personal care liquids, namely liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants, and components for these empty spray bottles in the form of caps and closures equipped with a manually actuated spraying mechanism to propel liquids, also in the form of foams and mists; empty spray bottles for use with liquids for plant care, namely solutions for plant care and shine, insect repellent, and components for these empty spray bottles in the form of caps and closures equipped with a manually actuated spraying mechanism to propel liquids, also in the form of foams and mists; empty spray bottles for use with liquids for pet care, namely pet smell remover, equine care sprays, liquid soaps and hair care products for animals, and components for these empty spray bottles in the form of caps and closures equipped with a manually actuated spraying mechanism to propel liquids, also in the form of foams and mists; empty spray bottles for use with liquids for car care, namely vehicle cleaning solutions, surface maintenance and repair solutions, odour fragrances, and components for these empty spray bottles in the form of caps and closures equipped with a manually actuated spraying mechanism to propel liquids, also in the form of foams and mists; empty spray bottles for use with liquids for food and cooking, namely solutions for cooking, dressing, seasoning, baking, including in the form of foams and mists, and components for these empty spray bottles in the form of caps and closures equipped with a manually actuated spraying mechanism to propel liquids, also in the form of foams and mists; trigger spray heads and dispensing closures connectable to containers and bottles to dispense its content, namely industrial, chemical or commercial liquids, also in the form of foams and mists; manually actuated pump dispensers connectable to containers or bottles to dispense cleaning agents and disinfecting solutions; manually actuated pump dispensers connectable to containers or bottles to dispense personal care liquids, namely liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants; manually actuated pump dispensers connectable to containers or bottles to dispense plant care liquids, namely solutions for plant care and shine, insect repellent; manually actuated pump dispensers connectable to containers or bottles to dispense pet care liquids, namely pet smell remover, equine care sprays, liquid soaps and hair care products for animals; manually actuated pump dispensers connectable to containers or bottles to dispense car care liquids, namely vehicle cleaning solutions, surface maintenance and repair solutions, odour fragrances; manually actuated pump dispensers connectable to containers or bottles to dispense food and cooking liquids, namely solutions for cooking, dressing, seasoning, baking, including in the form of foams and mists; hand operated atomizers, sold empty, for household use for use with cleaning agents and disinfecting solutions; hand operated vaporizers, sold empty, for household use, for personal care fluids, namely liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants; hand operated vaporizers, sold empty, for household use, for use with pet care liquids, namely pet smell remover, equine care sprays, liquid soaps and hair care products for animals; hand operated vaporizers, sold empty, for household use, for use with car care liquids, namely vehicle cleaning solutions, surface maintenance and repair solutions, odour fragrances; hand operated vaporizers, sold empty, for household use, for use with plant care liquids, namely solutions for plant care and shine, insect repellent; hand operated vaporizers, sold empty, for household use, for use with food and cooking liquids, namely solutions for cooking, dressing, seasoning, baking; plastic parts of dispensing containers and bottles for household use, namely trigger spray heads and dispensing closures; non-metallic bottles, sold empty, for use with cleaning solutions, disinfecting solutions, personal care fluids, plant care liquids as well as for pet care, car care, food and cooking liquids, including such liquids in the form of foams and mists; manually actuated fluid pump dispensers connectable to containers and bottles to dispense liquids in the field of cleaning and disinfecting, including in the form of foams and mists; non-metallic trigger spray containers and trigger spray bottles, sold empty, for dispensing industrial, industrial chemical, and commercial liquids, including foams and mists.
A gas-filled resilient body and uses thereof are described. The gas-filled resilient body may be used as a valve member, as a spring or as a gas-propelled dispenser.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
B65D 81/32 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu pour emballer plusieurs matériaux différents qui doivent être maintenus séparés avant d’être mélangés
F16K 15/14 - Soupapes, clapets ou valves de retenue à corps de soupapes flexibles
F16K 21/00 - Obturateurs de distribution pour fluides
G01F 11/08 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage du type à diaphragme ou à soufflet
A61M 5/20 - Seringues automatiques, p. ex. avec tige de piston actionnée automatiquement, avec injection automatique de l'aiguille, à remplissage automatique
F16K 15/18 - Soupapes, clapets ou valves de retenue à mécanisme de commandeSoupape de retenue et soupape à mécanisme de commande combinées
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated, empty and refillable, atomizers, vaporizers,
and sprayers for industrial or commercial use; cutlery,
kitchen knives, and cutting implements for kitchen use;
canteens of cutlery; boxes and containers adapted for
cutlery; mandolines [cooking tool]. Non-metallic containers and packaging bottles [containers]
for industrial, chemical and commercial liquids, including
foams and mists; non-metallic spraying heads and caps
connectable to containers and bottles to dispense its
content, namely industrial, chemical or commercial liquids,
including foams and mists; plastic packaging components for
containers and bottles, namely spraying heads and dispensing
closures. Empty aerosol sprayers and dispensers, not for medical use;
empty spray bottles and atomizers for household purposes,
also refillable; empty spray bottles and atomizers for
cooking purposes, also professional cooking such as in
restaurants, hotels; empty spray bottles and atomizers, also
refillable, for cooking oils, vinegar, soy sauce, cooking
wine, dressings, seasoning, water, and other liquid culinary
ingredients; pump condiment dispensers, not included in
other classes; manually actuated pump dispensers for
household purposes; manually actuated pump dispensers for
cooking oils, vinegar, soy sauce, cooking wine, dressings,
seasoning, water, and other liquid culinary ingredients;
tableware and kitchenware (not of precious metal or plated
or silvered); cutlery trays; household cooking utensils;
household kitchen and cooking containers; decorative objects
and sculptures of glass, crystal, ceramics and porcelain;
decorative glass bell jars; unworked or semi-worked glass
(except glass for building purposes); glassware, porcelain
and earthenware included in this class; chinaware; drinking
glasses and cups; flower pots, pots, vases, dishes, trays
and lantern holders not included in other classes;
candlesticks and other holders for candles or tea lights;
candle extinguishers; napkin rings and napkin holders; pots
and pans, not included in other classes; dustbins;
decorative and non-decorative porcelain, earthenware and/or
glassware; bowls and dishes; saucers, plates, carafes and
bottles; wine coolers; watering cans; insulating flasks;
portable cool boxes, non-electric; cake and baking tins;
coasters; decorative plates and dishes; barbecue forks,
gloves, mitts, turners and serving tongs; brushes for
cleaning barbecue grills; cooking utensils for barbecue use;
aluminum foils for cooking purposes.
15.
SPRAYER DEVICE WITH AEROSOL FUNCTIONALITY -FLAIROSOL
In exemplary embodiments of the present invention, Flair® based aerosol-type devices can be provided. Such, devices utilize a combination of Flair® technology, pre-compression valves and aerosol like pressurization of the dispensed liquid. Such a dispensing device has a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a reservoir and fills the pressure chamber with that liquid as a user operates the trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve. In a dispensing head a valve is provided to regulate the strength of the flow and preclude leakage. Once the liquid is sufficiently pressurized, it can be dispensed by a user opening an activation valve, such as by pressing on an activation button, and spray can be abruptly stopped by a user ceasing to push on such button. Or, for example, in alternate embodiments without an activation button, once the liquid is sufficiently pressurized, continuous spray occurs until the pressure chamber is emptied. By repeatedly pumping the trigger before the pressure chamber is fully emptied, continuous spray can be achieved. By designing the input volume to be amply greater than the volume of the pressure chamber, continuous spray with fewer pumping strokes can be implemented.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Hand operated, empty and refillable, atomizers, vaporizers, and sprayers for industrial or commercial use; cutlery, kitchen knives, and cutting implements for kitchen use; canteens of cutlery; boxes and containers adapted for cutlery; mandolines [cooking tool].
(2) Non-metallic containers and packaging bottles [containers] for industrial, chemical and commercial liquids, including foams and mists; non-metallic spraying heads and caps connectable to containers and bottles to dispense its content, namely industrial, chemical or commercial liquids, including foams and mists; plastic packaging components for containers and bottles, namely spraying heads and dispensing closures.
(3) Empty aerosol sprayers and dispensers, not for medical use; empty spray bottles and atomizers for household purposes, also refillable; empty spray bottles and atomizers for cooking purposes, also professional cooking such as in restaurants, hotels; empty spray bottles and atomizers, also refillable, for cooking oils, vinegar, soy sauce, cooking wine, dressings, seasoning, water, and other liquid culinary ingredients; pump condiment dispensers, not included in other classes; manually actuated pump dispensers for household purposes; manually actuated pump dispensers for cooking oils, vinegar, soy sauce, cooking wine, dressings, seasoning, water, and other liquid culinary ingredients; tableware and kitchenware (not of precious metal or plated or silvered); cutlery trays; household cooking utensils; household kitchen and cooking containers; decorative objects and sculptures of glass, crystal, ceramics and porcelain; decorative glass bell jars; unworked or semi-worked glass (except glass for building purposes); glassware, porcelain and earthenware included in this class; chinaware; drinking glasses and cups; flower pots, pots, vases, dishes, trays and lantern holders not included in other classes; candlesticks and other holders for candles or tea lights; candle extinguishers; napkin rings and napkin holders; pots and pans, not included in other classes; dustbins; decorative and non-decorative porcelain, earthenware and/or glassware; bowls and dishes; saucers, plates, carafes and bottles; wine coolers; watering cans; insulating flasks; portable cool boxes, non-electric; cake and baking tins; coasters; decorative plates and dishes; barbecue forks, gloves, mitts, turners and serving tongs; brushes for cleaning barbecue grills; cooking utensils for barbecue use; aluminum foils for cooking purposes.
17.
DEVICE FOR DISPENSING A MATERIAL BY MEANS OF PRESSURIZED GAS AND PARTIALLY GAS-FILLED TUBULAR BODY FOR USE THEREIN
A device for dispensing a material includes a reservoir for the material and an outlet channel connectable thereto. The reservoir has a tubular body partially filled with pressurized gas and partially filled with the material to be dispensed. One end of the tubular body is welded shut and an opposite end is closed by a sealing member extending over at least part of a cross-sectional area of the tubular body. The sealing member is arranged in a sleeve connected to the end of the tubular body opposite the welded end thereof. The sealing member has a pierceable diaphragm and the device may further comprise a piercing member. The sealing member can include a movable valve or can be removably fixed inside the tubular body and the device can include an operating member. The tubular body and the piercing member or operating member, respectively, may be movable towards each other.
B65D 83/28 - Buses, leurs moyens de support ou leurs accessoires spécialement adaptés à cet effet
B65D 83/64 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur avec un contenu et un propulseur séparés par des pistons
18.
DEVICE AND SYSTEM FOR DISPENSING A LIQUID FROM A CONTAINER, AND METHOD FOR ASSEMBLING A DEVICE FOR DISPENSING A LIQUID
A device for dispensing a liquid from a container is disclosed, comprising:
an engine, comprising a nozzle and a pump for transferring liquid from the container to the nozzle;
a trigger, moveable between a first position and a second position, connected to the pump for actuating the pump when brought from the first to the second position, and
connecting means, for connecting the engine to the container characterized by
a slider with at least one restricting element, slideable between a non-restricting position, in which the trigger is moveable between the first and second position, and a restricting position, in which the at least one restricting element restricts the movement of the trigger between the first and the second position.
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
19.
ENGINE FOR A LIQUID DISPENSING DEVICE AND LIQUID DISPENSING DEVICE INCLUDING SUCH ENGINE
The invention relates to an engine (1) for a liquid dispensing device, comprising: a frame (2); a pump chamber (3) arranged in the frame (2); a piston (4) movably arranged in the pump chamber (3); a trigger (5) movably connected to the frame (2) and operatively coupled with the piston (4); a nozzle (6); an outlet channel (7) arranged in the frame (6) and connecting the pump chamber (3) to the nozzle (6); an outlet valve (8) operatively connected with the outlet channel (7); and a pair of springs (9) mounted or mountable on opposite sides (2R, 2L) of the frame (2) and engaging or engageable with the trigger (5); wherein the springs (9) are connected to each other by a bridge piece (10) extending between the opposite sides (2R, 2L) of the frame (2) and configured for securing the outlet valve (8) to the frame (2). The invention further relates to a method of assembling an engine (1) for a liquid dispensing device, comprising the steps of: providing a frame (2) including a pump chamber (3) and an outlet channel (7) arranged therein; movably arranging a piston (4) in the pump chamber (3); movably connecting a trigger (5) to the frame (2) and operatively coupling the trigger (5) with the piston (4); operatively connecting an outlet valve (8) with the outlet channel (7); and mounting a pair of springs (9) on opposite sides (2L, 2R) of the frame (2) and engaging the springs (9) with the trigger (5); wherein the outlet valve (8) is secured to the frame (2) by means of a bridge piece (10) which connects the springs (9) to each other and which extends between the opposite sides (2L, 2R) of the frame (2).
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
20.
DEVICE FOR FASTENING A CAP OR A DISPENSING DEVICE TO A CONTAINER NECK
The invention relates to a device for fastening a cap or dispensing device to a container neck, comprising a number of protruding clamping members arranged distributed in peripheral direction of the neck on the neck, wherein at least two of the clamping members each comprise a first segment extending in a direction from a body of the container to an open end of the neck, and a second segment extending substantially in the peripheral direction of the neck from an outer end of the first segment facing toward the open end. A free outer end of the second segment remote from the first segment can here be chamfered or curved in the peripheral direction of the neck on a side directed toward the body of the container. The second segment can have a greater stiffness than the first segment. The first segment can take the form of a right triangle with a base in the peripheral direction of the neck, a leg connecting to the second segment and an oblique side defining a guide track for an internal protrusion of the cap or dispensing device.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Table cutlery, kitchen knives, and hand operated cutting implements for kitchen use; tableware sets in the nature of table cutlery; boxes and containers adapted for table cutlery; hand operated mandoline slicers; tableware, not of precious metal or plated or silvered, namely, knives, forks and spoons Empty trigger sprayer bottles and atomizers for professional cooking such as in restaurants, hotels; ; kitchenware, not of precious metal or plated or silvered, namely, drinking cups, saucers, mugs, plates, dishes, bowls, egg cups, cup lids, sippy cups, mixing cups, household storage containers, sold empty ; cutlery trays; household cooking utensils, namely, spatulas, cooking tweezers, cooking turners, soup ladles, skimmers; household kitchen and cooking containers, namely, all purpose household containers, kitchen containers, containers for food and food liquids, and containers for household use; decorative objects in the nature of centerpieces and sculptures of glass, crystal, ceramics and porcelain; decorative glass bells; unworked or semi-worked glass, except glass for building purposes; decorative glassware in the nature of beverage glassware, porcelain and earthenware plaques, centerpieces and figurines; china ornaments; drinking glasses and cups; flower pots, pots, vases, dishes, and serving and decorative trays for household purposes; candlesticks and other holders for candles or tea lights; candle extinguishers; napkin rings and napkin holders; pots and pans; dustbins for household purposes; decorative and nondecorative porcelain, earthenware and glassware figurines, plates and dishes; bowls and dishes; saucers, plates, carafes and bottles sold empty; coolers for wine; watering cans; insulating flasks; portable cool boxes, non-electric; cake tins and baked good tins sold empty for domestic use; coasters, not of paper or textiles; decorative plates and dishes; barbecue forks, gloves, mitts, turners and serving tongs; brushes for barbecue grills; cooking utensils for barbecue use, namely, barbeque branders
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(Based on 44(e)) Hand operated, empty and refillable, atomizers, vaporizers, and sprayers for industrial and commercial use (Based on 44(e)) Non-metallic containers and packaging bottles for industrial, chemical and commercial liquids, including foams and mists; non-metallic spraying heads and caps connectable to containers and packaging bottles to dispense its content, namely, industrial, chemical or commercial liquids, including foams and mists; plastic packaging components for containers and bottles, namely, spraying heads and dispensing closures (Based on Use in Commerce) Empty aerosol sprayer bottles and dispensing bottles, for dispensing liquids; empty spray bottles and atomizers for household purposes, also refillable; empty trigger sprayer bottles and atomizers for cooking purposes; empty trigger sprayer bottles and atomizers, also refillable, for use with cooking oils, vinegar, soy sauce, cooking wine, dressings, seasoning, water, and other liquid culinary ingredients; manually actuated pump dispensers for household purposes, namely, soap dispensing bottles, sold empty; manually actuated pump dispensers in the nature of kitchen utensils for use with cooking oils, vinegar, soy sauce, cooking wine, dressings, seasoning, water, and other liquid culinary ingredients
23.
PRODUCT DISPENSING SYSTEM COMPRISING A MOTOR DRIVEN AIR PUMP, A DISPENSING DEVICE AND A PRODUCT CONTAINER
The invention relates to a dispensing system, comprising a motor driven air pump having an air inlet and an air outlet, and a dispensing device. The dispensing device is releasably connected to the air pump. The dispensing device comprises an air connector connected to the air outlet of the pump; a mixture outlet; a product inlet; and a product uptake system connected to the air connector, the mixture outlet, and the product inlet. The dispensing system includes a product container for a product to be dispensed. The product container is connected to the product inlet. According to the invention the product container is integrated in the dispensing device. The product uptake system may include an ejector for sucking product from the container and/or a container air inlet for pressurizing the container.
B05B 7/24 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p. ex. un liquide et de l'air, une poudre et un gaz avec des moyens, p. ex. un récipient, pour alimenter en liquide ou autre matériau fluide un dispositif de décharge
B05B 7/14 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p. ex. un liquide et de l'air, une poudre et un gaz agencés pour projeter des matériaux en particules
In exemplary embodiments of the present invention, various novel dispensing devices can be provided. Such devices can involve a range of sprayer heads and sprayer/foamer systems incorporating such heads. Novel sprayer/foamer heads can include buffers of various types. By using a buffer, a user need not continually be pumping the device in order for the device to be spraying or foaming. In exemplary embodiments of the present invention, such a buffer can be spring loaded, spring loaded combination, elastomeric or gas. In exemplary embodiments of the present invention, the buffer can be in line or adjacent to a piston chamber. If adjacent, it can be connected to the piston chamber with a one way valve, to provide for spray after a downstroke of the piston has been completed, or without, to allow spraying to cease once a user releases the trigger or other actuator. In exemplary embodiments of the present invention, such novel sprayers and foamers can be mounted upside down, in various “Flairomop” devices, used to clean floors or the like. When using a buffer, a piston chamber can be designed to deliver greater amount of liquid per unit time than can be possibly dispensed through the nozzle or nozzles. The fraction of liquid that cannot be sent through the nozzle(s), due to their inherent restriction, can thus be sent to the buffer for dispensing after the piston downstroke has been completed. A volume of the piston chamber, a volume of the buffer, a pressure response of the buffer, the throughput of the nozzle, and the minimum opening pressure of the outlet valve can be arranged to restrict the outlet pressures of liquid droplets exiting the nozzle within a defined range.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
A47L 11/40 - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p. ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
A47L 13/22 - Balais à franges avec systèmes d'alimentation en liquide
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
B05B 15/62 - Aménagements pour le maintien des appareils de pulvérisation, p. ex. ventouses pour accrochage
B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
B29C 65/18 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage avec un outil chauffé
B29C 65/74 - Assemblage d'éléments préformésAppareils à cet effet par soudage et découpage
B29C 65/78 - Moyens pour la manipulation des éléments à assembler, p. ex. pour la fabrication de récipients ou d'objets creux
B29C 65/08 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage avec des vibrations ultrasonores
Dispensing devices are provided. Such devices utilize a combination of Flair® technology, pre-compression valves and aerosol-like pressurization of the dispensed liquid. An example dispensing device has, for example, a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a container and fills the pressure chamber with that liquid as a user operates a trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve. Liquid exiting the piston chamber under pressure enters a central vertical channel which is in fluid communication with both the pressure chamber and a dome valve, with pre-defined opening pressure, provided near the outlet channel at the top of the dispensing head.
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
B65D 83/62 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur avec un contenu et un propulseur séparés par des membranes, des sacs ou similaires
B05B 11/02 - Membranes ou pistons agissant sur le contenu à l'intérieur du récipient, p. ex. pistons suiveurs
The invention relates to a system for dosed dispensing of a fluid, comprising a container for the fluid and a dispensing device connected therewith, wherein the container comprises a form-retaining outer container and a flexible inner container connected therewith, wherein a space to be brought into fluid communication with the ambient atmosphere can be developed between the inner and outer containers, and wherein the dispensing device includes a housing and/or frame of which at least a part is integrally formed with the container.
assembling the container and the dispensing device; wherein at least a part of the dispensing device housing and/or frame is integrally formed with the container, and wherein assembling the container and the dispensing device comprises mounting a non-integrated part of the dispensing device in the part of the dispensing device housing and/or frame which is integrally formed with the container.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 11/02 - Membranes ou pistons agissant sur le contenu à l'intérieur du récipient, p. ex. pistons suiveurs
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
B29K 23/00 - Utilisation de polyalcènes comme matière de moulage
B29K 67/00 - Utilisation de polyesters comme matière de moulage
B29C 49/22 - Moulage par soufflage, c.-à-d. en soufflant une préforme ou une paraison dans un moule pour obtenir la forme désiréeAppareils à cet effet de préformes ou de paraisons multicouches
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers, vaporizers, and sprayers for use
with industrial, industrial chemical, and commercial
liquids. Non-metallic containers and bottles for industrial,
industrial chemical, and commercial liquids, including foams
and mists; caps connectable to containers and bottles for
industrial, chemical or commercial liquids, including foams
and mists; plastic packaging components for containers and
bottles, namely spraying heads and dispensing closures;
non-metallic containers for cleaning agents, disinfecting
solutions, personal care fluids, plant care liquids, pet
care, car care, food and cooking liquids, including foams
and mists. Aerosol dispensers not for medical use; empty spray bottles;
pump condiment dispensers; manually actuated pump
dispensers; dispensers for cleaning agents, disinfecting
solutions, personal care fluids, plant care liquids, pet
care, car care, food and cooking liquids, including foams
and mists; dispensers for liquid soap; manually actuated
pump dispensers connectable to containers or bottles to
dispense cleaning agents, disinfecting solutions, personal
care liquids, plant care liquids, pet care, car care, food
or cooking liquids, including foams and mists; hand operated
atomizers, vaporizers, and sprayers for use cleaning agents
and disinfecting solutions, personal care fluids, plant care
liquids, pet care, car care, food and cooking liquids;
dispensing units for household use; spray heads connectable
to containers and bottles to dispense its content, namely
industrial, chemical or commercial liquids, including foams
and mists; plastic packaging components for containers and
bottles, namely spray heads and dispensing closures;
non-metallic bottles for cleaning agents, disinfecting
solutions, personal care fluids, plant care liquids, pet
care, car care, food and cooking liquids, including foams
and mists; manually actuated fluid pump dispensers
connectable to containers and bottles to dispense cleaning
solutions, disinfecting solutions, personal care fluids,
plant care liquids, pet care, car care, food or cooking
liquids, including foams and mists.
A gas-filled resilient body and uses thereof are described. The gas-filled resilient body may be used as a valve member, as a spring or as a gas-propelled dispenser.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
B65D 81/32 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu pour emballer plusieurs matériaux différents qui doivent être maintenus séparés avant d’être mélangés
F16K 15/14 - Soupapes, clapets ou valves de retenue à corps de soupapes flexibles
F16K 21/00 - Obturateurs de distribution pour fluides
G01F 11/08 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage du type à diaphragme ou à soufflet
A61M 5/20 - Seringues automatiques, p. ex. avec tige de piston actionnée automatiquement, avec injection automatique de l'aiguille, à remplissage automatique
F16K 15/18 - Soupapes, clapets ou valves de retenue à mécanisme de commandeSoupape de retenue et soupape à mécanisme de commande combinées
31.
Sprayer device with aerosol functionality—flairosol
In exemplary embodiments of the present invention, Flair® based aerosol-type devices can be provided. Such devices utilize a combination of Flair® technology, pre-compression valves and aerosol like pressurization of the dispensed liquid. Such a dispensing device has a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a reservoir and fills the pressure chamber with that liquid as a user operates the trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve. In a dispensing head a valve is provided to regulate the strength of the flow and preclude leakage. Once the liquid is sufficiently pressurized, it can be dispensed by a user opening an activation valve, such as by pressing on an activation button, and spray can be abruptly stopped by a user ceasing to push on such button. Or, for example, in alternate embodiments without an activation button, once the liquid is sufficiently pressurized, continuous spray occurs until the pressure chamber is emptied. By repeatedly pumping the trigger before the pressure chamber is fully emptied, continuous spray can be achieved. By designing the input volume to be amply greater than the volume of the pressure chamber, continuous spray with fewer pumping strokes can be implemented.
B05B 9/00 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
32.
System and method for dispensing a mixture of a liquid and an additive and cartridge for use therein
A liquid dispensing system includes at least one container for storing the liquid to be dispensed, the at least one container having a neck defining a fill opening for the liquid. The system includes a liquid dispensing device releasably connectable to the at least one container, an exchangeable cartridge for an additive to be mixed with the stored liquid, where the cartridge is accommodated in the neck, and a piercing member for opening the cartridge. The cartridge includes a one-piece hollow body filled with the additive and with a pressurized gas, and the piercing member is arranged to pierce a wall of the hollow body. A method of dispensing a liquid by using the liquid dispensing system, and a cartridge for use in the liquid dispensing system and/or method.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B65D 81/32 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu pour emballer plusieurs matériaux différents qui doivent être maintenus séparés avant d’être mélangés
F16K 15/14 - Soupapes, clapets ou valves de retenue à corps de soupapes flexibles
B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
G01F 11/08 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume avec chambres de mesure qui se dilatent ou se contractent au cours du mesurage du type à diaphragme ou à soufflet
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/10 - Dispositions de pompage pour transférer le contenu du récipient vers une chambre de pompage par un effet d'aspiration et forcer le contenu à sortir par la buse de distribution
F16K 21/00 - Obturateurs de distribution pour fluides
A61M 5/20 - Seringues automatiques, p. ex. avec tige de piston actionnée automatiquement, avec injection automatique de l'aiguille, à remplissage automatique
F16K 15/18 - Soupapes, clapets ou valves de retenue à mécanisme de commandeSoupape de retenue et soupape à mécanisme de commande combinées
33.
DEVICE FOR DISPENSING A MATERIAL BY MEANS OF PRESSURIZED GAS AND PARTIALLY GAS-FILLED TUBULAR BODY FOR USE THEREIN
A device for dispensing a material is disclosed, comprising a reservoir for the material and an outlet channel connectable to the reservoir. The reservoir may comprise a tubular body partially filled with pressurized gas and partially filled with the material to be dispensed. One end of the tubular body may be welded shut and an opposite end of the tubular body may be closed by a sealing member extending over at least part of a cross-sectional area of the tubular body. The sealing member may be arranged in a sleeve which is connected to the end of the tubular body opposite the welded end thereof. The sealing member may comprise a pierceable diaphragm and the device may further comprise a piercing member. Alternatively, the sealing member may comprise a movable valve or the sealing member may be removably fixed inside the tubular body and the device may further comprise an operating member. The tubular body and the piercing member or operating member, respectively, may be movable towards each other.
A device (1) for dispensing a liquid from a container (C) is disclosed, comprising: • an engine (2), comprising a nozzle (3) and a pump for transferring liquid from the container (C) to the nozzle (3); • a trigger (5), movable between a first position and a second position, connected to the pump for actuating the pump when brought from the first to the second position, and • connecting means, for connecting the engine (2) to the container (C) characterized by a slider (9) with at least one restricting element (10, 11), slidable between a non-restricting position, in which the trigger is movable between the first and second position, and a restricting position, in which the at least one restricting element restricts the movement of the trigger (5) between the first and the second position.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
35.
DEVICE AND SYSTEM FOR DISPENSING A LIQUID FROM A CONTAINER, AND METHOD FOR ASSEMBLING A DEVICE FOR DISPENSING A LIQUID
A device (1) for dispensing a liquid from a container (C) is disclosed, comprising: ? an engine (2), comprising a nozzle (3) and a pump for transferring liquid from the container (C) to the nozzle (3); ? a trigger (5), movable between a first position and a second position, connected to the pump for actuating the pump when brought from the first to the second position, and ? connecting means, for connecting the engine (2) to the container (C) characterized by a slider (9) with at least one restricting element (10, 11), slidable between a non-restricting position, in which the trigger is movable between the first and second position, and a restricting position, in which the at least one restricting element restricts the movement of the trigger (5) between the first and the second position.
A device for dispensing a material is disclosed, comprising a reservoir for the material and an outlet channel connectable to the reservoir. The reservoir may comprise a tubular body partially filled with pressurized gas and partially filled with the material to be dispensed. One end of the tubular body may be welded shut and an opposite end of the tubular body may be closed by a sealing member extending over at least part of a cross-sectional area of the tubular body. The sealing member may be arranged in a sleeve which is connected to the end of the tubular body opposite the welded end thereof. The sealing member may comprise a pierceable diaphragm and the device may further comprise a piercing member. Alternatively, the sealing member may comprise a movable valve or the sealing member may be removably fixed inside the tubular body and the device may further comprise an operating member. The tubular body and the piercing member or operating member, respectively, may be movable towards each other.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Machines and apparatus for storing and dispensing gases,
fluids, liquids, foams, mousses, gels, including paints,
beverages, soft foods; parts for the aforementioned
apparatus. Non-metallic containers and bottles, also vacuum, for
storing and dispensing industrial, chemical or commercial
gases, fluids and liquids, including foams and mists;
spraying heads and caps connectable to the aforementioned
containers and bottles; plastic packaging components for the
aforementioned containers and bottles, namely spraying
heads, dispensing closures, inner bags. Non-metallic containers and bottles, also vacuum, for
storing and dispensing goods for kitchen or household
purposes; aerosol dispensers not for medical use; empty
spray bottles; pump condiment dispensers; manually actuated
pump dispensers for household purposes; dispensers for
cleaning agents, home disinfecting solutions, personal care
fluids, plant care liquids, pet care, car care, food and
cooking liquids, including foams and mists, all for
household purposes; dispensers for liquid soap; manually
actuated pump dispensers connectable to containers or
bottles to dispense cleaning agents, home disinfecting
solutions, personal care liquids, plant care liquids, pet
care, car care, food or cooking liquids, including foams and
mists, all for household purposes; hand operated atomizers,
vaporizers, and sprayers for use with cleaning agents, home
disinfecting solutions, personal care fluids, plant care
liquids, pet care, car care, food and cooking liquids, all
for household purposes; dispensing units for household use;
non-metallic containers and bottles for cleaning agents,
disinfecting solutions, personal care fluids, plant care
liquids, pet care, car care, food and cooking liquids,
including foams and mists, all for household purposes;
manually actuated fluid pump dispensers connectable to
containers and bottles to dispense cleaning solutions, home
disinfecting solutions, personal care fluids, plant care
liquids, pet care, car care, food or cooking liquids,
including foams and mists, all for household purposes;
plastic packaging components for the aforementioned
containers and bottles, namely spraying heads, dispensing
closures, inner bags.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Hand operated atomizers, vaporizers, and sprayers for use with industrial, industrial chemical, and commercial liquids.
(2) Non-metallic containers and bottles for industrial, industrial chemical, and commercial liquids, including foams and mists; caps connectable to containers and bottles for industrial, chemical or commercial liquids, including foams and mists; plastic packaging components for containers and bottles, namely spraying heads and dispensing closures; non-metallic containers for cleaning agents, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids, including foams and mists.
(3) Aerosol dispensers namely trigger aerosol sprayers for household use, kitchen use, personal care, plant care, pet care, car care and food preparation and cooking; manually actuated pump dispensers for attachment to containers for use in dispensing liquids; dispensers for cleaning agents, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids, including foams and mists; dispensers for liquid soap; manually actuated pump dispensers connectable to containers or bottles to dispense cleaning agents, disinfecting solutions, personal care liquids, plant care liquids, pet care, car care, food or cooking liquids, including foams and mists; hand operated atomizers, vaporizers, and sprayers for use cleaning agents and disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids; aerosol dispensers namely trigger aerosol sprayers for household use, kitchen use, personal care, plant care, pet care, car care and food preparation and cooking; spray heads connectable to containers and bottles to dispense its content, namely industrial, chemical or commercial liquids, including foams and mists; plastic packaging components for containers and bottles, namely spray heads and dispensing closures; non-metallic bottles for cleaning agents, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids, including foams and mists; manually actuated fluid pump dispensers connectable to containers and bottles to dispense cleaning solutions, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food or cooking liquids, including foams and mists.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers and sprayers for use with industrial, industrial chemical, and commercial liquids; hand operated vaporizers for use with industrial and industrial chemical liquids non-metallic trigger spray containers and trigger spray bottles, sold empty, for industrial, industrial chemical, and commercial liquids, including foams and mists; non-metallic closures for containers and bottles, namely trigger spray caps connectable to containers and bottles to dispense industrial, industrial chemical, or commercial liquids, including foams and mists; plastic packaging closures for containers and bottles, namely spraying heads and dispensing closures Aerosol dispensers not for medical use; empty spray bottles; concession dispensing equipment, namely pump condiment dispensers; manually actuated pump dispensers for attachment to containers for use in dispensing liquids; trigger spray dispensers for cleaning solutions and disinfecting solutions, including in the form of foams and mists; trigger spray dispensers for personal care fluids, namely liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants, including in the form of foams and mists; trigger spray dispensers for plant care liquids, namely solutions for plant care and shine, insect repellent; trigger spray dispensers for pet care liquids, namely pet smell remover, equine care sprays, liquid soaps and hair care products for animals; trigger spray dispensers for car care liquids, namely vehicle cleaning solutions, surface maintenance and repair solutions, odour fragrances; trigger spray dispensers for food and cooking liquids, sold empty, namely solutions for cooking, dressing, seasoning, baking; dispensers for liquid soap; manually actuated pump dispensers connectable to containers or bottles to dispense cleaning agents and disinfecting solutions; manually actuated pump dispensers connectable to containers or bottles to dispense personal care liquids, namely liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants; manually actuated pump dispensers connectable to containers or bottles to dispense plant care liquids, namely solutions for plant care and shine, insect repellent; manually actuated pump dispensers connectable to containers or bottles to dispense pet care liquids, namely pet smell remover, equine care sprays, liquid soaps and hair care products for animals; manually actuated pump dispensers connectable to containers or bottles to dispense car care liquids, namely vehicle cleaning solutions, surface maintenance and repair solutions, odour fragrances; manually actuated pump dispensers connectable to containers or bottles to dispense food and cooking liquids, namely solutions for cooking, dressing, seasoning, baking, including in the form of foams and mists; hand operated atomizers, sold empty, for household use for use with cleaning agents and disinfecting solutions; hand operated vaporizers, sold empty, for personal care fluids, namely liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants; hand operated vaporizers, sold empty, for use with pet care liquids, namely pet smell remover, equine care sprays, liquid soaps and hair care products for animals; hand operated vaporizers, sold empty, for use with car care liquids, namely vehicle cleaning solutions, surface maintenance and repair solutions, odour fragrances; hand operated vaporizers, sold empty, for use with plant care liquids, namely solutions for plant care and shine, insect repellent; hand operated vaporizers, sold empty, for use with food and cooking liquids, namely solutions for cooking, dressing, seasoning, baking; dispensing units for household use, namely sprays for use with cleaning agents and disinfecting solutions; plastic parts of dispensing containers and bottles for household use, namely trigger spray heads and dispensing closures; non-metallic bottles, sold empty, for use with cleaning solutions, disinfecting solutions, personal care fluids, plant care liquids as well as for pet care, car care, food and cooking liquids, including such liquids in the form of foams and mists; manually actuated fluid pump dispensers connectable to containers and bottles to dispense liquids in the field of cleaning and disinfecting, including in the form of foams and mists
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Empty hand-operated atomizers, vaporizers and sprayers for
use with industrial, chemical liquids; empty hand-operated
atomizers, vaporizers and sprayers for liquids in the field
of agriculture, gardening, animal care. Non-metal dispensing heads or dispensing containers for
industrial, chemical or commercial liquids, including foams
and mists; non-metal trigger sprayers and trigger spray
containers, also reusable, refillable and recyclable, to
hold liquids for chemical, industrial or commercial use;
non-metal containers for chemical, industrial or commercial
liquids; plastic packaging components for cans, bottles and
containers with dispensing capacity. Empty aerosol dispensers and cans, not for medical use;
empty trigger sprayers not for medical use; concession
dispensing equipment, namely, condiment pump dispensers and
manually actuated pump dispensers for attachment to
containers for the purpose of dispensing fluids, including
foams and mists; hand operated atomizers, vaporizers, and
sprayers for use with products [liquids] for household
cleaning, disinfection and hygiene; hand operated atomizers,
vaporizers, and sprayers for use with liquids in the field
of food and beverages; hand operated atomizers, vaporizers,
and sprayers for use with liquids in the field of automotive
cleaning, disinfection or hygiene; non-metallic empty
packaging components, comprising dispensing features, for
liquid products in the field of household cleaning, air
care, disinfection, hygiene, food and beverages; manually
actuated fluid pump dispensers connectable to packaging
containers for use with liquids in the field of household
cleaning, disinfection, hygiene, food and beverages; empty
hand-operated atomizers, vaporizers and sprayers for liquids
in the field of personal care.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers, vaporizers, and sprayers for use
with industrial, industrial chemical, and commercial
liquids. Non-metallic containers and packaging bottles [containers]
for industrial, chemical and commercial liquids, including
foams and mists; non-metallic spraying heads and caps
connectable to containers and bottles to dispense its
content, namely industrial, chemical or commercial liquids,
including foams and mists; plastic packaging components for
containers and bottles, namely spraying heads and dispensing
closures. Aerosol dispensers not for medical use; empty spray bottles;
pump condiment dispensers; manually actuated pump
dispensers; dispensers for cleaning agents, disinfecting
solutions, personal care fluids, plant care liquids, pet
care, car care, food and cooking liquids, including foams
and mists; dispensers for liquid soap; manually actuated
pump dispensers connectable to containers or bottles to
dispense cleaning agents, disinfecting solutions, personal
care liquids, plant care liquids, pet care, car care, food
or cooking liquids, including foams and mists; hand operated
atomizers, vaporizers, and sprayers for use as cleaning
agents and for disinfecting solutions, as well as for
personal care fluids, plant care liquids and for pet care,
car care, food and cooking liquids; dispensing units for
household use; non-metallic containers and bottles for
cleaning agents, for disinfecting solutions, for personal
care fluids, plant care liquids as well as for pet care, car
care, food and cooking liquids, including foams and mists;
manually actuated fluid pump dispensers connectable to
containers and bottles to dispense liquids in the field of
cleaning, disinfecting, personal care, plant care, pet care,
car care, food or cooking, including foams and mists.
A preform can be made from two different materials that do not bond together by a bi-injection process, using the same mold. First an outer preform can be fashioned first, then an inner preform molded through a center hole in the outer preform, and the preforms connected. Inner/outer preform materials can be different, e.g., PET/polyolefin or polyamide, or the same, e.g., PET/PET. To prevent mutual bonding during molding of the second, a non-stick coating can be sprayed on a surface portion of the first preform prior to molding, the second. Manufacturing order can be either outer/inner, or inner/outer, and the non-stick coating sprayed on the inside/outside of the perform first molded.
B65D 77/06 - Liquides ou semi-liquides enfermés dans des réceptacles flexibles disposés dans des réceptacles rigides
B65D 83/00 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu
B29B 11/04 - Fabrication de préformes par assemblage de matière préformée
B29C 49/00 - Moulage par soufflage, c.-à-d. en soufflant une préforme ou une paraison dans un moule pour obtenir la forme désiréeAppareils à cet effet
B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
B29C 65/06 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage en utilisant la friction, p. ex. soudage par rotation
B29C 65/08 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage avec des vibrations ultrasonores
B29C 65/48 - Assemblage d'éléments préformésAppareils à cet effet en utilisant des adhésifs
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Machines and apparatus for storing and dispensing gases, fluids, liquids, foams, mousses, gels, including paints, beverages, soft foods; parts for the aforementioned apparatus.
(2) Parts for the aforementioned apparatus; machines and apparatus for storing and dispensing gases, fluids, liquids, foams, mousses, gels, including paints, beverages, soft foods
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers, vaporizers, and sprayers for use
with industrial, industrial chemical, and commercial
liquids. Non-metallic containers and bottles for industrial,
industrial chemical, and commercial liquids, including foams
and mists; non-metallic spraying heads and caps connectable
to containers and bottles to dispense its content, namely
industrial, chemical or commercial liquids, including foams
and mists; plastic packaging components for containers and
bottles, namely spraying heads and dispensing closures. Aerosol dispensers not for medical use; empty spray bottles;
pump condiment dispensers; manually actuated pump
dispensers; dispensers for cleaning agents, disinfecting
solutions, personal care fluids, plant care liquids, pet
care, car care, food and cooking liquids, including foams
and mists; dispensers for liquid soap; manually actuated
pump dispensers connectable to containers or bottles to
dispense cleaning agents, disinfecting solutions, personal
care liquids, plant care liquids, pet care, car care, food
or cooking liquids, including foams and mists; hand operated
atomizers, vaporizers, and sprayers for use as cleaning
agents and for disinfecting solutions, as well as for
personal care fluids, plant care liquids and for pet care,
car care, food and cooking liquids; dispensing units for
household use; non-metallic containers and bottles for
cleaning agents, for disinfecting solutions, for personal
care fluids, plant care liquids as well as for pet care, car
care, food and cooking liquids, including foams and mists;
manually actuated fluid pump dispensers connectable to
containers and bottles to dispense liquids in the field of
cleaning, disinfecting, personal care, plant care, pet care,
car care, food or cooking, including foams and mists.
Machines, namely, power-operated hand-held dispensers for attachment to liquid containers for use in dispensing fluids and liquids, including in the form of foams, mousses, and gels; and replacement parts for the aforementioned dispensers Non-metallic containers and cylinders sold empty, including vacuum containers and cylinders sold empty, for storing and dispensing industrial and commercial gases, fluids and liquids, including foams and mists; non-metal closures for containers, namely, spraying head caps and caps connectable to non-metallic containers and cylinders for storing and dispensing industrial and commercial fluids and liquids, including foams and mists; plastic packaging closures for containers and cylinders for storing and dispensing industrial and commercial gases, fluids and liquids, namely, spraying head caps and dispensing closures
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Non-metallic bottles sold empty, including vacuum bottles sold empty, for storing and dispensing liquid goods for household cleaning purposes; aerosol dispensers not for medical use; empty spray bottles; pump condiment dispensers, namely, pump condiment dispensers for commercial concession stands; manually actuated pump dispensers for attachment to bottles for use in dispensing liquids; dispensers for cleaning solutions and disinfecting solutions, foams and mists; cylindrical dispensers for personal care fluids, namely, bottles, sold empty for use with liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, and deodorants; dispensers for liquids for plant care, namely, bottles, sold empty for use with liquid solutions for plant care; dispensers for pet care, namely, bottles, sold empty for use with liquid pet smell remover, equine care sprays, liquid shampoo and hair care products for animals; dispensers for car care, namely, bottles, sold empty for use with liquid cleaning solutions, surface maintenance and repair solutions, and odor fragrances; manually actuated pump dispensers connectable to containers or bottles to dispense cleaning solutions and disinfecting solutions; hand operated atomizers for household use for use with cleaning agents and disinfecting solutions; hand operated vaporizers sold empty for use with personal care fluids, sun protection liquids, liquid hair care products, liquid skin care products, facial sprays, perfumes, and deodorants; dispensing units for household use, namely, sprayers in the nature of dispensers for use with cleaning agents and disinfecting solutions; non-metallic bottles sold empty for use with cleaning solutions, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids, including such liquids in the form of foams and mists; manually actuated fluid pump dispensers connectable to containers and bottles for household use to dispense cleaning solutions, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food or cooking liquids, including such liquids in the form of foams and mists
A preform can be made from two different materials that do not bond together by a bi-injection process, using the same mold. First an outer preform can be fashioned first, then an inner preform molded through a center hole in the outer preform, and the preforms connected. Inner/outer preform materials can be different, e.g., PET/polyolefin or polyamide, or the same, e.g., PET/PET. To prevent mutual bonding during molding of the second, a non-stick coating can be sprayed on a surface portion of the first preform prior to molding, the second. Manufacturing order can be either outer/inner, or inner/outer, and the non-stick coating sprayed on the inside/outside of the perform first molded.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Hand operated atomizers, vaporizers, and sprayers for use with industrial, industrial chemical, and commercial liquids.
(2) Non-metallic containers and bottles for industrial, industrial chemical, and commercial liquids, including foams and mists; non-metallic spraying heads and caps connectable to containers and bottles to dispense its content, namely industrial, chemical or commercial liquids, including foams and mists; plastic packaging components for containers and bottles, namely spraying heads and dispensing closures.
(3) Aerosol dispensers not for medical use; empty spray bottles; pump condiment dispensers; manually actuated pump dispensers; dispensers for cleaning agents, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids, including foams and mists; dispensers for liquid soap; manually actuated pump dispensers connectable to containers or bottles to dispense cleaning agents, disinfecting solutions, personal care liquids, plant care liquids, pet care, car care, food or cooking liquids, including foams and mists; hand operated atomizers, vaporizers, and sprayers for use as cleaning agents and for disinfecting solutions, as well as for personal care fluids, plant care liquids and for pet care, car care, food and cooking liquids; dispensing units for household use; non-metallic containers and bottles for cleaning agents, for disinfecting solutions, for personal care fluids, plant care liquids as well as for pet care, car care, food and cooking liquids, including foams and mists; manually actuated fluid pump dispensers connectable to containers and bottles to dispense liquids in the field of cleaning, disinfecting, personal care, plant care, pet care, car care, food or cooking, including foams and mists.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Hand operated atomizers, vaporizers, and sprayers for use with industrial, industrial chemical, and commercial liquids.
(2) Non-metallic containers and packaging bottles [containers] for industrial, chemical and commercial liquids, including foams and mists; non-metallic spraying heads and caps connectable to containers and bottles to dispense its content, namely industrial, chemical or commercial liquids, including foams and mists; plastic packaging components for containers and bottles, namely spraying heads and dispensing closures.
(3) Aerosol dispensers namely trigger aerosol sprayers for household use, kitchen use, personal care, plant care, pet care, car care and food preparation and cooking; empty spray bottles; pump condiment dispensers; manually actuated pump dispensers for attachment to containers for use in dispensing liquids; dispensers for cleaning agents, disinfecting solutions, personal care fluids, plant care liquids, pet care, car care, food and cooking liquids, including foams and mists; dispensers for liquid soap; manually actuated pump dispensers connectable to containers or bottles to dispense cleaning agents, disinfecting solutions, personal care liquids, plant care liquids, pet care, car care, food or cooking liquids, including foams and mists; hand operated atomizers, vaporizers, and sprayers for use as cleaning agents and for disinfecting solutions, as well as for personal care fluids, plant care liquids and for pet care, car care, food and cooking liquids; dispensing units for household use, namely sprayers in the nature of dispensers, for use with cleaning agents and disinfecting solutions; non-metallic containers and bottles for cleaning agents, for disinfecting solutions, for personal care fluids, plant care liquids as well as for pet care, car care, food and cooking liquids, including foams and mists; manually actuated fluid pump dispensers connectable to containers and bottles to dispense liquids in the field of cleaning, disinfecting, personal care, plant care, pet care, car care, food or cooking, including foams and mists.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers and sprayers for use with industrial, industrial chemical, and commercial liquids; hand operated vaporizers for use with industrial and industrial chemical liquids Non-metallic containers, sold empty, for industrial, industrial chemical and commercial liquids, including foams and mists; non-metallic closures for containers and bottles, namely, spraying heads and caps connectable to containers and bottles to dispense industrial, industrial chemical or commercial liquids, including foams and mists; plastic packaging closures for containers and bottles, namely, spraying heads and dispensing closures Aerosol dispensers not for medical use; empty spray bottles; concession dispensing equipment, namely, pump condiment dispensers; manually actuated pump dispensers for attachment to containers for use in dispensing liquids; dispensers for cleaning solutions and disinfecting solutions, including foams and mists; dispensers for personal care fluids, namely, spray bottles, sold empty, for use with liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants, including foams and mists; dispensers for pet care, namely, spray bottles, sold empty, for use with pet smell remover, equine care sprays, liquid soaps and hair care products for animals, including foams and mists; dispensers for car care liquids, namely, spray bottles, sold empty, for use with vehicle cleaning solutions, surface maintenance and repair solutions, odor fragrances; dispensers for food and cooking liquids, namely, spray bottles, sold empty, for use with solutions for cooking, dressing, seasoning, baking; dispensers for liquids for plant care, namely, spray bottles, sold empty, for use with solutions for plant care and shine, insect repellent, including foams and mists; dispensers for liquid soap; manually actuated pump dispensers connectable to containers or bottles to dispense cleaning solutions and disinfecting solutions, including foams and mists; manually actuated pump dispensers connectable to containers or bottles to dispense personal care fluids, namely, liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants, including in the form of foams and mists; manually actuated pump dispensers connectable to containers or bottles to dispense pet care liquids, namely, pet smell removing preparations, equine care sprays, liquid soaps and hair care preparations for animals, including in the form of foams and mists; manually actuated pump dispensers connectable to containers or bottles to dispense car care liquids, namely, vehicle cleaning solutions, surface maintenance and repair solutions, and odor fragrances; manually actuated pump dispensers connectable to containers or bottles to dispense food and cooking liquids, namely, liquids for cooking, dressing, seasoning, and baking; manually actuated pump dispensers connectable to containers or bottles to dispense liquids for plant care, namely, solutions for plant care, including in the form of foams and mists; hand operated atomizers, sold empty, for household use for use with cleaning agents and disinfecting solutions; hand operated vaporizers, sold empty, for personal care fluids, namely, liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants; hand-operated plastic spray nozzles and spraying bottles, sold empty for use with pet care liquids, namely, pet smell remover, equine care sprays, liquid soaps and hair care products for animals; hand-operated plastic spray nozzles and spraying bottles, sold empty for use with car care liquids, namely, vehicle cleaning solutions, surface maintenance and repair solutions, odor fragrances; hand-operated plastic spray nozzles and spraying bottles, sold empty for use with plant care liquids, namely, solutions for plant care; hand-operated plastic spray nozzles and spraying bottles, sold empty for use with food and cooking liquids, namely, solutions for cooking, dressing, seasoning, baking; dispensing units for household use, namely, sprayers in the nature of dispensers, for use with cleaning agents and disinfecting solutions; non-metallic bottles, sold empty, for use with cleaning solutions, disinfecting solutions, personal care fluids, plant care liquids as well as for pet care, car care, food and cooking liquids, including such liquids in the form of foams and mists; manually actuated fluid pump dispensers connectable to containers and bottles to dispense liquids in the field of cleaning and disinfecting, including in the form of foams and mists
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Hand operated atomizers, vaporizers, and sprayers for use with industrial, chemical and commercial liquids.
(2) Non-metallic containers for industrial, chemical and commercial liquids, including foams and mists, and fluid dispensers connectable to such containers for use therewith to dispense industrial, chemical and commercial liquids, including foams and mists, from such containers.
(3) Aerosol dispensers not for medical use, concession dispensing equipment, namely, condiment pump dispensers and manually actuated pump dispensers for attachment to containers for use in dispensing cooking fluid, including foams and mists; dispensers for cleaning and disinfecting solutions, and household and household kitchen cleaning and cooking liquids, including foams and mists, dispensers for liquid soap, manually actuated pump dispensers for attachment to containers for use in dispensing cleaning and disinfecting solutions, and household and household kitchen liquids, including foams and mists; hand operated atomizers, vaporizers, and sprayers for use with both household and household kitchen liquids; dispensing units for disinfecting liquids, kitchen cleaning and cooking liquids, for household use; non-metallic containers for household and household kitchen liquids, including foams and mists, and manually actuated fluid pump dispensers connectable to such containers for use therewith to dispense household and household kitchen liquids, including foams and mists, from such containers.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Empty hand-operated atomizers, vaporizers and sprayers for use with industrial, chemical liquids; empty hand-operated atomizers, vaporizers and sprayers for liquids in the field of agriculture, gardening, animal care.
(2) Non-metal dispensing heads or dispensing containers for industrial, chemical or commercial liquids, including foams and mists; non-metal trigger sprayers and trigger spray containers, also reusable, refillable and recyclable, to hold liquids for chemical, industrial or commercial use; non-metal containers namely non-metal storage and dispensing bottles for packaging and dispensing industrial, chemical or commercial liquids; plastic packaging components for cans, bottles and containers with dispensing capacity.
(3) Empty aerosol dispensers namely empty aerosol trigger sprayer containers for household use, kitchen use, personal care use, plant care use, pet care use, car care use and food preparation and cooking use; empty spray bottles, for household use, kitchen use, personal care use, plant care use, pet care use, car care use and food preparation and cooking use; concession dispensing equipment, namely, condiment pump dispensers and manually actuated pump dispensers for attachment to containers for the purpose of dispensing fluids, including foams and mists; hand-operated atomizers, vaporizers, and sprayers for use with products [liquids] for household cleaning, disinfection and hygiene; hand-operated atomizers, vaporizers, and sprayers for use with liquids in the field of food and beverages; hand-operated atomizers, vaporizers, and sprayers for use with liquids in the field of automotive cleaning, disinfection or hygiene; non-metallic empty packaging components, namely non-metallic closures for empty bottles and containers equipped with a dispensing feature for use with storing and dispensing liquid products in the field of household cleaning, air care, disinfection, personal hygiene, and food and beverage preparation; manually actuated fluid pump dispensers connectable to packaging containers for use with liquids in the field of household cleaning, disinfection, hygiene, food and beverages; empty hand-operated atomizing, vaporizing and spraying bottles for use with storing and dispensing liquids in the field of personal care.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Empty hand-operated atomizers, vaporizers and sprayers for use with industrial liquids and industrial chemical liquids; empty hand-operated atomizers and sprayers for liquids for industrial and commercial use in the field of agriculture, gardening, animal care; empty hand-operated vaporizers for liquids for industrial and commercial use in the field of agriculture, gardening, animal care Non-metal dispensing closures for containers and non-metal dispensing containers for industrial, industrial chemical and commercial liquids, including in the form of foams and mists; disposable, reusable, refillable and recyclable non-metal trigger spraying closures and trigger spray containers to dispense and hold liquids for industrial chemical and commercial use; non-metal containers for industrial, industrial chemical and commercial liquids; plastic packaging closures for cans, bottles and containers with dispensing capacity, namely, spraying heads and dispensing closures Empty aerosol dispensers, not for medical use; empty non-metal aerosol cans, not for medical use; empty trigger sprayers, namely, empty spray bottles, not for medical use; concession dispensing equipment, namely, condiment pump dispensers and manually actuated pump dispensers for attachment to containers for the purpose of dispensing fluids, including foams and mists; hand operated atomizers for household use for use with liquids for household cleaning, disinfection and hygiene; hand operated spray dispensers, namely, empty spray bottles, for household use for use with liquids for household cleaning, disinfection and hygiene; hand operated atomizers, sold empty, for household use for use with liquids in the field of food and beverages; hand operated spray dispensers, namely, empty spray bottles, for household use for use with liquids in the field of food and beverages; hand operated trigger spray bottles, sold empty, for use with car care liquids, namely, vehicle cleaning solutions, surface maintenance and repair solutions, odor fragrances; non-metallic empty packaging components, namely, plastic spray nozzles and spraying bottles, sold empty, for dispensing liquid products in the field of household cleaning, air care, disinfection, hygiene, food and beverages; manually actuated fluid pump dispensers connectable to packaging containers for use with dispensing liquids in the field of household cleaning, disinfection, hygiene, food and beverages; empty hand-operated sprayers, namely, plastic spray nozzles and spraying bottles, sold empty, for household use with liquids in the field of personal care; empty hand-operated vaporizers for use with liquids in the field of personal care, namely, liquid soaps, liquids for sun protection, liquid hair care products, liquid skin care products, facial sprays, perfumes, deodorants
54.
Metered and active sprayer devices with aerosol functionality (“Flairosol II”)
In exemplary embodiments of the present invention, “Flairosol” dispensing devices can be provided. Such devices utilize a combination of Flair® technology, pre-compression valves and aerosol-like pressurization of the dispensed liquid. Such a dispensing device has, for example, a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a container, for example, the inner container of a Flair® bottle, and fills the pressure chamber with that liquid as a user operates a trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve, which serve to prevent backflow. Liquid exiting the piston chamber under pressure (supplied by, a user pumping the trigger) enters a central vertical channel which is in fluid communication with both the pressure chamber (above the pressure piston) and a dome valve provided near the outlet channel at the top of the dispensing head. The dome valve has a preset pressure, such that once exceeded by the liquid, opens and allows for a spray. If the liquid pressure drops below such preset pressure, the dome valve closes off the outlet channel, which serves to regulate the strength of the flow and preclude leakage. Alternatively, in an activated embodiment, for example, once the liquid is sufficiently pressurized, it can be dispensed by a user allowing the dome valve to open by pressing on an activation button that removes a dome lock.
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B65D 83/62 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur avec un contenu et un propulseur séparés par des membranes, des sacs ou similaires
In embodiments, aerosol-type devices are provided. The devices have a main body comprising a pressure chamber, with pressure piston and pressure spring, and a piston chamber which draws liquid from a reservoir and fills the pressure chamber as a user performs compression and release strokes. The piston chamber has both inlet and outlet valves. In a dispensing head a valve is provided to regulate the flow strength and preclude leakage. Once the liquid is sufficiently pressurized, it is dispensed by a user opening an activation valve, and spray can be abruptly stopped by closing the activation valve. In alternate embodiments, without an activation valve, once the liquid is pressurized, continuous spray occurs until the pressure chamber is fully emptied. Pumping the trigger before the pressure chamber is fully emptied achieves continuous spray. When the input volume is greater than the volume of the pressure chamber volume, continuous spray with fewer pumping strokes occurs.
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
Various uses of a gas-filled resilient body are disclosed. The gas-filled resilient body may be used as a valve member, as a spring or as a gas-propelled dispenser.
The invention relates to a liquid dispensing system comprising at least one container for storing the liquid to be dispensed, the at least one container having a neck defining an fill opening for the liquid; a liquid dispensing device releasably connectable to the at least one container; an exchangeable cartridge for an additive to be mixed with the stored liquid, said cartridge being accommodated in the neck; and means for opening the cartridge, wherein the cartridge comprises a one-piece hollow body filled with the additive and with a pressurized gas; and the opening means comprise at least one piercing member arranged to pierce a wall of the hollow body. The invention further relates to a method of dispensing a liquid by using the above liquid dispensing system. And finally, the invention relates to a cartridge for use in the liquid dispensing system and/or method.
Disclosed is a method of using a partially gas-filled resilient hollow body as a gas-propelled dispenser. The resilient hollow body is filled with compressed gas and a material to be dispensed, which is dispensed by piercing the resilient hollow body. Also disclosed is a rapid-action dispensing device. This device includes means for pressurizing a liquid to be dispensed, an outlet opening closed off by a manually operable valve, and a resilient hollow body filled with gas only and arranged in a buffer housing between the pressurizing means and the outlet; this buffers the pressurized liquid in a volume defined between the gas-filled resilient body and a wall of the buffer housing by compressing the gas-filled resilient hollow body until the valve is manually opened. Also disclosed is a dispensing device that includes a housing, having an outlet opening, a resilient hollow body partially filled with compressed gas and partially filled with a material to be dispensed, and a piercing member for piercing the resilient hollow body so as to allow the material to be urged out by the gas. In this device, the piercing member and the resilient hollow body are movable with respect to each other.
The invention relates to a liquid dispensing system comprising at least one container for storing the liquid to be dispensed, the at least one container having a neck defining an fill opening for the liquid; a liquid dispensing device releasably connectable to the at least one container; an exchangeable cartridge for an additive to be mixed with the stored liquid, said cartridge being accommodated in the neck; and means for opening the cartridge, wherein the cartridge comprises a one-piece hollow body filled with the additive and with a pressurized gas; and the opening means comprise at least one piercing member arranged to pierce a wall of the hollow body. The invention further relates to a method of dispensing a liquid by using the above liquid dispensing system. And finally, the invention relates to a cartridge for use in the liquid dispensing system and/or method.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
60.
Device, system and method for dispensing a liquid from a container
The invention relates to a device (1) for dispensing a liquid from a container (C), comprising a pump (2) having a suction side (S) that is adapted to be brought into fluid communication with the container (C), a spray nozzle (3) in fluid communication with a pressure side (P) of the pump (2) through an outlet channel (4), a pre-compression valve (5) arranged in the outlet channel (4), and a gas buffer (9) in fluid communication with the pressure side (P) of the pump (2) and with the spray nozzle (3). The gas buffer (9) may comprise a buffer chamber (10) in which a gas-filled resiliently deformable body (11) is arranged, and the gas buffer (9) may extend from the pressure side (P) of the pump (2) in a different direction than the outlet channel (4). The invention further relates to a system for dispensing a liquid, comprising a container (C) that is filled with the liquid and a dispensing device (1) of the type described above connected to the container (C). And the invention relates to a method for dispensing a liquid, comprising the steps of:—drawing the liquid from a container (C) and pressurizing the liquid by actuating a pump (2), wherein the container (C) and the pump (2) form part of a dispensing system;—guiding a part of the pressurized liquid to a spray nozzle (3) of the dispensing system;—spraying the liquid from the nozzle (3);—guiding another part of the pressurized liquid to a gas buffer (9) for temporary storage; and—spraying the stored liquid from the nozzle (3) when the pump (2) is not being actuated; wherein the pressurized liquid is guided from the pump (2) to the spray nozzle (3) in a different direction than from the pump (2) to the gas buffer (9).
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
61.
SYSTEM AND METHOD FOR DISPENSING A MIXTURE OF LIQUID AND ACTIVE LIQUID AND CARTRIDGE FOR USE THEREIN
A liquid dispensing system (1) comprising at least one container (2) for storing the liquid to be dispensed and a liquid dispensing device (4) releasably connectable to the at least one container (2), wherein a cartridge (3) for a active liquid to be mixed with the stored liquid is accommodated in a neck (10) of the container (2), said cartridge (3) comprising a sealed active liquid reservoir (6), opening means (16) for forming the outflow opening in at least one reservoir wall; and further comprising aerating means (23) for forming at least one aerating opening in at least one of a top wall (7) and a side wall (8) of the reservoir (6).
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B65D 81/32 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu pour emballer plusieurs matériaux différents qui doivent être maintenus séparés avant d’être mélangés
B65D 51/28 - Fermetures non prévues ailleurs combinées avec dispositifs auxiliaires pour des buts autres que la fermeture avec réceptacles auxiliaires pour objets ou matériaux supplémentaires
The invention relates to a liquid dispensing system comprising a liquid dispensing device (2) and one or more containers (3) for storing the liquid to be dispensed, wherein the liquid dispensing device is releasably connected to one of the containers. The liquid dispensing system includes means for preventing refilling of the at least one container. The refill prevention means may include a restriction element (7) which may be fixed in a neck of the container and may almost completely close off a fill opening defined by the neck. The invention further relates to a method of dispensing a liquid, comprising the steps of filling at least one container with the liquid to be dispensed, providing a liquid dispensing device, connecting the liquid dispensing device to the at least one container, and actuating the liquid dispensing device, wherein after filling the container is provided with means for preventing refilling thereof.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
63.
SYSTEM AND METHOD FOR DISPENSING LIQUID FOAM, IN PARTICULAR A DIRECT-FOAM CLEANING PRODUCT
A system for dispensing liquid foam, in particular a direct foam cleaning product, comprises a container for the liquid and a dispensing apparatus connected to the container. The dispensing apparatus comprises a pump comprising a pump chamber in fluid communication with the container and a piston arranged in the pump chamber, the piston and pump chamber being movable with respect to one another. An outlet channel connects the pump chamber to a nozzle. A pre-compression valve is arranged between the outlet channel and the nozzle; and a buffer comprising a buffer chamber is connected to the outlet channel. The buffer chamber includes a compressible variator arranged therein for varying the usable volume of the buffer chamber; wherein the nozzle, the buffer and the pump are configured and dimensioned such that the foam is dispensed in a predetermined spray pattern.
B05B 7/00 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p. ex. un liquide et de l'air, une poudre et un gaz
64.
DEVICE, SYSTEM AND METHOD FOR DISPENSING A LIQUID FROM A CONTAINER
The invention relates to a device (1) for dispensing a liquid from a container (C), comprising a pump (2) having a suction side (S) that is adapted to be brought into fluid communication with the container (C), a spray nozzle (3) in fluid communication with a pressure side (P) of the pump (2) through an outlet channel (4), a pre-compression valve (5) arranged in the outlet channel (4), and a gas buffer (9) in fluid communication with the pressure side (P) of the pump (2) and with the spray nozzle (3). The gas buffer (9) may comprise a buffer chamber (10) in which a gas-filled resiliently deformable body (11) is arranged, and the gas buffer (9) may extend from the pressure side (P) of the pump (2) in a different direction than the outlet channel (4). The invention further relates to a system for dispensing a liquid, comprising a container (C) that is filled with the liquid and a dispensing device (1) of the type described above connected to the container (C). And the invention relates to a method for dispensing a liquid, comprising the steps of: - drawing the liquid from a container (C) and pressurizing the liquid by actuating a pump (2), wherein the container (C) and the pump (2) form part of a dispensing system; - guiding a part of the pressurized liquid to a spray nozzle (3) of the dispensing system; - spraying the liquid from the nozzle (3); - guiding another part of the pressurized liquid to a gas buffer (9) for temporary storage; and - spraying the stored liquid from the nozzle (3) when the pump (2) is not being actuated; wherein the pressurized liquid is guided from the pump (2) to the spray nozzle (3) in a different direction than from the pump (2) to the gas buffer (9).
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
The invention relates to a system (1) for dosed dispensing of a fluid, comprising a contain (2) for the fluid and a dispensing device connected therewith, wherein the container comprises a form-retaining outer container (5) and a flexible inner container (4) connected therewith, wherein a space to be brought into fluid communication with the ambient atmosphere can be developed between the inner and outer containers (5, 4), and wherein the dispensing device includes a housing and/or frame of which at least a part is integrally formed with the container. The invention further relates to a method of manufacturing a system for dosed dispensing of a fluid.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B29K 23/00 - Utilisation de polyalcènes comme matière de moulage
B29K 67/00 - Utilisation de polyesters comme matière de moulage
B29C 49/22 - Moulage par soufflage, c.-à-d. en soufflant une préforme ou une paraison dans un moule pour obtenir la forme désiréeAppareils à cet effet de préformes ou de paraisons multicouches
In exemplary embodiments of the present invention, “Flairosol” dispensing devices can be provided. Such devices utilize a combination of Flair® technology, pre-compression valves and aerosol-like pressurization of the dispensed liquid. Such a dispensing device has, for example, a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a container, for example, the inner container of a Flair® bottle, and fills the pressure chamber with that liquid as a user operates a trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve, which serve to prevent backflow. Liquid exiting the piston chamber under pressure (supplied by a user pumping the trigger) enters a central vertical channel which is in fluid communication with both the pressure chamber (above the pressure piston) and a dome valve provided near the outlet channel at the top of the dispensing head. The dome valve has a preset pressure, such that once exceeded by the liquid, opens and allows for a spray. If the liquid pressure drops below such preset pressure, the dome valve closes off the outlet channel, which serves to regulate the strength of the flow and preclude leakage. Alternatively, in an activated embodiment, for example, once the liquid is sufficiently pressurized, it can be dispensed by a user allowing the dome valve to open by pressing on an activation button that removes a dome lock.
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B65D 83/62 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur avec un contenu et un propulseur séparés par des membranes, des sacs ou similaires
In exemplary embodiments of the present invention, Flair® based aerosol-type devices can be provided. Such devices utilize a combination of Flair® technology, pre-compression valves and aerosol like pressurization of the dispensed liquid. Such a dispensing device has a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a reservoir and fills the pressure chamber with that liquid as a user operates the trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve. In a dispensing head a valve is provided to regulate the strength of the flow and preclude leakage. Once the liquid is sufficiently pressurized, it can be dispensed by a user opening an activation valve, such as by pressing on an activation button, and spray can be abruptly stopped by a user ceasing to push on such button. Or, for example, in alternate embodiments without an activation button, once the liquid is sufficiently pressurized, continuous spray occurs until the pressure chamber is emptied. By repeatedly pumping the trigger before the pressure chamber is fully emptied, continuous spray can be achieved. By designing the input volume to be amply greater than the volume of the pressure chamber, continuous spray with fewer pumping strokes can be implemented.
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers, vaporizers, and sprayers for use
with industrial, chemical and commercial liquids. Non-metallic containers for industrial, chemical and
commercial liquids, including foams and mists, and fluid
dispensers connectable to such containers for use therewith
to dispense industrial, chemical and commercial liquids,
including foams and mists, from such containers. Aerosol dispensers not for medical use, concession
dispensing equipment, namely, condiment pump dispensers and
manually actuated pump dispensers for attachment to
containers for use in dispensing cooking fluid, including
foams and mists; dispensers for cleaning and disinfecting
solutions, and household and household kitchen cleaning and
cooking liquids, including foams and mists, dispensers for
liquid soap, manually actuated pump dispensers for
attachment to containers for use in dispensing cleaning and
disinfecting solutions, and household and household kitchen
liquids, including foams and mists; hand operated atomizers,
vaporizers, and sprayers for use with both household and
household kitchen liquids; dispensing units for disinfecting
liquids, kitchen cleaning and cooking liquids, for household
use; non-metallic containers for household and household
kitchen liquids, including foams and mists, and manually
actuated fluid pump dispensers connectable to such
containers for use therewith to dispense household and
household kitchen liquids, including foams and mists, from
such containers.
70.
SYSTEM AND METHOD FOR DISPENSING LIQUID FOAM, IN PARTICULAR A DIRECT-FOAM CLEANING PRODUCT
The invention relates to a system for dispensing liquid foam, in particular a direct foam cleaning product, comprising a container for the liquid and a dispensing apparatus connected to the container. Here, the dispensing apparatus comprises a pump comprising a pump chamber in fluid communication with the container and a piston arranged in the pump chamber, the piston and pump chamber being movable with respect to one another; an outlet channel connecting the pump chamber to a nozzle; a pre-compression valve arranged between the outlet channel and the nozzle; and a buffer comprising a buffer chamber connected to the outlet channel, the buffer chamber including a compressible variator arranged therein for varying the usable volume of the buffer chamber; wherein the nozzle, the buffer and the pump are configured and dimensioned such that the foam is dispensed in a predetermined spray pattern.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
71.
Liquid dispensing device having a pre-compression outlet valve
Provided is a liquid dispensing device that includes: a piston chamber; a piston that is moveable within the piston chamber to pressurize a liquid to be dispensed; a nozzle with a defined throughput for dispensing the liquid; an outlet valve having a defined minimum opening pressure arranged between the piston chamber and the nozzle; and a prime valve for priming the device, where the prime valve may be mechanically operable and may be arranged on or in the piston.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
72.
SYSTEM FOR DOSED DISPENSING OF A FLUID AND METHOD OF MANUFACTURING
The invention relates to a system (1) for dosed dispensing of a fluid, comprising a container (2) for the fluid and a dispensing device connected therewith, wherein the container comprises a form-retaining outer container (5) and a flexible inner container (4) connected therewith, wherein a space to be brought into fluid communication with the ambient atmosphere can be developed between the inner and outer containers (5, 4), and wherein the dispensing device includes a housing and/or frame of which at least a part is integrally formed with the container. The invention further relates to a method of manufacturing a system for dosed dispensing of a fluid.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers, vaporizers, and sprayers for use with industrial, industrial chemical, and commercial liquids Non-metallic containers for industrial, industrial chemical, and commercial liquids, including foams and mists, and fluid dispensers connectable to such containers for use therewith to dispense industrial, industrial chemical and commercial liquids, including foams and mists, from such containers Aerosol dispensers not for medical use, concession dispensing equipment, namely, condiment pump dispensers and manually actuated pump dispensers for attachment to containers for use in dispensing cooking fluid, including foams and mists; dispensers for cleaning and disinfecting solutions, and household and household kitchen cleaning and cooking liquids, including foams and mists, dispensers for liquid soap, manually actuated pump dispensers for attachment to containers for use in dispensing cleaning and disinfecting solutions, and household and household kitchen liquids, including foams and mists; hand operated atomizers, vaporizers, and sprayers for use with both household and household kitchen liquids; dispensing units for disinfecting liquids, kitchen cleaning and cooking liquids, for household use; non-metallic containers for household and household kitchen liquids, including foams and mists, and manually actuated fluid pump dispensers connectable to such containers for use therewith to dispense household and household kitchen liquids, including foams and mists, from such containers
74.
LIQUID DISPENSING DEVICE HAVING A PRE-COMPRESSION OUTLET VALVE
The invention relates to a liquid dispensing device comprising: a piston chamber; a piston that is moveable within the piston chamber to pressurise a liquid to be dispensed; a nozzle with a defined throughput for dispensing the liquid; an outlet valve having a defined minimum opening pressure arranged between the piston chamber and the nozzle; and a prime valve for priming the device. The prime valve may be mechanically operable and may be arranged on or in the piston. The liquid dispensing device may further comprise an operating member, which may protrude from an end wall of the piston chamber and which may be arranged to move the prime valve from a closed position to an open position when the moveable piston is near or at an end of its stroke. The outlet valve may be configured to minimize a difference between its opening pressure and its closing pressure. It may comprise a dome and the dome may have a stiffness which varies in radial direction.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
75.
Container with deformable inner container and method for manufacture thereof
The invention relates to a container for a product for dispensing, comprising a relatively stiff outer container (2) having at least one dispensing opening (3), and a deformable inner container (4) to be filled with the product which is accommodated in the outer container and which likewise has a dispensing opening (5). The inner container is connected to the outer container both in the vicinity of the dispensing opening and at least at one location remote therefrom. The connection is formed in that the outer container has an opening (8) through which protrudes at least one fixing element (10) connected to the inner container. This fixing element is pin-like and has an end part of which the dimensions are larger than those of the opening. The invention further relates to a method for manufacturing such a container.
B29C 49/22 - Moulage par soufflage, c.-à-d. en soufflant une préforme ou une paraison dans un moule pour obtenir la forme désiréeAppareils à cet effet de préformes ou de paraisons multicouches
B67D 1/08 - Appareils ou dispositifs pour débiter des boissons à la pression Détails
76.
Composite container and method for manufacturing same (“multi-layer preform”)
A composite container, comprising a form-retaining outer container comprising a neck, and a flexible inner container, the inner container comprising a dispensing opening mounted in the neck of the outer container is presented. The inner container is connected over a part of its surface area near the dispensing opening to a corresponding surface area of the inside of the outer container near the neck, via adhesive or weld connection, such that there remains a portion of the inner container not connected to the sidewall of the outer container. In response to an overpressure developed by a displacing medium introduced between the inner container and the outer container, a portion of the inner container that is not connected to the outer container moves at least one of: (i) towards the dispensing opening and (ii) within, the portion of the inner container that is connected to the outer container.
B29C 49/00 - Moulage par soufflage, c.-à-d. en soufflant une préforme ou une paraison dans un moule pour obtenir la forme désiréeAppareils à cet effet
B29C 49/22 - Moulage par soufflage, c.-à-d. en soufflant une préforme ou une paraison dans un moule pour obtenir la forme désiréeAppareils à cet effet de préformes ou de paraisons multicouches
B29C 65/50 - Assemblage d'éléments préformésAppareils à cet effet en utilisant des adhésifs utilisant des rubans adhésifs
Dispensing devices can include buffers. This obviates the need for continually pumping the device to dispense spray or foam. A buffer can be spring loaded, spring loaded combination, elastomeric or gas, and can be in line or adjacent to a piston chamber. Such sprayers and foamers can be mounted upside down. With a buffer, a piston chamber can deliver a greater amount of liquid per unit time than can be dispensed through the nozzle(s). The fraction of liquid that cannot be dispensed can be sent to the buffer for dispensing after the piston downstroke has completed. Volume of the piston chamber and buffer, pressure response of the buffer, throughput of the nozzle, and the minimum opening pressure of the outlet valve can be arranged to restrict the outlet pressures of liquid droplets exiting the nozzle within a defined range.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B05B 15/62 - Aménagements pour le maintien des appareils de pulvérisation, p. ex. ventouses pour accrochage
A47L 11/40 - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p. ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
A47L 13/22 - Balais à franges avec systèmes d'alimentation en liquide
B29C 65/18 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage avec un outil chauffé
B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
B29C 65/78 - Moyens pour la manipulation des éléments à assembler, p. ex. pour la fabrication de récipients ou d'objets creux
B29C 65/74 - Assemblage d'éléments préformésAppareils à cet effet par soudage et découpage
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
In exemplary embodiments of the present invention, various novel dispensing devices can be provided. Such devices can involve a range of sprayer heads and sprayer/foamer systems incorporating such heads. Novel sprayer/foamer heads can include buffers of various types. By using a buffer, a user need not continually be pumping the device in order for the device to be spraying or foaming. In exemplary embodiments of the present invention, such a buffer can be spring loaded, spring loaded combination, elastomeric or gas. In exemplary embodiments of the present invention, the buffer can be in line or adjacent to a piston chamber. If adjacent, it can be connected to the piston chamber with a one way valve, to provide for spray after a downstroke of the piston has been completed, or without, to allow spraying to cease once a user releases the trigger or other actuator. In exemplary embodiments of the present invention, such novel sprayers and foamers can be mounted upside down, in various "Flairomop" devices, used to clean floors or the like. When using a buffer, a piston chamber can be designed to deliver greater amount of liquid per unit time than can be possibly dispensed through the nozzle or nozzles. The fraction of liquid that cannot be sent through the nozzle(s), due to their inherent restriction, can thus be sent to the buffer for dispensing after the piston downstroke has been completed. A volume of the piston chamber, a volume of the buffer, a pressure response of the buffer, the throughput of the nozzle, and the minimum opening pressure of the outlet valve can be arranged to restrict the outlet pressures of liquid droplets exiting the nozzle within a defined range.
B05B 9/04 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs caractérisés par les moyens d'alimentation en liquide ou en autre matériau fluide comportant un réservoir sous pression ou compressibleAppareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs caractérisés par les moyens d'alimentation en liquide ou en autre matériau fluide comportant une pompe
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
79.
IMPROVED SPRAY/FOAM DISPENSER WITH AND WITHOUT BUFFERS
In exemplary embodiments of the present invention, various new generation dispensing devices can be provided. Such devices are vertically aligned, provide greater than 1.0 cc per piston stroke, and can involve a range of sprayer heads and sprayer/foamer systems incorporating such heads. Such novel sprayer heads can include a novel stretched piston, or, for example, the standard separate piston and piston chamber configuration. By using integration of parts, and a novel dome valve, exemplary sprayers are more easily manufactured, and have better operating properties. Finally, pre-compression is such novel valves is supplied by a novel dome valve with binary behavior, and minimal hysteresis.
B65D 47/34 - Fermetures avec évacuation par pompage
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
B65D 83/00 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu
03 - Produits cosmétiques et préparations de toilette; préparations pour blanchir, nettoyer, polir et abraser.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Liquid (including foams and mists) laundry preparations, soaps, cleaners and bleaches; liquid (including foams and mists) cleaning, polishing, scouring and abrasive preparations; soaps; perfumes, colognes and eau de toilette, cosmetics, hair lotions, hair spray and hair care preparations; dentifrices, mouthwashes and breath fresheners; deodorants; air fresheners and room fragrances; toiletries. Pump and trigger sprayers and dispensers, with and without containers, including foamers and misters, for dispensing industrial, household, kitchen and commercial liquids; pump and trigger sprayers and dispensers with integrated buffers, with and without containers, including foamers and misters, for dispensing industrial, household, kitchen and commercial liquids.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Hand operated atomizers, vaporizers, and sprayers for use with industrial, industrial chemical, and commercial liquids Dispensing units for air fresheners and sanitizers Non-metallic containers for industrial, industrial chemical, and commercial liquids, including foams and mists, and fluid dispensers connectable to such containers for use therewith to dispense industrial, industrial chemical and commercial liquids, including foams and mists, from such containers Aerosol dispensers not for medical use, concession dispensing equipment, namely, condiment pump dispensers and manually actuated pump dispensers for attachment to containers for use in dispensing cooking fluid, including foams and mists; dispensers for cleaning and disinfecting solutions, and household and household kitchen cleaning and cooking liquids, including foams and mists, dispensers for liquid soap, manually actuated pump dispensers for attachment to containers for use in dispensing cleaning and disinfecting solutions, and household and household kitchen liquids, including foams and mists; hand operated atomizers, vaporizers, and sprayers for use with both household and household kitchen liquids; Dispensing units for disinfecting liquids, kitchen cleaning and cooking liquids, for household use; Non-metallic containers for household and household kitchen liquids, including foams and mists, and manually actuated fluid pump dispensers connectable to such containers for use therewith to dispense household and household kitchen liquids, including foams and mists, from such containers
84.
Metered and active sprayer devices with aerosol functionality (“Flairosol II”)
“Flairosol” dispensing devices are presented. They utilize a combination of Flair® technology, precompression valves and aerosol like pressurization of the dispensed liquid. An exemplary device has a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring, a piston and a piston chamber which draws liquid from a container, and fills the pressure chamber with that liquid as a user operates a trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve, which serve to prevent backflow. A dome valve can be provided near the outlet channel at the top of the dispensing head, such that once its pressure is exceeded by the liquid, it opens and allows for a spray. Alternatively, in an activated embodiment, the dome valve is locked unless opened by a user.
B65D 88/54 - Grands réceptacles caractérisés par des moyens pour faciliter le remplissage ou le vidage
B65D 83/62 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur avec un contenu et un propulseur séparés par des membranes, des sacs ou similaires
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
Systems and methods to dispense various liquids, foams and sprays, of various viscosities, such as, for example, paints and stains, from a self-contained wearable apparatus are presented. These devices use the "bag within a bag" or inner container/outer container Flair® technology. A device can be provided that is portable and self-contained, can be worn by a user, and can utilize pre-filled containers of the product to be dispensed, thus obviating use of a separate paint container to which a user is effectively tethered. Novel activation mechanisms allow the system to intelligently sense when a user desires actuate/deactuate the device. These mechanisms incorporate fail-safe sensors that lock out the on/off switch if a user's hand is not sensed as actually holding the paint brush. Various Flair® bottles can be used, with various nozzles, brushes, rollers and other dispensing devices. Novel performs for the manufacture and blowing of multi-layer Flair® bottles are also presented, as well as details of multi-layer Flair® systems and their assembly.
B65D 83/00 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu
B65D 83/76 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu pour distribuer un contenu fluent au moyen d’un piston
B65D 77/06 - Liquides ou semi-liquides enfermés dans des réceptacles flexibles disposés dans des réceptacles rigides
F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme
B67D 7/02 - Appareils ou dispositifs pour transférer des liquides à partir de récipients ou de réservoirs de stockage en vrac vers des véhicules ou des récipients portables, p. ex. pour la vente au détail pour transférer des liquides autres que des carburants ou des lubrifiants
86.
METERED AND ACTIVE SPRAYER DEVICES WITH AEROSOL FUNCTIONALITY ("FLAIROSOL II")
In exemplary embodiments of the present invention, "Flairosol" dispensing devices can be provided. Such devices utilize a combination of Flair® technology, pre- compression valves and aerosol like pressurization of the dispensed liquid. Such a dispensing device has, for example, a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a container, for example, the inner container of a Flair® bottle, and fills the pressure chamber with that liquid as a user operates a trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve, which serve to prevent backflow. Liquid exiting the piston chamber under pressure (supplied by a user's pumping the trigger) enters a central vertical channel which is in fluid communication with both the pressure chamber (above the pressure piston) and a dome valve provided near the outlet channel at the top of the dispensing head. The dome valve has a preset pressure, such that once exceeded by the liquid, opens and allows for a spray. If the liquid pressure drops below such preset pressure the dome valve closes off the outlet channel, which serves to regulate the strength of the flow and preclude leakage. Alternatively, in an activated embodiment, for example, once the liquid is sufficiently pressurized, it can be dispensed by a user allowing the dome valve to open by pressing on an activation button that removes a dome lock.
B05B 9/04 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs caractérisés par les moyens d'alimentation en liquide ou en autre matériau fluide comportant un réservoir sous pression ou compressibleAppareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs caractérisés par les moyens d'alimentation en liquide ou en autre matériau fluide comportant une pompe
B65D 83/14 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur
87.
ISOLATION OF PRODUCT AND PROPELLANT IN AVARIOUS DISPENSING DEVICES AND PLATFORMS ("FLAIRFRESH")
In exemplary embodiments of the present invention platforms from which various dispensing devices, both manually operated as well as "touch-less" (motion sensor based) are presented. Such exemplary devices incorporate two main components: (i) the "bag within a bag" Flair® technology, and (ii) a OnePak type dispensing head (with a normally closed outlet valve). Such platforms can be, for example, overpressure based or underpressure based, can have various application based features, and can interface with various exemplary Flair type bottles. Exemplary embodiments described herein relate to dispensing systems where (i) the fluid or other dispensate to be dispensed, and (ii) the propellant used to dispense it, whether said propellant is a fluid, a gas, air at atmospheric pressure, or other, are completely separated in separate circuits, controlled separately, and only optionally mixed at the final dispensing time, if desired, at a point downstream of the normally closed outlet valve. Additionally, in such devices the propellant can be used for other ancillary functions, such as, for example, cleaning a spout or output channel, making foam or spray, controlling valves, pistons, pumps, making noise, and the like. Certain of such exemplary systems utilize a unique bottle in the dispensing appliance which (i) cannot be replaced by a competitor's, or other third party's bottle which also (ii) cannot be refilled by a consumer.
A preform can be made from two different materials that do not bond together by a bi-injection process, using the same mold. First an outer preform can be fashioned, then an inner preform molded through a center hole in the bottom of the outer preform, and the preforms connected. Inner/outer preform materials can be different, e.g., PET/polyolefin or polyamide, or same, e.g., PET/PET. To prevent mutual bonding during molding of the second, a non-stick coating can be sprayed on a surface portion of the first preform prior to molding the second. Manufacturing order can be either outer/inner, or inner/outer, and the non-stick coating sprayed on the inside/outside of the preform first molded.
B29C 65/48 - Assemblage d'éléments préformésAppareils à cet effet en utilisant des adhésifs
B29C 65/08 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage avec des vibrations ultrasonores
B29C 65/06 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage en utilisant la friction, p. ex. soudage par rotation
Improved pre-forms for Flair and Flair-type applications are presented. In exemplary embodiments of the present invention, if two different materials which do not bond together are used to make a pre-form, then such a pre-form can be made by a bi- injection process, using the same mold. In such exemplary embodiments, first the outer pre-form can be fashioned, and then the inner pre-form can be molded through a center hole provided at the bottom of the outer pre-form. The two pre-forms are then connected to each other. The two materials can be different, such as PET and a polyolefin or polyamide, or for example, they can even be the same, such as PET/PET, if steps are taken to prevent their bonding during the molding of the second pre-form layer. In such a process, a non-stick coating can be sprayed on the surface that will be between the pre-forms, where the second perform will touch the first one, and after such application, the second container can be molded, also in a 2C process. The order of manufacture can be either outer then inner, or inner then outer, in various exemplary embodiments. If outer then inner, the non-stick coating can be sprayed on the inside of the first molded outer perform, followed by molding of the inner prefrom. If the reverse, the non-stick coating is sprayed on the outside of the first molded inner perform, then followed by the molding of the outer perform. The material from which the inner container is made, the degree of shrinkage it will experience relative to the outer container, and the concomitant maximum hot fill temperature it can thus support, can all be designed for a given application, use or range of uses.
A liquid spraying device offers both a spraying and a foaming configuration, where a user can switch between them by a quarter turn of an outer nozzle. A woven screen can be welded to the inner surface of the outer nozzle. By turning the outer nozzle a quarter turn a user can move the outer nozzle forward of the inner nozzle, and thus switch between spraying and foaming configurations. In the foaming configuration, as the outer nozzle is turned outward, it is displaced by a given distance from the inner nozzle. This insures that the spray leaving the inner nozzle will fall upon the screen, thus creating foam. In a spraying configuration the liquid stream leaving the inner nozzle goes through a hole in the center of the screen and thus no foam is created.
F02M 47/02 - Appareils d'injection à fonctionnement périodique avec clapets d'injection actionnés par la pression du fluide du type accumulateurs-injecteurs, c.-à-d. dans lesquels la pression du combustible dans l'accumulateur tend à ouvrir et la pression du combustible dans une autre chambre tend à fermer les clapets d'injection et comportant des moyens pour supprimer périodiquement cette pression de fermeture
91.
FLAIR SPRAYERS AND ISOLATION OF PRODUCT AND VENTING/PROPELLANT IN DISPENSING DEVICES
Various liquid dispensing devices are presented based on Flair® technology. In exemplary embodiments of the present invention, a "Flair Sprayer" can be provided with no dip tube, and be capable of use in any orientation, including upside down. Because of its valving system, in which the product delivery circuit is a closed system, such a Flair Sprayer can pump out any air or other gas in a headspace of a bottle, and the product/liquid always reaches the pump intake, even with no dip tube. In exemplary embodiments of the present invention a dispensing device can have separate product and re-venting/propellant circuits, isolated one from the other, allowing for longer life and freshness of the product. In such exemplary embodiments displacement media can be used for various ancillary functions, all the while remaining isolated from the product, and the dispensing of the product can be adeptly controlled by pressure differentials.
A liquid dispensing device is presented. The device has a main body and a dispensing head. The main body includes a pressure chamber, a pressure spring and a pressure piston, and the dispensing head includes a piston and a piston chamber, a channel in fluid communication with the pressure chamber, an inlet valve provided between said channel and said piston chamber, an outlet valve, an outlet channel, and an outlet valve lock.
G01F 11/00 - Appareils qu'il faut actionner de l'extérieur, adaptés à chaque opération répétée et identique, pour mesurer et séparer le volume prédéterminé d'un fluide ou d'un matériau solide fluent à partir d'une alimentation ou d'un récipient sans tenir compte du poids, et pour fournir ce volume
B05B 9/08 - Appareillages pouvant être portés par une personne, p. ex. du type dorsal
93.
SPRAYER DEVICE WITH AEROSOL FUNCTIONALITY ("FLAIROSOL")
In exemplary embodiments of the present invention, Flair® based aerosol-type devices can be provided. Such devices utilize a combination of Flair® technology, pre-compression valves and aerosol like pressurization of the dispensed liquid. Such a dispensing device has a main body comprising a pressure chamber, the latter being provided with a pressure piston and a pressure spring. The device further has a piston and a piston chamber which draws liquid from a reservoir and fills the pressure chamber with that liquid as a user operates the trigger in various compression and release strokes. The piston chamber has both an inlet valve and an outlet valve. In a dispensing head a valve is provided to regulate the strength of the flow and preclude leakage. Once the liquid is sufficiently pressurized, it can be dispensed by a user opening an activation valve, such as by pressing on an activation button, and spray can be abruptly stopped by a user ceasing to push on such button. Or, for example, in alternate embodiments without an activation button,, once the liquid is sufficiently pressurized, continuous spray occurs until the pressure chamber is emptied. By repeatedly pumping the trigger before the pressure chamber is fully emptied, continuous spray can be achieved. By designing the input volume to be amply greater than the volume of the pressure chamber, continuous spray with fewer pumping strokes can be implemented.
B05B 11/00 - Appareillages monoblocs tenus à la main dans lesquels l'écoulement du contenu est produit par la force musculaire de l'opérateur au moment de l'utilisation
94.
DEVICE FOR MIXING MEDIA AND METHOD FOR PRODUCING SAME ("AEROFLAIR SPRAY NOZZLE")
A spray nozzle device is provided with a housing, a first supply line for supplying a first medium, and a flow channel which guides the first medium to a nozzle of the housing. Also provided in the housing is a second supply line for supplying a second medium, wherein at least one of the first and second media is substantially liquid. Further provided are distributing bodies, or elements which cause mixing of the first and second media in various ways, having various possible structures and components. Such distributing bodies operate to feed the second medium into the flow stream as the first media flows through the flow channel, and to thereby cause a mixing of the first medium and second medium. Following such mixing, the mixed media are guided to an outlet nozzle or bore provided in the housing, and ejected out of the housing into the surrounding area.
A composite container, comprising a form-retaining outer container and a flexible inner container is presented. The inner container comprises a dispensing opening and can be mounted in a neck of the outer container, and the inner container is further connected to the outer container by an adhesive or weld connection over a portion of its periphery. The adhesive or weld connection can take the form of a ring adhesion or weld extending transversely to a central longitudinal axis of the container, or can cover the entire surface area of a defined portion of the respective inner container and outer container walls, such as, for example, the upper one-half of the container. The adhesion or weld can be substantially permanent, or alternatively, the adhesive or weld connection can be adapted to detach in controlled manner under the influence of pressures occurring in the container. Additionally, a method for manufacturing such a composite container is also presented, including forming a form-retaining outer container pre-form comprising a neck, forming a flexible inner container pre-form comprising a dispensing opening, inserting the inner container pre-form into the outer container pre-form and fixing said inner container pre-form to the neck of the outer-container pre-form.
B65D 35/22 - Réceptacles pliables, de forme tubulaire, conçus de telle sorte que l'expulsion de leur contenu leur donne une déformation permanente, p. ex. tubes souples pour dentifrice ou autres produits plastiques ou semi-liquidesSupports adéquats avec plusieurs compartiments
96.
METHOD AND APPARATUS FOR PRESSURE EQUALIZED DISPENSING OF A PRESSURIZED LIQUID IN A CONTAINER (FLAIR BEVERAGE VALVES)
A method for dosed dispensing of a pressurized liquid is presented. In exemplary embodiments of the present invention, the method includes dispensing a liquid in a container via a dispensing opening into a dispensing space, where a difference in pressure between the container and the dispensing space is equalized in stages by using an intermediate dosing chamber. First the pressure is equalized between the container and the dosing chamber, then a quantity of the liquid is dispensed from the container into the dosing chamber, maintaining the pressure equivalence between the container and the dosing chamber by pressure communication between them. Next the dosing chamber is isolated both gaseously and liquidly from the container. In a second stage the pressure is equalized between the dosing chamber and the dispensing space, and the quantity of liquid in the dosing chamber is dispensed into the dispensing space as the pressure between the dosing chamber and the dispensing space is maintained equal. The method further includes providing the liquid in a first inner container of the container, and introducing a pressure equalizing medium into a second inner container, where the first and second inner containers adjoin each other at least with a deformable and/or displaceable side. The invention also relates to a dispensing device arranged to perform, inter alia, the disclosed method. In exemplary embodiments of the present invention a dispensing device can comprise a self-contained carbonated beverage dispenser that can be stored in a consumer's refrigerator, or can, for example, be self cooling.
A device for dispensing a medium from a container is presented. In exemplary embodiments of the present invention, an exemplary container (2) has at least one feed opening (10) connectable to the container by means of coupling means (8), a dispensing conduit (12) manufactured from substantially flexibly deformable material, and a closing means (18) for a substantially air-tight closing of the dispensing conduit therewith. In exemplary embodiments of the present invention methods for the manufacture of such exemplary dispensing devices can include injection molding the coupling means and the dispensing conduit as a perform, and stretching, blowing or any combination of stretching and blowing a portion of the preform so as to obtain a substantially flexibly deformable, thin-walled dispensing conduit. Alternatively, for example, the coupling means (8) and the dispensing conduit (12) can be separately generated, and later unified or joined.
At least one embodiment of the invention relates to a container for a product for dispensing, including a relatively stiff outer container having at least one dispensing opening, and a deformable inner container to be filled with the product which is accommodated in the outer container and which likewise has a dispensing opening. The inner container is connected to the outer container both in the vicinity of the dispensing opening and at least at one location remote therefrom. The connection is formed in that the outer container has an opening through which protrudes at least one fixing element connected to the inner container. This fixing element is pin-like and has an end part of which the dimensions are larger than those of the opening. At least one embodiment of the invention further relates to a method for manufacturing such a container.
B67B 7/00 - Dispositifs à main ou à moteur pour ouvrir des récipients fermés
B65D 83/00 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu
B29B 11/14 - Fabrication de préformes caractérisées par la structure ou la composition
B29C 49/22 - Moulage par soufflage, c.-à-d. en soufflant une préforme ou une paraison dans un moule pour obtenir la forme désiréeAppareils à cet effet de préformes ou de paraisons multicouches
The invention relates to a method for dispensing a product (P) from a flexible inner container (102) which is received in a relatively stiffer outer container (103), wherein during dispensing of the product ambient air (A) is drawn into an intermediate space (104) between the inner container and the outer container through at least one aerating opening (105). The indrawn ambient air is herein trapped after dispensing of the product. The invention further relates to a device for dispensing a product, comprising a flexible inner container (102) in which the product (P) is received, a relatively stiffer outer container (103) in which the flexible inner container is received, wherein an intermediate space (104) is formed between the inner container and the outer container, and at least one aerating opening (105) formed in the outer container for drawing ambient air (A) into the intermediate space, which dispensing device is provided with means (110) for trapping the indrawn ambient air.
The invention relates to a method for dosed dispensing of a liquid from a container that is connected to an outflow channel that may be closed off by a liquid valve, comprising opening the liquid valve, dispensing a dose of the liquid from the container through the outflow channel and closing the liquid valve, and blowing empty the outflow channel after closing of the liquid valve. During dispensing of the liquid a pressure in the container may be higher than atmospheric pressure and the liquid valve may be biased to its closed position by this higher than atmospheric pressure in the container. The invention further relates to a device for dosed dispensing of a liquid from a container, comprising an outflow channel that can be connected to the container and that can be closed off by a liquid valve, and means for blowing empty the outflow channel when the liquid valve is closed. These blowing empty means can be adapted to connect the outflow channel with a source of gas under higher than atmospheric pressure when the liquid valve is closed.
