Abrégé

An audio amplification device includes a charge pump circuit and an operational amplifier. The charge pump circuit generates an output voltage when receiving a power-on reset signal. The operational amplifier has a first input terminal for receiving a first input signal, a second input terminal for receiving a second input signal, a third input terminal for receiving the output voltage, a fourth input terminal for receiving a switching signal output, and an output terminal. The operational amplifier generates an amplified signal at the output terminal according to the first and second input signals, the output voltage and the switching signal output and outputs the amplified signal to a load circuit. When a level of the power-on reset signal changes from a high logic level to a low logic level, the operational amplifier is controlled by the switching signal output to pull a potential of the output terminal to zero.

Classes IPC  ?

• H03F 1/02 - Modifications des amplificateurs pour augmenter leur rendement, p. ex. étages classe A à pente glissante, utilisation d'une oscillation auxiliaire
• H03F 1/30 - Modifications des amplificateurs pour réduire l'influence des variations de la température ou de la tension d'alimentation
• H03F 3/185 - Amplificateurs à basse fréquence, p. ex. préamplificateurs à fréquence musicale comportant uniquement des dispositifs à semi-conducteurs comportant des dispositifs à effet de champ
• H03G 3/30 - Commande automatique dans des amplificateurs comportant des dispositifs semi-conducteurs

Abrégé

An automatic gain controller includes multiple resistors, multiple switches, a buffer, a charge pump circuit and a voltage level shifter. The resistors are connected in series between an input terminal for receiving an input signal and an inverting input terminal of an operational amplifier. Each of the switches has a first terminal coupled to a corresponding one of the resistors, and a second terminal coupled to the inverting input terminal. The switches are respectively controlled by multiple switching signals so as to be turned on or turned off. The buffer generates a buffer signal according to the voltage at the inverting input terminal. The charge pump circuit generates a boost voltage according to the buffer signal and a clock signal. The voltage level shifter converts voltage levels of multiple control signals according to the buffer signal and the boost voltage to generate and respectively output the switching signals to the switches.

Classes IPC  ?

• H03G 3/30 - Commande automatique dans des amplificateurs comportant des dispositifs semi-conducteurs

Abrégé

A power stage control circuit applied to a voltage converter includes a current sensing circuit, a control circuit, and a driving circuit, wherein the voltage converter includes a first switch and a second switch. The current sensing circuit senses a current associated with the first switch, and converts current into a sensing voltage. The control circuit performs multiple first logical operations according to the sensing voltage, a second switch driving signal, a zero crossing detection voltage, a compensation voltage, and a reference voltage, in order to generate a modulation signal and a determination signal, for controlling turn-on and turn-off of the first switch and the second switch and dynamically setting an inductor peak current of an inductor, respectively. The driving circuit performs multiple second logical operations according to the modulation signal and the determination signal in order to generate a first switch driving signal and the second switch driving signal.

Classes IPC  ?

• H02M 3/158 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant continu sans transformation intermédiaire en courant alternatif par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs avec commande automatique de la tension ou du courant de sortie, p. ex. régulateurs à commutation comprenant plusieurs dispositifs à semi-conducteurs comme dispositifs de commande finale pour une charge unique
• H02M 1/00 - Détails d'appareils pour transformation

Abrégé

In a power converter, a phase controller divides a full COT control signal into a master COT control signal and at least one slave COT control signal. The master COT control signal triggers a master PWM-signal generator to generate a master PWM signal accordingly, and each slave COT control signal triggers a corresponding slave PWM-signal generator to generate the slave PWM signal for a corresponding slave driver by adjusting a width of each pulse of the corresponding slave COT control signal according to a comparison between a sensed current of a master driver and a sensed current of the corresponding slave driver. Then, the master driver provides a master current output for a load device according to a master PWM signal, and each slave driver provides a slave current output for the load device according to the slave PWM signal corresponding thereto.

Classes IPC  ?

• H02M 1/15 - Dispositions de réduction des ondulations d'une entrée ou d'une sortie en courant continu utilisant des éléments actifs
• H02M 1/084 - Circuits spécialement adaptés à la production d'une tension de commande pour les dispositifs à semi-conducteurs incorporés dans des convertisseurs statiques utilisant un circuit de commande commun à plusieurs phases d'un système polyphasé
• H02M 3/158 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant continu sans transformation intermédiaire en courant alternatif par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs avec commande automatique de la tension ou du courant de sortie, p. ex. régulateurs à commutation comprenant plusieurs dispositifs à semi-conducteurs comme dispositifs de commande finale pour une charge unique

Abrégé

An audio amplifier chip includes an audio amplifier, a current providing circuit, a detection circuit, and a control circuit. The audio amplifier is arranged to drive a speaker, wherein the audio amplifier has multiple differential input terminals, and a direct current (DC) blocking capacitor is coupled to one of the multiple differential input terminals. The current providing circuit is arranged to provide at least one current for charging the DC blocking capacitor. The detection circuit is coupled to a node located between the one of the multiple differential input terminals and the DC blocking capacitor, and is arranged to detect whether an external resistor of the audio amplifier chip exists according to an input voltage from the node, in order to generate a detection result. The control circuit is arranged to determine a start-up time of the audio amplifier according to the detection result.

Classes IPC  ?

• H03F 3/183 - Amplificateurs à basse fréquence, p. ex. préamplificateurs à fréquence musicale comportant uniquement des dispositifs à semi-conducteurs

Abrégé

A voltage level shifter includes a first voltage regulation unit, a second voltage regulation unit, a first latch unit and an output unit. The first voltage regulation unit and the second voltage regulation unit respectively receive first and second input signals and generate first and second adjustment signals respectively. The first latch unit receives the first and second adjustment signals and generates a first latch signal accordingly. The output unit generates an output signal according to the first latch signal, an input voltage and a control signal. A high logic level voltage of the output signal is greater than the respective high logic level voltages of the first input signal and the second input signal. Wherein, the first voltage regulation unit and the second voltage regulation unit are each a capacitively coupled voltage regulation unit and each includes an input capacitor. The input capacitor has no capacitance to ground at one end.

Classes IPC  ?

• H03K 19/00 - Circuits logiques, c.-à-d. ayant au moins deux entrées agissant sur une sortieCircuits d'inversion
• H03K 3/356 - Circuits bistables
• H03K 19/0185 - Dispositions pour le couplageDispositions pour l'interface utilisant uniquement des transistors à effet de champ

Abrégé

A charge pump device includes a voltage adjustment unit, an output capacitor, a first output unit and a second output unit. The voltage adjustment unit performs voltage pumping or voltage reducing operation on a power supply voltage according to first to fourth control signals, a positive pump voltage and an negative pump voltage to generate a first voltage adjustment output and a second voltage adjustment output at a first node and a second node respectively. The output capacitor has a first output terminal and a second output terminal. When the first output unit is turned on, the first voltage adjustment output charges the output capacitor through the first output unit, so that the first output terminal generates the positive pump voltage. When the second output unit is turned on, the second voltage adjustment output charges the output capacitor through the second output unit, so that the second output terminal generates the negative pump voltage. When the first output unit is turned on, the second output unit is not turned on. When the second output unit is turned on, the first output unit is not turned on.

Classes IPC  ?

• H02M 3/07 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant continu sans transformation intermédiaire en courant alternatif par convertisseurs statiques utilisant des résistances ou des capacités, p. ex. diviseur de tension utilisant des capacités chargées et déchargées alternativement par des dispositifs à semi-conducteurs avec électrode de commande
• H02M 1/00 - Détails d'appareils pour transformation

Abrégé

The oscillator includes a reference current generating circuit, a voltage modulator circuit, and an oscillating circuit. The reference current generating circuit is arranged to generate a reference current. The voltage modulator circuit is arranged to receive a feedback voltage, and perform a voltage modulation operation according to a first reference voltage and the feedback voltage, to generate a modulated voltage. The oscillating circuit is coupled to the reference current generating circuit and the voltage modulator circuit, and arranged to generate an oscillation signal with an oscillation frequency according to the reference current and the modulated voltage.

Classes IPC  ?

• H03K 5/01 - Mise en forme d'impulsions
• H03B 5/12 - Éléments déterminant la fréquence comportant des inductances ou des capacités localisées l'élément actif de l'amplificateur étant un dispositif à semi-conducteurs

Abrégé

A controller applied to a servomotor includes a flash memory, a microcontroller, and a processing circuit. The flash memory is arranged to store a first program code for controlling the servomotor. The microcontroller is arranged to determine whether an alarm of the servomotor occurs, wherein in response to the alarm of the servomotor occurring, the microcontroller is arranged to store an error log corresponding to the alarm in the flash memory. In addition, a second program code is programmed into the processing circuit in advance, wherein the second program code is a copied version of the first program code; and in response to the alarm of the servomotor occurring, the processing circuit is arranged to execute the second program code.

Classes IPC  ?

• G05B 19/4155 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par le déroulement du programme, c.-à-d. le déroulement d'un programme de pièce ou le déroulement d'une fonction machine, p. ex. choix d'un programme

Abrégé

A write leveling system includes a frequency divider, a signal processing circuit, and a data control circuit. The frequency divider is arranged to perform a frequency dividing operation upon a clock signal to generate multiple frequency-divided clock signals. The signal processing circuit is arranged to perform signal processing upon a data strobe signal to generate multiple processed data strobe signals. The data control circuit is arranged to generate a data signal according to the multiple frequency-divided clock signals and the multiple processed data strobe signals, for indicating whether a rising edge of the data strobe signal is located at a first level or a second level of the clock signal, wherein the first level is higher than the second level.

Classes IPC  ?

• G11C 11/4076 - Circuits de synchronisation
• G11C 7/10 - Dispositions d'interface d'entrée/sortie [E/S, I/O] de données, p. ex. circuits de commande E/S de données, mémoires tampon de données E/S
• G11C 7/22 - Circuits de synchronisation ou d'horloge pour la lecture-écriture [R-W]Générateurs ou gestion de signaux de commande pour la lecture-écriture [R-W]
• G11C 11/4096 - Circuits de commande ou de gestion d'entrée/sortie [E/S, I/O] de données, p. ex. circuits pour la lecture ou l'écriture, circuits d'attaque d'entrée/sortie ou commutateurs de lignes de bits
• G11C 8/18 - Circuits de synchronisation ou d'horlogeGénération ou gestion de signaux de commande d'adresse, p. ex. pour des signaux d'échantillonnage d'adresse de ligne [RAS] ou d'échantillonnage d'adresse de colonne [CAS]

Abrégé

A signal recovery system includes multiple frequency dividers, multiple signal recovery circuits, and a data signal generating circuit. The multiple frequency dividers perform a frequency dividing operation upon a clock signal and a data strobe signal, respectively, to generate a set of frequency-divided clock signals and a set of frequency-divided data strobe signals. The multiple signal recovery circuits perform a signal recovery operation upon the set of frequency-divided clock signals and the set of frequency-divided data strobe signals, respectively, to generate a recovered clock signal and a recovered data strobe signal. The data signal generating circuit generates a data signal according to the recovered clock signal and the recovered data strobe signal, for indicating whether a rising edge of the data strobe signal is located at a first level or a second level of the clock signal, wherein the first level is higher than the second level.

Classes IPC  ?

• H03L 7/099 - Détails de la boucle verrouillée en phase concernant principalement l'oscillateur commandé de la boucle
• H03K 19/20 - Circuits logiques, c.-à-d. ayant au moins deux entrées agissant sur une sortieCircuits d'inversion caractérisés par la fonction logique, p. ex. circuits ET, OU, NI, NON
• H03L 7/08 - Détails de la boucle verrouillée en phase

Abrégé

A method for enabling a permanent magnet synchronous motor (PMSM) to start in a reverse direction may include: estimating a load torque according to a torque and an actual rotational speed of the PMSM, to generate an estimated load torque; controlling the torque according to the estimated load torque to decelerate the PMSM, until the actual rotational speed of the PMSM is reduced to a predetermined target rotational speed; in response to the actual rotational speed of the PMSM being reduced to the predetermined target rotational speed, determining whether an energy of the PMSM is not greater than a threshold value, wherein the energy of the PMSM comprises a potential energy; and in response to the energy of the PMSM not being greater than the threshold value, starting to control the torque for making the PMSM rotate in a forward direction.

Classes IPC  ?

• H02P 21/34 - Dispositions pour le démarrage
• H02P 21/00 - Dispositions ou procédés pour la commande de machines électriques par commande par vecteur, p. ex. par commande de l’orientation du champ
• H02P 21/20 - Estimation du couple

Abrégé

A Class-D audio amplifier includes a triangular wave generator, a wave reshaping device and a pulse-width modulator. The triangular wave generator generates a first triangular wave. The wave reshaping device generates a second triangular wave by reshaping the first triangular wave. The pulse-width modulator modulates a pair of differential audio input waves with the second triangular wave instead of the first triangular wave to reduce a switching loss of the Class-D audio amplifier.

Classes IPC  ?

• H03F 3/217 - Amplificateurs de puissance de classe DAmplificateurs à commutation
• H03K 3/037 - Circuits bistables
