Abstract

A method for setting a sighting device with a telescopic sight and an attachment device is provided. The attachment device includes a display, a control element, and a non-transitory computer-readable storage medium, and is connected to the telescopic sight such that the display can be observed through the telescopic sight. The method includes displaying a center marking at a center position on the display and activating a first interaction mode, in which the center position of the center marking can be shifted into a new center position by operating at least one control element, displaying a circular marking and activating the second interaction mode, in which the size of the circular marking is changeable by operating at least one control element, and storing display information regarding the new center position and the size of the circular marking in the non-transitory computer-readable storage device.

IPC Classes  ?

• F41G 1/54 - Devices for testing or checking
• F41G 1/38 - Telescopic sights specially adapted for smallarms or ordnanceSupports or mountings therefor

Goods & Services

optical apparatus and instruments; binoculars; field glasses; telescopes; sighting telescopes; spotting scopes; monoculars; rifle scopes; laser distance meters; night vision sights; and parts of the aforementioned goods.

Goods & Services

Information technology and audio-visual, multimedia and photographic devices; photographic lenses; smart devices, namely smartphones, tablets and smart watches; parts of all the aforesaid goods.

Goods & Services

Micro-lithography equipment; machines for use in the manufacture by micro-lithography, especially in the manufacture of electronic components, integrated circuits, semi-conductors; universal fixtures and clamping devices used with dimensional measuring apparatus and instruments (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); parts, fittings and components for all the aforesaid goods. Optical apparatus and instruments; semiconductor lenses; apparatus and software for metrology (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); electric, electronic and optical apparatus and instruments for use in the manufacture by microlithography, especially of electronic components, semi-conductors, integrated circuits (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); electric, electronic and optical apparatus and instruments for use in microlithography (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); software for use in the electronics, micro-lithography, semi-conductor, integrated circuit and integrated optical systems industries; software for the design, testing and fabrication of photo-lithographic masks; semi-conductors; integrated circuits; photo-lithographic masks (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); laser light sources for use in semiconductor manufacturing (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); electronic imaging platforms in the field of inspection of semiconductor materials, namely, semiconductor wafers and reticles (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); electron beam inspection apparatus using scanning method; parts, fittings and components for all the aforesaid goods. Maintenance and repair services in connection with machines, apparatus and instruments for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries. Education and training in connection with the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries; education and training in connection with the use of software in the micro-lithography, semiconductor, integrated circuit, magnetic domain memories and integrated optical systems industries; advisory and consultancy services in connection with the aforesaid services. Technical advisory and consultancy services in connection with machines, apparatus and instruments for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); design, maintenance and development of computer software for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries and for the design, testing and fabrication of photo-lithographic masks; advisory and consultancy services in connection with the aforesaid services.

Abstract

An electro-optical observation device includes a device housing, a lens group arranged in the device housing, and a display unit arranged in the device housing and being configured to display a captured image or overlay information on a beam path. Moreover, the observation device includes an eyepiece arranged on an exit side with respect to the display unit and including at least one electrically conductive element, and a control device. The control device is in contact with the electrically conductive element and configured to form a capacitive proximity sensor with the electrically conductive element and control the display unit based on a measured quantity ascertained with the capacitive proximity sensor.

IPC Classes  ?

• H04N 23/11 - Cameras or camera modules comprising electronic image sensorsControl thereof for generating image signals from different wavelengths for generating image signals from visible and infrared light wavelengths
• H04N 23/51 - Housings
• H04N 23/53 - Constructional details of electronic viewfinders, e.g. rotatable or detachable

Abstract

A telescopic sight system includes a telescopic sight and a setting assembly. The telescopic sight has a housing, an objective lens assembly, a reticle element, an adjustment mechanism, and an adjustment turret. The setting assembly can be reversibly coupled to the adjustment turret and has a coupling peg and a peg carrier. A receiving shaft and a blocking spring are arranged in the adjustment turret. The coupling peg has two annular grooves. A groove bottom of the first annular groove is arranged at a smaller spacing than the spring width from an outer edge of the receiving shaft. The second annular groove is recessed with respect to the first annular groove. The blocking spring lies in the first annular groove when the coupling peg has been arranged in the fixing position, and in the second annular groove when the coupling peg has been arranged in the release position.

IPC Classes  ?

• F41G 1/387 - Mounting telescopic sights on smallarms
• F41G 1/54 - Devices for testing or checking

Abstract

For analysis of the state of a plant (2) or of another eukaryote, an evaluation device or an evaluation system (30) has an evaluation circuit (34) which is designed to carry out an evaluation (36) of spectral data. The spectral data or data generated on the basis thereof by preprocessing are divided into multiple parts and analyzed using an analysis logic. The analysis logic comprises at least one attention mechanism.

IPC Classes  ?

• G01N 21/31 - Investigating relative effect of material at wavelengths characteristic of specific elements or molecules, e.g. atomic absorption spectrometry
• G01N 21/84 - Systems specially adapted for particular applications

Abstract

The invention relates to a computer-implemented method (200) for determining an eye orientation of the eyes (24) of a patient (22) for execution by a mobile device (10) with a display unit (12) and a camera (14) which is arranged on the same side of the mobile device (10) as the display unit (12). The method (200) comprises outputting (202) instructions (18) to the patient (22) to support the patient (22) in orienting the mobile device (10) relative to the eyes (24) of the patient (22) such that the display unit (12) and the camera (14) are positioned in a predetermined region relative to the eyes (24) of the patient (22) and are facing the eyes (24). The method also comprises determining (204) a position of the eyes (24) relative to the mobile device (10), displaying (206) a light visualisation (16) on the display unit (12), and capturing (208) at least one image of the eye (24) by means of the camera (14) such that in the captured image a cornea reflection (26) of the light visualisation (16) displayed on the display unit (12) can be determined in each of the eyes (24) of the patient (22). Furthermore, the method comprises determining (210) a position of the respective cornea reflection (26) in the eye (24) on the basis of the captured at least one image and determining the eye orientation of both eyes (24) using the position of the respective cornea reflection (26) in the eye (24).

IPC Classes  ?

• A61B 3/08 - Subjective types, i.e. testing apparatus requiring the active assistance of the patient for testing binocular or stereoscopic vision, e.g. strabismus
• A61B 3/14 - Arrangements specially adapted for eye photography
• A61B 3/15 - Arrangements specially adapted for eye photography with means for aligning, spacing or blocking spurious reflection

Abstract

The invention relates to a method (50) for defining the focal plane (40) of a stereoscopic virtual image from an optical arrangement (20) which can be worn in front of the eyes (1) and which has at least one optical device (25) for radiating a stereoscopic virtual image. The method comprises the following steps: ascertaining the heterophoria of a person (52); based on the ascertained heterophoria, ascertaining a dependency (9) between the vergence distance and the focus distance (53); ascertaining a curve of the minimum relative vergence (11) (54); determining a depth-of-field region (43) (55); ascertaining a first focus distance (41) and a second focus distance (42), wherein the second focus distance (42) has a higher value in dioptres than the first focus distance (41), wherein the focus distance between the first focus distance (41) and the second focus distance (42) corresponds to the determined depth-of-field region (43) and wherein the first focus distance (41) is defined such that it forms an intersection point with the curve of the minimum relative vergence (11), said intersection point having a vergence value of at most 1 dioptre (56); and defining the focal plane (40) (57) of the stereoscopic virtual image in a region between the second focus distance (42) and the first focus distance (41).

IPC Classes  ?

• G02B 27/01 - Head-up displays

Abstract

The invention relates to a spectacle lens (1) comprising - a spectacle lens rear surface (11) facing towards the eye; - a spectacle lens front surface (13) facing away from the eye; - a Fresnel structure (3) comprising at least two Fresnel zones (3-1 to 3-6) providing a focusing effect, wherein the focusing effect of the Fresnel structure (3) is based at least partially on a refractive index gradient within the Fresnel zones (3-1 to 3-6), and the Fresnel structure (3) has boundary surfaces (5a to 5e) at which a high refractive index of one Fresnel zone (3-1 to 3-6) and a low refractive index of an adjacent Fresnel zone (3-1 to 3-6) adjoin one another. The at least one boundary surface (5a to 5e) has a rear-side intersection line (4a to 4e) with the spectacle lens rear surface (11) and a front-side intersection line (6a to 6e) with the spectacle lens front surface (13). The rear surface region of the spectacle lens rear surface (11) enclosed by the innermost rear-side intersection line (4a) has a rear-side geometric centre of gravity (RS) and the front-side surface region of the spectacle lens front surface (11) enclosed by the innermost front intersection line (6a) has a front-side geometric centre of gravity (VS). The rear-side intersection line (4a to 4e) has a smaller distance from the rear-side geometric centre of gravity (RS) than the front-side intersection line (6a to 6e) from the front-side geometric centre of gravity (VS), for at least 25% of all azimuth angles.

IPC Classes  ?

• G02C 7/02 - LensesLens systems
• G02B 3/08 - Simple or compound lenses with non-spherical faces with discontinuous faces, e.g. Fresnel lens
• B29D 11/00 - Producing optical elements, e.g. lenses or prisms

Abstract

The invention relates to detecting a shape deviation in three dimensions, 3D, of an inspection object (11) of a 3D target geometry (33), in which back projections on the 3D target geometry (33) are determined by at least one processing circuit (34), wherein, for a plurality of 2D images of the inspection object (11), one back projection each is determined on at least one part of the 3D target geometry (33). The determined back projections for the plurality of 2D images are compared by the at least one processing circuit (34) in order to detect the shape deviation.

IPC Classes  ?

• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures
• G06T 7/00 - Image analysis

Abstract

The invention relates to an optical device (20) for projecting a pattern onto a surface (98), the optical device (20) comprising the following: a slide (30), wherein the slide (30), for generating the pattern, refracts and/or diffracts and/or reflects and/or absorbs some of the light radiated into the optical device (20), and a projection optical unit (60), wherein the projection optical unit (60) is designed to image the pattern onto the surface (98), characterised in that the slide (30) and the projection optical unit (60) are designed in a single piece.

IPC Classes  ?

• G02B 27/18 - Optical systems or apparatus not provided for by any of the groups , for optical projection, e.g. combination of mirror and condenser and objective

Abstract

The disclosure relates to an optical system and to a camera having an optical system and being configured to image an object. The optical system includes a sensor unit, lens units and an immersion unit. When viewed in the light incidence direction, first the first lens unit, then the second lens unit, then the immersion unit, and then the sensor unit are arranged along an optical axis. Further, the immersion unit is arranged both at the second lens unit and at the sensor unit. The second lens unit and the immersion unit together have positive refractive power.

IPC Classes  ?

• H04N 23/23 - Cameras or camera modules comprising electronic image sensorsControl thereof for generating image signals from infrared radiation only from thermal infrared radiation
• G02B 9/04 - Optical objectives characterised both by the number of the components and their arrangements according to their sign, i.e. + or – having two components only
• G03B 30/00 - Camera modules comprising integrated lens units and imaging units, specially adapted for being embedded in other devices, e.g. mobile phones or vehicles

Abstract

The aim of the invention is to analyze the condition of a plant. In order to achieve this aim, an apparatus (10) comprises a near-field camera (21) and a spectral analytical measuring device (22). The near-field camera (21) has a first field of view (41, 44) relative to a housing (20) of the apparatus (10). The spectral analytical measuring device (22) has a second field of view (42) relative to the housing (20), wherein the second field of view (42) is contained entirely in the first field of view (41, 44).

IPC Classes  ?

• G01N 21/31 - Investigating relative effect of material at wavelengths characteristic of specific elements or molecules, e.g. atomic absorption spectrometry
• G01N 21/84 - Systems specially adapted for particular applications
• G01N 33/00 - Investigating or analysing materials by specific methods not covered by groups
• G01N 21/359 - Investigating relative effect of material at wavelengths characteristic of specific elements or molecules, e.g. atomic absorption spectrometry using infrared light using near infrared light
• G01N 21/88 - Investigating the presence of flaws, defects or contamination

Abstract

The invention relates to an apparatus (10) or to a system which can assist with the analysis of a plant or a plurality of plants (2). The apparatus (10) or the system has an image capturing device (21) which is designed to capture at least one image (60) of at least one part of the plant or the plurality of plants (2). The apparatus (10) or the system has a human-machine interface (24) which is designed to output information which is obtained on the basis of the at least one image (60) and which indicates at least one area suitable for a measurement for the purpose of analyzing the plant or the plurality of plants (2).

IPC Classes  ?

• G01N 21/84 - Systems specially adapted for particular applications
• G01N 33/00 - Investigating or analysing materials by specific methods not covered by groups

Abstract

The invention provides a method for producing optical elements for a customised spectacle lens for an image-generating display device which can be positioned on a user's head, said method comprising the following steps: A) producing a plurality of base stacks (25) of a first variant and a plurality of base stacks (25) of a second variant, wherein the base stacks (25) of all variants in each case comprise a waveguide (11) with a first side (16) and a second side (17) and a first lens (20) connected to the first side (16), the base stacks (25) of the same variant in each case have the same optical properties, and base stacks (25) of different variants differ in at least one predetermined optical property, B) producing a custom lens (21) for the user based on their visual impairment and based on a selected base stack variant, and C) providing a base stack (25) of the selected variant and the produced custom lens (21) so as to be able to connect the produced custom lens (21) with the provided base stack (25) to produce the spectacle lens (3) customised for the user.

IPC Classes  ?

• G02B 27/01 - Head-up displays
• G02C 7/08 - Auxiliary lensesArrangements for varying focal length

Abstract

The invention relates to a computer implemented method (10) for training a machine learning model (28) for semantic image segmentation (30), the method comprising: obtaining training images (12) together containing at least three different types of annotations (24), and training the machine learning model (28) using a loss function, wherein the formulation of the loss function at at least one pixel depends on the types of annotations (24) at the pixel and on the types of annotations (24) within each batch. The invention also relates to a computer implemented method for semantic segmentation making use of the trained machine learning model, and to corresponding systems, computer programs and computer readable media.

IPC Classes  ?

• G06F 18/2115 - Selection of the most significant subset of features by evaluating different subsets according to an optimisation criterion, e.g. class separability, forward selection or backward elimination
• G06F 18/214 - Generating training patternsBootstrap methods, e.g. bagging or boosting
• G06F 18/22 - Matching criteria, e.g. proximity measures
• G06V 10/82 - Arrangements for image or video recognition or understanding using pattern recognition or machine learning using neural networks

Goods & Services

Optical apparatus and instruments; binoculars; field glasses; telescopes; sighting telescopes; spotting scopes; monoculars; riflescopes; photographic apparatus and instruments; cameras; thermal imaging cameras; night vision devices; sensors; laser distance meters; accessories, especially tripods, adapters, carrying straps, stands and mounts for the aforementioned goods

Goods & Services

optical apparatus and instruments; binoculars; field glasses; telescopes; sighting telescopes; spotting scopes; monoculars; riflescopes; photographic apparatus and instruments; cameras; thermal imaging cameras; night vision devices; sensors; laser distance meters; accessories, especially tripods, adapters, carrying straps, stands and mounts for the aforementioned goods.

Abstract

A wavefront manipulator includes a first optical component and a second optical component arranged one behind the other along a reference axis. The first optical component and the second optical component are arranged movably relative to one another in a plane perpendicular to the reference axis. The first optical component and the second optical component each include a first optical element having at least one freeform surface, a refractive index m and an Abbe number v1, and a second optical element having at least one freeform surface, a refractive index n2 and an Abbe number v2, which are arranged one behind the other along the reference axis, the Abbe numbers v1 and v2 differing from one another (v1≠v2).

IPC Classes  ?

• G02B 3/00 - Simple or compound lenses
• G02B 3/02 - Simple or compound lenses with non-spherical faces

Abstract

The invention relates e.g. to a head-mounted optical system for augmented reality applications. A Fresnel lens (220) having multiple regions (91, 92) of different geometrical properties of the particular Fresnel zone or of different supported optical resolutions is used.

IPC Classes  ?

• G02B 3/08 - Simple or compound lenses with non-spherical faces with discontinuous faces, e.g. Fresnel lens
• G02B 3/10 - Bifocal lensesMultifocal lenses
• G02B 27/01 - Head-up displays
• G02B 27/00 - Optical systems or apparatus not provided for by any of the groups ,

Abstract

A wavefront manipulator has at least a first optical component and a second optical component arranged in succession along a reference axis. The first optical component and the second optical component are arranged so as to be movable relative to one another perpendicular to the reference axis. The first optical component and the second optical component each include a first optical element and at least one further optical element with differing refractive index profiles η1(λ) and ηi(λ) arranged in succession along the reference axis, with the optical elements having, in relation to local coordinates x and y of the optical components, a spatially dependent length Δz(x,y) in the z-direction parallel to the reference axis.

IPC Classes  ?

• G02B 26/08 - Optical devices or arrangements for the control of light using movable or deformable optical elements for controlling the direction of light
• G02B 3/00 - Simple or compound lenses
• G02B 3/02 - Simple or compound lenses with non-spherical faces
• G02B 7/04 - Mountings, adjusting means, or light-tight connections, for optical elements for lenses with mechanism for focusing or varying magnification
• G02B 27/00 - Optical systems or apparatus not provided for by any of the groups ,

Goods & Services

(1) Micro-lithography equipment; machines for use in the manufacture by micro-lithography, especially in the manufacture of electronic components, integrated circuits, semi-conductors; universal fixtures and clamping devices used with dimensional measuring apparatus and instruments (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); parts, fittings and components for all the aforesaid goods. (2) Optical apparatus and instruments; semiconductor lenses; apparatus and software for metrology (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); electric, electronic and optical apparatus and instruments for use in the manufacture by microlithography, especially of electronic components, semi-conductors, integrated circuits (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); electric, electronic and optical apparatus and instruments for use in microlithography (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); software for use in the electronics, micro-lithography, semi-conductor, integrated circuit and integrated optical systems industries; software for the design, testing and fabrication of photo-lithographic masks; semi-conductors; integrated circuits; photo-lithographic masks (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); laser light sources for use in semiconductor manufacturing (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); electronic imaging platforms in the field of inspection of semiconductor materials, namely, semiconductor wafers and reticles (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); electron beam inspection apparatus using scanning method; parts, fittings and components for all the aforesaid goods. (1) Maintenance and repair services in connection with machines, apparatus and instruments for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries. (2) Education and training in connection with the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries; education and training in connection with the use of software in the micro-lithography, semiconductor, integrated circuit, magnetic domain memories and integrated optical systems industries; advisory and consultancy services in connection with the aforesaid services. (3) Technical advisory and consultancy services in connection with machines, apparatus and instruments for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries (term considered too vague by the International Bureau pursuant to Rule 13 (2) (b) of the Regulations); design, maintenance and development of computer software for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries and for the design, testing and fabrication of photo-lithographic masks; advisory and consultancy services in connection with the aforesaid services.

Abstract

The present invention relates to an optical system, comprising a first and a second optical element and at least two polymer layers, to a method for producing an optical system, and to the use of the optical system for reality systems.

IPC Classes  ?

• G02B 7/00 - Mountings, adjusting means, or light-tight connections, for optical elements
• B29D 11/00 - Producing optical elements, e.g. lenses or prisms
• G02B 7/02 - Mountings, adjusting means, or light-tight connections, for optical elements for lenses

Abstract

Various examples of the disclosure pertain to an optical system for augmented reality applications, e.g., glasses or head-up display. A Fresnel lens (111, 112) is used in combination with an optical waveguide (122). Various designs of the Fresnel lens are disclosed.

IPC Classes  ?

• G02B 27/01 - Head-up displays
• G02B 3/08 - Simple or compound lenses with non-spherical faces with discontinuous faces, e.g. Fresnel lens

Abstract

The invention relates to a computer-implemented method which is designed to verify correctness of assembly. The method comprises determining an actual 3D model of the assembly based on image data of the assembly, and comparing the 3D model so determined with a target 3D model of the assembly for the purpose of verifying correctness of assembly.

IPC Classes  ?

• G06T 7/00 - Image analysis

Abstract

The invention relates to a sample vessel (1) for cultivating biological samples (9), comprising a cavity (2) for receiving a medium (8); at least one inlet opening (10) for feeding the medium (8) into the cavity (2); and a sample chamber (3) arranged within the cavity (2) for receiving a sample (9), wherein the sample chamber (3) is separated by at least one lateral wall (4) from a remaining chamber of the cavity (2) and the at least one lateral wall (4) has openings (6) by means of which the medium (8) contained in the cavity (2) can become connected to the sample chamber (3). The sample vessel (1) is characterised in that the at least one lateral wall (4) stands on a floor (5) of the sample chamber (3); and the floor (5) is permeable for wavelengths of at least one wavelength range of visible light and therefore it is possible to illuminate the sample chamber (3), and/or capture a detection radiation coming out of the sample chamber (3), through the floor (5) of the cavity (2). The invention also relates to a device (12) for operating the sample vessel (1), and to a microscope (17).

IPC Classes  ?

• C12M 1/32 - Inoculator or sampler multiple field or continuous type
• C12M 1/00 - Apparatus for enzymology or microbiology
• C12M 1/12 - Apparatus for enzymology or microbiology with sterilisation, filtration, or dialysis means
• C12M 1/34 - Measuring or testing with condition measuring or sensing means, e.g. colony counters

Abstract

The invention relates to a computer-implemented method (100) for training a segmentation model (300) for images, particularly medical images, the method (100) comprising: obtaining (101) a dataset (310), the dataset (310) comprising a set of labeled images (311) and a set of unlabeled images (312), the images (311,312) being taken with an imaging apparatus (20), and the labeled images (311) comprising annotated components (201); creating (102) synthesized training samples (215) from the obtained dataset (310); and training (103) the model (300) using the synthesized training samples (215); wherein creating (102) the synthesized training samples (215) comprises: matching at least one of the annotated components (201) with at least one (202) of the unlabeled images (312); and transferring at least one of the annotated components (201) to at least one of the unlabeled images (312) depending on the matching.

IPC Classes  ?

• G06V 10/26 - Segmentation of patterns in the image fieldCutting or merging of image elements to establish the pattern region, e.g. clustering-based techniquesDetection of occlusion
• G06V 10/75 - Organisation of the matching processes, e.g. simultaneous or sequential comparisons of image or video featuresCoarse-fine approaches, e.g. multi-scale approachesImage or video pattern matchingProximity measures in feature spaces using context analysisSelection of dictionaries
• G06V 10/74 - Image or video pattern matchingProximity measures in feature spaces
• G06V 10/774 - Generating sets of training patternsBootstrap methods, e.g. bagging or boosting

Goods & Services

Apparatus for heating and steaming items and fabrics, not for industrial purposes; Burners and heaters for laboratory use; Cooking, heating, cooling and preservation equipment, for food and beverages; Drying installations; Filters for industrial and household use; Fireplaces; Flues and installations for conveying exhaust gases; Fog and smoke machines; Heating elements and filaments; Heating, ventilating, and air conditioning and purification equipment (ambient); Igniters; Industrial treatment apparatus and installations; Lighting and lighting reflectors; Nuclear installations; Personal heating and drying implements; Refrigerating and freezing equipment; Regulating and safety accessories for water and gas installations; Sanitary installations, water supply and sanitation equipment; Sun tanning appliances.

Abstract

The application relates to a method and a device for generating an anomaly map for the detection of defects of a production object. A production object image is divided into a plurality of image portions. An image portion vector is then determined for each image portion. Each element of the image portion vector indicates the presence of reference production object features in the associated image portion. In addition, for each image element an item of location information relating to the image portion is encoded in the image portion vector and an anomaly value is determined on the basis of the image portion vector. The anomaly value indicates a deviation of the image portion vector, said deviation being determined on the basis of at least one reference image portion vector. Finally, the anomaly map is generated on the basis of the anomaly values determined for the image portions. The anomaly values are arranged in the anomaly map on the basis of the items of location information.

IPC Classes  ?

• G06T 7/00 - Image analysis

Abstract

The invention relates to methods and systems for determining a pose, said methods and systems capturing at least one two-dimensional diffraction pattern caused by diffracting coherent radiation (14) at a diffractive element (30) in the far field. The diffractive element (30) has a non-periodic volumetric diffraction structure (31). A pose of the diffractive element (30) is determined based on the at least one two-dimensional diffraction pattern and data dependent on the non-periodic volumetric diffraction structure (31).

IPC Classes  ?

• G01B 11/00 - Measuring arrangements characterised by the use of optical techniques
• G02B 5/18 - Diffracting gratings

Abstract

The invention relates to methods and systems for determining a pose, said methods and systems capturing and analysing a plurality of two-dimensional diffraction patterns. The plurality of two-dimensional diffraction patterns are caused by diffracting coherent radiation with different wavelength components (141, 142) at an element (30). An evaluation device (20) is designed to determine a pose of the element (30) based on the plurality of two-dimensional diffraction patterns (50).

IPC Classes  ?

• G01B 11/00 - Measuring arrangements characterised by the use of optical techniques
• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures
• G01B 11/26 - Measuring arrangements characterised by the use of optical techniques for measuring angles or tapersMeasuring arrangements characterised by the use of optical techniques for testing the alignment of axes
• G01B 9/02 - Interferometers
• G01B 9/02001 - Interferometers characterised by controlling or generating intrinsic radiation properties
• G02B 5/18 - Diffracting gratings
• G02B 5/32 - Holograms used as optical elements
• G02B 27/42 - Diffraction optics
• G03H 1/00 - Holographic processes or apparatus using light, infrared, or ultraviolet waves for obtaining holograms or for obtaining an image from themDetails peculiar thereto
• G03H 1/04 - Processes or apparatus for producing holograms
• G03H 1/26 - Processes or apparatus specially adapted to produce multiple holograms or to obtain images from them, e.g. multicolour technique

Abstract

Various examples of the disclosure relate to coherent imaging techniques such as digital holography or Fourier ptychography. Aberrations are corrected. The aberrations are corrected according to the field location.

IPC Classes  ?

• G03H 1/08 - Synthesising holograms
• G02B 21/36 - Microscopes arranged for photographic purposes or projection purposes
• G03H 1/04 - Processes or apparatus for producing holograms
• G03H 1/00 - Holographic processes or apparatus using light, infrared, or ultraviolet waves for obtaining holograms or for obtaining an image from themDetails peculiar thereto

Abstract

The invention relates to a computer-implemented method for generating (100) reference data for use in a manufacturing and/or assembly process. The method can include the method step of obtaining (101) a digital model of a workpiece. The digital model can be, in particular a 3D model. The digital model can also be, in particular a CAD model. The workpiece can be, in particular an assembled workpiece. In another step, the method can include obtaining (102) video data of the manufacturing and/or assembly process of the workpiece. The method can also include generating (103) a digital schedule of the manufacturing and/or assembly process based at least partially on the digital model and the video data.

IPC Classes  ?

• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]
• G05B 19/4097 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by using design data to control NC machines, e.g. CAD/CAM
• G05B 19/42 - Recording and playback systems, i.e. in which the programme is recorded from a cycle of operations, e.g. the cycle of operations being manually controlled, after which this record is played back on the same machine
• B25J 9/16 - Programme controls

Abstract

A method for operating a mobile terminal including an image recording device includes capturing at least one recording of a scene and checking at least one of optionally several recordings checked for the presence of a light source. Subsequently, a position of the light source is determined relative to an optical center and a shape, an intensity and/or a color is determined for the light source. An algorithm trained in relation to imaging properties of a given optical unit is then used to generate a flare image of a lens flare for this light source and the given optical unit using the position of the light source. The flare image is subsequently combined with the recording to form a combination image and the combination image is stored in a memory component.

IPC Classes  ?

• G06T 7/80 - Analysis of captured images to determine intrinsic or extrinsic camera parameters, i.e. camera calibration
• G06T 5/90 - Dynamic range modification of images or parts thereof

Abstract

An electro-optical observation system for hunting includes an electronic image detector and an optical unit assigned to the image detector. The observation system further includes a processor configured to indirectly or directly exchange data with the image detector, to analyze an image stream, which was acquired with the image detector, in view of the presence of an object that is sufficiently different from an image background, and to control a user interface to output a notification to a user in the case of the presence detected on the basis of the analysis of the image stream.

IPC Classes  ?

• H04N 7/18 - Closed-circuit television [CCTV] systems, i.e. systems in which the video signal is not broadcast
• G06V 20/52 - Surveillance or monitoring of activities, e.g. for recognising suspicious objects
• G06V 40/10 - Human or animal bodies, e.g. vehicle occupants or pedestriansBody parts, e.g. hands
• H04N 23/23 - Cameras or camera modules comprising electronic image sensorsControl thereof for generating image signals from infrared radiation only from thermal infrared radiation

Abstract

An optical arrangement for a mobile device includes a lens and an image receiver, the installation length L0 of the optical arrangement being no more than 10 millimeters. The image receiver has a curved detector surface. The lens is typically arranged to be displaceable along a center axis relative to the image receiver between a compressed state and an operating state.

IPC Classes  ?

• G03B 30/00 - Camera modules comprising integrated lens units and imaging units, specially adapted for being embedded in other devices, e.g. mobile phones or vehicles
• H04N 23/55 - Optical parts specially adapted for electronic image sensorsMounting thereof

Abstract

The invention relates to a computer-implemented method (100) for training a volumetric model (200,230,240) on training data (210), the method (100) comprising: obtaining (101) the training data (210), the training data (210) comprising volumes taken with an imaging apparatus (20), at least one of the volumes being sparsely annotated; and training (102) the model (200,230,240) using the training data (210), the training (102) being regularized based on at least one positional proximity constraint and/or at least one semantic proximity constraint constructed from the training data (210).

IPC Classes  ?

• G06V 10/774 - Generating sets of training patternsBootstrap methods, e.g. bagging or boosting
• G06T 7/162 - SegmentationEdge detection involving graph-based methods
• G06V 10/82 - Arrangements for image or video recognition or understanding using pattern recognition or machine learning using neural networks
• G06V 20/64 - Three-dimensional objects

Goods & Services

Micro-lithography equipment; machines for use in the manufacture by micro-lithography, especially in the manufacture of electronic components, integrated circuits, semi-conductors; universal fixtures and clamping devices used with dimensional measuring apparatus and instruments; parts, fittings and components for all the aforesaid goods. Optical apparatus and instruments; semiconductor lenses; apparatus and software for metrology; electric, electronic and optical apparatus and instruments for use in the manufacture by microlithography, especially of electronic components, semi-conductors, integrated circuits; electric, electronic and optical apparatus and instruments for use in microlithography; software for use in the electronics, micro-lithography, semi-conductor, integrated circuit and integrated optical systems industries; software for the design, testing and fabrication of photo-lithographic masks; semi-conductors; integrated circuits; photo-lithographic masks; laser light sources for use in semiconductor manufacturing; electronic imaging platforms in the field of inspection of semiconductor materials, namely, semiconductor wafers and reticles; electron beam inspection apparatus using scanning method; parts, fittings and components for all the aforesaid goods. Maintenance and repair services in connection with machines, apparatus and instruments for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries. Education and training in connection with the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries; education and training in connection with the use of software in the micro-lithography, semiconductor, integrated circuit, magnetic domain memories and integrated optical systems industries; advisory and consultancy services in connection with the aforesaid services. Technical advisory and consultancy services in connection with machines, apparatus and instruments for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries; design, maintenance and development of computer software for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries and for the design, testing and fabrication of photo-lithographic masks; advisory and consultancy services in connection with the aforesaid services.

Abstract

A manufacturing installation for producing a plurality of workpieces comprises a manufacturing machine having a moveable machine element, a machine controller configured to control the moveable machine element, and a metrology device configured to determine actual characteristics of a produced workpiece. A data set defining desired workpiece characteristics is obtained and a first workpiece is produced in a plurality of first successive manufacturing steps. A plurality of first process parameters are repeatedly recorded in order to obtain a respective first process parameter sequence for each first process parameter. First sequential mapping data associate each first control command with first process parameters recorded at the time when a respective first control command was executed. Deviations between the actual first workpiece characteristics and the desired workpiece characteristics are obtained by inspecting the first workpiece using the metrology device. Second control commands are determined on the basis of the deviations and on the basis of the first sequential mapping data. A second workpiece is produced using the manufacturing installation and the plurality of second control commands.

IPC Classes  ?

• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]
• G05B 19/401 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control arrangements for measuring, e.g. calibration and initialisation, measuring workpiece for machining purposes

Abstract

The invention relates to a digital long-range optical apparatus (1) for imaging an object (2), having an optical axis (OA), having a lens (3) for imaging the object (2), the lens (3) being arranged along the optical axis (OA), having a processor unit (4), and having a display unit (5) for displaying an image of the object (2), the processor unit (4) being line-connected to the display unit (5). The digital long-range optical apparatus (1) comprises a beam splitter unit (7), with the lens (3) being arranged first along the optical axis (OA) in a direction of light incidence (LE), followed by the beam splitter unit (7). Further, a first detector (8A) and a second detector (8B) are provided. The first detector (8A) is designed to detect first light (L1) generated by the beam splitter unit (7) and the second detector (8B) is designed to detect second light (L2) generated by the beam splitter unit (7).

IPC Classes  ?

• H04N 23/16 - Optical arrangements associated therewith, e.g. for beam-splitting or for colour correction
• G02B 23/04 - Telescopes, e.g. binocularsPeriscopesInstruments for viewing the inside of hollow bodiesViewfindersOptical aiming or sighting devices involving prisms or mirrors for the purpose of beam splitting or combining, e.g. fitted with eyepieces for more than one observer
• H04N 23/80 - Camera processing pipelinesComponents thereof

Goods & Services

Software for smart devices, namely smartphones, tablets and smart watches.

Abstract

A method is provided for operating an electro-optic observation device, in particular a thermal imaging device, which includes an electronic viewfinder, a proximity sensor and a position sensor. According to the method, a predefined distance range in front of the viewfinder is monitored for a presence of a user with the proximity sensor, a position variable which is characteristic of the orientation of the observation device is captured with the position sensor, information concerning a current use situation of the observation device is derived from the presence of the user within the distance range and/or the position variable, and at least one specific function of the observation device that influences an image display is activated or at least enabled depending on the information concerning the current use situation.

IPC Classes  ?

• H04N 23/63 - Control of cameras or camera modules by using electronic viewfinders
• H04N 23/60 - Control of cameras or camera modules
• H04N 23/611 - Control of cameras or camera modules based on recognised objects where the recognised objects include parts of the human body
• G01J 5/0804 - Shutters
• G01P 15/18 - Measuring accelerationMeasuring decelerationMeasuring shock, i.e. sudden change of acceleration in two or more dimensions

Abstract

A method for creating a second series of individual images with a first series of individual images, the individual images of the first or the second series of individual images having been captured with an objective, includes determining the entrance pupil and the field of vision of the objective for the individual images of the first series and creating or adapting the individual images of the second series in accordance with the entrance pupil and the field of vision of the objective of the individual image in question of the first series.

IPC Classes  ?

• G06T 15/50 - Lighting effects
• G06T 15/20 - Perspective computation

Abstract

The present invention relates to a method for producing an optical arrangement (41) which comprises at least one optical waveguide (2) and at least one optical component (11, 12). The method comprises the following steps: providing (21) an optical waveguide (2) having a surface (3, 4), and an optical component (11, 12) having a rear-side surface (14, 15), the surface (3, 4) of the optical waveguide (2) and the rear-side surface (14, 15) of the optical component (11, 12) being designed for mutually facing arrangement and having a surface geometry matched to one another; providing (22) a mask (32) which is designed to cover the edge region of the surface (3, 4) of the optical waveguide (2) and the rear-side surface (14, 15) of the optical component (11, 12) at least in part; arranging (23) the mask (32) on the surface (3, 4) of the optical waveguide (2) or the rear-side surface (14, 15) of the optical component (11, 12) in such a way that the edge region of the surface (3, 4, 14, 15) is covered at least in part; applying (24) an adhesive (16) to the surface (3, 4) of the optical waveguide (2) or the rear-side surface (14, 15) of the optical component (11, 12); placing (25) the rear-side surface (14, 15) of the optical component (11, 12) and the surface (3, 4) of the optical waveguide (2) against one another; curing (26) the adhesive (16); and removing (27) the mask (32).

IPC Classes  ?

• G02B 27/01 - Head-up displays
• G02C 7/08 - Auxiliary lensesArrangements for varying focal length
• G02C 11/00 - Non-optical adjunctsAttachment thereof
• F21V 8/00 - Use of light guides, e.g. fibre optic devices, in lighting devices or systems
• G02B 27/00 - Optical systems or apparatus not provided for by any of the groups ,

Goods & Services

Information technology and audio-visual, multimedia and photographic devices; photographic lenses; smart devices, namely smartphones; tablet computers and smart watches; parts of all the aforesaid goods.

Abstract

An apparatus for measuring, inspecting and/or processing objects is provided. The apparatus has a mobile platform for moving the apparatus through a region in space and a kinematic system attached to the mobile platform. An instrument head is fitted to the kinematic system. The apparatus furthermore comprises a controller configured to determine a first estimate of a pose of a target object on the basis of an image from a camera of the apparatus and a digital representation of the target object, to control the mobile platform on the basis of the first estimate, to move toward the target object, to determine a second estimate, in particular a more accurate estimate, of the pose of the target object on the basis of signals from at least one sensor of the apparatus and to control the kinematic system to position the instrument head on the target object on the basis of the second estimate.

IPC Classes  ?

• G06T 7/70 - Determining position or orientation of objects or cameras

Goods & Services

Chemical substances, chemical materials and chemical preparations, and natural elements. Coatings. Downloadable and recorded content; Information technology and audio-visual, multimedia and photographic devices; Magnets, magnetizers and demagnetizers; Scientific and laboratory devices for treatment using electricity; Apparatus, instruments and cables for electricity; Optical devices, enhancers and correctors; Safety, security, protection and signalling devices; Diving equipment; Navigation, guidance, tracking, targeting and map making devices; Measuring, detecting, monitoring and controlling devices; Scientific research and laboratory apparatus, educational apparatus and simulators.

Abstract

The invention relates to an optical waveguide (20) for arrangement in the beam path (5) of an optical arrangement with a device (11) for output coupling and/or input coupling an imaging beam path. The optical waveguide (20) comprises a GRIN element having at least one curved surface (12, 13), the GRIN element having a refractive index distribution designed to reduce the aberrations, arising due to the curvature of the GRIN element, in an imaging path of a virtual image created by means of light waves guided in the optical waveguide (20) by total-internal reflection.

IPC Classes  ?

• F21V 8/00 - Use of light guides, e.g. fibre optic devices, in lighting devices or systems
• G02B 3/00 - Simple or compound lenses
• G02B 6/028 - Optical fibres with cladding with core or cladding having graded refractive index
• G02B 27/00 - Optical systems or apparatus not provided for by any of the groups ,

Abstract

An optical arrangement is provided. The optical arrangement has a center axis, an object side, an image side, and a catadioptric arrangement. The optical arrangement has an installation space of no more than 25 millimeters from the object side to the image side along the center axis, and a linear obscuration of no more than 60 percent.

IPC Classes  ?

• G02B 17/08 - Catadioptric systems
• G02B 9/10 - Optical objectives characterised both by the number of the components and their arrangements according to their sign, i.e. + or – having two components only one + and one – component
• G02B 9/02 - Optical objectives characterised both by the number of the components and their arrangements according to their sign, i.e. + or – having one + component only

Abstract

An optical arrangement having a center axis, an object side, an image side, and a catadioptric arrangement is provided. The catadioptric arrangement includes first and second partly reflective optical components, the first optical component including radially inner and radially outer regions, the inner region being configured to be transparent to light incident from the object side, and the outer region being configured to reflect light incident from the object side, the second optical component including a radially inner region and a radially outer region, the outer region being configured to be transparent to light incident from the object side, and the inner region being configured to be transparent to light incident from the object side and to reflect light incident from the image side. At least one further optical component with positive refractive power is arranged at the inner region of the second optical component on the object side.

IPC Classes  ?

• G02B 13/00 - Optical objectives specially designed for the purposes specified below
• G02B 17/08 - Catadioptric systems
• G02B 9/12 - Optical objectives characterised both by the number of the components and their arrangements according to their sign, i.e. + or – having three components only

Abstract

The invention relates to an optical waveguide (1) for arranging in the beam path of an optical assembly (41, 45, 47), wherein the optical waveguide (1) comprises a substrate (2) with at least two opposing boundary surfaces (9) for guiding optical waves (4) by means of total internal reflection. The at least two boundary surfaces (9) each have an outer layer (40) with a refractive index progression whereby, starting from the respective boundary surface (9), the effective refractive index of the outer layer (40) reduces over a determined course outwards at an increasing distance from the boundary surface (9).

IPC Classes  ?

• G02B 1/118 - Anti-reflection coatings having sub-optical wavelength surface structures designed to provide an enhanced transmittance, e.g. moth-eye structures

Abstract

A portable optical observation device is provided. The portable optical observation device includes an optical group which has a plurality of optical elements arranged in distributed fashion along an optical axis, and a housing which surrounds the optical group at least radially around the optical axis. Moreover, the observation device includes at least one electronic assembly and at least one planar battery cell which is shaped against the housing, configured to be at least moisture resistant, and configured to supply the electronic assembly with power.

IPC Classes  ?

• G02B 23/18 - HousingsCapsMountingsSupports, e.g. with counterweight for binocular arrangements

Goods & Services

Real-time camera-tracking system consisting of hardware and software components for virtual production and post-production; software, in particular visualization and virtual reality software; graphics software; interface software; application software; mobile application software; platform software; data and file management software and database software; virtual and augmented reality software; plug-ins being downloadable software; image processing software; hardware; compact computing unit; cameras; camera systems, consisting of cameras, infrared emitters and sensors. Organization and conduction of trainings. Software development, design, programming and implementation; hosting services; software as a service (SaaS); rental of software; design of graphic and visualization software; platform as a service (PaaS); database design, development and hosting services; organization and award of certifications in the area of virtual production and post-production.

Abstract

The invention relates to an optical system (7) having an optical axis (OA), having a display unit (5) for displaying an image, having an eyepiece (6) for viewing the image, the eyepiece (6) comprising a lens unit (L1). The display unit (5) is designed in such away that a marginal ray light beam (9) emanates from an edge (8) of the display unit (5) and propagates to the lens unit (L1) in a light incidence direction (L). The display unit (5) is arranged first along the optical axis (OA) in the light incidence direction (L), followed by the lens unit (L1) arranged on the optical axis (OA). No further optical unit of the optical system (7) is arranged between the lens unit (L1) and a pupil of the eye (2). The marginal ray light beam (9) has a chief ray (HS). The chief ray (HS) propagates at a first chief ray height (H1) at the lens unit (L1) and at a second chief ray height (H2) at the display unit (5). The first chief ray height (H1) is at least level with the second chief ray height (H2).

IPC Classes  ?

• G02B 25/00 - EyepiecesMagnifying glasses
• G02B 23/12 - Telescopes, e.g. binocularsPeriscopesInstruments for viewing the inside of hollow bodiesViewfindersOptical aiming or sighting devices with means for image conversion or intensification
• G02B 9/04 - Optical objectives characterised both by the number of the components and their arrangements according to their sign, i.e. + or – having two components only

Goods & Services

Maintenance, repair, and parts replacement services for semiconductor equipment

Goods & Services

Licensing of computer software in the fields of vision care, medical technology, semiconductors, industrial metrology, microscopy, photography, cinematography, spectroscopy, and consumer optics; Providing intelligence in the nature of reconnaissance services and surveillance services; Providing information related to anti-counterfeiting integrity and security of tangible property; Monitoring of closed network security devices, namely, alarms and home security systems for protecting personal property; security advisory services being personal security consultation; information related to personal security; legal services in the fields of vision care, medical technology, semiconductors, industrial metrology, microscopy, photography, cinematography, spectroscopy, and consumer optics; Legal services relating to the protection of intellectual property in the fields of vision care, medical technology, semiconductors, industrial metrology, microscopy, photography, cinematography, spectroscopy, and consumer optics; Legal services in the field of intellectual property in the fields of vision care, medical technology, semiconductors, industrial metrology, microscopy, photography, cinematography, spectroscopy, and consumer optics; Legal services, namely, copyright protection services in the fields of vision care, medical technology, semiconductors, industrial metrology, microscopy, photography, cinematography, spectroscopy, and consumer optics; security assessments of risks to individuals or property; Providing security surveillance services, namely, providing security surveillance of premises for others; security surveillance services relating to the security of tangible property; security surveillance services for third parties; Rental of safety protective equipment for safety purposes; Rental of safety equipment, namely, protective clothing and protective equipment for safety purposes; Rental of safety monitoring equipment being security camera surveillance equipment; management of commercial property rights being the management of industrial property rights and copyrights in the fields of vision care, medical technology, semiconductors, industrial metrology, microscopy, photography, cinematography, spectroscopy, and consumer optics; Licensing of technology being computer programs, computer software, intellectual property and industrial property rights in the fields of vision care, medical technology, semiconductors, industrial metrology, microscopy, photography, cinematography, spectroscopy, and consumer optics

Goods & Services

Land vehicle parts, namely, windshields featuring a transparent holographic waveguide Window panes featuring a transparent holographic waveguide; window pane assemblies featuring a transparent holographic waveguide and a light-sensitive sensor, a light source and an imaging device Headwear used in hunting; Clothing used in hunting, namely, headgear, shirts, pants, jackets and waistcoats; Footwear used in hunting Toys, games, and playthings being toy prism glasses and science experiment kits for children; Sporting and physical exercise equipment, namely, scent eliminating wipes for use associated with hunting and outdoor recreation

Abstract

The invention relates to an optical system (7) comprising a display unit (5) for displaying an image and comprising an eyepiece (6) for observing the image. The eyepiece (6) comprises a first lens group (LG1) and a second lens group (LG2). An intermediate pupil (ZP) is arranged between the first lens group (LG1) and the second lens group (LG2). The second lens group (LG2) is designed to image the image displayed by the display unit (5) into the intermediate pupil (ZP). The first lens group (LG1) is designed to image the image arranged in the intermediate pupil (ZP) into a spatial region (B). The intermediate pupil (ZP) and the spatial region (B) are conjugate to one another. A filter unit (E, FE) and/or a wavefront manipulator (E, WM) is/are arranged at the intermediate pupil (ZP).

IPC Classes  ?

• G02B 21/00 - Microscopes
• G02B 21/36 - Microscopes arranged for photographic purposes or projection purposes
• G02B 5/18 - Diffracting gratings
• G02B 3/00 - Simple or compound lenses
• G02B 27/00 - Optical systems or apparatus not provided for by any of the groups ,
• G02B 27/09 - Beam shaping, e.g. changing the cross-sectioned area, not otherwise provided for
• G02B 7/00 - Mountings, adjusting means, or light-tight connections, for optical elements

Goods & Services

software for smart devices, namely smartphones, tablets and smart watches.

Goods & Services

Provision of information in the field of additive manufacturing Advertising, marketing and promotional activities for others in the nature of viral marketing, billboards, promotional exhibits, sponsored ads, online promotion, website and content creation, and business services for the sale and purchase of goods and services, in the fields of vision care, medical technology, semiconductors, industrial metrology, microscopy, photography, cinematography, spectroscopy, and consumer optics; promotional marketing services for others in the fields of vision care using audio and visual media; advertising and marketing services in the fields of vision care provided by means of social media, blogging, video blogging; Retail store services featuring spectacle frames and lenses, eyeglasses, sunglasses, eyeglass cases, contact lenses, contact lens cleaning solutions, ski googles, sports glasses, reading glasses, magnifying loupes, microfiber cleaning cloths, screen cleaning wipes impregnated with a cleaning preparation, lens cleaning wipes impregnated with a cleaning preparation, liquid cleaners and cleaning sprays for screens, optical and spectacle lenses, antifogging agents for optical and spectacle lenses, binoculars, carrying cases and straps for binoculars, spotting scopes, carrying cases, straps, photo and camera adapters for spotting scopes, riflescopes, weather protection covers for riflescopes, camera lenses, filters for camera lenses, digital cameras, carrying cases for camera lenses and digital cameras; retail store and wholesale store services featuring optical apparatus and instruments, measuring apparatus and instruments, ophthalmology and medicine; Data processing services, namely, compilation of data in computer databases Providing online non-downloadable computer software platforms for database management for use in the field of ophthalmology

Goods & Services

Maintenance and repair services in connection with machines, apparatus and instruments for use in the electronics, micro-lithography, semi-conductor, integrated circuit, magnetic domain memories and integrated optical systems industries; repair of scientific, research, photographic, cinematographic, audiovisual, optical, measuring, testing, checking, apparatus and instruments; repair of spectacle lenses, spectacles, microscopes, surgical microscopes, binoculars, riflescopes, spotting scopes, night vision devices, lenses, planetariums, planetarium projectors; repair, installation, maintenance, rebuilding, upgrading, retrofitting and refurbishing services in the field of medical equipment; repair, installation, maintenance, rebuilding, upgrading, retrofitting and refurbishing services in the field of computer hardware, data processing equipment

Goods & Services

Microfiber cleaning cloths

Abstract

The invention relates to a 3D printing apparatus (100) for manufacturing a workpiece. The apparatus (100) has a first radiation source (1), for emitting a first radiation (2) for carrying out a non-linear absorption polymerisation, and a second radiation source (3) for emitting a second radiation (4) for carrying out optical coherence tomography, wherein a first beam path (5) can be traversed by the first radiation (2) and a second beam path (6) can be traversed by the second radiation (4), and wherein the first beam path (5) and the second beam path (6) are formed completely independently of one another. The invention also relates to a 3D printing method (200, 400) for manufacturing a workpiece, another 3D printing apparatus (300), a method for analysing a quality of a raw material (12) of a non-linear absorption polymerisation, a method for checking an orientation of a substrate (8) to be printed by non-linear absorption polymerisation, a method for determining a spatially resolved degree of conversion of a non-linear absorption polymerisation, a method for analysing a structural sharpness of a structure produced by non-linear absorption polymerisation, and a method for three-dimensional reconstruction of a workpiece manufactured by non-linear absorption polymerisation.

IPC Classes  ?

• B29C 64/124 - Processes of additive manufacturing using only liquids or viscous materials, e.g. depositing a continuous bead of viscous material using layers of liquid which are selectively solidified
• B29C 64/393 - Data acquisition or data processing for additive manufacturing for controlling or regulating additive manufacturing processes
• B33Y 10/00 - Processes of additive manufacturing
• B33Y 50/02 - Data acquisition or data processing for additive manufacturing for controlling or regulating additive manufacturing processes

Goods & Services

Anti-fog preparations in the nature of condensation-preventing chemicals Coatings for use by others in the further processing of spectacle lenses, namely, antireflective coatings and protective coatings for ophthalmic lenses; chemical coatings for spectacle lenses Screen cleaning wipes impregnated with a cleaning preparation; lens cleaning wipes impregnated with a cleaning preparation; liquid cleaners and cleaning sprays for screens, optical and spectacle lenses; antifogging agents for optical and spectacle lenses; cleaning cloths impregnated with polishing preparations; cleaning cloths impregnated with cleaning agents; wiping cloths impregnated with cleaning agents for spectacles; cleaning cloths for camera lenses and screens impregnated with cleaning agents; liquid cleaners and cleaning sprays for spectacles, lenses, camera lenses and screens

Goods & Services

Contact lens cleaners, namely contact lens cleaning preparations; liquid cleaning solutions and liquid storage solutions for contact lenses, namely, disinfectants for contact lenses; sterile solutions used in ophthalmic surgery to protect the inner lining of the cornea and maintain the front chamber of the opened eye being viscoelastic agents for ophthalmic purposes; injectable solutions used in ophthalmic surgery to protect the inner lining of the cornea and maintain the front chamber of the opened eye, namely, viscoelastic agents; injection syringes, sold pre-filled, for surgical purposes for ophthalmic intraocular surgery, in particular for the injection of viscoelastic preparations; viscoelastic preparations, namely, viscoelastic agents for use in ophthalmic or intraocular surgery; containers specially adapted for viscoelastic substances for ophthalmic and intraocular surgery, viscoelastic ophthalmological liquids used during eye surgery; chemical reagents and diagnostic agents for medical purposes; disinfectants for sanitary purposes and medical purposes; plasters for medical purposes, namely, adhesive plasters, plasters for healing medical purposes, medicated compresses, medicated swabs, gauze, gauze for dressings, medical dressings, X-ray contrast agents; absorbent cotton for medical purposes being cotton swabs for medical use; absorbent cotton products for medical and hygienic purposes, namely, cotton sticks for medical purposes and cotton swabs for medical purposes; surgical sets, namely, pharmaceutical products for treating ophthalmological diseases, dressings for surgery, surgical bandages, X-ray contrast agents, and radiopharmaceutical detection threads; plasters for medical purposes; medicated compresses; swabs for medical use; bandages for skin wounds; X-ray contrast agents; incision foils, namely, medical adhesive strips for closing incisions; balanced salt solution for medical purposes being saline solution for medical purposes Micro-lithography equipment, namely, semiconductor wafer processing equipment; machines for micro-lithography manufacturing, in particular, the manufacture of electronic components, integrated circuits, semi-conductors; structural replacement parts, fittings and components for lithography machines; universal fixtures and clamping devices for metrological applications being machine tools, namely, clamps, vises, jaws, stands, and jigs for use in the precision clamping of work pieces

Goods & Services

Optical devices, enhancers and correctors, namely, optical glasses; semiconductor optical lenses; apparatus for metrology, namely, optical frequency metrology devices and downloadable software for use in metrology; electric, electronic and optical apparatus and instruments, namely, components for wafer steppers comprising mirrors, optical lenses and a light source, for use in the manufacture of microlithography, especially of electronic components, semi-conductors, integrated circuits; lens objectives for use with wafer steppers and illuminators, namely, optical lenses; measuring instruments to measure positions of structures on photomasks; mask repair tools used in the semiconductor industry; apparatus and instruments for aerial photogrammetry of lithography photomasks in the field of semiconductor technology; equipment for measuring and evaluating the quality of optical systems, in particular wavefront aberrometers; electron microscopes and parts thereof; smartglasses; Downloadable software for the operation of electron microscopes; Downloadable computer software for digital image processing; recorded and downloadable software for use in field of ophthalmology and ophthalmic surgery; 3D scanners; recorded and downloadable software for use in metrology and quality control; recorded and downloadable metrology software and computer hardware for the analysis of the surface quality of work pieces; scientific, surveying, optical, measuring, and checking apparatus and instruments, namely, 3D-digitizer, optical coordinate measuring device, optical measuring device for 3D-deformation analysis, dynamic 3D device for analysis and/or for measuring form changes of sheet metal components and optical apparatus for 3D-visualization, laser level measuring apparatus, x-ray measuring apparatus, 3D measuring apparatus, coordinate measuring apparatus; optical measuring apparatus, in particular, apparatus for three-dimensional measuring, analysis of changes in dimensions or shape, of expansion, of deformation and oscillation in the fields of quality control, reverse engineering, rapid prototyping, material testing, simulation verification, optimizing forming processes, verification of tools, sheet metal forming, material testing, vibration analysis and crash tests; optical objectives, namely, optical device for optical measuring apparatus; ophthalmic lenses; optical lenses; handheld laser scanners for industrial inspection; Downloadable computer programs for three-dimensional digitalization of objects, for analysis of changes in dimension or shape and expansion and for analysis of three-dimensional deformation and oscillation; coordinate measuring machines for use in quality control, reverse engineering, rapid prototyping, material testing, simulation verification, optimizing forming processes, verification of tools, sheet metal forming, material testing, vibration analysis and crash tests; thermal imaging cameras and devices; thermal imaging devices to observe nature; infrared cameras; cameras for observing game and cameras for hunting in the nature of trail cameras; cases and backpacks especially adapted for holding optical apparatus and instruments, in particular, for holding binoculars, telescopes, camera lenses, thermal imaging cameras and other optical devices; data processing equipment and computers; computer hardware; Downloadable computer software for controlling indoor climate; Downloadable mobile application software to connect with microscopes and to take pictures and videos of microscopic samples; downloadable mobile application software to calculate ballistics tailored to riflescopes and manage hunting grounds; Downloadable computer software for use in image processing; spectacle lenses, in particular, tinted and plastic spectacle lenses and coloured spectacle lenses, and replacement parts thereof; Spectacle lenses, namely, attachable lenses; ski goggles, magnifying glasses; magnifying spectacles; polarizing spectacles; telescope spectacles; magnifiers being magnifying lenses; aspherical optics in the nature of aspherical lenses; ophthalmological apparatus and instruments, namely, autorefractors, keratometers, lensmeters, autorefractometers, keratometers, wavefront aberrometers and corneal topographers, non-contact tonometers; illumination devices for use with microscopes; lasers and laser equipment not intended for medical purposes, and parts of such laser equipment for manufacturing optical systems and components, in particular, spectacles, binoculars, lenses, contact lenses and intra-ocular lenses; protective eye pieces such as goggles and eye shields; optical filter; recorded software used in the field of ophthalmology to change a surgical microscope's settings based on the user's work flow; recorded software used to operate surgical lasers; recorded software in the field of ophthalmology for performing keratometry and analysis; recorded software for surgical apparatus and instruments, namely, software for an eye tracking and eye registration system in laser refractive surgery and for intraocular lens centration in cataract surgery; Downloadable software used in the field of ophthalmology to change a surgical microscope's settings based on the user's work flow; Downloadable software to perform refractive laser vision correction; Downloadable software used during neurosurgery to visualize and interpret the flow of blood and to analyze data from the operation, none for use in connection with ultrasound imaging; projectors for planetaria; optical measuring analyzers; for laboratory use; scientific apparatus, namely, spectrometers; optical measuring analyzers; for laboratory use; scientific apparatus, namely, spectrometers; scientific apparatus, namely, spectral sensors; scientific apparatus, namely, spectral sensors; measuring, detecting, monitoring and controlling instruments, indicators and controllers, namely, three-coordinate measuring machines, rotary tables for coordinate measuring, optical angle measuring; scientific research and laboratory apparatus, educational apparatus and simulators; focused ion beam system comprised of computer hardware and downloadable computer software for use in performing analysis and proto typing in the field of nano-fabrication and imaging; Communications servers for linking instruments used in the semiconductor field and for analyzing and evaluating data obtained from such instruments; teaching apparatus and simulators in the nature of scientific equipment for use in simulations for semiconductor manufacturing, namely, electronic simulators for semiconductor manufacturing; information technology, audiovisual, multimedia and photographic equipment in the nature of mixed reality and virtual reality optics glasses; downloadable software for the design, testing and fabrication of photolithographic masks; recorded data in the nature of downloadable data files featuring semiconductor industry solutions; Downloadable computer software for use in operating measuring instruments to measure positions of structures on photomasks and evaluating data they provide; downloadable and recorded computer software in the nature of server software for providing semiconductor industry solutions; downloadable and recorded computer software in the nature of utility tool software for providing semiconductor industry solutions; downloadable and recorded computer operating system programs; downloadable and recorded office and business application software for visualizing, processing, comparing of data and virtual and augmented reality measuring, detection, monitoring and control solutions; smartglasses; Downloadable computer software for use in the fields of pharmaceuticals, biotechnology, medical apparatus and plant protection; Downloadable computer software for controlling and managing access server applications; 3D scanners; cameras; projection apparatus, namely, laser-beam-emitting devices for 3D-visualization, slide or photograph projection apparatus, slide projectors, video projectors; Downloadable CAD programs, namely, downloadable software for use in the construction and automated manufacturing industry and for database management; infrared cameras; smart devices, namely, smartphones, tablet computers; Downloadable computer software for data management, file management and database management software; Downloadable computer software for use in the field of computer-generated imagery, computer-generated graphics, computer-generated animation and interactive computer graphics; downloadable computer software for use in the creation of digital storyboards, pre-visualization and animatics; Downloadable computer software for use in the preparation of film and video shot or scene planning and visual effects planning for motion pictures, films, cinematographic productions, television programmes, computer and video games and other visual and audiovisual media; computers for image processing and computer graphics applications; computer hardware and downloadable computer software for use in creating visual effects and animations for motion pictures, films, cinematographic productions, television programmes, computer and video games and other visual and audiovisual media; computer hardware and downloadable computer software for use in performance and motion capture for motion pictures, films, cinematographic productions, television programmes, computer and video games and other visual and audiovisual media; computer hardware and downloadable computer software for the scanning, digitization, encoding, storage, retrieval, display and manipulation of cinematographic and photographic images; computer hardware and downloadable computer software for use in real-time camera tracking and augmented reality within motion pictures, films, cinematographic productions, television programmes, computer and video games and other visual and audiovisual media; spectacles; protection lenses being protective glasses, magnifying glasses, magnifier spectacles, spectacle frames; protective eye wear, namely, laser protective eyewear; Hand-held tablet computers designed to illustrate the amount of protection against ultraviolet light present in a pair of eyeglasses; downloadable software for opticians and optometrists that creates an avatar of the patient and enables the virtual try-on of spectacle frames; downloadable software used in the field of ophthalmology to collect and analyze clinical data and to optimize intraocular lens calculation in treatment planning; recorded computer firmware for the common use and sharing, via a network or data infrastructure, of data in the field of refractive laser surgery regarding diagnosis, treatment and the continuous optimization thereof on the basis of the gathered results; downloadable software for the communication, information, appointment management and data exchange between patients, doctors and other health care professionals and their staff; Downloadable eyecare data management software to detect, and connect to, compatible medical, surgical and ophthalmological devices, and to import data from such devices; downloadable surgical software to detect, and connect to, compatible medical, surgical and ophthalmological devices, and to import data from such devices; downloadable computer software for laser vision correction in the field of ophthalmology; waveguides for guiding light waves, namely, transparent waveguides, transparent holographic waveguides, and transparent holographic waveguides made of glass, a glass-polymer sandwich or a polymer-polymer sandwich, said waveguides comprising at least one holographic optical element; waveguide assemblies comprising a transparent waveguide for guiding light waves and a light-sensitive sensor, light emitting diodes (LEDs) as a light source and a non-medical imaging device for the recording, transmission and reproduction of light distributions or images; waveguide assemblies comprising a transparent holographic waveguide for guiding light waves and a light-sensitive sensor, light emitting diodes (LEDs) as a light source and a non-medical imaging device for the recording, transmission and reproduction of light distributions or images; smart device displays featuring a transparent waveguide, namely, smart glasses displays, head-up displays for automobile drivers and aircraft pilots, television screen displays, computer screen displays, smartphone screen displays, and head-mounted displays; smart device displays comprising a transparent holographic waveguide for guiding light waves, namely, smart glasses displays, head-up displays for automobile drivers and aircraft pilots, television screen displays, computer screen displays, smartphone screen displays, and head-mounted displays; smart device display devices comprising a transparent waveguide for guiding light waves and a light-sensitive sensor, a light source and a non-medical imaging device for the recording, transmission and reproduction of light distributions or images, namely, smart glasses displays, head-up displays for automobile drivers and aircraft pilots, television screen displays, computer screen displays, smartphone screen displays, and head-mounted displays; smart device display devices featuring a transparent holographic waveguide and a light-sensitive sensor, a light source and an imaging device, namely, smart glasses displays, head-up displays for automobile drivers and aircraft pilots, television screen displays, computer screen displays, smartphone screen displays, and head-mounted displays; head-up display devices for use in vehicles or general aviation comprising a transparent holographic waveguide for guiding light waves and a light-sensitive sensor, a light source and a non-medical imaging device for the recording, transmission and reproduction of light distributions or images; head mounted display devices, namely, smart glasses featuring a transparent holographic waveguide and a light-sensitive sensor, a light source and an imaging device; spectacle lenses featuring a transparent holographic waveguide; data glass devices, namely, smart glasses featuring a transparent holographic waveguide and a light-sensitive sensor, a light source and an imaging device; holographic optical elements in the nature of optical devices, namely, optical lenses; reflective holographic optical elements in the nature of optical devices, namely, optical lenses; transmissive holographic optical elements in the nature of optical devices, namely, optical lenses; Frequency Modulated Continuous Wave Lidar-sensors, semiconductor chips, radar apparatus; virtual reality headsets; audiovisual headsets Devices for destroying eye lenses, for use in surgery; ophthalmic cameras to be used in surgery; Medical diagnostic, examination and monitoring equipment; medical imaging equipment for use in surgical procedures; furniture especially made for medical purposes, namely, instrument tables for ophthalmological equipment; surgical apparatus and instruments for use in ophthalmic surgery, namely, near visual acuity testers; ophthalmometers; vision testing equipment, namely, ophthalmoscopes; medical devices for eye examination, namely, refractioning units; skiaskopes in the nature of medical devices for eye examination, namely, retinoscopy; Ophthalmic cameras for medical purposes, namely, fundus cameras; tonometers; instrument tables in the nature of medical procedure tables; biometer for intraocular lenses retina cameras; ophthalmic workstations being medical examination tables; magnifying loupes for medical purposes, namely, ophthalmological magnifiers; ophthalmological apparatus and instruments; refraction apparatus; centering apparatus; keratometers; colposcopes; phoropters being ophthalmic examination equipment; ophthalmological apparatus for eye tracking and eye registration in laser refractive surgery and intraocular lens centration in cataract surgery; apparatus and instruments for use in refractive eye laser correction surgery, namely, femtosecond lasers and excimer lasers for corneal refractive surgery; medical, surgical apparatus and instruments, namely, medical endoscopes; intraocular lenses; medical apparatus and instrument for use in phacoemulsification procedures ; medical apparatus and instrument for use in vitrectomy procedures; medical loupes being magnifying glasses for medical examination purposes; medical instruments used in ophthalmic surgeries for injecting intraocular lenses into the eye; component parts for ophthalmic laser slit lamps, namely, foot switches for parameter control, central laser controlling elements, and multi-touch control panels; medical and surgical apparatus and instruments for use in ophthalmic surgery; drapes for surgical purposes; microscopes, in particular, surgical and dental microscopes; medical endomicroscopes; optical apparatus and instruments, namely, medical endoscopes; surgical microscopes and replacement parts thereof; laser for medical use; laser for refractive surgery; diagnostic tomographic product for medical purposes that provides imaging and biometric measurement of ocular structures and tissues; medical apparatus and instruments for use in medical and surgical procedures, namely, radio frequency generators for supplying signals to electrodes applied to biological tissue; medical and surgical devices, namely, ultrasonic surgical systems for aspiration, tissue ablation, and bone cutting; devices used in intra-ocular lens surgery to virtually simulate implantation of the lens ; infusion-aspiration tubes for medical use; aspirated fluid collection bags for medical purposes; medical and surgical apparatus and instruments for use in ophthalmic surgery in the nature of vitrectomy cutters; surgical instruments, namely, bipolar forceps; surgical sutures materials; examination, protective and surgical gloves for medical and surgical purposes; surgical protective hoods and head veils in the nature of protective head wraps for medical use; cloths for sterile covering of patients and objects, namely, clothing especially for operating rooms being medical gowns and surgical sterile sheets; syringes for medical purposes; cannulas for anesthetics with receptacles; ophthalmological cannulas for saline solutions, cannulas for incisions; medical filter needles for injections; surgical clothing for medical personnel, namely, surgical gowns; disposable articles, namely, disposable syringes, disposable nozzles for dental syringes, disposable needles for medical purposes, disposable gloves for medical purposes, disposable protective gloves for medical purposes, disposable speculums; surgical robots; medical apparatus, namely, therapeutic x-ray systems comprised primarily of an electron beam x-ray generating probe and controller; medical optical apparatus to visualize in vivo cellular structures

Goods & Services

(1) Real-time camera-tracking system consisting of hardware and software components for virtual production and post-production; software, in particular visualization and virtual reality software; graphics software; interface software; application software; mobile application software; platform software; data and file management software and database software; virtual and augmented reality software; plug-ins being downloadable software; image processing software; hardware; compact computing unit; cameras; camera systems, consisting of cameras, infrared emitters and sensors. (1) Organization and conduction of trainings. (2) Software development, design, programming and implementation; hosting services; software as a service (SaaS); rental of software; design of graphic and visualization software; platform as a service (PaaS); database design, development and hosting services; organization and award of certifications in the area of virtual production and post-production.

Goods & Services

Real-time camera-tracking system comprised of computer hardware and downloadable and recorded software components for virtual production and post-production; Downloadable and recorded software, in particular, downloadable and recorded visualization and virtual reality software for real-time visualization of computer graphics for visual effects; Downloadable and recorded computer graphics software; Downloadable and recorded graphical user interface software; Downloadable and recorded computer application software for controlling and generating real-time visualization of computer graphics for visual effects; Downloadable mobile application software for controlling and generating real-time visualization of computer graphics for visual effects; Downloadable and recorded computer software platforms for generating and recording camera tracking and lens data for visual effects; Downloadable and recorded computer application software for data management, file management and database management; Downloadable and recorded virtual and augmented reality software for generating and recording camera tracking data for visual effects applications; Downloadable and recorded computer software in the nature of plug-ins for use in 3D rendering software for generating computer graphics for visual effects; downloadable and recorded computer software for processing digital images; computer hardware; compact computing units, namely, laptops; cameras; camera systems comprised of cameras, infrared emitters and sensors Organization and conduction of trainings in the field of camera tracking and virtual production; Entertainment services, namely, organization and award of certifications to demonstrate excellence in the field of camera tracking and virtual production Software development, design, programming and implementation; web site hosting services; software as a service (SaaS) services featuring software for generating and recording camera tracking information to facilitate the generation of computer graphics for visual effects; rental of computer software for generating and recording camera tracking data for visual effects; design of computer graphics and visualization software; platform as a service (PaaS) featuring computer software platforms for generating camera tracking data for applications in visual effects; Platform-as-a-service (PaaS) featuring computer software platforms for the digital application of lens effects in the field of cinematography; database design, development and website hosting services

Goods & Services

software for smart devices, namely smartphones, tablets and smart watches.

Abstract

An electro-optic observation device, in particular a thermal imaging device, is provided. The electro-optic observation device includes a handheld device housing, a lens group arranged in the device housing on the entrance side, an image capture unit arranged in the device housing on the image side with respect to the lens group, an image display unit arranged in the device housing, an eyepiece arranged on the exit side with respect to the image display unit, and also a control device configured to control at least the image display unit depending on user-specifically variable parameters. In addition, the electro-optic observation device includes, as input means for varying the parameters, a rotary wheel accessible on the device housing for access by a user.

IPC Classes  ?

• G06F 3/033 - Pointing devices displaced or positioned by the userAccessories therefor
• G02B 23/12 - Telescopes, e.g. binocularsPeriscopesInstruments for viewing the inside of hollow bodiesViewfindersOptical aiming or sighting devices with means for image conversion or intensification
• G06F 3/0362 - Pointing devices displaced or positioned by the userAccessories therefor with detection of 1D translations or rotations of an operating part of the device, e.g. scroll wheels, sliders, knobs, rollers or belts
• G06F 3/0487 - Interaction techniques based on graphical user interfaces [GUI] using specific features provided by the input device, e.g. functions controlled by the rotation of a mouse with dual sensing arrangements, or of the nature of the input device, e.g. tap gestures based on pressure sensed by a digitiser
• G16H 30/20 - ICT specially adapted for the handling or processing of medical images for handling medical images, e.g. DICOM, HL7 or PACS

Goods & Services

Information technology and audio-visual, multimedia and photographic devices; photographic lenses; smart devices, namely smartphones; tablets and smart watches; parts of all the aforesaid goods.

Abstract

A wide-field swept-source OCT method for imaging a moving object (14), in particular the anterior chamber (16) of the human eye, is described, the method including the following steps: - providing wavelength-tuned illumination radiation (B) having individual illumination pulses (10.L0, 10.L1) of different centroid wavelengths, - illuminating the object (14) using the illumination radiation (B) and imaging the object (14) on a 2-D detector (22) which has an image recording cycle of exposure intervals (4.1, 4.2, 4.3, 4.4) and read-out intervals (6.1, 6.2, 6.3), - emitting the illumination pulses (10.L0, 10.L1, 10.L2) as a series of illumination pulse pairs (10.L0, 10.L1; 10.L0, 10.L2) of a first illumination pulse (10.L0) and a second illumination pulse (10.L1, 10.L2), with illumination pulses (10.L0) with the same centroid wavelengths being repeated at least once over the illumination pulse pairs (10.L0, 10.L1; 10.L0, 10.L2), - synchronizing the illumination pulses (10.L0, 10.L1, 10.L2) and the detector (22) such that the illumination pulse pairs (10.L0, 10.L1; 10.L0, 10.L2) are grouped around every second (6.1, 6.3) of the read-out intervals (6.1, 6.2, 6.3) of the sequence (2), and - generating image pairs from the detector signals corresponding to the illumination pulse pairs (10.L0, 10.L1; 10.L0, 10.L2), - determining changes between the image data of the illumination pulses (10.L0) with the same centroid wavelength repeated over the illumination pulse pairs (10.L0, 10.L1; 10.L0, 10.L2) and using the changes to correct movements of the object (14) in the image data.

IPC Classes  ?

• A61B 6/03 - Computed tomography [CT]
• A61B 3/10 - Objective types, i.e. instruments for examining the eyes independent of the patients perceptions or reactions

Goods & Services

Real-time camera-tracking system consisting of hardware and software components for virtual production and post-production; software, in particular visualization and virtual reality software; graphics software; interface software; application software; mobile application software; platform software; data, file management and database software; virtual and augmented reality software; plug-ins; image processing software; hardware; compact computing unit; cameras; camera systems, consisting of cameras, infrared emitters and sensors. Organization and conduction of trainings; organization and award of certifications. Software development, design, programming and implementation; hosting services; software as a service (SaaS); rental of software; design of graphic and visualization software; platform as a service (PaaS); database design, development and hosting services.

Abstract

A lens control system and a method for compensating a disturbance force acting on a lens group of an optical assembly are provided. The optical assembly includes an actuator configured to move the lens group along an optical axis in response to an optical lens position command received from the camera controller. The lens control system further includes an optical assembly controller with a power driver configured to apply an electrical energy to the actuator to produce a force that acts on the lens group to move the lens group to a commanded position, a current sensor configured to measure a current flowing through the actuator in response to the electrical energy applied to the at least one actuator, and a position sensor configured to generate position information by measuring an actual position of the lens group.

IPC Classes  ?

• H04N 5/232 - Devices for controlling television cameras, e.g. remote control
• H04N 17/00 - Diagnosis, testing or measuring for television systems or their details
• G02B 7/02 - Mountings, adjusting means, or light-tight connections, for optical elements for lenses

Abstract

A wavefront manipulator (1) is disclosed, comprising at least a first optical component (2) and a second optical component (3), which are disposed one behind the other along a reference axis (9), wherein the first optical component (2) and the second optical component (3) can be moved relative to each other perpendicularly to the reference axis (9). The first optical component (2) and the second optical component (3) each comprise a first optical element (4) and at least one additional optical element (5) with different refractive index curves n1(λ) and ni(λ), said optical elements being disposed one behind the other along the reference axis (9), and the optical elements (4, 5) having a length ∆z(x,y) in the z-direction parallel to reference axis, said length being location-dependent with respect to local coordinates x and y of the optical component (2, 3).

IPC Classes  ?

• G02B 3/00 - Simple or compound lenses

Abstract

12212122).

IPC Classes  ?

• G02B 3/00 - Simple or compound lenses

Abstract

Methods of manufacturing eyeglasses are provided. The method may include providing a blank (63) with an outcoupling element (25) and machining the blank to provide a light receiving surface based on the at least one physiological parameter. Corresponding blanks and sets of eyeglasses are also provided.

IPC Classes  ?

• G02B 27/01 - Head-up displays

Abstract

Centration parameters for fitting spectacle lenses to a predetermined spectacle frame and to the head of a subject are determined with a computer-implemented method. At least two calibrated images, recorded from different recording directions, of the head of the subject wearing the spectacle frame are provided, wherein geometric parameters are established by geometric position determination. The geometric parameters describe the position of the eyes and the geometry of the spectacle frame, and the centration parameters are calculated from the geometric parameters. Further, a three-dimensional model for the spectacle lenses, which are to be received in the spectacle frame, is fitted to the geometry of the geometric parameters that describe the geometry of the spectacle frame.

IPC Classes  ?

• G02C 13/00 - AssemblingRepairingCleaning
• G06T 7/50 - Depth or shape recovery
• G06T 7/00 - Image analysis
• G06T 7/70 - Determining position or orientation of objects or cameras
• G06T 7/60 - Analysis of geometric attributes
• H04N 23/56 - Cameras or camera modules comprising electronic image sensorsControl thereof provided with illuminating means
• H04N 23/90 - Arrangement of cameras or camera modules, e.g. multiple cameras in TV studios or sports stadiums

Abstract

A method for forming an image of an object, a computer program product, and an image forming system for carrying out the method are provided. In the method, data about the object are provided by a first data processing device, and a first data record with first data is provided. The first data record is loaded from the first data processing device into a second data processing device. A second data record is loaded from a data memory into the second data processing device in dependence on the first data record loaded into the second data processing device. A processing data record is generated or detected based on the second data record. A two-dimensional output image of the object is generated by processing the data about the object with the processing data record, the output image having a predeterminable number of output image pixels.

IPC Classes  ?

• G06T 15/20 - Perspective computation
• G06F 21/62 - Protecting access to data via a platform, e.g. using keys or access control rules
• G06T 5/80 - Geometric correction
• G06T 15/50 - Lighting effects

Abstract

It is an object of the invention to improve processes, apparatuses and systems for measuring a measured variable. To this end, a measured variable is measured in a measuring process on the basis of an NV center as a quantum sensor. The NV center has a plurality of quantum states and is optically excitable on the basis of an occupancy of one of the quantum states into at least one excited state of the quantum states by means of an excitation light. The at least one excited state can decay at least with emission of emission light of the NV center. In the measuring process, the NV center is irradiated by the excitation light, the excitation light having a time periodic modulation, and a respective occupancy probability and/or a respective lifetime of the quantum states depending on the measured variable and the excitation light. A phase shift is determined between the emission light of the NV center and the modulation of the excitation light and a measurement value for the measured variable is determined on the basis thereof.

IPC Classes  ?

• G01V 3/00 - Electric or magnetic prospecting or detectingMeasuring magnetic field characteristics of the earth, e.g. declination or deviation
• G01N 21/64 - FluorescencePhosphorescence
• G01N 24/10 - Investigating or analysing materials by the use of nuclear magnetic resonance, electron paramagnetic resonance or other spin effects by using electron paramagnetic resonance
• G01R 33/00 - Arrangements or instruments for measuring magnetic variables
• G01R 33/26 - Arrangements or instruments for measuring magnetic variables involving magnetic resonance for measuring direction or magnitude of magnetic fields or magnetic flux using optical pumping
• G01R 33/60 - Arrangements or instruments for measuring magnetic variables involving magnetic resonance using electron paramagnetic resonance

Goods & Services

Information technology and audio-visual, multimedia and photographic devices; photographic lenses; smart devices, namely smartphones; tablets and smart watches; parts of all the aforesaid goods.

Goods & Services

Information technology and audio-visual, multimedia and photographic devices; photographic lenses; smart devices, namely smartphones, tablets and smart watches; parts of all the aforesaid goods.

Goods & Services

Camera lenses.

Goods & Services

Optical apparatus and instruments; information technology, audio-visual, multimedia and photographic devices; smartphones; software; all of the aforesaid excluding photographic and cinematographic lenses.

Goods & Services

Camera lenses.

Goods & Services

Skin, eye and nail care preparations. Dietary supplements and dietetic preparations; dental preparations and medicated dentifrices; sanitary preparations and articles; pest control preparations and articles; medical and veterinary preparations; air deodorising and air purifying preparations. Physical therapy equipment; sex aids; medical and veterinary apparatus and instruments; medical furniture and bedding, equipment for moving patients; prosthetics and artificial implants; clothing, headgear and footwear, braces and supports, for medical purposes; clothing, headgear and footwear for medical personnel and patients, mobility aids; hearing protecting devices; feeding aids and pacifiers. Headgear; clothing; footwear; parts of clothing, footwear and headgear, namely, cuffs, pockets, ready-made linings, heels and heelpieces, cap peaks and hat frames (skeletons). Sporting and physical exercise equipment; Christmas trees of synthetic material, party novelties and artificial Christmas trees; fairground and playground apparatus; toys, games, and playthings.

Goods & Services

Camera lenses.

Abstract

A lens main body includes an inner housing, a lens element mounted on the inner housing, an adjustable functional element mounted on the inner housing, and an electrical drive arranged on the inner housing to adjust the functional element, a controller arranged on the inner housing, a securing device configured to reversibly receive an outer housing extending around the inner housing in a tubular fashion, and a first signal interface to receive control signals for the controller, arranged on the inner housing, and configured to reversibly couple to a mating interface of the outer housing. An outer housing for the lens main body, and a lens formed from the lens main body and the outer housing have an altered functional scope vis-à-vis the lens main body. In addition, a lens assembly includes, besides the lens main body, two outer housings having a different functional scope.

IPC Classes  ?

• H04N 23/55 - Optical parts specially adapted for electronic image sensorsMounting thereof
• H04N 23/663 - Remote control of cameras or camera parts, e.g. by remote control devices for controlling interchangeable camera parts based on electronic image sensor signals
• H04N 23/60 - Control of cameras or camera modules
• H04N 23/959 - Computational photography systems, e.g. light-field imaging systems for extended depth of field imaging by adjusting depth of field during image capture, e.g. maximising or setting range based on scene characteristics

Goods & Services

Photographic lenses; software for information technology and audio-visual, multimedia and photographic devices; software for electrical and electronic devices; software for smart devices, smartphones, tablets and smart watches.

Goods & Services

Information technology, audio-visual, multimedia and photographic devices; photographic lenses; electrical and electronic devices; smart devices; smartphones; tablets; smart watches; parts of all the aforesaid goods.
