A differential type threshing roller device and a use method thereof. The device comprises a plurality of sections of threshing rollers which are connected in series by means of a main transmission shaft (1), and the rotating speed of a middle threshing roller is larger than that of the threshing rollers at two ends. The differential type threshing roller device enhances the tobacco tearing effect of the middle threshing roller.
A24B 5/06 - Ecotage du tabac; Traitement des côtes ou des nervures en détachant des côtes le reste des feuilles
F16H 1/32 - Transmissions à engrenages pour transmettre un mouvement rotatif avec engrenages à mouvement orbital dans lesquels l'axe central de la transmission est situé à l'intérieur de la périphérie d'un engrenage orbital
4.
DEVICE AND METHODS FOR MEASURING LONG STEM CONTENT IN TOBACCO STEM
A device for measuring long stem content in a tobacco stem comprises the following components: a feed belt (1), a vibrating trough (8), an X-ray measurement belt (7), and a collection box (4). An X-ray source (2) is provided above the X-ray measurement belt (7). An X-ray detector (3) is provided below the X-ray measurement belt (7), and is connected to an industrial computer (6) via a network cable (5). Further included are two methods using said device to measure long stem content in a tobacco stem: an area-based method and an attenuation value-based method. The device has a simple structure, and the methods are simple and reliable, thus enabling quick, convenient, and accurate measurement of long stem content and short stem content in tobacco stems.
G01N 23/04 - Recherche ou analyse des matériaux par l'utilisation de rayonnement [ondes ou particules], p.ex. rayons X ou neutrons, non couvertes par les groupes , ou en transmettant la radiation à travers le matériau et formant des images des matériaux
Hand-rolling tobacco; Lighters for smokers; Matches; Tobacco; electronic cigarettes; liquid solutions for use in electronic cigarettes; flavourings, other than essential oils, for tobacco; cigarettes; Cigarette tips; Cigarette filters.
7.
UNWINDING, SHREDDING, GATHERING, AND ROD FORMING MECHANISM BASED ON CIGARETTE FILTER MAKING DEVICE
An unwinding, shredding, gathering, and rod forming mechanism based on a cigarette filter making device. A cigarette filter making device is used for unwinding, shredding, gathering, and rod forming based on a tobacco sheet. Specifically, an active unwinding device for a tobacco sheet roll is additionally provided after an opening roller of the cigarette filter making device, and the line speed of the active unwinding device matches the rod forming line speed of a main machine; a pair of opening rollers close to a cigarette gun are replaced with a shredding roller provided with discontinuous rolling threads (4) along the circumference; a shred guide horn mouth (14) is replaced with a conical gathering horn mouth with an inlet having a diameter of 80-120 mm.
An equipment for producing non-traditional cut tobacco cigarettes, comprising a plurality of drum wheels; non-traditional cut tobacco rod sections (40) and composite filter sections (41) are transferred to a wrapping zone (33) by means of the drum wheels; tipping paper (18) is supplied along the centrosymmetric plane MU for double-width tipping paper, so as to allow the non-traditional tobacco rod sections (40) and the composite filter sections (41) to be wrap-formed; and the centrosymmetric plane MU for the double-width tipping paper, the centrosymmetric plane MF for double-length composite filter sections, and the centrosymmetric plane MK for a double-cigarette final cutter all have a distance of zero from the central plane MM of a machine. By means of ensuring that the centrosymmetric plane MU for the double-width tipping paper, the centrosymmetric plane MF for the double-length composite filter sections, and the centrosymmetric plane MK for the double-cigarette final cutter all have a distance of zero from the central plane MM of the machine, the present invention has solved the problems in which when the equipment operates at a high speed, the outer appearance and quality of the cigarettes do not meet requirements and waste costs are generated resulting from the misalignment of the tipping paper (18) with a filter rod at a side that requires alignment; thus, the objective of controlling the quality and appearance of cigarettes is achieved, and production efficiency is simultaneously improved.
Disclosed is a separate guide and delivery mechanism suitable for short cigarette production. The delivery mechanism comprises a cutting drum wheel, a delivery drum wheel and a separating drum wheel, disposed in parallel lines, wherein a flow guide plate is movably disposed above the separating drum wheel, a fixed part is disposed on an outside convex face of the flow guide plate, the fixed part is connected to a connection part by a pin, and one end of the connection part is fixed onto a valve seat of the separating drum wheel by a fastener, and the other end of the connection part is provided with a fixed handle; and a guide plate matching the flow guide plate is radially disposed on an inside concave face of the flow guide plate. The present invention can satisfy high-accuracy high-reliability separation, can realize high-accuracy high-reliability guiding during cigarette separation, can control a cigarette separation path by means of mutual tangential and normally acting forces while also satisfying the requirement for a complex loading environment during cigarette separation, and can adapt to the separation of cigarettes having different functions, different shapes and different volumes, and is thus convenient for twisting and connection forming of cigarettes in the next process.
B65G 47/24 - Dispositifs pour influencer la position relative ou l'orientation des objets pendant le transport par transporteurs présentant les objets selon un orientement donné
B65G 47/88 - Eléments pour séparer ou stopper, p.ex. doigts
10.
NOVEL CIGARETTE PREPARATION METHOD CAPABLE OF COMBINING MULTIPLE MATERIALS AND STRUCTURES
A novel cigarette preparation method capable of combining multiple materials and structures, comprising the following procedures: selecting a tobacco bundle roll manufactured from a mixture of a tobacco raw material and a balsam compound and preparing the tobacco bundle roll into tobacco rod segments by means of a filter rod forming machine; selecting a novel raw and auxiliary material roll manufactured from different compound materials, and preparing the novel raw and auxiliary material roll into tobacco filter base rod segments having different materials and specifications by means of the filter rod forming machine; then, selecting one or more of the different tobacco filter base rod segments and preparing same into composite filter rod segments comprising different materials and internal structures by means of binary or multi-component composite forming; and finally roll-forming, according to a given arrangement and combination order, the tobacco rod segments and one or more composite filter rod segments by means of a cigarette tipping machine having two or more hoppers having different specifications, so as to finally prepare novel cigarettes having multiple materials and internal structures. The present invention achieves the purpose of tar reduction and harm reduction, structural diversification, and material diversification.
(1) Heating elements; Heating plates; Heat regenerators; Portable electric heaters; Gas lighters; Cooling vats for furnaces; Tobacco roasters; Hot air ovens; Cooling evaporators.
(2) Rolling tobacco; Lighters for smokers; Matches; Tobacco; Electronic cigarettes; Liquid solutions for use in electronic cigarettes; Tobacco flavourings; Cigarettes; Cigarette tips; Cigarette filters; Tobacco heaters.
YUXI JIXINGDEYI TRADE & INDUSTRY CO., LTD. (Chine)
Inventeur(s)
Mou, Dingrong
Wang, Yi
Zou, Quan
Zhao, Yunchuan
Chen, Ran
Yang, Guangtao
Gao, Xiaohua
Cai, Yuan
Qi, Wenhui
Qiao, Xiaohui
Xiao, Wenpin
Dou, Yuanchun
Fan, Hao
Qian, Binghai
Abrégé
The present invention comprises: a separation silo, a discharge silo, a upper sidewall of the separation silo communicated with the discharge silo through a communication port, wherein an air curtain is disposed in the communication port to isolate the silos from each other, a discharge port is disposed at the bottom of the discharge silo, a suction outlet is mounted on the top of the separation silo, a feeding port is disposed at the lower part of a sidewall of the separation silo, which is precisely facing towards the underside of the end of the belt conveyer, a vibration trough is arranged at the lower part of the separation silo, a damper plate is disposed underside thereof, an air inlet is located underbelly thereof at the bottom of the separation silo, a rejection outlet is installed at the underside end of the vibrating trough.
B07B 7/00 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci
B07B 11/06 - Dispositifs d'alimentation ou de déchargement
B07B 9/00 - Combinaisons d'appareils à cribler ou tamiser ou à séparer des solides par utilisation de courants de gaz; Disposition générale des installations, p.ex. schéma opératoire
B07B 7/08 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci utilisant la force centrifuge
B07B 7/01 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci utilisant la pesanteur
B07B 11/00 - Disposition des accessoires dans les appareils à séparer les solides par utilisation de courants de gaz
17.
Method for threshing and pneumatic separation of tobacco leaves
A method for threshing and pneumatic separation of tobacco leaves, including: 1) transporting a mixture of the tobacco slices and stems from a primary threshing set into primary pneumatic separation unit for sorting out tobacco slices, and transporting a remaining mixture into a secondary threshing set; 2) transporting the mixture from the secondary threshing set into a secondary pneumatic separation unit for sorting out the tobacco slices and qualified stems, and transferring a remaining mixture to a tertiary threshing set; 3) transporting the mixture from the tertiary threshing set into a tertiary pneumatic separation unit for sorting out the tobacco slices and the qualified stems, and transferring a remaining mixture into a quaternary threshing set; 4) transporting the mixture from the quaternary threshing set into a quaternary pneumatic separation unit for sorting out the tobacco slices and the qualified stems, and returning a remaining mixture to the quaternary threshing set.
B07B 4/08 - Séparation des solides, obtenue en soumettant leur mélange à des courants de gaz pendant que le mélange est supporté par des cribles, des tamis ou des éléments mécaniques analogues
B07B 11/06 - Dispositifs d'alimentation ou de déchargement
B07B 9/02 - Combinaisons d'appareils semblables ou différents, pour séparer les solides, par utilisation de courants de gaz
18.
NEW HIGHLY-EFFICIENT ENERGY-SAVING THRESHING AIR SEPARATION PROCESS AND DEVICE
A new highly-efficient energy-saving threshing air separation process and device, used to perform air separation on tobacco flakes and tobacco stalks. The process sequentially comprises the following steps: a scraping plate feeding machine (2), a bin type feeding machine (3), a proportional distributor (4), a first-level threshing machine set (5), a conveying belt (6), a first-level air separation machine set (7), a stalky leaf conveying belt (10), a second-level threshing machine set (11), a conveying belt (12-14), a second-level air separation machine set (15), a stalky leaf conveying belt (19), a third-level threshing machine set (20), a conveying belt (21-23), a third-level air separation machine set (24), a stalky leaf conveying belt (28), a fourth-level threshing machine set (29), a conveying belt (30), and a fourth-level air separation machine set (31). The first-level air separation machine set (7) is provided with an air pressure type double-bin air separator (9) that only selects qualified tobacco flakes through air separation; and the second-level, third-level air, and fourth-level air separation machine sets (15, 24, 31) are provided with air pressure type three-bin air separators (17, 26) that can select qualified tobacco flakes and tobacco stalks through air separation.
A24B 5/06 - Ecotage du tabac; Traitement des côtes ou des nervures en détachant des côtes le reste des feuilles
B07B 9/00 - Combinaisons d'appareils à cribler ou tamiser ou à séparer des solides par utilisation de courants de gaz; Disposition générale des installations, p.ex. schéma opératoire
B07B 11/00 - Disposition des accessoires dans les appareils à séparer les solides par utilisation de courants de gaz
19.
NEW HIGHLY-EFFICIENT ENERGY-SAVING THRESHING AIR SEPARATION PROCESS AND DEVICE
A new highly-efficient energy-saving threshing air separation process and device, used to perform air separation on tobacco flakes and tobacco stalks. The process sequentially comprises the following steps: a scraping plate feeding machine (2), a bin type feeding machine (3), a proportional distributor (4), a first-level threshing machine set (5), a conveying belt (6), a first-level air separation machine set (7), a stalky leaf conveying belt (10), a second-level threshing machine set (11), a conveying belt (12-14), a second-level air separation machine set (15), a stalky leaf conveying belt (19), a third-level threshing machine set (20), a conveying belt (21-23), a third-level air separation machine set (24), a stalky leaf conveying belt (28), a fourth-level threshing machine set (29), a conveying belt (30), and a fourth-level air separation machine set (31). The first-level air separation machine set (7) is provided with an air pressure type double-bin air separator (9) that only selects qualified tobacco flakes through air separation; and the second-level, third-level air, and fourth-level air separation machine sets (15, 24, 31) are provided with air pressure type three-bin air separators (17, 26) that can select qualified tobacco flakes and tobacco stalks through air separation.
A24B 5/06 - Ecotage du tabac; Traitement des côtes ou des nervures en détachant des côtes le reste des feuilles
B07B 9/00 - Combinaisons d'appareils à cribler ou tamiser ou à séparer des solides par utilisation de courants de gaz; Disposition générale des installations, p.ex. schéma opératoire
B07B 11/00 - Disposition des accessoires dans les appareils à séparer les solides par utilisation de courants de gaz
YUXI JIXINGDEYI TRADE & INDUSTRY CO., LTD. (Chine)
Inventeur(s)
Mou, Dingrong
Wang, Yi
Zou, Quan
Zhao, Yunchuan
Chen, Ran
Yang, Guangtao
Gao, Xiaohua
Cai, Yuan
Qi, Wenhui
Qiao, Xiaohui
Xiao, Wenpin
Dou, Yuanchun
Fan, Hao
Qian, Binghai
Abrégé
An air-pressure-type dual-bin air-powered separator. An upper side wall of a separation bin (11) is in communication with an upper side wall of a material drop bin (12); a conveyor mesh belt (5) connects the separation bin (11) and the material drop bin (12) through the communication opening between the two; an air curtain separating the two bins is provided at the communication opening; a material outlet (9) is provided at the bottom of the material drop bin (12); the top of the separation bin (11) is provided with a negative-pressure air-suction port (6); a material inlet (4) is provided at the bottom of the end facing the conveyor mesh belt (5) on a side wall of the separation bin (11); a vibration groove (3) is provided at the bottom of the separation bin (11); a damping plate (2) is provided at the bottom of the vibration groove (3); an air inlet (1) facing an opening at the bottom end of the separation bin (11) is provided at the lower portion of the damping plate (2); an end of the vibration groove (3) connects to a removed material drop outlet (10). The air-powered separator can separate useless particles of different densities from material according to needs, collect useful material, prevent material particles from breaking and becoming smaller due to mechanical fiction, and has the characteristics of high efficiency, low energy consumption, simple structure, and low material loss.
A flip top cigarette pack comprises a cover(3) and a pack body(2). Top of the rear wall of the pack body is connected with bottom of the rear wall of the cover. Each top of two side walls of the pack body is a concavedown arc shape. Each bottom of two side walls of the cover is a convex arc shape corresponding to the shape of that of the top. The cigarette pack improves the loading type of the combination of the cover and the pack body, avoids the clearance difference generated by two sides of the cigarette pack after finishing and improves the quality of pack and the percent of pass.
B65D 85/10 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers pour objets compressibles ou flexibles en forme de baguettes ou tubulaires pour cigarettes
23.
FILP TOP CIGARETTE PACK WITH CONCAVEDOWN BOTTOM EDGES OF SIDE WALLS OF FLIP TOP
A flip top cigarette pack comprises a cover(3) and a pack body(2). Top of the rear wall of the pack body is connected with bottom of the rear wall of the cover. Each top of two side walls of the pack body is an arc shape. Each bottom of two side walls of the cover is an arc shape corresponding to the shape of that of the top. The cigarette pack improves the loading type of the combination of the cover and the pack body, avoids the clearance difference generated by two sides of the cigarette pack after finishing and improves the quality of pack and the percent of pass.
B65D 85/10 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers pour objets compressibles ou flexibles en forme de baguettes ou tubulaires pour cigarettes
Tobacco, chewing tobacco, cigars, cigarettes containing
tobacco substitutes not for medical purposes, cigarettes,
cigarillos, herbs for smoking, snuff, tobacco in the shape
of thread and powder.
ASHIMA FILTER CIGARETTES YUNNAN CHINA MADE IN YUXI CIGARETTE FACTORY XI YU XIYANYUHAIJIANKANG KAOYANXING JIAOYOUHANLIANG ZHONG GOULUZUIXIANGYAN YUXIJUANYANCHANGCHUPIN
